Makita Maktec MT241 Technical Information

Portable cut-off
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Model MT241 has been developed as the aesthetic change model
of maktec MT240, featuring industrial performance and durability
at less expense.
S
pecification
Voltage (V)
110
120
220
230
240
No load speed: min
Wheel size: mm (")
Weight according to
EPTA-Procedure 01/2003*
Cord length: m (ft)
Capacity: mm (")
Form of materials
D: Diameter
W: Width
H: Height
S: Side
T: Thickness
*1 with Abrasive cut-off wheel 355
*2 Weight shown above is the model with Center cap.
S
tandard equipment
Socket wrench 17
Abrasive cut-off wheel 355 ............................... 1
Note: The standard equipment for the tool shown may vary by country.
O
ptional accessories
No
MT241
355mm (14") Portable Cut-Off
Current (A)
Cycle (Hz)
15.0
50/60
15.0
50/60
9.6
50/60
9.2
50/60
8.8
50/60
rpm.
-1=
Diameter
Arbor
Thickness
: kg (lbs)
1
Miter angle
D
W
H x W: 102 (4) x 194 (7-5/8)
H
H x W: 70 (2-3/4) x 233 (9-1/8)
W
H x W: 119 (4-11/16) x 119 (4-11/16)
H
S x S: 137 (5-3/8) x 137 (5-3/8),
S
S
T
................................ 1
Continuous Rating (W)
Input
1,650
---
2,000
2,000
2,000
15.7 (34.6)*
2.0 (6.6) for Brazil, 2.5 (8.2) for Oceania, 3.0 (9.8) for other countries
0°
ø115 (4-1/2)
T: 10 (3/8)
W
Dimensions: mm (")
Length (L)
Width (W)
Height (H)
Output
900
900
1,400
1,400
1,400
3,800
355 (14)
25.4 (1)
3 (1/8)
2
45°
ø115 (4-1/2)
H x W: 115 (4-1/2) x 103 (4-1/16)
H x W: 106 (4-3/16) x 106 (4-3/16)
S x S: 100 (4) x 100 (4),
T: 10 (3/8)
PRODUCT
P 1/ 9
H
L
500 (19-3/4)
280 (11)
620 (24-3/8)
Max. Output(W)
2,500
2,500
3,000
3,000
3,000

Advertisement

loading

Related Manuals for Makita Maktec MT241

Summary of Contents for Makita Maktec MT241

  • Page 1 ECHNICAL INFORMATION PRODUCT P 1/ 9 MT241 Models No. Description 355mm (14") Portable Cut-Off ONCEPT AND MAIN APPLICATIONS Model MT241 has been developed as the aesthetic change model of maktec MT240, featuring industrial performance and durability at less expense. Dimensions: mm (") Length (L) 500 (19-3/4) Width (W)

  • Page 2: Necessary Repairing Tools

    Ring 17 Outside where Safety cover contacts 57a Surface where 86 Base contacts Gear housing complete Makita Grease N No.1 57b Gear room where Helical gear 49 rotates 25 g Base Punched hole for Pipe 20-128 passing a little Fig.
  • Page 3 P 3/ 9 epair [3] DISASSEMBLY/ASSEMBLY [3]-1. Armature DISASSEMBLING Disassemble Armature (Fig. 2, Fig. 3). Fig. 2 1. Remove Handle (L) by unscrewing four Tapping screws and three M5x30 Pan head screws. 4x18 Tapping screw (4 pcs.) Handle (L) M5x30 Pan head screw (3pcs.) 2.
  • Page 4 P 4/ 9 epair [3] DISASSEMBLY/ASSEMBLY [3]-1. Helical gear 49 DISASSEMBLING (1) Remove M10x25 Hex flange head bolt, Outer flange, Cut off wheel, O ring 14, Ring 17, Inner flange. (2) Remove Gear section (Fig. 4). Fig. 4 1. Unscrew M5x40 Pan head screws that 2.
  • Page 5 P 5/ 9 epair [3] DISASSEMBLY/ASSEMBLY [3]-3. Vise section DISASSEMBLING Vise section is fixed to Base as follows. * at Screw guide with two M8x30 Pan head screws * by interlocking of Shoulder pin 10-16 with the guide groove on Base (1) Make Screw guide free from Base by unscrewing two M8x30 Pan head screws.
  • Page 6 P 6/ 9 epair [3] DISASSEMBLY/ASSEMBLY [3]-3. Vise section ASSEMBLING Take the reverse step of Disassembling (Fig. 7). Chain has to be fixed to Screw guide on the side where Protrusion is furnished (Fig. 8). Fig. 8 Align the Chain with the Protrusion on Screw guide. M8x30 Pan head screw Protrusion on Screw guide...
  • Page 7 P 7/ 9 epair [3] DISASSEMBLY/ASSEMBLY [3]-4. Base DISASSEMBLING Fig. 11 5. Insert 1R003 into Pipe 20-128 and open it 6. Remove Torsion spring 24. fully in the Pipe to grip its internal surface. Now Motor unit is separated And pull out the Pipe while twisting them. from Base.

  • Page 8: Circuit Diagram

    P 8/ 9 ircuit diagram Fig. D-1 Color index of lead wires' sheath Blue Black Brown White This lead wire is black for some countries in stead of brown. This lead wire is white for some countries in stead of blue. * Terminal block Noise Switch...
  • Page 9 P 9/ 9 iring diagram Fig. D-3 Wiring in Handle R Put Noise suppressor Do not loosen lead wires in this part. in this place, if it is used. Noise suppressor Route Field lead wires (black), (white) between Rib A and Rib B in Handle R. And pass them through Line filter.
