Summary of Contents for CompuLab Face
- Page 1 FACE MODULE Design Guide...
- Page 2 To the extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by CompuLab, its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
-
Page 3: Table Of Contents
GPIOs ..........................10 Power ..........................10 Miscellaneous ......................... 11 FACE MODULE CONNECTORS ................. 12 FACE Extension Connectors (PX1, PX2) ..............12 ELECTRICAL DESIGN RECOMMENDATIONS ............14 General Design Guidelines .................... 14 PCIe Design Guidelines ....................14 SATA Design Guidelines ....................14 USB Design Guidelines .................... - Page 4 Table 1 Document Revision Notes Date Description January 2011 First release Revised February 2012 FACE Module Design Guide...
-
Page 5: Introduction
About This Document This document is part of a set of reference documentation necessary to design and program custom FACE modules for CompuLab products. Related Documents For additional information not covered in this document, please refer to the documents listed in Table... -
Page 6: Overview
The CompuLab product line of industrial PCs is designed to support custom functionality and I/O extensions with FACE (Function And Connectivity Extension) modules. FACE modules are implemented by an internal extension board and a simple sheet-metal panel. The extension board is connected to the PC motherboard with two board-to-board connectors featuring standard PC interfaces such as PCIe, USB2, SATA, SMBus etc. -
Page 7: Face Module Interfaces
PCIe clock 1 negative PCIE_CLK2_P PX2-B26 PCIe clock 2 positive PCIE_CLK2_N PX2-B27 PCIe clock 2 negative PCIe reset. Asserted during transition to PCIE_RESET# PX1-B31 S3/S4/S5. PCIE_WKUP# PX1-A37 PCIe wake-up PCIE_CLKREQ# PX2-A41 PCIe clock request Revised February 2012 FACE Module Design Guide... -
Page 8: Sata
USB port 13 negative I/O USB Overcurrent USB_P7_P8_OVC PX1-B16 USB over current for ports 7 and 8 USB_P4_P12_OVC PX1-A26 USB over current for ports 4 and 12 USB_P5_P13_OVC PX1-A47 USB over current for ports 5 and 13 Revised February 2012 FACE Module Design Guide... -
Page 9: Smbus
Multiplexed command / address / data bit 2 LPC_LAD3 PX1-A33 Multiplexed command / address / data bit 3 LPC_CLK PX1-B23 33MHz clock for LPC devices LPC_LFRAME# PX1-B24 LPC bus frame LPC_SER_IRQ PX1-B22 Serial IRQ Revised February 2012 FACE Module Design Guide... -
Page 10: Gpios
PX2-A25, PX2-B25, PX2-A32, PX2-B32, PX2-A38, PX2-B41, PX2-A44, PX2-A50 PX1-B7, PX1-A13, PX1-B13, 5V_S5 S5-domain 5V power rail PX1-B19, PX2-A19, PX2-B19 PX1-A47, PX1-A48, PX1-A49, PX1-A50, PX1-B47, PX1-B48, VCC_12V Main 12V power rail PX1-B49, PX1-B50, PX2-B48, PX2-B49, PX2-B50 Revised February 2012 FACE Module Design Guide... -
Page 11: Miscellaneous
PX2-B31, PX2-A35, PX2-B33, PX2-B34, PX2-B35, PX2-B36, PX2-B37, PX2-B38, PX2-B42, PX2-B43, PX2-B45, PX2-B46 PX2-A8, PX2-A9, PX2-A11, PX2-A12, PX2-B8, PX2-B9, PX2-B11, PX2-A26, PX2-A27, Should be left disconnected. PX2-A28, PX2-A29, PX2-A30, PX2-A31, PX2-A33, PX2-A34, PX2-A36, PX2-A37 Revised February 2012 FACE Module Design Guide... -
Page 12: Face Module Connectors
FACE MODULE Connectors FACE MODULE CONNECTORS FACE Extension Connectors (PX1, PX2) Table 12 PX1 connector pin-out Signal Name Signal Name SATA_P2_TX_P RESERVED SATA_P2_TX_N RESERVED IR RX SATA_ACT# SATA_P2_RX_P RESERVED SATA_P2_RX_N RESERVED 5V_S5 SATA_P3_TX_P SATA_P1_TX_P SATA_P3_TX_N SATA_P1_TX_N SMBALERT# RESERVED SATA_P3_RX_P SATA_P1_RX_P... - Page 13 SMBUS_THRM_CLK SMBUS_P2_DAT SMBUS_THRM_DAT PCIE_CLKREQ# FCH_GPIO57 RESERVED FCH_GPIO58 RESERVED FCH_PWM0_GPIO197 USB_P13_P RESERVED USB_P13_N RESERVED USB_P5_P13_OVC FCH_PWM1_GPIO198 USB_P5_P VCC_12V USB_P5_N VCC_12V VCC_12V Table 14 PX1, PX2 connector data Manufacturer Mfg. P/N Mating connector 61082-10260[2|6]LF 61083-10460[2|6]LF Revised February 2012 FACE Module Design Guide...
-
Page 14: Electrical Design Recommendations
Trace spacing should be ≥ 4:1 on both sides of the pair. Avoid stubs or test points on the signal pairs. Please refer to the reference schematics and layout designs available in the FACE module design package. 5.3 SATA Design Guidelines ... -
Page 15: Usb Design Guidelines
Place the choke within 1.0” of the USB connector. Please refer to the reference schematics and layout designs available in the FACE module design package. 5.5 Power Supplies Design Guidelines ... -
Page 16: Mechanical Design Considerations
Mechanical design considerations MECHANICAL DESIGN CONSIDERATIONS FACE Module PCB design The mechanical drawings below specify component placement restrictions. Full mechanical drawings are available as part of the “FACE module design package” at http://www.fit-pc.com/. Figure 1 FACE module PCB top Figure 2... -
Page 17: Face Module Panel Design
FACE Module Panel Design Can be made of sheet metal 1.3mm to 1.4mm Connector holes can be manufactured by laser cutting, milling or punching. Full mechanical drawings are available as part of the “FACE module design package” at http://www.fit-pc.com/. Figure 3...
