Sanyo VHR-690 Service Manual

FILE NO.
SERVICE MANUAL
Video Cassette Recorder
s *O
VHR-690
(New Zealand)
VHR-690
VHR-699
(Austraha)
VHR-796E
(U. K.)
~
f[l
o
'" -
0
lj
Ioa
m
~~m
ml ;
'@
CONTENTS
)
1
I
SELF-DIAGNOSIS DISPLAY .................................................... 2
1. DISASSEMBLY .................................................................... 5
2. ELECTRICAL ADJUSTMENT .............................................. 9
Please see other materials with Reference
3. TEST POINTS FOR TAPE PATH ADJUSTMENT .............15
number given in table below.
4. PARTS LIST
-
MECHANISM PARTS ......................................................... 16
CABINET & CHASSIS PARTS ........................................... 19
ELECTRICAL PARTS ........................................................ 20
ACCESSORIES .................................................................. 30
PACKING MATERIALS ...................................................... 30
CIRCUIT DIAGRAMS (Refer to the separate volume)
Materials
I Model No. / Reference No. ]
rpROD"cTsAFE
The components designated by a symbol (~) in this schematic diagram designates components whose value are of special
significance to product safety. Should any component designated by a symbol need to be replaced, use only the part designated
in the parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
NOTE: 1. Parts order must contain model number, part number, and description.
2, Substitute parts maybe supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
PK4HN/NZ, A2, A, E6 14316317,16, 15,26
REFERENCE No.SM531 545
