Page 1 10. Spare Parts List © Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by means, electronic, mechanical, photographic, or otherwise without the prior permission of Philips.
Page 2: Important Safety Notice
SERVICE NOTE: The CRT DAG is not at chassis ground. IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all Philips Consumer Electronics Company** Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations.
Page 3 FIRE AND SHOCK HAZARD 1. Be sure all components are positioned in such a way as to avoid the possibility of adjacent component shorts. This is especially important on those chassis which are transported to and from the service shop. 2.
Page 4: Leakage Current Cold Check
X-RADIATION 1. Be sure procedures and instructions to all your service personnel cover the subject of X-radiation. Potential sources of X-rays in TV receivers are the picture tube and the high voltage circuits. The basic precaution which must be exercised is to keep the high voltage at the factory recommended level.
Page 5 megohm and 5.2 megohms. When the exposed metal does not have a return path to the chassis, the reading must be infinity. Remove the jumper from the ac line cord. LEAKAGE CURRENT HOT CHECK 1. Do not use an isolation transformer for this test. Plug the completely reassembled receiver directly into the ac outlet.
Page 6 Philips approved type. PARTS REPLACEMENT Many electrical and mechanical parts in Philips television sets have special safety related characteristics. These characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
Page 7 Chassis Identification and Interchangability Chassis Identification An identification label is located on the outside of the cabinet back. The first four characters (25R5) indicate the basic chassis series. The next two numbers (01) identify the total Electronic Package in the Cabinet.
Page 8 20R501 00APT145 CRT Module 00EMR590 Main Chassis 00ALR016 IR Assembly 00AVJ177 Jack Panel 003403130005 Varactor Tuner Typical Model: PA5020C1 25R501 00APT146 CRT Module 00EMR525 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner Typical Model: 25T222 25R502 00APT146 CRT Module 00EMR535 Main Chassis 00ALR016...
Page 9 Typical Model: HD2716 27R504 00APT146 CRT Module 00EMR507 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner Typical Model: CC2762 27R505 00APT146 CRT Module 00EMR597 Main Chassis 00ALR016 IR Assembly 00AVJ177 PRO Video Jack Panel 00ASW116 Keyboard 00AWR006 Diode Modulator 003403130005 Varactor Tuner Typical Model: PA5027...
Page 10 00EMR586 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner N /A Typical Model: TP2782C1 27R513 00APT146 CRT Module 00EMR577 Main Chassis 00ASW116 Keyboard 00ALR016 IR Assembly 003403130005 Varactor Tuner Typical Model: FS2770B1 32R502 00APT146 CRT Module 00EMR562 Main Chassis 00ALR016 IR Assembly 00ASW116...
Page 11 00APT145 CRT Module 00EMR590 Main Chassis 00ALR016 IR Assembly 00AVJ177 Jack Panel 003403130005 Varactor Tuner Typical Model: PA5020C1 25R501 00APT146 CRT Module 00EMR525 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner Typical Model: 25T222 25R502 00APT146 CRT Module 00EMR535 Main Chassis 00ALR016...
Page 12 27R504 00APT146 CRT Module 00EMR507 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner Typical Model: CC2762 27R505 00APT146 CRT Module 00EMR597 Main Chassis 00ALR016 IR Assembly 00AVJ177 PRO Video Jack Panel 00ASW116 Keyboard 00AWR006 Diode Modulator 003403130005 Varactor Tuner Typical Model: PA5027 27R506 00APT146...
Page 13 00ALR016 IR Assembly 00ASW116 Keyboard 003403130005 Varactor Tuner N /A Typical Model: TP2782C1 27R513 00APT146 CRT Module 00EMR577 Main Chassis 00ASW116 Keyboard 00ALR016 IR Assembly 003403130005 Varactor Tuner Typical Model: FS2770B1 32R502 00APT146 CRT Module 00EMR562 Main Chassis 00ALR016 IR Assembly 00ASW116 Keyboard 00AWR007...
Page 14 FS3270B101 32" 32R507 XS3272C101 (Canada) 32" 32R503 TP3287C101 32" 32R502 TP3262C101 32" 32R503 TS3262C101 32" 32R503 TS3272C101 32" 32R502 PHILIPS PA5020C101 20" 20R501 27T502C101 27" 27R501 27T502C102 27" 27R512 LP2970C101 (Latin) 29" 27R509 LP2971C101 (Latin) 29" 27R508 LS2940C101 (Latin) 29"...
