Page 1: Air Conditioner
DVM S AM✴✴✴FXVAGR Series AM✴✴✴FXVAGH Series AM✴✴✴HXVAGH Series AM✴✴✴MXV✴NR Series Air Conditioner installation manual imagine the possibilities Thank you for purchasing this Samsung product. DB68-03850A-14... -
Page 2: Table Of Contents
Contents Safety precautions ......................3 Preparing for installation . -
Page 3: Safety Precautions
❇ Generally, system air conditioners should not be relocated after installation. But when it has to be relocated for inevitable reasons, please contact Samsung’s qualified dealers for system air conditioners. • Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety precautions Check the following before installation and service work. Before welding, remove dangerous and inflammable things that may cause an explosion and fire around the work. Before welding, remove the refrigerant from inside the pipe or the product. - If you perform welding while refrigerant is in the pipe, it may increase the pressure of the refrigerant and cause the pipe to burst.
- Page 5 CAUTION SIGNS Do not install the drain pipe directly to the bottom part of the outdoor unit and built a proper drainage so that water drains out smoothly. If not, pipe may freeze or bursts during winter time and cause damage to the product or water leakage.
-
Page 6: Preparing For Installation
Safety precautions Changes in DVM S (inverter) compare to conventional models that has to noted when installing For optimal distribution of the refrigerant, you must use Y-joint as branch joint for connecting outdoor units. (To not use T-joint) You cannot operate normally if you do not complete the trial operation through outdoor unit key mode. You must use KEY MODE to run trial operation. -
Page 7: Outdoor Unit Combination
Outdoor unit combination Make sure to use an indoor unit that is compatible with DVM S. Indoor units can be connected within the range indicated in following table. If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and heating capacity of the indoor unit may decrease. - Page 8 Preparing for installation Model name for combination AM180FXVAGH AM200FXVAGH AM220FXVAGH AM240HXVAGH AM260HXVAGH Number of individual outdoor units AM080FXVAGH AM100FXVAGH AM120FXVAGH AM140FXVAGH AM160FXVAGH Combined outdoor unit AM180FXVAGH AM200FXVAGH AM220FXVAGH AM240HXVAGH AM260HXVAGH 50.4 61.6 67.2 72.8 Cooling (kW) Rated capacity Heating (kW) 56.7 69.3 75.6...
- Page 9 Model name for combination AM380HXVAGH1 AM400HXVAGH1 AM420HXVAGH1 AM440HXVAGH1 AM460HXVAGH1 Number of individual outdoor units AM080FXVAGH AM100FXVAGH AM120FXVAGH AM140FXVAGH AM160FXVAGH Combined outdoor unit AM180FXVAGH AM200FXVAGH AM220FXVAGH AM240HXVAGH AM260HXVAGH Cooling (kW) 106.6 112.8 117.6 123.2 128.8 Rated capacity 119.7 126.9 132.3 138.6 144.9 Heating (kW) Total capacity of the...
- Page 10 Preparing for installation Model name for combination AM580HXVAGH1 AM600HXVAGH1 AM620HXVAGH1 AM640HXVAGH1 AM660HXVAGH1 AM680HXVAGH1 Number of individual outdoor units AM080FXVAGH AM100FXVAGH AM120FXVAGH AM140FXVAGH AM160FXVAGH Combined outdoor unit AM180FXVAGH AM200FXVAGH AM220FXVAGH AM240HXVAGH AM260HXVAGH 163.2 168.2 173.6 179.2 184.8 190.4 Cooling (kW) Rated capacity Heating (kW) 183.6 189.0...
- Page 11 Compact type (Heat pump) Model name for combination AM360HXVAGH2 AM380HXVAGH2 AM460HXVAGH2 AM480HXVAGH2 Number of individual outdoor units AM120FXVAGH AM200FXVAGH Combined outdoor unit AM220FXVAGH AM240HXVAGH AM260HXVAGH 100.8 106.4 128.8 134.4 Cooling (kW) Rated capacity 113.4 119.7 144.9 151.2 Heating (kW) 50.4 53.2 64.4 67.2...
- Page 12 Preparing for installation Model name for combination AM620HXVAGH2 AM640HXVAGH2 AM680HXVAGH2 AM700HXVAGH2 Number of individual outdoor units AM120FXVAGH AM200FXVAGH Combined outdoor unit AM220FXVAGH AM240HXVAGH AM260HXVAGH 173.6 179.2 190.4 196.0 Cooling (kW) Rated capacity 195.3 201.6 214.2 220.5 Heating (kW) 86.8 89.6 95.2 98.0 Minimum (kW)
- Page 13 Standard type (Heat recovery) Model name for combination AM080FXVAGR AM100FXVAGR AM120FXVAGR AM140FXVAGR AM160FXVAGR Number of individual outdoor units AM080FXVAGR AM100FXVAGR AM120FXVAGR AM140FXVAGR AM160FXVAGR AM180FXVAGR Combined outdoor unit AM200FXVAGR AM220FXVAGR AM240MXVGNR AM260MXVGNR AM280MXVGNR AM300MXVANR 22.4 33.6 Cooling (kW) Rated capacity 25.2 31.5 37.8 50.4...
