  • Page 1 4-270-482- Digital Colour TV Operating Instructions KDL-22CX32D...
  • Page 2 Please refer to the illustration that actually equipped with the product. Introduction Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Notice for Digital TV function •...

  • Page 3: Table Of Contents

    Table of Contents Start-up Guide Safety Information...8 Precautions...9 Safety information about built-in DVD player...10 Precautions about built-in DVD player...10 Overview of the remote ...11 Overview of the TV buttons and indicators ...13 Watching TV Watching TV ...14 Using the Digital Electronic Programme Guide (EPG) Using the Digital Favourite list Playing a DVD...18 Enjoying Karaoke...21...

  • Page 4: Start-Up Guide

    Start-up Guide 1: Checking the accessories Table-Top Stand (1) Screws for stand (7) Remote RM-ED046 (1) Size AA batteries (2) To insert batteries into the remote Push to open • Observe the correct polarity when inserting batteries. • Do not use different types of batteries together or mix old and new batteries.
  • Page 5 3: Connecting an aerial/cable/VCR/DVD recorder Connecting an aerial/cable only Terrestrial signal Coaxial cable Connecting an aerial/cable/VCR/DVD recorder with SCART Coaxial cable Terrestrial signal or Scart lead Coaxial cable VCR/DVD recorder Connecting an aerial/cable/VCR/DVD recorder with HDMI or cable HDMI cable VCR/DVD recorder 4: Preventing the TV from toppling over...
  • Page 6 Tie the wood screw and the machine screw with a strong cord (not supplied). • An optional Sony support belt kit is used to secure the TV. Contact your nearest Sony Service Centre to purchase a kit. Have your TV model name ready for reference.
  • Page 7 The TV has now tuned in all the available channels. • USB System Update You can update the TV system using USB memory. Obtain information from the website below. http://support.sony-europe.com/TV/ To tune the TV for Cable connection Press to select “Quick Scan” or “Full Scan”, then press “Quick Scan”...

  • Page 8: Safety Information

    • Leave space around the TV set as shown below. • It is strongly recommended that you use a Sony wall-mount bracket in order to provide adequate air-circulation. Installed on the wall 30 cm 10 cm...

  • Page 9: Precautions

    If the following problems occur... Turn off the TV set and unplug the mains lead immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. When: –...

  • Page 10: Safety Information About Built-In Dvd Player

    other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

  • Page 11: Overview Of The Remote

    TV programmes, “HDMI Device Selection” is displayed when the button is pressed. • “Control for HDMI” (BRAVIA Sync) is only available with the connected Sony equipment that has the BRAVIA Sync or BRAVIA Theatre Sync logo or is compatible with Control for HDMI. 3 AUDIO •...
  • Page 12 qs PROG/CH +/–/ • In TV mode: Selects the next (+) or previous (-) channel. • In Text mode (page 15): Selects the next ( – Previous channel Press to return to the channel that was last viewed (for more than five seconds).

  • Page 13: Overview Of The Tv Buttons And Indicators

    Overview of the TV buttons and indicators 1 Z – Eject Ejects the disc. 2 N – Play Starts disc playback. 3 x – Stop Stops disc playback. 4 1 – Power Turns the TV on or off. • To disconnect the TV completely, pull the plug from the mains.

  • Page 14: Watching Tv

    Watching TV Watching TV Press 1 on the side of the TV to turn on the TV. When the TV is in standby mode (the 1 (standby) indicator on the TV front panel is red), press "/1 on the remote to turn on the TV. Press DIGITAL/ANALOG to switch between digital and analogue modes.
  • Page 15 To access Text Press /. Each time you press /, the display changes cyclically as follows: Text t Text over the TV picture (mix mode) t No Text (exit the Text service) To select a page, press the number buttons or To reveal hidden information, press •...

  • Page 16: Using The Digital Electronic Programme Guide (Epg)

    Using the Digital Electronic Programme Guide (EPG) GUIDE Today 11: 30 12: 00 BBC ONE Homes Under the Hammer BBC TWO Ready Steady Cook Extraordinary People: Britains Iden... ITV1 Dancing On Ice Exclusive Channel 4 Sign Zone: Ancient Rome: The Rise a... Five House Law and Order: Special Victims U...

