- Page 1 Training Manual .6 − 50 Hz Compact Models MENUMASTER C O M M E R C I A L M I C R O W A V E O V E N HDC−5 _ 50 Hz R2 June 2007 www.amanacommercial.com...
-
Page 2: Model Number List
Model Number List DEC11E..(P1325203M) MCHDC521 ..(P1331246M) (P1330512M) (P1331225M) DEC11E2..(P1331213M) UC11E ....(P1325204M) (P1331235M) (P1330513M) DEC14E..(P1325207M) UC11E2 ..(P1331214M) (P1330516M) (P1331236M) DEC14E2..(P1331217M) UC14E ....(P1325208M) (P1331239M) (P1330517M) DEC18E..(P1325211M) UC14E2 ..(P1331214M) (P1330520M) (P1331240M) DEC18E2..(P1331221M) UC18E ....(P1325212M) (P1331243M) (P1330517M) HDC511 ..(P1325201M) UC18E2 ..(P1331222M) (P1330510M) (P1331244M) HDC511A ..(P1325213M) UHDC511 ..(P1325202M) (P1330511M) HDC5112 ..(P1331211M) -
Page 3: Table Of Contents
Table of Contents Model Number List .......................2 Table of Contents .........................3 Specifications ........................4 Quick Start Reference Guide....................5 Inner Door/Window Removal....................7 Technical Bulletin CR-236-B - Broken Tray................8 Air Flow ..........................9 Improved Filter for .6 Compact Ovens................10 Interlock Switches......................11 Switch Replacement / Door Adjustment................12 Touch Panel and Control Board..................13 Disassembly .......................14 –... -
Page 4: Specifications
CAUTION All safety information must be followed as provided in Service Manual RS5320013. W ARNING To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Models HDC511* HDC514* HDC518* HDC511A... -
Page 7: Inner Door/Window Removal
Inner Door/Window Removal 1. Open oven door. 2. Remove screws on hinge side. 3. Beginning at the bottom, carefully insert 1” putty knife between inner and outer door. Pry up on inner door to release tabs, (2 tabs per side). Work in a clockwise direction to release all tabs, see illustration below. -
Page 8: Technical Bulletin Cr-236-B - Broken Tray
Bulletin July 31, 2001 Date √ Comm. Microwave Dehumidifier Dishwasher √ Export Comm. Domm. Microwave Heating Product CR−236−B Laundry Product PTAC Products Range Product EXCMW-125-B Refrigerator/Fzr Room Air Cond. Page 1 of 1 Parts Manual Update Type Policy Letter √ Service Information Service Managers Attention √... -
Page 9: Air Flow
Air Flow Air filter must be in place and cleaned regularly. On two tube ovens: To ensure proper spacing and air flow, air ducts must be in place if oven is installed in a closed back installation. -
Page 10: Improved Filter For .6 Compact Ovens
Improved Filter for .6 Compact Ovens New improved filter kit 12002550, is now available from Maytag Services and in production ovens beginning December 2003. The new filter is more durable, easier to remove, clean, and reinstall. New filter kit part number 12002550 will replace old filter part numbers 12135801, 12135802, 12135803 and 12135804. -
Page 11: Interlock Switches
INTERLOCK SWITCHES R0150154 Early Production Switch R0000277 Replacement for Early Production Switch Primary Monitor Logic Primary Mounting screws Mounting Monitor screws Secondary Logic Secondary 12538901Q Later Production Switch Primary / Logic Monitor Mounting screws Secondary... -
Page 12: Switch Replacement / Door Adjustment
SWITCH REPLACEMENT / DOOR ADJUSTMENT WARNING To avoid risk of electrical shock, personal injury or death; disconnect electrical power before servicing. 1. Remove and retain two (2) screws securing 8. With door closed, loosen door hinge bolts 1/2 switch to cavity. Remove switch. turn. -
Page 13: Touch Panel And Control Board
TOUCH PANEL and CONTROL BOARD Error Codes Replace Board. Replace Board. Replace Board. Replace Board. Replace Touch Panel. Replace Board. -
Page 14: Disassembly
Disassembly To avoid the risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Component Location Screws Diode location single magnetron ovens Capacitor Diode location Touch panel 2 magnetron ovens @MF SET #13 @MF SET #13 @MF SET #13... - Page 15 Disassembly To avoid the risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Antenna Motor High Voltage Components Magnetrons Antenna assembly Antenna Motor Shaft Antenna assembly Snap Ring bottom Washer NOTE: Raised rib on edge of washer must face away from cavity.
- Page 16 Disassembly To avoid the risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Spill shield Cavity Control thermal board cutout Blower motor Snubber Triac Fuse Lamp and receptacle High Voltage Transformer Power cord Magnetron TCO...
-
Page 17: Component Specifications
Component Specifications WARNING To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Illustration Component Testing Results Thermal Cutout Disconnect all wires from TCO. Measure resistance across terminals. Cavity Thermal Fuse ........ - Page 18 Component Specifications WARNING To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Illustration Component Testing Results Transformer This transformer is equipped with a Discharge Capacitor Remove all wires from terminals, and 155°...
- Page 19 Component Specifications WARNING To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Illustration Component Testing Results Controller board Line voltage to control board P2 connector Pin 1—Pin 3........Line voltage (All Conditions) Output drive voltage to triac Triac terminals........
-
Page 20: Power Testing Procedure
To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor before servicing, unless testing requires power. All Amana and Menumaster microwave oven power outputs are rated using the IEC705 standards. Using the IEC705 test method requires precision measurements and equipment that is not practical to be performed in the field. -
Page 21: Isolation Test - Two Magnetron Models
Isolation Test – Two Magnetron Models WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires power. If the customer is complaining of low heat, it may be necessary to isolate the upper and lower high voltage systems. Method 1 1. -
Page 22: Wiring And Schematic Diagrams
Wiring and Schematic Diagrams To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires power. DANGER HIGH VOLTAGE Sample: Oven Schematic, One (1) Tube (Magnetron) - Page 23 Wiring and Schematic Diagrams To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Sample: Oven Wiring Diagram, One (1) Tube (Magnetron)
- Page 24 Wiring and Schematic Diagrams To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires power. DANGER HIGH VOLTAGE Sample: Oven Schematic, Two (2) Tube (Magnetron)
- Page 25 Wiring and Schematic Diagrams To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires power. Sample: Oven Wiring Diagram, Two (2) Tube (Magnetron)
