Sony VAIO S VGN-S67GP/S Brochure & Specs

Silvery design elegance meets enterprising mobility.
VAIO S
VGN-S67GP/S
Intel ® Centrino ® Mobile Technology
Specifications
Model VGN-S67GP/S
® ®
Platform Intel Centrino Mobile Technology
® ® 1 ®
• Intel Pentium M Processor 750 (1.86GHz)* • Intel PRO/Wireless 2200BG Network Connection • Intel
® ®
Operating System Microsoft Windows XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)
Processor System Bus 533MHz
Memory Bus 533MHz
Cache Memory L1 Cache: 64KB L2 Cache: 2MB (on CPU)
2 3
Main Memory 512MB DDR2 SDRAM* (upgradeable up to 2GB)* (partially shared with video memory)*
2 SO-DIMM slots (The pre-installed memory module uses one)
5
Hard Disk 60GB (C: 20GB, D: 40GB* ) Serial ATA, 5400rpm
6
Optical Drive CD-RW/DVD-ROM Drive*
Maximum reading speed: DVD+RW, DVD-RW, DVD+R, DVD-R, DVD+R DL (Double Layer): 4 / DVD-ROM: 8 / CD-R, CD-RW, CD-ROM: 24
Maximum writing speed: CD-R, CD-RW: 24
Graphics Accelerator • Dual display compatible • 3D graphics acceleration compatible
® ® ® 4
• NVIDIA GeForce Go 6400 with NVIDIA TurboCache™ * (PCI Express 16 connection)
4
Video Memory 128MB*
Display 13.3˝ Wide (WXGA: 1280 800) TFT colour display (Clear Bright LCD: Single Lamp, Wide View)
7
Interfaces • USB 2.0 2* • i.LINK (IEEE 1394) S400 (4 pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)
• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector
8
• Memory Stick Slot* (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer compatible)
9 ®
Wireless LAN • Integrated Wireless LAN IEEE 802.11b/802.11g* • Intel PRO/Wireless 2200BG Network Connection
10
• Data rate: maximum 11Mbps (802.11b) 54Mbps (802.11g)* • Frequency: 2.4GHz
® ® 10
Bluetooth • Bluetooth standard version 2.0+EDR* • Output: maximum +6dBm • Frequency: 2.4GHz
Modem V.92 and V.90 Compliant
PC Card Slot Type I/II 1, CardBus Support
®
Audio • Intel High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers
Keyboard / Input Device • ca 18mm Key pitch / ca 2mm Key stroke • 82 Keys • Intelligent Touchpad
11 12
Battery VGP-BPS2* Lithium-ion battery: up to 3.5 hours of use*
Dimensions (W H D) 312.5 29.9-35.4 224.8mm
Weight 1.95kg (including the supplied battery)
Software Applications • Adobe Reader 7 • Adobe Photoshop Elements 4.0 (Installer) • Adobe Premiere Standard • DVgate Plus 2.2 • Image Converter 2 Plus
• Norton Internet Security 2006 • Roxio DigitalMedia SE 7 • PictureGear Studio 2.0 • SonicStage 3.3 • SonicStage Mastering Studio 2.1
• SonicStage Mastering Studio Audio Filter 2.0 • VAIO Control Center 1.1 • VAIO Edit Components 5.0 • VAIO Media 5.0
• VAIO Original Screen Saver • VAIO Recovery Utility 2.6 • VAIO Update 2.1 • VAIO Zone 1.4 • WinDVD 5 for VAIO
Supplied Accessories
• AC adapter (VGP-AC19V10) • Lithium-ion battery (VGP-BPS2)
13
Warranty One year*
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 If memory modules of the same capacity are installed to both of the two memory module slots, computer will run in dual
channel mode and provide better performance. *3 By removing the pre-installed 512MB memory module and adding two 1GB memory modules. *4 NVIDIA
combines the size and bandwidth of video memory and dynamically available system memory for optimal system performance. *5 Includes necessary data for recovery (setting back to initial
shipment settings) in the hard disk drive consuming approximately 5GB in size. *6 This product is designed to playback discs that conform to the Compact Disc Digital Audio standard
specifications (CD Standard). A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. Please be aware that the
audio side (non-DVD side) of a DualDisc may not play on this product because it does not conform to the CD Standard. *7 High-speed/Full-speed/Low speed compatible. *8 Compatibility
confirmed with Sony branded "Memory Stick" media only. *9 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may reduce the communication speed due to
radio interference. Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure communication with IEEE 802.11b products. When
the communication speed is not as fast as expected, changing the wireless channel on the access point may increase the communication speed. *10 The communication speed varies
depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the radio conditions, and the software in use. In addition,
communication may be cut off depending on the radio conditions. *11 This product may only function with a genuine Sony battery designed for this model. *12 Estimated battery life (under
JEITA Battery Run Time Measurement Method (ver.1.0).) When the power-saving mode is on. Actual battery life may vary with different operating conditions and settings. For further details,
please visit vaio-online.sony.com *13 Warranty conditions may vary by region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation and/or its subsidiaries.
Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other countries. Intel, Intel logo, Intel Inside, Intel
Inside logo, Intel Centrino, Intel Centrino logo, Intel SpeedStep, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other
countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. All other product and brand names may be
trademarks or registered trademarks of their respective owners. Whilst information given is true at time of printing, small production changes in the course of our company's policy of
improvement through research and design might not necessarily be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
Optional Accessories (availability depends on region)
VGP-PRS2 VGP-UMS50
Port Replicator
Monitor connector (DVI-D) Stylish, easy-to-use sloping design
Monitor connector (VGA, D-SUB 15 pin) Innovative PTFE sole for precise operation
Printer connector Sensor resolution: 800 dots per inch
Network connector
USB 2.0 connector ( 3)
VGP-BPL2 PCGA-UMS3/B
Lithium-ion Battery
Rechargeable battery Sophisticated, dynamic exterior
Maintenance-free optical design
Sensor resolution: 800 dots per inch
VGP-AC19V10 VGP-CKS1
AC Adapter
Universal voltage compatible: AC100 – 240V Suitable size just for VAIO S
Durable nylon outer material
Soft lining prevents scratches
Stylish VAIO logo accent
vaio-online.sony.com
®
915PM Express Chipset
4
Sony recommends Microsoft
Windows XP Professional.
®
VGN-S67GP/S
1
3 4 5 6 7
S1 S2
10
12
®
TurboCache™ technology
13 14 15
17 18
1. Indicators
2. Wireless LAN switch
3. Network (RJ-45) connector (100BASE-TX/10BASE-T)
4. Modular (RJ-11) connector
USB Optical Mouse
5. Microphone jack (stereo mini)
6. Headphone jack (stereo mini)
7. Monitor connector (VGA, D-SUB 15 pin)
8. PC Card slot (Type I/II
9. PC Card eject button
10. Shortcut buttons
11. Power button
USB Optical Mouse (Compact)
12. Built-in stereo speakers
13. CD-RW/DVD-ROM drive
14. Manual eject hole
15. Disc eject button
* Availability depends on region.
16. Memory Stick Slot
(
Standard/Duo Size, MagicGate, Memory Stick PRO,
high-speed data transfer compatible)
Carrying Case
17. i.LINK (IEEE 1394) S400 (4 pin) connector
18. USB 2.0 connector ( 2)
19. DC-IN connector
®
2
8 9
11
12
16
19
