- Page 1 Product Description HUAWEI E5573Cs-322 Mobile WiFi V200R001 Issue Date 2016-04-12 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang...
- Page 3 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description About This Document Summary This document provides information about the major functions, supported services and system architecture. The following table lists the contents of this document. Chapter Details 1 Overview The supported network modes, basic services and functions, and the appearance of the product.
-
Page 4: Date 2016
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description History Issue Details Date First release. 2016-04-12 Issue 01 (2016-04-12) Commercial in Confidence Page 4 of 20... -
Page 5: Table Of Contents
3.1.2 USB Modem .......................... 14 3.1.3 LTE/3G/Wi-Fi Auto Offload ....................14 3.2 SMS ..............................14 3.3 Connecting an Android Device to the E5573Cs-322 Using a 2D Barcode ........15 4 System Architecture ..................... 16 4.1 System Architecture ........................16 ... -
Page 6: Overview
Short Message Service (SMS) You can connect the E5573Cs-322 with the USB interface of a computer, or connect the E5573Cs-322 with the Wi-Fi. In the service area of the LTE FDD/DC-HSPA+/HSPA+/HSPA/UMTS or EDGE/GPRS/GSM network, you can surf the Internet and send/receive messages/emails cordlessly. The E5573Cs-322 is fast, reliable, and easy to operate. -
Page 7: Optional Features
Optional features refer to features that are not supported by the standard version or are disabled by default. These features can be customized according to operator or customer requirements. The E5573Cs-322's optional feature is as follows: IPv6/IPv4 dual stack (optional) ... -
Page 8: Features
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Features 2.1 Main Features The E5573Cs-322 mainly supports the following features: LTE FDD (DL) data service of up to 150 Mbit/s LTE FDD (UL) data service of up to 50 Mbit/s ... -
Page 9: Technical Specifications
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description 2.2 Technical Specifications 2.2.1 Hardware Table 2-1 lists the hardware specifications. Table 2-1 Hardware specifications Item Specifications Technical WAN: LTE standard FDD/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM WLAN: IEEE 802.11b/g/n LTE: Operating frequency FDD B1/B3/B7/B8/B20 DC-HSPA+/HSPA+/HSPA/UMTS: B1/B8 EDGE/GPRS/GSM: B2/B3/B5/B8 WLAN: 2.4 GHz... - Page 10 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Item Specifications Power supply AC: 100–240 V DC: 5 V, 1 A Battery Type: Li (rechargeable) Capacity: 3.8 V, 1500 mAh Maximum working time: 6 hours (depending on the network) Maximum standby time: 300 hours (depending on the network)
-
Page 11: Software
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description 2.2.2 Software Table 2-2 lists the software specifications. Table 2-2 software specifications Item Description Writing/Sending/Receiving Sending/Receiving extra-long messages Storage: Up to 500 messages can be saved in the internal memory of the E5573Cs-322. - Page 12 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Item Description Network status display: signal, operator name, system mode, and so on. LTE network switch: turn on/off LTE network PIN management: activate/deactivate PIN, PIN lock, changing PIN, unblocking by using the PUK.
-
Page 13: Services And Applications
3.1 Data Service 3.1.1 Wireless Modem The E5573Cs-322 can be used as a wireless modem when the Wi-Fi is enabled. You can directly use the default settings (or configure APN on the E5573Cs-322 Web page) and set up a wireless network connection. Then you can access the Internet. -
Page 14: Usb Modem
Product Description 3.1.2 USB Modem After you connect the E5573Cs-322 and PC with a USB data cable, the Web page is displayed on the PC desktops automatically. You can directly use the default settings (or configure APN on the E5573Cs-322 Web page) and set up a network connection. -
Page 15: Connecting An Android Device To The E5573Cs-322 Using A 2D Barcode
3.3 Connecting an Android Device to the E5573Cs-322 Using a 2D Barcode If you are using an Android device and has the HUAWEI HiLink App installed, you can quickly connect your device to the E5573Cs-322 to access the Internet by scanning a 2D Barcode on the E5573Cs-322 label. -
Page 16: System Architecture
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description System Architecture 4.1 System Architecture Figure 4-1 shows the system architecture. Figure 4-1 System architecture Mobile WiFi Software module Hardware module Application systerm Web page Web server Protocol stack Radio frequency module Bottom layer drivers... -
Page 17: Functional Modules
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description 4.2 Functional Modules Radio frequency module: It sends/receives radio signals and modulates/demodulates the radio frequency (RF) signals and baseband signals Baseband signal processing: It processes LTE FDD/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM baseband digital signals, including: Modulating/Demodulating LTE ... -
Page 18: Packing List
HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Packing List This chapter describes the items contained in the package of the E5573Cs-322. Table 5-1 lists the items contained in the package of the E5573Cs-322. Table 5-1 Packing list of the E5573Cs-322... - Page 19 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Acronyms and Abbreviations The Third Generation Advanced Encryption Standard application level gateway access point name ARPU average revenue per user ASCII American Standard Code for Information Interchange DHCP Dynamic Host Configuration Protocol demilitarized zone...
- Page 20 HUAWEI E5573Cs-322 Mobile WiFi V200R001 Product Description Operating System personal computer personal identification number Plug and Play packet switched PIN unblocking key subscriber identity module short messaging service SOHO small office home office SSID Service Set Identifier Thin Film Transistor...