  • Page 17: Using The Digital Favourite List

    Using the Digital Favourite list Favourite Set-up Favourites 1 Enter Programme Number: BBC ONE More 4 BBC TWO abc1 ITV1 Channel 4 UKTV Gold Five The HITS BBC Three UKTV Bright Ideas ITV2 Sky Sports UKTV History Digital Favourite list * This function may not be available in some countries/regions.

  • Page 18: Playing A Dvd

    Playing a DVD Getting ready Press 1 on the TV, or "/1 on the remote to turn on the TV. The Standby indicator on the front panel of the TV changes to green from red. Press to select the DVD mode. The input source menu appears on the screen.
  • Page 19 Step-by-step chapter selection Press > to select the next chapter during playback. Press . to select the previous chapter during playback. Pausing or resuming playback You can pause or resume playback of a DVD as desired. Press x once to pause playback. Press N or X to resume playback.
  • Page 20 S-VCD/VCD Playback PBC (playback control) This is the navigation option for PBC, S-VCD/ VCDs. PBC information is stored in the disc at the factory. PBC is activated when it is ready for delivery. PBC and channel information in the S-VCD/VCD indicate the navigation options.

  • Page 21: Using Karaoke

    • The voice input from microphone is not output from the audio output jacks of the TV or Sony/Phillips Digital Interface. Neither “Key Change” or “Vocal Reducer” (page 32) are applied to the audio output signal.

  • Page 22: Using Optional Equipment

    Using Optional Equipment Connecting optional equipment You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied. DVD player PC (HDMI output) Blu-ray disc player Digital video camera Hi-Fi audio equipment with optical audio input Hi-Fi audio equipment DVD player with...

  • Page 23: Viewing Pictures From Connected Equipment

    When connecting mono equipment, connect to the • Be sure to use only an authorised HDMI cable bearing the HDMI logo. We recommend that you use a Sony HDMI cable. • When HDMI control compatible equipment is connected, communication with the connected equipment is supported.

  • Page 24: Playing Back Photo/Music/Video Via Usb

    – Do not remove the USB device. The data on the USB device may be damaged. • Sony will not be held liable for any damage to, or loss of, data on the recording media due to a malfunction of any connected devices or the TV.
  • Page 25 Basic operation of Photo/Music/Video You can operate the connected USB device by the TV remote. Item Description m / M Fast reverses/fast forwards the file when pressed during playback. . / > Goes to the beginning of the previous/ next file. Starts playback.
  • Page 26 USB Video format Extension Container .avi .wmv .asf .mp4 .mov .3gp .mkv .mpg .mpeg .vob .ts, .m2ts USB Music format Extension Audio Codec .mp3 .wma WMA v8 USB Photo format Extension Image Codec .jpg, .jpeg JPEG DCF2.0 or EXIF2.21 supported. •...

  • Page 27: Using Bravia Sync With Control For Hdmi

    TV speaker to the audio system. • Adjusts the volume (2 +/–) and mutes the sound (%) of a connected audio system. • You can operate the connected Sony equipment that has the BRAVIA Sync logo by the TV remote by pressing: –...

  • Page 28: Using Menu Functions

    Using MENU Functions Navigating through TV Menu “MENU” allows you to enjoy various convenient features of this TV. You can easily select channels or inputs sources and change the settings for your TV. Press HOME. HOME Digital Favourites Digital EPG Photo Music Video...

