User Manual
FWF 81663W
Safety information.......................................2
Safety instructions...................................... 4
Product description.....................................6
Control panel.............................................. 7
Programme Chart....................................... 9
Consumption values................................. 11
Options..................................................... 13
CONTENTS
Settings.....................................................15
Before first use......................................... 15
Daily use...................................................16
Hints and tips............................................21
Care and Cleaning....................................23
Troubleshooting........................................26
Technical Data..........................................29
Advertisement
Table of Contents
Related Manuals for Frigidaire FWF 81663W
Summary of Contents for Frigidaire FWF 81663W
-
Page 1: Table Of Contents
User Manual FWF 81663W CONTENTS Safety information........2 Settings.............15 Safety instructions........4 Before first use......... 15 Product description........6 Daily use...........16 Control panel..........7 Hints and tips..........21 Programme Chart........9 Care and Cleaning........23 Consumption values......... 11 Troubleshooting........26 Options............. 13 Technical Data..........29... -
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 3 SAFETY INFORMATION If the mains power supply cable is damaged, it must be • replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. Before any maintenance operation, deactivate the appliance • and disconnect the mains plug from the socket. Do not use high pressure water sprays and/or steam to clean •...
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Installation Electrical connection WARNING! The installation must comply with Risk of fire and electric shock. relevant national regulations. • The appliance must be earthed. • Remove all the packaging and the transit • Always use a correctly installed bolts including rubber bush with plastic shockproof socket. - Page 5 SAFETY INSTRUCTIONS of the appliance with the use of water in the factory. • You can extend the drain hose to maximum 400 cm. Contact the Authorised Service Centre for the other drain hose and the extension. WARNING! Risk of injury, electric shock, fire, burns or damage to the appliance.
-
Page 6: Product Description
PRODUCT DESCRIPTION Appliance overview Worktop Detergent dispenser Control panel Door handle Rating plate Quick Reminder sticker Feet for levelling the appliance Fixing plate kit (4055171146) Available from your authorised dealer. If you install the appliance on a plinth, secure the appliance in the fixing plates. Read carefully the instructions supplied with the accessory. -
Page 7: Control Panel
CONTROL PANEL drained out with the water, in such a way Special features that there is no need to access this area for Your new washing machine meets all regular maintenance and cleaning. Refer to modern requirements for an effective chapter 'Care and Cleaning' for best treatment of laundry with low water, energy maintenance and care of the appliance. - Page 8 CONTROL PANEL Display A. The time area: • : the programme duration • : the "finish in" time • : the alarm codes • : the message of error • : the programme is completed. B. The child lock indicator: •...
-
Page 9: Programme Chart
PROGRAMME CHART MAXIMUM PROGRAMME LOAD PROGRAMME DESCRIPTION TEMPERATURE REFERENCE (TYPE OF LOAD AND SOIL LEVEL) RANGE SPIN SPEED A short cycle for synthetic and delicate items with 30'@30° 1 kg light soil level or for items to freshen up. 30°C 800 rpm White cotton and coloured cotton. - Page 10 PROGRAMME CHART Programme options compatibility PRO- GRAMME ■ ■ ■ ■ 30'@30° ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ cotton ■ ■ ■ ■ ■ ■ ■ ■ cotton eco ■ ■ ■ ■ ■ ■ ■ ■...
-
Page 11: Consumption Values
CONSUMPTION VALUES Stated values are obtained in laboratory conditions with relevant standards. Different causes can change the data: the quantity and type of laundry and ambient tempera‐ ture. Water pressure, the supply voltage and the temperature of inlet water may also affect the washing programme duration. - Page 12 CONSUMPTION VALUES APPROXI- ENERGY WATER CON- MATE PRO- LOAD PROGRAMMES CONSUMP- SUMPTION GRAMME (KG) TION (KWH) (LITRE) DURATION (MINUTES) wool 0,45 30°C 1) This programme at 60 °C with a load of 8 kg is the reference programme for energy label data, in compliance with UAE. S 5010 2:2013.