Page 15 00EMR507 A002 Main Chassis 4835 219 28234 00EMR512 A002 Main Chassis 4835 219 28235 00EMR515 A002 Main Chassis 4835 219 28228 00EMR525 A002 Main Chassis 4835 219 28236 00EMR532 A002 Main Chassis 4835 219 28237 00EMR535 A002 Main Chassis 4835 219 28238 00EMR537 A002 Main Chassis 4835 219 28239...
Page 16 Model Replacement Parts List MODEL REPLACEMENT PARTS LISTS NOTE: THE "S" IN THE LEFT COLUMN INDICATES THE PART IS A CRITICAL SAFETY COMPONENT AND SHOULD BE REPLACED ONLY WITH THE PHILIPS PART NUMBER. BELL & HOWELL GNB1271106,1107, 1108 27" 4835 321 17079...
Page 17 4835 240 27007 Speaker 2.25X5" (2 used) 4835 138 17047 Battery f/Transmitter (1.5V) 001B 734 4E001 Owner's Manual GNB12911029 1103 32" 4835 321 17079 AC Cord 4835 432 97599 Back 4835 410 37237 Buttons 4835 256 97264 Clip, Anode Lead 4835 131 27106 CRT A80EFF272X53 4835 157 97052...
Page 18 4835 459 17524 Overlay 4835 240 37024 Speaker 3X5" (2 used) 4835 138 17047 Battery f[Transmitter (1.5V) 001B 722 6E001 Owner's Manual 001B 722 6E001 Owner's Manual CC2772A101,A102,A103 27" 4835 321 17079 AC Cord 4835 432 97582 Back 4835 410 97027 Buttons 4835 256 97264 Clip, Anode Lead...
Page 19 4835 535 27006 Yoke Wedges (3 used) C101, C102, C104 4835 157 97058 Degaussing Coil 4835 256 97265 Degaussing Coil Holder 4835 430 67141 Front (C101, C103, C104) 4835 430 67142 Front (C102) 4835 450 67202 Lens, IR 4835 459 17522 Nameplate 4835 459 17519 Overlay, Jack Panel...
Page 20 4835 430 67122 Front 4835 450 67200 Lens, IR 4835 459 17522 Nameplate 4835 459 17519 Overlay, Jack Panel 4835 240 27007 Speaker 2.25X5" (2 used) 4835 138 17047 Battery f/Transmitter (1.5V) 001B 721 8E001 Owner's Manual 001B 721 8F001 Owner's Manual MAGNAVOX 25TS52C202,C203 25"...
Page 21 4835 131 27127 CRT A63AFW36X (C103) 4835 150 27008 Convergence & Purity Asm. 4835 150 17116 Deflection Yoke 4835 535 27006 Yoke Wedges (3 used) 4835 157 97077 Degaussing Coil 4835 256 97265 Degaussing Coil Holder 4835 430 57163 Front 4835 459 17517 Nameplate 4835 459 17519...
Page 22 4835 410 37233 Button Asm. 4835 256 97264 Clip, Anode Lead 4835 450 67205 Crystal 4835 131 27091 CRT A63AFW42X (C202) 4835 131 27127 CRT A63AFW36X (C203) 4835 150 27008 Convergence & Purity Asm. 4835 150 17116 Deflection Yoke 4835 535 27006 Yoke Wedges (3 used) 4835 157 97077 Degaussing Coil...
Page 23 4835 432 97582 Back 4835 410 97027 Buttons 4835 256 97264 Clip, Anode Lead 4835 450 67218 Crystal 4835 131 27123 CRT A68AGN32X (A101, A103) 4835 131 27134 CRT A68AGN32XO2(A102) 4835 150 27008 Convergence & Purity Asm. (A101, A103) 4835 150 17098 Deflection Yoke (A101, A103) 4835 535 27006 Yoke Wedges (3 used)
Page 24 4835 450 67213 Crystal 4835 131 27123 CRT A68AGN32X(C101,C103) 4835 131 27134 CRT A68AGN32XO2 (C102) 4835 150 27008 Convergence & Purity Asm. (C101, C103) 4835 150 17098 Deflection Yoke (C101, C103) 4835 535 27006 Yoke Wedges (3 used) 4835 157 97058 Degaussing Coll 4835 256 97265 Degaussing Coil Holder...