  • Page 29: Settings

    Settings Picture Picture Mode Selects the picture mode. “Vivid”: For enhanced picture contrast and sharpness. “Standard”: For standard picture. Recommended for home entertainment. “Custom”: Allows you to store your preferred settings. “Cinema”: For film-based content. Suitable in a theatre-like environment. “Photo”: For standard viewing of photographs.
  • Page 30 Film Mode Provides improved picture movement when playing DVD or VCR images taken on film, reducing picture blur and graininess. “Auto”: Provides the original film-based content as is. “Off”: Turns off the “Film Mode” feature. • If the image contains irregular signals or too much noise, “Film Mode” is automatically turned off even if “Auto”...
  • Page 31 Surround Selects the surround mode. “On”: Delivers surround effects that help you enjoy the virtual two-ch surround audio with just the two internal TV speakers. “Simulated Stereo”: Adds a surround-like effect to mono programmes. “Cinema”: Delivers surround effects just like the high-grade audio systems found in movie theatres.
  • Page 32 Karaoke “Karaoke”: Selects the karaoke mode, “On” or “Off”. “Key Change”: Changes the key of music. The key can be adjusted by semitone steps. “Vocal Reducer”: Reduces the volume of the vocal part in the music. The effectiveness of function depends on the music type. “Mic1 Volume/Mic2 Volume”: Adjusts the volume of Microphone 1 and 2.
  • Page 33 PC Adjustment Customises the TV screen as a PC monitor. • This option is only available if a PC signal is received. • “Auto Adjustment” may not work well with certain input signals. In such cases, manually adjust “Phase”, “Pitch”, “Horizontal Shift”, and “Vertical Shift”. “Screen Format”: Select “Normal”...
  • Page 34 Label Assigns a name of your choice, up to five letters or numbers, to the selected channel. Allows you to fine-tune the selected programme number manually if you feel that a slight tuning adjustment will improve the picture quality. Audio Filter Improves the sound for individual channels in the case of distortion in mono broadcasts.
  • Page 35 “Subtitle Set-up” • “Subtitle Setting”: When “For Hard Of Hearing” is selected, some visual aids may also be displayed with the subtitles (if TV channels broadcast such information). • “Primary Preferred Language”: Selects preferred language which subtitles are displayed in. •...

  • Page 36: Parental Lock

    Parental Lock Sets an age restriction for programmes. Any programme that exceeds the age restriction can only be watched after a PIN Code is entered correctly. • For cable operators in Netherlands, the PIN code should be entered when the programme rating is above or equal to the age you specify.
  • Page 37 Set-up USB Auto Start Automatically enters the thumbnail view of the last played Photo/Music/Video when the TV is turned on and a USB device is connected to the USB port then turned on. Sleep Timer Sets a period of time after which the TV automatically switches itself into standby mode.
  • Page 38 DivX® VOD “DivX® VOD Registration Code”: Displays the registration code that is required to play DivX® VOD content. “DivX® VOD Deregistration Code”: Displays the deregistration code that is required to play DivX® VOD content. DVD Settings “Downmix”: Switches the method for mixing down to 2 channels when you play a DVD which has Dolby Digital format.
  • Page 39 Reset Resets all the “Eco” settings to the factory settings. Power Saving Selects the power saving mode to reduce the power consumption of the TV. “Standard”: Default settings. “Reduce”: Reduces the power consumption of the TV. “Picture Off”: Switches off the picture. You can listen to the sound with the picture off.

  • Page 40: Additional Information

    Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
  • Page 41 SU-WL100 Screen centre point Display dimensions Model name KDL-22CX32D 53.0 Figures in the above table may differ slightly depending on the installation. WARNING The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of the TV.

  • Page 42: Specifications

    Specifications System Panel System LCD (Liquid Crystal Display) Panel TV System Depending on your country/region selection Analogue: B/G, D/K, L, I Digital: DVB-T, DVB-C Colour/Video System Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC HP@L4.0, MP@L4.0 Channel Coverage Analogue: 46.25 - 855.25 MHz Digital: VHF/UHF...
  • Page 43 Model name KDL- 22CX32D Power and others Power Requirements 220–240 V AC, 50 Hz Energy Efficiency Class Screen Size (measured Approx. 54.8 cm / 22 inches diagonally) 42.0 W Power in “Home”/ consumption “Standard” mode in “Shop”/ 60 W “Vivid” mode Average annual energy 61 kWh...

  • Page 44: Troubleshooting

    Check the items in the tables below. If the problem still persists, have your TV serviced by qualified service personnel. • For further information, please contact Sony Customer Information Centre at the address or telephone that appears on the supplied guarantee.
  • Page 45 Keep this Instruction manual safe you’ll need it Television in the UK is going digital, bringing us all more. Please see overleaf to find out when your area switches to digital. Digital UK is the independent, non-profit organisation leading the process of digital TV switchover in the UK.
  • Page 46 If you are missing any channels, it may be that they are not available in your area, or that your aerial needs upgrading. If you have any questions, please contact Sony on 0844 8466555 or call Digital UK on 0845 6 50 50 50 or visit www.digitaluk.co.uk †Calls charged at BT rate of 3p per minute daytime and 1p per minute evenings and weekends.
  • Page 48 For useful information about Sony products 4-270-482-11(1) © 2011 Sony Corporation...
