3.8 Installation of an Internal Hard Disk Drive
ATTENTION
The information described in this chapter is for service technician only!
A 2.5 inch drive bay within the RXi Box IPC-XP may be equipped with a standard SATA drive. The use of Solid
State Drives is recommended. Standard rotating disk drives may be used if they withstand the intended
temperature range within the RXi Box IPC-XP box:
Figure 10: Internal SATA installation, vendor is subject to change
3.9 Initial Power-On Operation
After a few seconds, the RXi Box IPC-XP system BIOS banner will be displayed on the screen. If you have seen
all the on-screen messages to this point, you can be confident that the RXi Box IPC-XP is running properly and
is ready to be set up for your application.