Page 25 001B 721 2E001 Owner's Manual TS2752C201,C202,C205 27" 4835 219 47173 Ant. Isolator 4835 219 47174 Nut f/Isolator 4835 219 47175 Washer f/Isolator 4835 321 17079 AC Cord 4835 432 97579 Back 4835 432 17667 Buttons 4835 256 97264 Clip, Anode Lead 4835 450 67214 Crystal 4835 131 27123...
Page 26 4835 459 17517 Nameplate 4835 459 17519 Overlay 4835 240 27007 Speaker 2.25XV (2 used) 4835 138 17012 Battery ffTransmitter (AA) 001B 734 1E001 Owner's Manual TP2782C101,C102,C103,C104 27" 4835 321 17079 AC Cord 4835 432 97579 Back 4835 410 37244 Button Asm.
Page 27 4835 131 27136 CRT A78LCU30X 4835 150 17131 Deflection Yoke 4835 535 27006 Yoke Wedges (3 used) 4835 157 97052 Degaussing Coil 4835 256 97261 Degaussing Coil Holder 4835 430 67119 Front 4835 450 67202 Lens, IR 4835 459 17517 Nameplate 4835 459 17519 Overlay...
Page 28 4835 138 17047 Battery f/Transmitter (1.5V) 001B 722 5E001 Owner's Manual TS3268C101,C103,C104 31" 4835 321 17079 AC Cord 4835 432 97599 Back 4835 410 37246 Buttons 4835 256 97264 Clip, Anode Lead 4835 450 67211 Crystal 4835 150 27008 Convergence & Purity (C104) 4835 131 27106 CRT A80EFF272X53 (C101, C103) 4835 131 27137...
Page 29 4835 459 17519 Overlay, Jack Panel 4835 240 27007 Speaker 2.25X5" (2 used) 4835 138 17047 Battery f/Transmitter (1.5V) 001B 722 5E001 Owner's Manual PHILIPS PA5020C101 20" 4835 432 97573 Back 4835 410 97025 Buttons 4835 131 27121 CRT AS1JAR70X 4835 150 27007 Convergence &...
Page 30 4835 450 67214 Crystal 4835 131 27117 CRT A68AGN33X (C102) 4835 131 27123 CRT A68AGN32X (C101, C104) 4835 131 27134 CRT A68AGN32X02 (C103) 4835 150 27008 Convergence & Purity Asm. (C101,C102,C104) 4835 150 17098 Deflection Yoke (C101, C104) 4835 150 17113 Deflection Yoke (C102) 4835 535 27006 Yoke Wedges (3 used)
Page 31 001B 732 7F001 Owner's Manual 27PS82C101,C102,C103 27" 4835 321 17079 AC Cord 4835 432 97579 Back 4835 410 37244 Button Asm. 4835 256 97264 Clip, Anode Lead 4835 450 67214 Crystal 4835 131 27123 CRT A68AGN32X (C101, C103) 4835 131 27134 CRT A68AGN32XO2 (C102) 4835 150 27008 Converg.
Page 32 4835 459 17521 Nameplate 4835 459 17518 Overlay 4835 240 37022 Speaker 3" (2 used) 4835 138 17001 Battery f/Transmitter (AAA) 001B 723 9S001 Owner's Manual LS296IC101,C102,C103 29" 4835 321 17079 AC Cord 4835 272 17003 AC Adapter 4835 015 57126 AC Plug Adapter 4835 432 97581 Back...
Page 33 32FP74B101,B102 32" 4835 321 17079 AC Cord 4835 432 97583 Back 4835 410 97027 Buttons 4835 256 97264 Clip, Anode Lead 4835 450 67218 Crystal 4835 131 27106 CRT A80EFF272X53 4835 157 97052 Degaussing Coil 4835 256 97265 Degaussing Coil Holder 4835 432 67214 Front Grille Asm.
Page 34 INDICATES A COMPONENT WHICH WILL VARY DEPENDING UPON SCREEN SIZE, PRODUCTION DATES AND OPTIONAL FEATURES INSTALLED. PLEASE SEE THE REPLACEMENT PARTS LIST FOR SPECIFIC PART INFORMATION. 7. SPARK GAPS SHOWN ON THE CRT BOARD SCHEMATIC ARE INTERNAL TO THE CRT SOCKET. THIS WAVEFORM (#9) AT PINS 31 THROUGH 35 ARE PULSE WIDTH MODULATED.