- Page 14 Preparing for installation Model name for combination AM280MXVGNR AM300MXVANR AM320FXVGNR AM340FXVGNR AM360FXVGNR Number of individual outdoor units AM080FXVAGR AM100FXVAGR AM120FXVAGR AM140FXVAGR AM160FXVAGR AM180FXVAGR Combined outdoor unit AM200FXVAGR AM220FXVAGR AM240MXVGNR AM260MXVGNR AM280MXVGNR AM300MXVANR 78.6 89.6 95.2 101.6 Cooling (kW) Rated capacity 88.2 94.5 100.8...
- Page 15 Model name for combination AM480FXVGNR AM500FXVGNR AM520FXVGNR AM540FXVGNR AM560FXVGNR Number of individual outdoor units AM080FXVAGR AM100FXVAGR AM120FXVAGR AM140FXVAGR AM160FXVAGR AM180FXVAGR Combined outdoor unit AM200FXVAGR AM220FXVAGR AM240MXVGNR AM260MXVGNR AM280MXVGNR AM300MXVANR 134.4 145.6 151.2 156.8 Cooling (kW) Rated capacity 151.2 157.5 163.8 170.1 176.4 Heating (kW)
- Page 16 Preparing for installation Model name for combination AM700FXVGNR AM720FXVGNR AM740FXVGNR AM760FXVGNR AM780FXVGNR AM800FXVGNR Number of individual outdoor units AM080FXVAGR AM100FXVAGR AM120FXVAGR AM140FXVAGR AM160FXVAGR AM180FXVAGR Combined outdoor unit AM200FXVAGR AM220FXVAGR AM240MXVGNR AM260MXVGNR AM280MXVGNR AM300MXVANR 201.6 207.2 212.8 218.4 224.2 Cooling (kW) Rated capacity Heating (kW) 220.5...
-
Page 17: Moving The Outdoor Unit
Moving the outdoor unit Select the moving path in advance. Be sure that moving path can support weight of the outdoor unit. Do not slant the product more than 30˚ when carrying it. (Do not lay the product down in sideways.) Surface of the heat exchanger is sharp. -
Page 18: Selecting Installation Location
Selecting installation location Decide the installation location, with the consideration of the following conditions, under user’s approval. Place where hot discharge air or noise from the outdoor unit may not disturb the neighbor (Especially in residential areas, keep the operation hours in mind.) Place where structure can bear the weight and vibration of the outdoor unit. - Page 19 Environment Installation conditions Anti-Corrosion Effect from Installation Anti corrosion Effect by Maintenance • After Corrosion Protection period With Anti-corrosion coating (2 years) Seashore within 500m years from installation Cleaning & Spray R-Pro : Direct exposure * Check 1 year later from installation 2 years extended •...
- Page 20 Selecting installation location • System air conditioner may cause static noise when listening to AM stations. Therefore, select an installation location for indoor unit where electrical wiring can be done while keeping certain distance from a radio, CAUTION computer and stereo equipment. - Especially, keep the unit at least 3m away from the electrical equipment in an area with weak electromagnetic waves and put the main power cable and communication cables in a separately installed protection tube.
-
Page 21: Space Requirement For Installation
Space requirement for installation Space requirement was decided based on following conditions; Cooling mode, outdoor temperature of 35 °C. Larger space is required if the outdoor temperature is higher than 35 °C or if the place is heated easily by quantity of solar radiation. - Page 22 Space requirement for installation Module installation Over 300 Height of the wall is Front side Over 100 unlimited Over 100 Front Over 400 Over 400 side Over 100 <Case 1> <Case 2> Over 100 Over 100 Over 100 Over 100 Front side Over 100 Over 100...
-
Page 23: Accessories
Accessories Accessories You must keep following accessories until the installation is finished. Hand over the installation manual to the customer after finishing the installation. Installation manual (1) Optional accessories Following optional accessories are needed for connecting pipes between the indoor and outdoor units. Classification Model Name Specification... -
Page 24: Base Construction And Installation Of The Outdoor Unit
Base construction and installation of the outdoor unit • Make sure to remove the wooden pallet before installing the outdoor unit. If you do not remove the wooden pallet, there is risk of fire during welding the pipes. If the outdoor unit is installed with wooden pallet on, and WARNING it was used for long period time, wooden palette may break and cause electrical hazard or high pressure may damage the pipes. -
Page 25: Outdoor Unit Installation
Outdoor unit installation Base ground H beam or anti-vibration frame Over 200 mm Outdoor unit base mount and anchor bolt position Outdoor unit - Anti-vibration frame (4-Ø 12) Anti-vibration - Base ground (4-Ø 18) (Unit : mm) Classification DVM S Small Type DVM S Large A Type DVM S Large B type 1,295... - Page 26 Base construction and installation of the outdoor unit Examples of draining work Construct the drainage ditch with reinforced concretes and make sure that water-proofing work is done. For smooth draining of defrost water, make sure to apply 1/50 slope. Construct a drainage around the outdoor unit to prevent the defrost water (from the outdoor unit) from stagnating, overflowing or freezing near the installation space.
