Summary of Contents for Hanna Instruments HI935012
- Page 1 HI935012 Beer Thermometer...
- Page 2 Dear Thank you for choosing a Hanna Instruments product. Customer, Please read this instruction manual carefully before using this meter. This manual will provide you with the necessary information for correct use of this meter, as well as a precise idea of its versatility.
- Page 3 Table of Contents ............Preliminary Examination ........... General Description and Intended Use ......Specifications ............Operational Guide ............ Meter Setup ............. Battery Replacement ..........Temperature Probe ............ Accessories ............... Certification .............. Recommendations for Users ........Warranty ..............
- Page 4 Remove the meter from the packing material and examine it to make sure that no damage has occurred during shipping. If there is any damage, contact your local Hanna Instruments Office. Each meter is supplied complete with: • Temperature probe •...
- Page 5 Temperature checks provide peace of mind the operation is running smoothly and the batch will be uncompromised. Hanna Instruments manufactures the HI935012 Beer thermometer to meet the tough environment encountered in the beer sector.
- Page 6 Main features: • FC762N2 thermistor probe • Calibration Check feature • User calibration at 0 °C • Remaining battery life indication/low battery detection • Auto‑off capability • Waterproof casing IP65 HI935012 Interchangeable FC762 series Thermistor probes...
- Page 7 ‑20.0 to 120.0 °C Range* ‑4.0 to 248.0 °F 0.1 °C Resolution 0.1 °F Meter Accuracy ±0.1 °C (‑20.0 to 120.0 °C) ±0.2 °F (‑4.0 to 248.0 °F) @ 23.0°C ±5°C ±0.3 °C (‑10.0 to 80.0 °C) ±0.5 °F (14 to 176 °F) Probe Accuracy FC762N2 ±0.7 °C / ±1.3 °F remaining...
- Page 8 Each meter is supplied with batteries. Remove the battery cover, unwrap the supplied batteries and install them while paying attention to their polarity (see the “Battery replacement” section for more details). START UP Connect the temperature probe to the meter. To switch the meter ON, press the ON/OFF button on the front of the meter.
-
Page 9: Calibration Check
CALIBRATION CHECK The meter is provided with an automatic CAL Check feature at start‑up, which allows the user to check the meter calibration status. If the meter is calibrated, the display will stabilize and show “0.0 °C” (“32.0 °F“), ±0.3 °C (±0.5 °F) for a few seconds. - Page 10 Note: If the measurement is outside the ±1.5 °C (±2.7 °F) window, the meter enters Calibration mode with value blinking. Contact you local Hanna Instruments office for a check if the blinking persists. • When the meter reaches the stability condition, which is detected when the measurement remains within ±0.2 °C (±0.4 °F) for 5 seconds, the calibration is accepted and the reading becomes 0 °C (32 °F).
- Page 11 MEASUREMENT If a temperature probe is plugged in, the meter displays the measured temperature. If the measurement is unstable, the meter will display ⌛ until the measurement becomes stable. If the reading is slightly beyond the measurement range, the meter flashes the closest full‑scale value. To switch the meter OFF, press the ON/OFF key.
-
Page 12: Warning Messages
The display shows blinking dashes and “NO PROBE” message is displayed. CALIBRATION CHECK ERROR MESSAGE If during CALIBRATION CHECK the meter displays more than ±0.3 °C (±0.5 °F), then an “Err” message is displayed. Contact your local Hanna Instruments Office for recalibration. - Page 13 Enter Setup Mode to change the temperature unit (°C or °F) or to adjust the auto‑off time. To enter the Setup Mode, press the SET button located inside the battery compartment. SET button • Use the ON/OFF button to switch between “°C” or “°F”.
-
Page 14: Battery Replacement
8 minutes 60 minutes Disabled Each meter is provided with an auto‑off feature, which switches the meter off after a certain period of non‑use, to save battery life. BATTERY REPLACEMENT When the remaining battery life is less than 10% the battery tag blinks on the display to warn the user. - Page 15 Replace the three 1.5V AAA alkaline batteries located in the battery compartment, observing the indicated polarity. Replace the battery cover making sure that the gasket is in place.
- Page 16 All Hanna Instruments temperature probes are pre‑calibrated at the factory and are ready‑to‑use. These interchangeable probes make it possible to switch from one probe to another within the family without requiring recalibration. Note: To clean the meter and the probe, do not use aggressive detergents.
- Page 17 All Hanna Instruments conform to the CE European Directives. RoHS compliant Disposal of Electrical & Electronic Equipment. The product should not be treated as household waste. Instead hand it over to the appropriate collection point for the recycling of electrical and electronic equipment which will conserve natural resources.
-
Page 18: Recommendations For Users
Recommendations Before using these products, make sure they are entirely suitable for your specific for Users application and for the environment in which they are used. Any variation introduced by the user to the supplied equipment may degrade the meters’ performance. -
Page 19: Warranty
Technical Service department and then send it with shipping costs prepaid. When shipping any meter, make sure it is properly packed for complete protection. Hanna Instruments reserves the right to modify the design, construction or appearance of its products without advance notice. - Page 20 World Headquarters Hanna Instruments Inc. Highland Industrial Park 584 Park East Drive Woonsocket, RI 02895 USA www.hannainst.com Local Office Hanna Instruments Inc. Highland Industrial Park 584 Park East Drive Woonsocket, RI 02895 USA Phone: 800.426.6287 Fax: 401.765.7575 e‑mail: tech@hannainst.com Printed in ROMANIA...
