Black Max BM907500BT Starting/Stopping Instructions

R
BM907500BT
STARTING/STOPPING
INSTRUCTIONS
These instructions replace the starting and stopping instructions in your operator's manual
and quick reference guide.
STARTING THE ENGINE
See Figures 1 - 2.
NOTICE:
On a level surface with the engine off,
check the lubricant level before each
use of the generator.
NOTE: If location of generator is not level,
the unit may not start or may shut down
during operation.
 Unplug all loads from the generator.
 Verify the run switch is in the ON position.
 Turn the fuel valve to the ON (I) position.
 Turn the on/off switch ON ( l ).
 Pull the choke out to the START position.
NOTE: If engine is warm or the
temperature is above 50˚F, push the
choke in to the RUN position.
 Press the start button to start the engine.
NOTE: The LCD display must be on for
the engine to be started with the start
button. If the LCD display is off, press
and release the pairing button or toggle
the on/off switch off and on.
NOTE: The battery may require charging
before the generator can be started us-
ing only the start button. Until then, the
generator can be started by pulling the
recoil starter grip. Once the generator
is started, the battery will charge as the
unit runs.
 The generator can also be started by
pulling the recoil starting grip until the
engine runs.
NOTE: Do not allow the grip to snap
back after starting; return it gently to
its original place.
 Allow the engine to run for 15-30
seconds, then move the choke to the
RUN position.
STOPPING THE ENGINE
See Figure 1.
To stop the engine under normal oper-
ating conditions:
 Remove any load from the generator.
 Turn the fuel valve to the OFF (O)
position.
 Turn the on/off switch OFF ( O ).
To stop the engine in an emergency
situation:
 Put either the on/off switch or the run
switch in the OFF (O) position.
WARNING:
While operating and storing, keep at
least 3 feet of clearance on all sides
of this product, including overhead.
Allow a minimum of 30 minutes of
"cool down" time before storage.
Heat created by muffler and exhaust
gases could be hot enough to cause
serious burns and/or ignite combustible
objects.
Fig. 1
C
ON D
OFF
E
A
F
B
A - On/off switch (interruptor de encendido/
apagado)
B - Start button (botón de arranque)
C - Fuel valve (válvula de combustible)
D - On (encendido)
Fig. 2
B
A
A - Pull choke out to START position [tirar del
anegador hacia la posición arranque)
B - Push choke in to RUN position (empujar el
anegador hacia la posición funcionamiento)
G
E - Off (apagado)
F - Recoil starter grip (mango del arrancador
retráctil)
G - Run switch (interruptor de encendido)
OWT INDUSTRIES, INC.
P.O. Box 1427
Anderson, SC 29622, USA
2
1
1-800-726-5760
www.blackmaxtools.com
995000399
3-6-18 (REV:01)