- Page 27 Cautions regarding on connecting the anchor bolt CAUTION Tighten the rubber washer to prevent the bolt connection part of the outdoor unit from corroding. Rubber washer Anchor specification Diameter of Anchor length Sleeve length Fastening Size Insert depth drill bit (a) torque Ø...
-
Page 28: Installing The Wind/Snow Prevention Duct
Base construction and installation of the outdoor unit Caution for installing discharge duct Static pressure of the discharge duct should be within the standard specification (78.45 Pa) when installing the CAUTION duct. If you remove the fan guard to install the discharge duct, make sure to install a safety net on the duct outlet. Foreign substance may enter into the product and there could be a risk of personal injury. - Page 29 Installing the outdoor unit in cold region In cold regions with lots of snowfall, install a snow prevention duct, as a sufficient countermeasure, to prevent snow from accumulating on the outdoor unit. When the snow prevention duct is not installed, frost may accumulate on the heat exchanger and heating operation may not work normally.
- Page 30 Installing the wind/snow prevention duct Installing the outdoor unit in windy region In windy regions such as near sea shores, protection wall or wind protection duct must be installed for normal operation of the outdoor unit. (Refer to the illustration of the snow prevention duct, for installing the wind protection duct.) Install the wind prevention duct with the consideration of major wind direction.
-
Page 31: Refrigerant Pipe Installation
Refrigerant pipe installation • When installing, make sure there is no leakage. When collecting the refrigerant, stop the compressor first before removing the connection pipe. If the refrigerant pipe is not properly connected and the compressor works WARNING with the service valve open, the pipe inhales the air and it makes the pressure inside of the refrigerant cycle abnormally high which may lead to explosion and injury. - Page 32 Refrigerant pipe installation Selecting refrigerant pipe First branch joint Increase the main pipe size Install the refrigerant pipe according to main pipe size of each outdoor unit capacity. When the pipe length (including elbow) between an outdoor unit and the farthest indoor unit exceeds 90m, you must increase the size of the pipe (main pipe) by one grade which connects between the outdoor unit to the first branch joint.
- Page 33 33.6 kW 40.0 kW 61.6 kW Ex.) 135.2 kW Pipe size (mm) Capacity (kW) Liquid pipe Gas pipe 33.6 kW Ø 12.70 Ø 28.58 73.6 kW Ø 19.05 Ø 34.92 135.2 kW Ø 19.05 Ø 41.28 Size of the pipe connected to the outdoor unit (A) Select the size of the main pipe according to the below table. *Maximum pipe length within 90m *Maximum pipe length over 90m Outdoor unit capacity (kW)
- Page 34 Refrigerant pipe installation Size of the pipe between branch joints (B) Select the pipe size according to the sum of indoor unit capacity which will be connected after the branch. ❇ However, if the size of the pipe between branch joints (B) is bigger than the size of the pipe connected to the outdoor unit (A), apply the pipe size (A).
- Page 35 Branch joint 33.6 kW 40.0 kW 61.6 kW Branch joint between outdoor units (C) Classification Model name Specification (kW) MXJ-TA3419M 135.2 kW and below Y-joint for outdoor unit (C) MXJ-TA4122M Over 135.2 kW First branch joint (D) Make a selection according to outdoor unit capacity. Model name of the Classification Outdoor unit capacity (kW)
- Page 36 Refrigerant pipe installation 33.6 kW 40.0 kW 61.6 kW Ex.) 135.2 kW Pipe size (mm) Capacity (kW) High pressure Liquid pipe Gas pipe gas pipe 33.6 kW Ø 12.70 Ø 28.58 Ø 19.05 73.6 kW Ø 19.05 Ø 34.92 Ø 28.58 135.2 kW Ø 19.05 Ø 41.28 Ø...
- Page 37 Size of the pipe between branch joints (B) Select the pipe size according to the sum of indoor unit capacity which will be connected after the branch. ❇ However, if the size of the pipe between branch joints (B) is bigger than the size of the pipe connected to the outdoor unit (A), apply the pipe size (A).
- Page 38 Refrigerant pipe installation Branch joint 33.6 kW 39.2 kW 44.8 kW Branch joint between outdoor units (C) Classification Model name Specification (kW) MXJ-TA3419M 135.2 kW and below Liquid/Low pressure Y-joint (C) MXJ-TA4122M Over 135.2 kW MXJ-TA3100M 135.2 kW and below High pressure Y-joint (C) MXJ-TA3800M Over 135.2 kW First branch joint (D) Make a selection according to outdoor unit capacity.
