Bionaire BFH3521 Instruction Leaflet

BFH3521-UM_08ESM1.qxd 5/9/08 11:32 AM Page 1
Digital Tower
HEATER FAN
When using electrical appliances, basic safety
precautions should always be followed to reduce the risk
BFH3521
of fire, electric shock, and injury to persons, including the
following:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance
directly into a 120V AC electrical outlet.
3. The heater is hot when in use. To avoid burns, DO NOT
let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 ft (0.9 m) from the front
of the heater and keep them away from the sides and
rear.
4. DO NOT run cord under carpeting. DO NOT cover cord
with throw rugs, runners, or the like. Arrange cord away
from traffic area and where it will not be tripped over.
5. This heater is not intended for use in bathrooms,
laundry areas and similar indoor location. NEVER locate
heater where it may fall into a bathtub or other water
container.
6. Extreme caution is necessary when any heater is used
by, or near children or invalids, and whenever the
heater is left operating and unattended.
7. Always unplug the heater when not in use.
8. When unplugging, be sure to pull by the plug and not
the cord.
9. DO NOT insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
10.DO NOT operate heater with a damaged cord or plug,
or after the heater malfunctions, has been dropped or
damaged in any manner. Return appliance to
manufacturer for examination, electrical or mechanical
adjustment, or repair.
Read instructions before operating.
11.A heater has hot and arcing or sparking parts inside.
Retain for future reference.
DO NOT use it in areas where gasoline, paint, or
Instruction Leaflet flammable liquids are used or stored.
12.Use appliance only for intended household use as
☎
described in this manual. Any other use not
INFO-LINE
recommended by the manufacturer may cause fire,
If after having read this leaflet, you have any
electric shock, or injury to persons. The use of
questions or comments on your heater,
attachments not recommended or sold by the
manufacturer may cause hazards.
call 1-800-253-2764 in North America.
127555/9100020008876
13.DO NOT use outdoors.
AUTO SAFETY SHUT-OFF WITH INSTANT TIP OVER
3. By pressing the Arrow Buttons ( / ),
PROTECTION
program the heater to turn off in up to 16 hours from
This heater is equipped with a patented, technologically-
the current time, in increments of 1 hour.
advanced safety system that requires the user to reset
4. After setting the timer, the LED display will return to
the heater if there is a potential overheat situation. When
show the current room temperature.
a potential overheat temperature is reached, the system
5. After the predetermined length of time has passed, the will automatically shut the heater off. It can only resume
operation when the user resets the unit.
heater will automatically shut off.
To Reset the Heater:
Set Timer to turn heater ON:
If the unit shuts down, follow these steps:
1. While the heater is off, press and hold the Arrow
Buttons ( / ) simultaneously. 1. Unplug the unit.
2. By pressing the up and down buttons, program the 2. Wait 30 minutes to cool down.
heater to turn on up to 16 hours in advance of current
3. Plug unit in and operate normally.
time, in increments of 1 hour.
Tip-Over Shut-Off:
3. After the preset length of time has passed, the heater
If the unit is tipped over in any direction, it will instantly shut
will automatically turn on at the last mode setting that
off. To reset, simply place the heater in an upright position.
was programmed. If no program was set, the heater
Press the Mode/On button and it will operate normally.
will turn on Auto Mode HI Power at 75°F for a preset
time of 2 hours. TROUBLESHOOTING
If your heater fails to operate:
• UNPLUG THE UNIT
Press the Oscillation Button ( ) to activate or stop
oscillation feature. • Make sure the electrical outlet or circuit breaker is working.
Please do not manually turn the heater on the • Check for obstructions. If you find an obstruction turn
the heater OFF, and unplug the unit. Carefully remove
base. It is designed to turn only by motorized oscillation.
the obstruction and follow the reset instructions.
CLEANING/MAINTENANCE
• The temperature may be set too low. Adjust the
Always unplug the heater before cleaning and allow the
thermostat until the heater restarts.
heater to cool down.
1. Clean the unit with a soft cloth moistened with a mild
soap solution.
2. NEVER use abrasive or flammable solvents to clean the
unit.