-
Page 13: Options
OPTIONS intensive temperature With this option you can wash very soiled With this option you can change the default laundry. temperature. The washing cycle lasts longer with this Indicator = cold water. option. The indicator of the set temperature comes The related indicator comes on. - Page 14 OPTIONS extra rinse With this option you can add some rinses to a washing programme. Use this option for persons allergic to detergents and in areas where the water is soft. The related indicator comes on. 1) See in "Settings" how to activate this option.
-
Page 15: Settings
SETTINGS Permanent Extra Rinse With this option you can permanently have During installation or before first use an extra rinse when you set a new you may observe some water in the programme. appliance. This is residual water left in •... -
Page 16: Daily Use
DAILY USE Using detergent and additives WARNING! Refer to Safety chapters. Loading the laundry Open the water tap. Connect the mains plug to the mains socket. 1. Pull the door handle to open the appliance door. 2. Put the laundry in the drum, one item at a time. - Page 17 DAILY USE Liquid or powder detergent 2. Adjust the flap in position B. 3. Put back the drawer in the recess. The default position of the flap is A (powder detergent). When you use the liquid detergent: • Do not use gelatinous or thick liquid detergents.
- Page 18 DAILY USE • Put the detergent and the fabric Starting a programme with the conditioner into the compartments. finish in option • Carefully close the detergent drawer. 1. Touch the button again and again to Activating the appliance choose the number of hours in which Press and hold the on/off button to activate you want the washing cycle to be or deactivate the appliance.
- Page 19 DAILY USE The programme continues. • In the display comes on. • The indicator of the button goes off. Cancelling a programme • The door lock indicator goes off. 1. Press the button for some seconds • You can open the door. to cancel the programme and to •...
- Page 20 DAILY USE AUTO-OFF option The AUTO-OFF stand-by option automatically deactivates the appliance to decrease the energy consumption. All the indicators and the display go off when : • You do not use the appliance for 5 minutes before you touch the Press the button on/off to activate the appliance again.
-
Page 21: Hints And Tips
HINTS AND TIPS We recommend that you pre-treat these The laundry load stains before you put the items in the • Divide the laundry in: white, coloured, appliance. synthetics, delicates and wool. Special stain removers are available. Use • Obey the washing instructions that are the special stain remover that is applicable on the laundry care labels. - Page 22 HINTS AND TIPS Water hardness If the water hardness in your area is high or moderate, we recommend that you use a water softener for washing machines. In areas where the water hardness is soft it is not necessary to use a water softener. To know the water hardness in your area, contact your local water authority.
-
Page 23: Care And Cleaning
CARE AND CLEANING • Select the cotton programme with the WARNING! highest temperature with a small quantity of detergent. Refer to Safety chapters. Door seal This appliance is designed with a self The appliance is intended for normal cleaning draining system, allowing light household use only. - Page 24 CARE AND CLEANING Cleaning the inlet hose and the valve filter 45° 20°...
- Page 25 CARE AND CLEANING Frost precautions If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump. Do this procedure also when you want to do the emergency drain.
-
Page 26: Troubleshooting
TROUBLESHOOTING WARNING! Refer to Safety chapters. Introduction The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the table). If the problem persists, contact the Authorised Service Centre. With some problems, the acoustic •... - Page 27 TROUBLESHOOTING PROBLEM POSSIBLE SOLUTION • Make sure that the water tap is open. The appliance does not • Make sure that the pressure of the water supply is not too fill with water properly. low. For this information, contact your local water authority. •...
- Page 28 TROUBLESHOOTING PROBLEM POSSIBLE SOLUTION • Make sure the levelling of the appliance is correct. Refer to The appliance makes an 'Installation instruction'. unusual noise. • Make sure that the packaging and/or the transit bolts are re‐ moved. Refer to 'Installation instruction'. •...
-
Page 29: Technical Data
TECHNICAL DATA Dimension Width/ Height/ Depth/ 600 mm/ 850 mm/ 520 mm/ 576 Total depth Electrical connection Voltage 220 - 240 V Overall power 2000 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, ex- cept where the low voltage equipment has no pro-... - Page 30 ENVIRONMENTAL CONCERNS dispose of appliances marked with the Recycle materials with the symbol . Put symbol with the household waste. Return the packaging in relevant containers to the product to your local recycling facility or recycle it. Help protect the environment and contact your municipal office.
