Sentry Xpress 5.0
Digital Temperature Controller
Cone-Fire and Ramp-Hold Instructions
°F
°C
°C Display Dot
Temperature Display
No Display Dot: Tempera-
ture display is in °F.
Right-Hand Display Dot:
Temperature display is in °C.
See page 19 for instructions
on selecting °F and °C.
Time Display
Center Display Dot:
Separates hours from min-
utes. Example: Display
shown above is 1 hour
and 30 minutes.
To stop a firing, press
Start/Stop key at any
time. ABRT will appear,
and the heating ele-
ments will turn off. Press
Start/Stop again to re-
turn to IDLE.
IM-222/3-19
Start/Stop Key
1) On/Off: Starts and stops a firing.
2) Enter Data: Press after each pro-
gramming step. It works like the Enter
key on a computer.
Up Arrow Key
1) Raise Numbers
2) Select a Firing Mode: From
[IDLE]
press Start/Stop. Press Up
Arrow to select Cone-Fire or
Ramp-Hold.
3) Edit a Program While the Kiln
is Firing p16:
[ SKIP ] Skip a segment
[HLDT ] Change hold time
[CHGT] Change end temperature
4) All Other Options:
[ DELA] Select how Delay works.17
[ TC ] Select thermocouple type.
p18
[ALAR ] Set temperature alarm. p18
[DIAG ] Check amps. p19
[ F/C ] Select °F or °C display p19
[ LIM ] Set max temperature. p19
[COST] Look up cost of a firing. 19
[ EXIT ] Press Start/Stop to return
to IDLE.
[OPT2 ] Press Start/Stop to see
level 2 options.
[OFST ] Adj. cone temperature. p16
[TCOS] Adjust thermocouple. p20
[TEDE ] Change sensitivity of
the FTH, FTC and LTDE warning
alarms. p20
[HTDE ] Change sensitivity of the
HTDE shut down alarm. p21
[LOCK] Lock programs. p21
[AOP1 ] For kilns with the optional
AOP switch box electrical outlet.p22
[ELEC ] Check circuit board tem-
perature, useful in hot weather. p22
[ EXIT ] Press Start/Stop to return
to IDLE.
[OPT3 ] Press Start/Stop to see
level 3 options.
[COOL] Select Slow Cooling so it
appears during Cone-Fire program-
ming. p17
[RATE ] Select your preferred type
of rate. p22
[CENT ] Enter cost of electricity. 23
[ KW ] Enter kiln's wattage. p23
[SFTY ] See kiln's max tempera-
ture. p24
[SOFT ] See software version. p24
[ CFG ] Shows controller model.24
[ RST ] Reset the controller to its
factory default settings. p24
Indicator
Lights
Top: Light is on dur-
ing programming.
Middle: Light is on dur-
ing program review.
Bottom: Light turns on
only when the elements
are on during a firing.
Down Arrow Key
1) Lower Numbers
2) Repeat the Last Fir-
[IDLE]
ing: From
press
Down Arrow. The pro-
gram you have selected
will appear one step at a
time. When
[STRT]
ap-
pears, press Start/Stop.
Page 5
4) Review a Program:
During firing, press Down
Arrow. The program you
entered will appear one
step at a time. Page 5
Quick Cone-Fire
programming . . .
page 10
Ramp-Hold
programming for
the power user . . .
page 13
Error messages . . .
pages 25 - 27
Confused about
display messages?
. . . pages 28 - 29