3. After cleaning, be sure to completely dry the unit with a If you have any questions regarding your product or
cloth or towel.
would like to learn more about other Bionaire
please contact our Consumer Service Department at
4. Store heater in a cool, dry location.
1-800-253-2764 or visit our website at
5. The manufacturer recommends that you store the unit
www.bionaire.com.
in its original carton.
Over time, dust may accumulate on the front grills.
This can be removed by wiping the unit with a damp
cloth.
14.To prevent a possible fire, DO NOT block air intakes or
exhaust in any manner. DO NOT use on soft surfaces,
like a bed, where openings may become blocked.
15.To disconnect heater, turn controls to OFF, then remove
plug from outlet.
16.Avoid the use of an extension cord because the
extension cord may overheat and cause a risk of fire.
However, if you have to use an extension cord, the
cord shall be No. 14 AWG minimum size and rated not
less than 1875 watts.
17.If the heater will not operate, see specific instructions
on Auto Safety Shut-off.
18.DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user
serviceable parts. All servicing should be performed by
qualified personnel only.
19.Discontinue use if plug or outlet is hot. It is
recommended that the outlet be replaced if plug or
outlet is hot to touch.
CONSUMER SAFETY INFORMATION
THIS APPLIANCE HAS A POLARIZED
AC PLUG (one blade is wider than the
other). To reduce the risk of electric
shock, this plug is intended to fit in a
polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a
qualified electrician to install the proper outlet.
TECHNICAL SPECIFICATIONS
• Wattage: 1500W (+5% -10%)
• Working voltage: 120V AC/60Hz
ASSEMBLY INSTRUCTIONS
Carefully remove your heater from the box. Make certain
to remove parts from both sides of the packing foam.
Please save carton for off-season storage.
This package includes:
1 - Tower Heater
® products,
1 - Pedestal Pole Step 5 – Slide the base and the locking nut onto the cord,
smooth surface facing up.
1 - Remote Control
Make sure to align the dot on the back of the
2 - AAA Batteries for Remote Control
base to the dot on the neck of the heater.
Step 6 – Hold base straight while tightening the locking
nut by turning clockwise.
Before operation, insert 2 "AAA" batteries (included) into
the back of the remote control.
Step 7 – Insert the power cord through the opening at the
• Do not mix old and new batteries. rear of the base, twist to lock in place (see Figure
3).
• Do not mix alkaline, standard (carbon-zinc), or
Step 8 – Carefully turn the heater upright, place on a firm,
rechargeable (nickel-cadmium) batteries.
level surface.
The remote control for this unit has the capability of
operating all control panel functions. Please note this
OPERATING INSTRUCTIONS
remote control will not work through walls.
1. Place heater on a firm, level surface.
2. Your heater comes assembled and ready to use in the
reduced height configuration.
3. To use with pedestal, see Assembly Instructions.
If you are planning on using the pedestal, start with Step 1
4. Avoid overloading your circuit by not using other high
(Steps 1-6 see Figure 1 and Figure 2)
wattage appliances in the same outlet. At 1500 Watts,
this unit draws 12.5 Amps.
Step 1 – Turn the heater upside down and place on a firm,
level surface.
The power light will illuminate when the heater is
plugged in.
Step 2 – Unscrew the locking nut by turning
counterclockwise. Slide the locking nut and base
off of the power cord.
Step 3 – Slide the pedestal pole onto the cord – internal
threads first.
Step 4 – Screw the pedestal clockwise onto the (neck)
threaded end on the bottom of the heater until
you feel resistance.
A
B
Heater
E
Neck
Pedestal Pole
A
Base
B
Locking Nut
Power Cord
Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions or if in Canada, Sunbeam
Corporation (Canada) Limited doing business as Jarden
Consumer Solutions (collectively "JCS") warrants that for
a period of one year from the date of purchase, this
product will be free from defects in material and
workmanship. JCS, at its option, will repair or replace this
product or any component of the product found to be
defective during the warranty period. Replacement will be
made with a new or remanufactured product or
component. If the product is no longer available,
replacement may be made with a similar product of equal
or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical
functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from
the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is
required to obtain warranty performance. JCS dealers,
service centers, or retail stores selling JCS products do
not have the right to alter, modify or any way change the
terms and conditions of this warranty.
