Contents: Important information Before first use Important safety notes Important notes on use of the freezer Important notes on first use and general usage Freezer layout and storage Control panel layout Setting the temperature Super freeze mode Eco mode Safety key lock Screen saver mode Timer function Mute function...
Page 3
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number...
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH WEEE DIRECTIVE 2012/19/EU. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service.
Page 5
Important This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
be provided on the rating plate) you must take care during trans- portation and installation to prevent the cooling system elements from being damaged. R600a is an environmentally friendly and natural gas, but is explosive. In the event of a leak due to damage to the cooling system, move your freezer away from open flames or heat sources and ventilate the room in which the appliance is located for 5 minutes.
freezer compartments as they could explode. • The maximum amount of fresh food that can be frozen within a 24 hour period is 8 kg. • Do not attempt to freeze more than the maximum amount. • To freeze fresh food more quickly, set the control panel to super freeze a few hours prior to placing the food in the freezer.
Freezer layout and storage Fig. 1 1 - Control panel 4 - Bottom freezer drawer 2 - Freezer flaps 5 - Large freezer drawer 3 - Freezer drawers...
Page 9
Control panel and usage Fig. 2 A - Temperature key K - Safety key lock symbol B - Low voltage symbol (page 16) L - Alarm/error symbol C - Eco mode symbol M - Mute key D - Super freeze symbol E - Temperature display Please note: The ‘e’...
Setting the temperature The default temperature for the fridge at first switch on should be -18°C. To adjust the temperature: • Press the key. The temperature display should start to flash. • Each press of the key should adjust the temperature on the display by 1 degree, with the range available being -16 to -24°C.
Eco mode This mode stores goods at approx. -18°C, consuming minimal energy. It offers the best balance between food storage and energy consumption. • Press the key repeatedly until the eco symbol ‘e’ has a box around it. If no button is pressed for a second, the mode will activate.
Timer function This feature allows a timer to be set in 5 minute increments up to a maximum time of 30 minutes. If you want to chill something quickly, you can use this function to remind you that the item is in the freezer. •...
continues, contact service. Maintenance, care and cleaning Always disconnect the appliance from the power before ANY cleaning or maintenance. • Leave spaces between food items wherever possible to allow air to flow between them. Do not allow food items or containers to touch the rear or side walls of the appliance.
• Check the door seal for any kinks, debris or damage. If you notice any, and are unable to resolve the issue yourself, contact CDA Customer Care so that the seal can be replaced.
Page 15
If ice/frost has formed; • It is normal for some ice droplets and/or frost to form on the back wall and drawer fronts of the appliance, particularly if the door has been opened a lot. This does not constitute a fault . •...
Fault codes ERROR TYPE MEANING REASON REMEDY Appears when one or more of the freezer parts Call a service agent for assistance as Failure warnings fail or there is a problem soon as possible. in the cooling system. This warning especially 1.
• The plug should be fully accessible at all times. (700 with • Ensure ventilation openings are kept handle) clear. • Do not use a multi-plug adaptor in the socket to connect this appliance 1860 alongside other appliances. • Do not tilt the freezer beyond 45º. •...
N.B. Ensure that the plug socket is situated in an easily accessible place. If the power supply cable or plug is damaged, it must be replaced by a CDA authorised agent. If the plug socket does not match the freezer plug, it must be replaced by the manufacturer or an authorised service agent in order to avoid a hazard.
Page 19
Storage volume (freezer) Star rating Automatic Defrosting type Climate class T/SN Airborne accoustic noise emissions dB(A) E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
Page 20
For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.eu Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 F: 01949 862 003 E: customer.care@cda.eu www.cda.eu...
