- Page 1 CUBELET ICE DISPENSER DCM-60KE DCM-60KE-P DCM-120KE DCM-120KE-P INSTRUCTION MANUAL DCM-60KE Telford 70 Stafford Park 7, Telford, Shropshire TF3 3BQ UK L1L009115 (050818)
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ............................1 I. INSTALLATION INSTRUCTIONS ..............................3 1. CONSTRUCTION ................................3 2. ACCESSORIES ...................................3 3. UNPACKING ..................................3 4. LOCATION ...................................4 5. INSTALLATION ..................................5 6. ELECTRICAL CONNECTIONS ............................5 7. WATER SUPPLY AND DRAIN CONNECTIONS .........................5 II. OPERATING INSTRUCTIONS ..............................6 1. START UP ....................................7 2. -
Page 3: Important Safety Information
ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury. - Page 4 ENGLISH The use of any electrical appliance involves the observance of some fundamental rules. In particular: * Instances of high humidity and moisture increase the risk of electrical short circuits and potential electrical shocks. If in doubt, disconnect the ice dispenser. * Do not damage the power cord or pull it in order to disconnect the ice dispenser from the electrical supply network.
-
Page 5: Installation Instructions
ENGLISH I. INSTALLATION INSTRUCTIONS 1. CONSTRUCTION Air Outlet (Ventilation Louver) Operation Panel Operation Switch Dispense Switch (DCM-60/120KE-P only) Ice Making Switch Front Cover Dispensing Outlet Push Lever Adjustable Leg (DCM-60/120KE only) Grille* Power Cord * Grille faces up or down depending on models. -
Page 6: Location
ENGLISH CAUTION Do not lift or manoeuvre the carton by using the shipping bands. When moving the unit by hand, hold the unit bottom. Do not hold the filter to lift up the unit. The condenser fins inside may cause injury. Always wear protective gloves when carrying the unit. -
Page 7: Installation
ENGLISH 5. INSTALLATION CAUTION Incorrect installation can cause harm to people, animals or other items, for which the manufacturer cannot be held responsible. Keep the adjustable leg height within 0 to 15 mm to prevent reduction in leg strength or injury caused by a falling adjuster. * Place the ice dispenser on a firm level surface at counter top height. -
Page 8: Operating Instructions
ENGLISH Hose Clamp Water Supply Inlet G3/4 Drain Hose Water Supply Tap Inlet Hose Inlet Hose Drain Outlet 5cm air gap Drain [Connection to the drain] * Attach the grey flexible drain hose (accessory) to the fitting at the bottom of the drain pan. Use the hose clamp (accessory) to obtain a leak free joint. -
Page 9: Start Up
ENGLISH IMPORTANT To prevent ice and/or water from scattering or splashing: [DCM-60/120KE] [DCM-60/120KE-P] * Use a container with more than a 7 cm opening. * Use a container with more than a 7 cm opening and more than * Place the container about 1 cm below the dispensing outlet a 12 cm height. -
Page 10: Dispensing Ice
The amount of water dispensed in the portion control depends on water pressure. Hook Model Default Setting Adjustable Range Hole (two) DCM-60KE Ice: Ice: 20 - 990g (in 10g steps) DCM-120KE Water: Not adjustable Water: Not adjustable... -
Page 11: Switch Lock Function
ENGLISH 3) To deactivate the portion control, press the portion control switch again. The display goes off. 4) Replace the front cover in its correct position. [b] Adjusting portion control 1) Remove the front cover. 2) Press and hold the portion control switch on the control panel for 3 seconds. The display shows the current portion control setting for ice dispensing. -
Page 12: Preparing The Ice Dispenser For Long Storage
ENGLISH [DCM-60/120KE-P] 2) Press and hold the ice switch, ice & water switch, and water switch at the same time for 3 seconds. The dispense switch flashes, and the continuous dispensing becomes available. Note: To deactivate the continuous dispensing, move the ice making switch to the “ON” position or remove the front cover. - Page 13 To prevent possible damage, do not clean the plastic parts with water above 40°C or in a dishwasher. IMPORTANT For spare parts information, contact your local Hoshizaki service agent. [a] Exterior Wipe the exterior at least once per week with a clean, soft cloth. Use a damp cloth containing a neutral cleaner to wipe off grease or dirt.
-
Page 14: Inspection And Maintenance
The extruding head (upper bearing) and mechanical seal must be replaced after four years from installation or 20,000 hours of operation, whichever comes first, to prevent the risk of serious accidents or failures. Contact your local Hoshizaki service agent for replacement. -
Page 15: Before Calling For Service
* The power is supplied to the unit. * The water is turned on. * The air filter is clean. For further assistance or advice, contact your local Hoshizaki service agent. 4. DISPOSAL Comply with local regulations regarding disposal of this appliance and its refrigerant gas. -
Page 16: Warranty
5. WARRANTY Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or workmanship for the duration of the “warranty period”. The warranty shall be effective for two years from the date of installation.
