- Page 1 Lightweight B A G L E S S V A C U U M U S E R ’ S G U I D E 3120 SERIES Safety Instructions Product View Assembly Operations 6-10 Maintenance and Care Troubleshooting Warranty ug010-0291_3120_507.indd 1 ug010-0291_3120_507.indd 1 5/22/07 5:25:07 PM 5/22/07 5:25:07 PM...
-
Page 2: Important Safety Instructions
■ Do not modify the polarized plug to fit a non-polarized outlet or extension cord. ■ Do not leave vacuum cleaner unattended when it is plugged in. ■ Unplug from outlet when not in use and before servicing. -
Page 3: Product View
roduct view Cord Hook Carrying Handle Upper Tank Primary Separator Easy Empty™ Dirt Cup Inner and Outer Lower Tank Circular Filters w w w . b i s s e l l . c o m ug010-0291_3120_507.indd 3 ug010-0291_3120_507.indd 3 Ergonomically Designed Handle Power Switch... -
Page 4: How To Use This Guide
Please read this guide thoroughly before assembling your vacuum cleaner. Pay particular attention to the product diagram, assembly instructions, and part names. Locate and organize all parts before assembly. Familiarize yourself with the parts and where they go. -
Page 5: Transporting Cleaner
perations Transporting cleaner To move your cleaner from room to room, put the handle in the upright position, tilt the cleaner back on its rear wheels, and push forward. The cleaner can also be moved by using the carrying handle on the front. Using your cleaner Remove the plastic plug guard and dispose. -
Page 6: Maintenance And Care
aintenance and care How to maintain your Vacuum To maintain maximum cleaning performance, the following maintenance steps must be performed: Clean the dirt tank if any visible clogs occur. Empty the dirt cup when the dirt reaches the “Full” line on the side. Check the inner and outer circular filters, and the pre-motor filter at least once a month and clean or replace as needed. -
Page 7: Cleaning Lower Tank/Inner Circular Filters
aintenance and care Cleaning the lower tank and inner circular filters Turn off vacuum and unplug it from electrical outlet. Remove dirt cup by pulling the dirt cup release handle then lift dirt cup out. Grasp the lower tank located at the bottom of the dirt cup and twist to unlock and remove. -
Page 8: Cleaning The Pre-Motor Filter
aintenance and care Cleaning the pre-motor filter The pre-motor filter protects the motor from debris. It is the small, round filter located underneath the dirt cup, right above the motor. Unplug the cleaner from the electrical outlet. Remove dirt cup by pulling the dirt cup release handle then lift dirt cup out. -
Page 9: Power Cord Storage
When you have finished using your Lightweight Bagless Vacuum, store the power cord on the cord wrap. Turn off vacuum cleaner and unplug power cord. Loop power cord around cord wraps on back of cleaner, making certain Quick Release cord wrap is pointed up towards handle. -
Page 10: Replace Drive Belt
aintenance and care Replace drive belt Follow steps 1-4 of previous section, “Clean and replace rotating floor brush”. Check drive belt carefully for wear, cuts and stressed areas. If the drive belt appears worn, you will need to replace it. Grasp old drive belt and remove from motor shaft. -
Page 11: Troubleshooting
Vacuum cleaner won’t run Possible causes 1. Vacuum cleaner is not plugged in 2. Household fuse/breaker Vacuum cleaner won’t pick up dirt Possible causes 1. Dirt cup is full 2. Filter dirty 3. Hose not secure 4. Dirt cup not in place 5. -
Page 12: Limited One Year Warranty
Saturday 9 a.m. - 8 p.m. ET Or write: BISSELL Homecare Inc. PO Box 3606 Grand Rapids MI 49501 ATTN: Consumer Services ©2007 BISSELL Homecare, Inc Grand Rapids, Michigan All rights reserved. Printed in China Part Number 010-0291 Rev 3/07 Visit our website at: www.bissell.com...