This warranty does not cover normal wear of parts or
damage resulting from any of the following: negligent use
or misuse of the product, use on improper voltage or
current, use contrary to the operating instructions,
disassembly, repair or alteration by anyone other than
JCS or an authorized JCS service center. Further, the
warranty does not cover: Acts of God, such as fire, flood,
hurricanes and tornadoes.
JCS shall not be liable for any incidental or consequential
damages caused by the breach of any express, implied
or statutory warranty or condition.
Except to the extent prohibited by applicable law, any
implied warranty or condition of merchantability or fitness
for a particular purpose is limited in duration to the
duration of the above warranty.
JCS disclaims all other warranties, conditions or
representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind
resulting from the purchase, use or misuse of, or inability
to use the product including incidental, special,
consequential or similar damages or loss of profits, or for
any breach of contract, fundamental or otherwise, or for
any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the
exclusion or limitation of incidental or consequential
damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusion may not apply
to you.
Press the button in below sequence to select
your precise comfort level, the selected setting will then
appear on LED Display:
1. – OFF
When the heater is plugged in, Power Light will illuminate,
the heater is at OFF Mode without heat output. Or you
may shut off the heater at any time by pressing the
button on remote control.
2. – Manual HIGH Heat
The heater will run continuously at HIGH heat.
3. – Manual LOW Heat
The heater will run continuously at LOW heat at reduced
wattage.
4. – Auto HIGH
Use Arrow Buttons (
temperature. The LED Display will return to show the
room temperature. The heater will then cycle On and Off
to maintain the preset temperature.
5. – Auto LOW
Use Arrow Buttons (
temperature. The LED Display will return to show the
room temperature. The heater will then cycle On and Off
to maintain the preset temperature.
CONTROL PANEL & REMOTE CONTROL
Please make sure the set temperature is higher
than the current room temperature.
C It is normal for the heater to cycle On and Off as
it maintains the preset temperature. To prevent the unit
from cycling, you need to raise the thermostat setting.
When the preset temperature is reached, the fan will run
Auto Off for 30 seconds without heat. This cool down process
75 75
Mode/On Mode/On ensures an accurate and consistent temperature reading.
Hold to turn off Hold to turn off
D
If you unplug the heater, you will have to reset the digital
thermostat again by following the above instructions.
Auto Off
Digital thermostat has memory. The digital
thermostat will remember the previous temperature setting
after the unit has been turned off. However, if the unit is
unplugged, the digital thermostat will be reset and will no
longer remember the previous temperature setting.
A. Mode/On Button
B. Oscillation Button
C. LED Display
The Digital Thermostat allows user to program the heater to turn
D D. Arrow Buttons at a preset time or turn
(Up/Down)
Auto Off Timer:
E. Off Button
1. Select the mode and/or temperature you wish the
(Remote Control
heater to run in.
F
only)
2. While the heater is running, press and hold the
F. Timer Button
Arrow Buttons (
(Remote Control
Or press the Timer button (
only)
to activate Timer.
This warranty gives you specific legal rights, and you may
also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
In the U.S.A.
If you have any question regarding this warranty or would
like to obtain warranty service, please call 1-800-253-2764
and a convenient service center address will be provided
to you.
In Canada
If you have any question regarding this warranty or would
like to obtain warranty service, please call 1-800-253-2764
and a convenient service center address will be provided
to you.
In the U.S.A., this warranty is offered by Sunbeam
Products, Inc. doing business Jarden Consumer
Solutions located in Boca Raton, Florida 33431. In
Canada, this warranty is offered by Sunbeam Corporation
(Canada) Limited doing business as Jarden Consumer
Solutions, located at 20 B Hereford Street, Brampton,
Ontario L6Y 0M1. If you have any other problem or claim
in connection with this product, please write our
Consumer Service Department.
© 2008 Sunbeam Products, Inc. doing business as
Jarden Consumer Solutions. All Rights Reserved.
Distributed by Sunbeam Products, Inc. doing business as
Jarden Consumer Solutions, Boca Raton, Florida 33431.
BFH3521UM08ESM1
/ ) to set your desired
/ ) to set your desired
after a set amount of time:
/ ) simultaneously.
) on the remote control
Printed in China