-
Page 39: Additional Refrigerant
Additional refrigerant 46.4 kW 61.6 kW (33.6 kW + 28.0 kW) Ø12.70 (5 m) Ø9.52 (1 m) Ø12.70 (5 m) 4.5 kW Ø15.88 (10 m) Ø12.70 (5 m) Ø6.35 (5 m) 5.6 kW Ø12.70 (10 m) Ø12.70 (10 m) Ø12.70 (5 m) Ø6.35 (10 m) Ø6.35 (15 m) Ø9.52 (10 m) Ø9.52 (10 m) - Page 40 Refrigerant pipe installation Amount of additional refrigerant for each indoor unit (ⓑ) (Unit : kg) Capacity (kW) 1000 1 .5 1 .7 2 .2 2 .8 3 .2 3 .6 4 .5 5 .6 7 .1 8 .2 9.3 11 .2 12 .8 14 22 22 .4 28 Model Slim 1way cassette (JSF)
- Page 41 Capacity (kW) 1000 1 .5 1 .7 2 .2 2 .8 3 .2 3 .6 4 .5 5 .6 7 .1 8 .2 9.3 11 .2 12 .8 14 22 22 .4 28 Model New Boracay 0.24 0.24 0.32 0.32 0.49 0.49 0.49 ✴✴✴...
- Page 42 Refrigerant pipe installation Example of refrigerant calculation for HP models Amount of Total amount Unit amount of Length (m) additional of additional refrigerant (kg/m) Classification Size of liquid pipe refrigerant (kg) refrigerant (kg) ① ② ①×② ∑(①×②) Ø 6.35 0.02 Ø...
- Page 43 Amount of Total amount Unit amount of Number of units additional of additional Model name of refrigerant (kg/EA) Classification refrigerant (kg) refrigerant (kg) indoor unit ① ② ①×② ∑(①×②) 4way cassette 0.45 2.25 (AM071FN4DEH✴) 4way cassette 0.57 1.14 (AM112FN4DEH✴) ⓑ 4.66 Indoor unit (ⓑ) Neo Forte 0.27...
- Page 44 Refrigerant pipe installation Keeping refrigerant pipe To prevent foreign materials or water from entering the pipe, storing method and sealing method (especially during installation)is very important. Apply correct sealing method depending on the environment. Exposure place Exposure time Sealing type Longer than one month Pipe pinch Outdoor...
-
Page 45: Cutting Or Flaring The Pipes
Cutting or flaring the pipes 1. Make sure that you prepared the required tools. Pipe cutter, Deburring tool, flaring tool and pipe holder, etc. 2. If you want to shorten the pipe, cut it with a pipe cutter ensuring that the cut edge remains at 90° with the side of the pipe. - Page 46 Refrigerant pipe installation Connecting the flared pipes Check if the flaring is properly done according to the standard size. Align the center of the piping and tighten the flare nut with your hands. Then, tighten the flare nut with torque wrench in a direction of the arrow indicated in below illustration.
- Page 47 Pipe installation for an outdoor unit 1. Direction of the pipe Refrigerant pipe can be withdrawn from the front, left and right side. Take necessary method to install the pipes according to the condition of the installation site. Front side connection Left side connection Right side connection Caution for using knock-out hole...
- Page 48 Refrigerant pipe installation 2. Connecting refrigerant pipe for outdoor unit Classification Front side connection Right/left (and bottom) side connection • First, remove the piping cover from the outdoor • Separate the knock-out hole at the bottom unit. side of the unit and install the pipe. •...
- Page 49 3. Pipe installation between the outdoor units You will need branch joints, which is an optional accessory, for connecting in between outdoor units in order to combine outdoor units in module. ❇ For optimal distribution of the refrigerant, you must use Y-joint as branch joint for connecting outdoor units. (Do not use T-joint) When you install the outdoor units in module, there is no restriction of installation order among outdoor units.
- Page 50 Refrigerant pipe installation Examples of refrigerant pipe installation 1. Using Y-joint 2. Using distribution header 1. Using Y-joint Note 1) Note 1) Direct-connected indoor unit without MCU (for HR only) - This indoor unit can only be used for cooling operation. (Heating operation is not possible.) - Connect indoor unit to liquid and low pressure gas pipe.
- Page 51 Allowable length of the refrigerant pipe and the installation examples Classification Single Installation Module installation Outdoor unit Outdoor unit Branch joint Branch joint Installing only with Y-joint Indoor unit Indoor unit Outdoor unit Outdoor unit Branch joint Distribution header Distribution header Installing with Y-joint Branch joint and distribution...
- Page 52 Refrigerant pipe installation Classification Example Remarks Installing only with b+c+d+e+f+g+p ≤ 45 m Y-joint Maximum Installing with Y-joint 45 m or less i+k ≤ 45 m First branch and distribution header allowable joint ~ Farthest Pipe length length after Installing only with Indoor unit i ≤...
- Page 53 Classification Installation with Y-joint Installing with MCU only Cooling Only Indoor Unit (Connecting Only Low Pressure Gas Pipe / Liquid Pipe note3 Installing with MCU and Y-joint Classification Example Remarks Equivalent length a+g+j ≤ 200 m (220 Actual pipe Installing only with MCU 200 m or less length Y-joint: 0.5 m...