Page 35 COMPONENT AND SPECIAL SYMBOLS: • INDICATES AN SMD 'CHIP' TYPE COMPONENT AND AS SUCH WILL BE LOCATED ON THE BOTTOM SIDE OF THE PRINTED CIRCUIT BOARD. INDICATES A COMPONENT WHICH WILL VARY DEPENDING UPON SCREEN SIZE, PRODUCTION DATES AND OPTIONAL FEATURES INSTALLED. PLEASE SEE THE REPLACEMENT PARTS LIST FOR SPECIFIC PART INFORMATION.
Page 36 Service Adjustment Notes Caution: The RS Chassis incorporates a "HOT" ground system. Always use a separate isolation transformer when applying power to the ex-posed chassis. Service Adjustment Notes: Unless otherwise specified: All service adjustments are "HOT" voltagewise. For maximum safety, ensure the use of properly insulated tools.
Page 37 Adjust R712 to straighten the vertical lines on the left and right sides of the picture. Adjust R714 to remove any trapezoid distortion (tilt) from the vertical lines on the left and right sides of the screen. NOTE: An adjustment of register 80 (Horz Center) in the service test mode may need to done to center the raster properly on the screen before preforming step number 5.
Page 38 Slowly spread the 2-X Pole purity rings to center the Green portion of the screen leaving the same amount of Red on the left side as there is blue on the right. Loosen the Yoke Clamp screws and slide the Yoke back to the point of best Green Purity. Tighten the Yoke Clamp screw slightly so that the Yoke can still be moved with some friction.
Page 39: White Balance
White Balance 1 Turn the set on. 2 Using the MENU set the color, brightness, picture and sharpness controls to MINIMUM. Select ANTENNA INPUT and disconnect the antenna. 3 Set Sub-Bright Control R390 (E-3) to minimum (Fully clockwise) 4 Set G2 to minimum. 5 Set Green and Blue Drive Controls to mid-range.
Page 40 Wide Band Adjustment 1. Make the following changes to the VG91: Mode Switch set to L Ch., Stereo Pilot set for 1 00% NORM. 2. Enter 83 with remote for Wide Band/Spectrum adjustments. 3. Adjust Wide Band for Null on scope at Test Point 53 (B-1) (Pin 33 IC200) using +/- buttons on remote. Spectrum 1.
Page 41 FEATURE = Indicates current register (SEE CHASSIS FEATURE CHART) 05 = Current register value in Hexadecimal format. By pressing the STATUS/EXIT button on the transmitter the run timer will be displayed in the upper left corner, also in Hexadecimal. To select another register, press the menu bottom on the transmitter until the desired register is displayed, or each register may be accessed directly by entering the register number.The following is a list of "Default"...
Page 42 3. Move the meter probe to OSD test point, TP33 (E-2). 4. Adjust L325 (E-2) to achieve a voltage at TP33 that is equal to one half of the voltage recorded at TP32 (approximately 2.5Vdc). This voltage must be set within the following tolerances: -10% to +2% of half of the voltage recorded at TP32.
Page 43 2403.84615 0.00 2403.84866 0.09 2403.85116 0.18 2403.85367 0.27 2403.85617 0.36 2403.85867 0.45 2403.86118 0.54 2403.86368 0.63 2403.86619 0.72 2403.86869 0.81 2403.87119 0.90 2403.87370 0.99 2403.87620 1.08 2403.87871 1.17 2403.88121 1.26 2403.88371 1.35 2403.88622 1.44 2403.88872 1.53 2403.89123 1.62 2403.89373 1.71 2403.89623 1.80 2403.89874...
Page 44 2403.99139 5.22 2403.99389 5.31 2403.99639 5.40 2403.99890 5.49 2404.00140 5.58 2404.00391 5.67 2404.00641 5.76 2404.00891 5.85 2404.01142 5.94 2404.01392 6.03 2404.01643 6.12 2404.01893 6.21 2404.02143 6.30 2404.02394 6.39 2404.02644 6.48 2404.02895 6.57 2404.03145 6.66 2404.03395 6.75 2404.03646 6.84 2404.03896 6.93 2404.04147 7.02 2404.04397...
