SBC250
2-Up Networked Docking Station
IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accor­
dance with the manufacturer's instructions.
8. DO NOT install near any heat sources such as open flames, radiators, heat registers, stoves, or other appara­
tus (including amplifiers) that produce heat. Do not place any open flame sources on the product.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been dam­
aged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled with liquids, such as vas­
es, on the apparatus.
16. The MAINS plug or an appliance coupler shall remain readily operable.
17. The airborne noise of the Apparatus does not exceed 70dB (A).
18. Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a protective earthing
connection.
1/12

Advertisement

Table of Contents
loading

Related Manuals for Shure SBC250

Summary of Contents for Shure SBC250

  • Page 1 SBC250 2-Up Networked Docking Station IMPORTANT SAFETY INSTRUCTIONS 1. READ these instructions. 2. KEEP these instructions. 3. HEED all warnings. 4. FOLLOW all instructions. 5. DO NOT use this apparatus near water. 6. CLEAN ONLY with dry cloth. 7. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accor­...

  • Page 2: General Description

    General Description SBC250 networked docking station provides simple charging, configuration, and storage for either 2 ULXD6 and ULXD8 transmitters. Dock transmitters for 15 minutes to get 1 hour of use, or charge for 3 hours for a full charge.

  • Page 3: Rack And Wall Mounting

    Shure Incorporated • Rack- or wall-mountable with Shure URT3 mounting tray (sold separately) Rack and Wall Mounting SBC250 can be rack- or wall-mounted using the optional Shure URT3 universal rack tray for added flexibility when storing ULXD6 boundary microphones. ①...

  • Page 4: Controls And Connectors

    ⑥ Ethernet Status LED (Green) • Off = No network link • On = Network link established • Flashing = Network link active ⑦ Charging Slots (USB 3.0) Slide any ULXD6 or ULXD8 transmitter with Shure rechargeable batteries into slots to begin charging. 4/12...

  • Page 5: Power Connections

    2. The docking station turns on and off via toggle switch. If the docking station loses power, transmitters will also power off. Connecting Transmitters Insert a ULXD6 or ULXD8 transmitter with Shure rechargeable batteries into the slot as shown: 5/12...
  • Page 6 If you have multiple devices to manage, connect each device to a router or network switch. The Ethernet port LEDs on your device will illuminate to indicate network connectivity. Verify that Shure devices can see each other by looking for the network connectivity icon on the front panel (location varies).
  • Page 7 Displays battery temperature (in Celsius and Fahrenheit) and status. Tip: To identify individual transmitters on the SBC250, press and hold the mute button on your ULXD6 or ULXD8 to make the corresponding icon in WWB flash. Clicking Dismiss all clears the flashing.
  • Page 8 Connecting to an External Control System SBC250 networked docking stations connect to external control systems such as AMX or Crestron via the Ether­ net. Use only one controller per system to avoid messaging conflicts. For a comprehensive list of command strings, visit http://www.shure.com (http://www.shure.com).

  • Page 9: Firmware Updates

    Firmware is embedded software in each component that controls functionality. Periodically, new versions of firmware are developed to incorporate additional features and enhancements. To take advantage of design im­ provements, download new versions of the firmware using the Shure Update Utility tool. Download Shure Update Utility at http://www.shure.com/suu (http://www.shure.com/suu).

  • Page 10: Specifications

    Storage Temperature Range -29°C (-20°F) to 74°C (165°F) Certifications Meets essential requirements of all applicable European Directives. The CE Declaration of Conformity can be obtained from: www.shure.com/europe/compliance Authorized European representative: Shure Europe GmbH Headquarters Europe, Middle East & Africa Department: EMEA Approval Jakob-Dieffenbacher-Str.

  • Page 11: Important Product Information

    Note: EMC conformance testing is based on the use of supplied and recommended cable types. The use of other cable types may degrade EMC performance. Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate this equipment.

  • Page 12: Information To The User

    Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate the equipment. Licensing of Shure wireless microphone equipment is the user’s re­ sponsibility, and licensability depends on the user’s classification and application, and on the selected frequency.