- Page 54 Refrigerant pipe installation Classification Example Remarks 110 m / 110 m Outdoor unit ~ H1 ≤ 110 m / 110 m Note 1) Indoor unit 40 m or less H2 ≤ 40 m Indoor unit ~ Maximum But, when AM✴✴✴✴NQDEH✴ / Indoor unit allowable AM✴✴✴JNV✴...
- Page 55 Note 1) When indoor unit is located at higher level than outdoor unit, allowable height difference is 110m, (If the height difference is over 40m, contact your local dealer for more information.) but when the indoor unit is located at lower level than outdoor unit, allowable height difference is 110m (If the height difference is over 50m, need to decide whether to install PDM kit or not.) Model name of the PDM kit : MXD-A38K2A, MXD-A12K2A, MXD-A58K2A...
-
Page 56: Installing The Branch Joints
Refrigerant pipe installation Installing the branch joints Branch joints must be installed ‘horizontally’ or ‘vertically’ . Horizontal installation Vertical installation • For A~J type branch joints : Connect the branch joint to the connection pipe with the provided reducer. • For K~Z type branch joints : Cut the connection part of the branch joint or the provided socket, according to the NOTE diameter of the connection pipe, before connecting them. - Page 57 Installing the distribution header 1. Select the reducer that fits the diameter of the pipe. Socket Provided item Pipe * Socket Pipe* Pipe* Pipe* To indoor unit To indoor unit To outdoor unit To outdoor unit Socket Socket <Gas side> <Liquid side>...
- Page 58 Refrigerant pipe installation 3. Install the distribution header horizontally. Install the distribution header horizontally so that its ports does not face down. Socket Distribution header Horizon line Below ±10° Pipe (Separately purchased item) Horizon line Horizon line Below ±15° < Liquid side > Horizon line Below ±15°...
- Page 59 ❇ Use the attached reducer according to the selected pipe size. To other outdoor unit Pipe To other outdoor joint or outdoor unit Reducer Reducer Pipe To other outdoor joint or Y-joint of the main pipe <Liquid side> ❇ Use the attached reducer according to the selected pipe size. To other outdoor unit Pipe To other outdoor joint or outdoor unit...
- Page 60 Refrigerant pipe installation Installing the MCU MCU specification Model MCU-S6NEK2N MCU-S4NEK3N MCU-S2NEK2N MCU-S1NEK1N Exterior of MCU Number of connectable indoor Up to 8 units Up to 8 units Up to 8 units Up to 8 units units at one port The maximum capacity of the 16 kW...
- Page 61 Installing the indoor units Model MCU-S6NEK2N MCU-S4NEK3N MCU-S2NEK2N MCU-S1NEK1N Example installing (Each port connection) MCU series connection Example installing (MCU series connection) Under 16.0 kW indoor unit : Don’t use Y-connector This unit is only 16.0 kW ~ 28.0 kW indoor unit : Use Y-connector at the Gas & Liquid line connectable for one port under 16 kW If you want to continuous cooling operation under -5 °C, set outdoor ‘Expand...
- Page 62 Refrigerant pipe installation How to connect the pipes 70 mm Protect with wet towel when welding 70 mm Pipe connection from outdoor unit Default installing direction. Low pressure gas pipe connection (welding) High pressure gas pipe connection (welding) Liquid pipe connection (welding) Pipe connection to indoor unit Gas pipe (welding) Liquid pipe (welding)
-
Page 63: Electrical Wiring Work
Electrical wiring work Specification of the circuit breaker and power cable Single (Heat pump) Model AM080FXVAGH 18.0 AM100FXVAGH 21.1 AM120FXVAGH 25.0 AM140FXVAGH 25.0 AM160FXVAGH 32.0 AM180FXVAGH 39.1 AM200FXVAGH 42.5 AM220FXVAGH 44.5 AM240HXVAGH 55.0 AM260HXVAGH 58.0 Standard module (Heat pump) Model AM280HXVAGH1 57.0 AM300HXVAGH1... - Page 64 Electrical wiring work Model AM720HXVAGH1 146.0 AM740HXVAGH1 153.1 AM760HXVAGH1 156.5 AM780HXVAGH1 158.5 AM800HXVAGH1 158.5 Compact module (Heat pump) Model AM360HXVAGH2 80.0 AM380HXVAGH2 83.0 AM460HXVAGH2 100.5 AM480HXVAGH2 102.5 AM500HXVAGH2 113.0 AM520HXVAGH2 116.0 AM580HXVAGH2 125.5 AM600HXVAGH2 127.5 AM620HXVAGH2 138.0 AM640HXVAGH2 141.0 AM680HXVAGH2 144.0 AM700HXVAGH2 147.0...