Page 45 2404.13662 10.53 2404.13912 10.62 2404.14163 10.71 2404.14413 10.80 2404.14663 10.89 2404.14914 10.98 2404.15164 11.07 2404.15415 11.16 2404.15665 11.25 2404.15915 11.34 2404.16166 11.43 2404.16416 11.52 IF CLOCK IS SLOW Freq.,Hz. Byte [+ Comp.] (Hex) (sec./day) 2403.84615 0.00 2403.84365 0.09 2403.84115 0.18 2403.83864 0.27 2403.83614...
Page 46 2403.74850 3.51 2403.74599 3.60 2403.74349 3.69 2403.74099 3.78 2403.73848 3.87 2403.73598 3.96 2403.73347 4.05 2403.73097 4.14 2403.72847 4.23 2403.72596 4.32 2403.72346 4.41 2403.72095 4.50 2403.71845 4.59 2403.71595 4.68 2403.71344 4.77 2403.71094 4.86 2403.70843 4.95 2403.70593 5.04 2403.70343 5.13 2403.70092 5.99 2403.69842 5.31 2403.69591...
Page 47 2403.60327 8.73 2403.60076 8.82 2403.59826 8.91 2403.59575 9.09 2403.59325 9.18 2403.59075 9.27 2403.58824 9.36 2403.58574 9.45 2403.58323 9.54 2403.58073 9.63 2403.57823 9.72 2403.57572 9.81 2403.57322 9.90 2403.57071 9.99 2403.56821 10.08 2403.56571 10.17 2403.56320 10.26 2403.56070 10.35 2403.55819 10.44 2403.55569 10.53 2403.55319 10.62 2403.55068...
Page 48 All Models (7538) - INTERCONNECT WIIRING DIAGRAM...
Page 49 All Models (7538) - MAIN CHASSIS SECTION 1...
Page 50: Main Chassis Section 2 2
All Models (7538) - MAIN CHASSIS SECTION 2...
Page 51: Main Chassis Section 3 3
All Models (7538) - MAIN CHASSIS SECTION 3...
Page 52: Main Chassis Section 4 4
All Models (7538) - MAIN CHASSIS SECTION 4...
Page 53: Main Chassis Section 5 5
All Models (7538) - MAIN CHASSIS SECTION 5...
Page 54: Main Chassis Section 6 6
All Models (7538) - MAIN CHASSIS SECTION 6...
Page 55: Main Chassis Section 7 7
All Models (7538) - MAIN CHASSIS SECTION 7...
Page 56: Crt Panel Apt145 , Apt 146 8
All Models (7538) - CRT PANEL APT145 , APT 146...
Page 57: Keyboard(Asw116)& Ir Recvr(Alr016)
All Models (7538) - KEYBOARD(ASW116)& IR RECVR(ALR016)
Page 58 All Models (7538) - PRO-VIDEO JACK PANEL AVJ177...
Page 59 All Models (7538) - DIODE MODULATOR PANEL AWR006/007...
Page 60: R5 Main Chassis Pcb (Top View)
All Models (7538) - R5 MAIN CHASSIS PCB (TOP VIEW)
Page 61: Main Chassis Pcb (Btm View)
All Models (7538) - MAIN CHASSIS PCB (BTM VIEW)
Page 62 All Models (7538) - CRT PCB APT146...
Page 63 All Models (7538) - CRT PCB APT145...
Page 64 All Models (7538) - PRO-VIDEO JACK PANEL PCB AVJ177...
Page 65 All Models (7538) - DIODE MODULATOR PCB AWR006/007...
Page 66 32R5(7538) 5v p-p 5v p-p 2.5v p-p 7v p-p .1m sec 20µ sec .1µ sec 20µ sec 2.5v p-p 5v p-p 7.8v p-p 5.7v p-p .1µ sec 5m sec 50µ sec 50µ sec 3.6v p-p 2v p-p 1.2v p-p 4.4v p-p 50µ...
Page 67 32R5(7538) .8v p-p 1.2v p-p 1.2v p-p 1v p-p 20µ sec 20µ sec 20µ sec 20µ sec 4v p-p 162v p-p 1160v p-p 1.2v p-p 20µ sec 20µ sec 20µ sec 20µ sec 3.2v p-p 3v p-p 1v p-p 4.5v p-p 20µ...
