Programming & Operating Crest Elite Infrared™ Pillow Speakers with Set Top Box Control (STB)
Crest Elite Infrared Pillow Speaker with Set Top Box control can be programmed to operate your TV, DVD and Set Top Box by simply following the Instructions listed
below. TV and Set Top Box are always programmed together, and needs to be programmed prior to programming DVD. Note: If you have multiple beds/TVs in the
same room, please see instructions on page 2 before proceeding with programming. Pressing video button will either let you control your DVD player, or access
Video On Demand functions if the service is offered by your cable/satellite TV provider. From this point on Set Top Box and Video On Demand will be referred to as
STB and VOD respectively.
Programming to operate TV and STB
1. Locate your TV brand and STB or cable/satellite TV provider in the Entertainment Device Codes section located below and on page 2. If more than one code is listed
for your device, start with the first code listed. If you intend to use your pillow speaker to control your DVD player as well, use the codes from 'w/DVD' column for STB,
otherwise use the codes from 'w/VOD' column.
2. Press the tv button. You should get a short confirmation LED flash above the tv button.
3. Press and hold the info/CC/5 and channel down buttons. The tv LED will flash for one second confirming you are entering programming mode. Continue holding
both buttons down until the tv LED starts to flash. This should take approximately three seconds.
4. Release the channel down button while the tv LED is flashing from step three. The tv LED will stop flashing. Continue to hold down the info/CC/5 button until the
tv LED starts to flash again. This should take approximately three seconds.
5. Release the info/CC/5 button while the tv LED is flashing from step four. The tv LED will stop flashing and remain off. You will have roughly 15 seconds to begin
entering the three-digit device code from step one.
6. Enter the three-digit TV code. The tv LED will flash once after each digit is entered to signify that the digit has been accepted. Once the code has been entered, the
tv LED will remain off for two seconds followed by a two second flash to signify a valid code entry.
7. Type in the three-digit STB code. The tv LED will flash once after each digit is entered to signify that the digit has been accepted. Once the code has been entered
the tv LED will remain off for two seconds followed by a two second flash to signify a valid code entry.
8. Test all the buttons on the pillow speaker. If the code doesn't work, program the pillow speaker by repeating steps two through seven with another device code
listed for your device brand.
Programming to operate DVD player
1. Locate your DVD brand in the Entertainment Device Codes section located on page two. If more than one code is listed for your device, start with the first code listed.
2. Press the video button. You should get a short confirmation LED flash above the video button.
3. Press and hold the info/CC/5 and mute buttons. The video LED will flash for one second confirming you are entering programming mode. Continue holding both
buttons down until the video LED starts to flash. This should take approximately three seconds.
4. Release the mute button while the video LED is flashing from step three. The LED will stop flashing. Continue to hold down the info/CC/5 button until the video
LED starts to flash again. This should take approximately three seconds.
5. Release the info/CC/5 button while the video LED is flashing from step four. The video LED will stop flashing and remain off. You will have roughly 15 seconds to
begin entering the three-digit device code for DVD from step one.
6. Enter the three-digit DVD code. The video LED will flash once after each digit is entered to signify that the digit has been accepted. Once the code has been entered,
the video LED will remain off for two seconds followed by a two second flash to signify a valid code entry.
7. Test all the buttons on the pillow speaker. If the code doesn't work, program the pillow speaker by repeating steps two through seven with another DVD code
listed for your DVD brand.
Note: If you see the LED flash five times very quickly while entering device code, then either the code that was entered was invalid or too much time elapsed between
digit entries. In this case, repeat the entire programming procedure. Your pillow speaker will return to normal operation throughout steps two through four if you
simply release both the info/CC/5 and channel down or mute buttons. In either of these two cases your pillow speaker will default back to the codes that were being
used prior to programming.
Entertainment Device Codes
Listed below are the most common TV, DVD and STB brands. If your brand is not listed or none of the codes worked for you, please contact our Technical Support
Department for help at 1-800-328-8908 or visit our website www.cresthealthcare.com for a more extensive list of entertainment device codes.
Set Top Box Overlay
2
year
warranty
TV Brand Three-Digit Device Code
Insignia® 035
HCI Healthcare TV™ 006
LG® 001, 004, 005, 020, 056, 073, 091, 102, 104 (Bed 2), 106 (Bed 2), 107 (Bed 3), 108 (Bed 4)
Panasonic® 002, 003, 008, 013, 014, 019, 022, 023, 036, 057
PDI® 002, 003, 014, 012, 017, 062, 087, 092, 100
Phillips® 002, 003, 004, 014, 024, 028, 037, 064, 072, 075, 076, 077
RCA® 000, 004, 018, 020, 021, 023, 065, 070, 103
Samsung 002, 003, 004, 014, 018, 020
Sharp® 004, 026, 051, 093
Sony® 038
Vizio® 048, 060, 071, 115