- Page 65 Standard module (Heat recovery) Model AM320FXVGNR 67.5 AM340FXVGNR 69.5 AM360FXVGNR 69.5 AM380FXVGNR 76.5 AM400FXVGNR 83.6 AM420FXVGNR 87.0 AM440FXVGNR 98.0 AM460FXVGNR 105.0 AM480FXVGNR 112.1 AM500FXVGNR 115.5 AM520FXVGNR 117.5 AM540FXVGNR 128.0 AM560FXVGNR 133.0 AM580FXVGNR 140.0 AM600FXVGNR 146.0 AM620FXVGNR 140.5 AM640FXVGNR 142.5 AM660FXVGNR 142.5 AM680FXVGNR 149.5...
- Page 66 Electrical wiring work • This device is intended for the connection to a power supply system with a maximum permissible system NOTE impedance shown in the table (on the left page) at the interface point (power service box) of the user’s supply. •...
- Page 67 Power and communication cable configuration Main power and the ground cable must be withdrawn through the knock-out hole on the bottom-right or right side of the cabinet. Withdraw the communication cable from the designated knock-out hole on the bottom-right side of the front part. Install the power and communication cable using separate cable protection tube.
- Page 68 Electrical wiring work Specification of the protection tube Name Temper grade Applicable conditions When the protection tube is installed indoor and not exposed Flexible PVC conduit to outside, because it is embedded in concrete structure When the protection tube is installed indoor but exposed to Class 1 flexible conduit Galvanized steel sheet outside so there are risk of damage to the protection tube...
-
Page 69: Power Wiring Diagram
Power wiring diagram Supplying 3 phase 4 wires (380-415 V~) <When the module combination is in the tables of "Outdoor unit combination"> 3 phase 4 wires (380-415 V~) MCCB+ Sub unit Main unit ELCB Main unit Sub unit 1 Sub unit 2 Main unit Sub unit Single phase 2 wires (220-240 V~) - Page 70 Electrical wiring work <When the module combination is not in the tables of “Outdoor unit combination”> 3 phase 4wires 380 - 415 V~ MCCB+ MCCB+ MCCB+ ELCB ELCB ELCB Main unit Sub unit 1 Sub unit 2 Main unit Sub unit Single phase 2 wires Communication cable (Outdoor unit ~...
-
Page 71: Selecting Solderless Ring Terminal
Selecting solderless ring terminal Select a solderless ring terminal for a power cable according to the nominal dimensions for cable. Apply insulation coating to the connection part of the solderless ring terminal and the power cable. Silver solder Nominal dimensions for cable (mm Nominal dimensions for screw (mm) Standard dimension (mm) 16.5... -
Page 72: Connecting The Power Terminal
Electrical wiring work Connecting the power terminal Connect the cables to the terminal board with solderless ring terminals. Properly connect the cables by using certified and rated cables and make sure to fix them properly so that external force is not applied to the terminal. Use a driver and wrench that can apply the rated torque when tightening the screws on the terminal board. - Page 73 Examples of how to use the cable striper <Cable striper> 1. Adjust the blade position by coin. (Controller is at the bottom side of the tool.) Fix the blade position according to the outer sheath thickness of the power cable. 2.
- Page 74 Electrical wiring work Fixing the power cable 3 phase 4 wires (380- 415 V~) ELCB MCCB+ Sub unit communication cable Sub unit 3 phase 380-415 V~ • Do not let the power cable come into contact with the pipes inside the outdoor unit. If the power supply cable touches the pipes, the vibration of the compressor is transferred to the pipes and can damage the power supply CAUTION cables or pipes, creating the danger of fire or explosion.
- Page 75 Fixing the ground cable Connect the ground cable to the grounding hole inside the power supply box. Grounding Withdrawing the power cable Withdrawing from the front side - Connect the power cable protection tube into the power supply box as shown picture.
- Page 76 Electrical wiring work Installing the Solution device When the number of indoor units installed with the outdoor unit is 16 or less Terminal block with indoor unit Terminal block with outdoor unit sub module Terminal block with solution device...
- Page 77 Connecting the MCU (MCU-S6NEE1N, MCU-S4NEE1N, MCU-S4NEE2N, MCU-S2NEK1N) Example 1 Indoor unit Indoor unit Outdoor MCCB unit 220-240 V~ Example 2 Indoor unit Indoor unit Indoor unit Outdoor MCCB unit 220-240 V~ Power must be supplied to the MCU separately from the outdoor unit. Connect the communication cable of the outdoor unit (F1, F2) to the communication cable of the MCU (F1, F2) •...
- Page 78 Electrical wiring work Connecting the MCU (MCU-S6NEK2N, MCU-S4NEK3N, MCU-S2NEK2N, MCU-S1NEK1N) Example MCCB Indoor unit Indoor unit Outdoor MCCB unit 220-240 V~ Power must be supplied to the MCU separately from the outdoor unit. Connect the communication cable of the outdoor unit (F1, F2) to the communication cable of the MCU (F1, F2) •...
