Components

A
B
C
D
E
F
G
Front
A. Control Panel
B. Carry Handle
C. Air Outlet
D. Water Tank Handle
E. Water Tank Cover
F. Water Tank
G. Wheels
H. Housing Body
I. Air Inlet and Filter
J. Continuous Drainage Outlet (with Plug)
K. Pump Drainage Outlet
L. Cord Storage
6
LAD500_ANZ_IB_C19.indd 6
Back
Not Pictured
Air Filter
Dust Filter
Carbon Filter
Pump Drainage Hose (8m)
Pump Outlet Clip
Pump Suction Hose (20cm)
Pump Suction Joint
Drainage Hose (gravity-assisted)
Power Cord
Water Level Sensor
H
I
J
K
L