-
Page 79: Grounding Work
Grounding work Grounding must be done by a qualified installer for your safety. Grounding the power cable The standard of grounding may vary according to the rated voltage and installation place of the air conditioner. Ground the power cable according to the following table. Power condition Voltage to ground is lower than 150V Voltage to ground is over 150V... -
Page 80: Air Tightness Test And Vacuum Drying
Air tightness test and vacuum drying Air tightness test Use tools for R-410A to prevent the inflow of foreign substances and resist against the internal pressure. Do not remove the core of filling port. Use Nitrogen gas for air tightness test as shown in the illustration. Manifold gage Manifold gage High pressure... - Page 81 Vacuum drying pipes and indoor units Use tools for R-410A to prevent the inflow of foreign substances and resist against the internal pressure. Use vacuum pump that allows vacuuming under -100.7kPa (5 Torr). Use the vacuum pump with the check valve to prevent pump oil from flowing backward while the vacuum pump is stopped.
-
Page 82: Pipe Insulation
Pipe insulation Insulating the refrigerant pipes and branch joints Check for gas leakage before completing (the hose and pipe insulation) and if there is no sign of leakage, make sure to insulate the pipes and hoses. Use EPDM material insulator that meets the following conditions. Test item Unit Standard... - Page 83 Insulate the refrigerant pipe Make sure to insulate the refrigerant pipe, branch joint, distribution header, and the connection part of the pipes. If you insulate the pipes, condensed water will not fall from the pipes. Check if there are any cracks on the insulation at the bent part of the pipe. Insulator Clamp Insulator...
-
Page 84: Insulating The Branch Joint
Pipe insulation Insulate the distribution header Fix the distribution header with a cable tie and cover the connected part. Insulation Insulate the distribution header and the welded part and wrap the connected part with an adhesive insulation tape to prevent dew formation. Adhesive insulation tape Insulate after welding a stopper Insulate the refrigerant... -
Page 85: Charging Refrigerant (For The Turkish Market Only)
Insulating the pipe located inside of the outdoor unit With a pipe insulator, insulate the pipe up to whole service valve located inside of the outdoor unit. Seal the gap between the outdoor unit pipe and the insulator. Rainwater and dewdrops may soak through the gap between the pipe and the insulation of the outdoor unit installed on the outside. - Page 86 Charging refrigerant (for the turkish market only) Please fill in the following with indelible ink on the refrigerant charge label supplied with this product and on this manual. ① : the factory refrigerant charge of the product. ② : the additional refrigerant amount charged in the field. ①+② : the total refrigerant charge.
- Page 87 Module installation Open the manifold gauge valve connected to the liquid side service valve and add the liquid refrigerant. If you cannot add the whole quantity of the refrigerant while the outdoor unit is stopped, open the gas side and liquid side service valve.
-
Page 88: Basic Segment Display
Basic segment display Step Display content Display SEG 1 SEG 2 SEG 3 SEG 4 At initial power input Checking segment display “8” “8” “8” “8” SEG 1 SEG 2 SEG 3 SEG 4 Number of communicated While setting communication units between indoor and outdoor unit Number of connected indoor units... - Page 89 Setting outdoor unit option switches : B TYPE Setting outdoor install option Step Button Display Description Note Start Outdoor unit address Outdoor unit Step1 Setting required display Press (K1+K2) for Outdoor unit address 00: Main unit 2 seconds Unit address K4 x 1 time 01: Sub1 unit Step2...
- Page 90 Setting outdoor unit option switch and key function Installing and setting the option with tact switch and explanation of the functions Setting the option 1. Press and hold K2 to enter the option setting. (Only available when the operation is stopped) - If you enter the option setting, display will show the following.
- Page 91 Optional item Input unit SEG1 SEG2 SEG3 SEG4 Function of the option Remarks Disabled (Factory default) Emergency E560 will occur when all Set compressor 1 as operation for Individual the compressors are set as malfunction state compressor malfunction state. Set compressor 2 as malfunction malfunction state 7-9 (Factory default in case of...
- Page 92 Setting outdoor unit option switch and key function Optional item Input unit SEG1 SEG2 SEG3 SEG4 Function of the option Remarks Enables the silent mode for Disabled (Factory default) night-time in cooling mode LEVEL 1 / Auto (It operates automatically depending on the LEVEL 2 / Auto temperature.)
- Page 93 Optional item Input unit SEG1 SEG2 SEG3 SEG4 Function of the option Remarks Expand Disabled (Factory default) operational When enabled, continuous temperature cooling operation is possible Main range for cooling Enabled even in low temperature operation (HR condition up to -15°C, but noise only) of the MCU will increase Automatic setting (Factory...
- Page 94 Setting outdoor unit option switch and key function Setting key operation and checking the view mode with tact switch < A type > < B type > K1 control KEY operation Display on segment Press and hold 1 Auto trial operation “K”...
- Page 95 K2 (Number of KEY operation Display on segment press) 1 time Refrigerant charging in Cooling mode “K” “5” “BLANK” “BLANK” 2 times Trial operation in Cooling mode “K” “6” “BLANK” “BLANK” 3 times Pump down all units in Cooling mode “K”...
- Page 96 Setting outdoor unit option switch and key function < A type > < B type > Display on segment K4 (Number of KEY operation press) SEG 1 SEG2, 3, 4 1 time Outdoor unit model AM160FXV✴✴✴✴ Off, 1, 6 2 times Order frequency of the compressor 1 120 Hz 1, 2, 0...
- Page 97 Display on segment K4 (Number of KEY operation press) SEG 1 SEG2, 3, 4 25 times Current frequency (Compressor 1) 120 Hz 1,2,0 26 times Current frequency (Compressor 2) 120 Hz 1,2,0 27 times Suction 2 temperature -42 °C -, 4, 2 Master indoor unit not selected BLANK, N, D 28 times...
-
Page 98: Setting The Mcu And Pipe Addresses (For Hr Only)
Setting the MCU and Pipe Addresses (for HR Only) You can set the MCU address, the MCU ports to use, and the address for each MCU port connected to each indoor unit. ✴ It is for 2nd-generation MCU only. (MCU-S NEK2N,MCU-S4NEK3N,MCU-S1NEK1N) Setting the MCU address and the MCU ports to use You can set the MCU address and the MCU ports on the MCU PBA. - Page 99 Setting the Pipe Addresses Manually You can use the wired or wireless remote control or the S-NET Pro 2 to set the pipe addresses for each indoor unit. Setting by using the wired or wireless remote control (For how to operate the remote control buttons, see the remote control user manual.) 1.
- Page 100 Setting the MCU and Pipe Addresses (for HR Only) Setting the Pipe Addresses Automatically (Auto pipe pairing operation) You can use the Automatic pipe-address setting operation to automatically set the address of each MCU port that is connected to an indoor unit. If an MCU port is set incorrectly or a pipe between an MCU and an indoor unit is connected incorrectly, that indoor unit is indicated.
- Page 101 ❇ Before running the Auto pipe pairing operation, be sure to close the front cabinet. If this operation is run with the front cabinet open, the product may be damaged and the pipe addresses cannot be correctly recognized. To run the Auto pipe pairing operation, take the following steps: 1.
-
Page 102: Things To Check After Completing The Installation
Setting the MCU and Pipe Addresses (for HR Only) 2. When the Auto pipe pairing operation finishes, the following data is shown on the outdoor unit display. Result Outdoor unit display Description Setting completed Indoor unit data - SEG 1,2 = indoor unit address / SEG 3,4 = error status 00: An MCU port is not disabled, or a pipe is not connected. - Page 103 3. Check if the R-410A indoor units are connected. 4. When N phase is not correctly connected to R, S and T phase, over-voltage protection control will be in effect and it will cut-off the power of the PCB. Check the power cable connection of the N phase if the PCB is not turned on. 5.
-
Page 104: Inspection And Test Operation
Inspection and test operation Precautions before test operation • When the outdoor temperature is low, turn on the main power 6 hours before beginning the operation. CAUTION - If you start the operation immediately after turning on the main power, it may cause serious damage to the part within the product. - Page 105 - In Auto trial operation, product will automatically select either cooling or heating mode and operate in selected mode. - In the temperature range marked with slashed pattern, system protection control may trigger during operation.(If the system protection control is enabled, it can be hard to get the precise judgment after the auto trial operation.) - When the temperature is outside of guaranteed range, accuracy of judgment on auto trial operation may decrease near boarder line area.
- Page 106 Inspection and trial operation Measure to take when E503 error occurs Is the ball valve on the outdoor unit Take corrective measures. opened? Has the correct amount of additional refrigerant Take corrective measures. been injected into the indoor unit and liquid line? Perform Trial Operation (cooling/heating) - See the instructions on Key operation modes.
- Page 107 ❇ Symptoms for abnormal operation of the 4way valve - Abnormal noise during compressor operation, Increase in the suction temperature. ❇ Symptoms for abnormal operation of the Main EEV - It is not possible to control the superheat (SH) - It is not possible to secure a DSH of higher than 20K ❇...
- Page 108 Inspection and trial operation Measure to take when E505, E506 error occurs Keep all the outdoor units in vacuum mode for 5 min. - See the instructions on Key operation modes. Is the deviation between pressure sensors on outdoor units greater than 0.2MPa? Is the ball valve (service valve) on each outdoor unit Open the valve.
- Page 109 ❇ For more information, see the troubleshooting in the service manual. • When the auto trial operation for pressure sensor was executed before the pressure of the outdoor unit is equalized (when there's close to no difference between high and low pressure), error may occur even though CAUTION the product is normal.
-
Page 110: Automatic Refrigerant Amount Detection Function
Automatic refrigerant amount detection function This function detects amount of refrigerant in the system through refrigerant amount detection operation Start times Input S-CHECKER signal Press the Tact switch "K2" 5 Satisfy the temperature condition Satisfy the temperature condition Check the amount of refrig er Check the amount of refrig er Check stability Check stability... - Page 111 • If the temperature is out of the guaranteed range below, exact result will not be obtained. - Indoor: 20~32 °C CAUTION - Outdoor: 5~43 °C • If the operation cycle is not stable, the operation of refrigerant amount check may be forcibly finished. •...
