Designed, Manufactured and Supported in the USA
VIKING
C O M M U N I C A T I O N & S E C U R I T Y S O L U T I O N S
Boost Talk Battery and Current to
The TBB-1B will boost talk battery
voltage up to 48VDC, and current up
to 26mA on single analog line
extensions behind PABX's and
electronic key systems. This is
helpful for powering line powered
devices such as touch tone dialers
and emergency phones on low
voltage and/or low loop current
extensions.
When the TBB-1B is being used,
the power LED lights extra bright to
Features
• Boost talk battery voltage up to 48VDC
• Boost talk battery loop current up to
26mA
• Power LED also displays activity
• Passes original ringing through to the
device
• Passes caller ID data
• Passes hook switch flash
• Passes CPC signals
• Power adapter included
• Compatible with touch tone dialing
Note: Not compatible with pulse/rotary
dialing.
www.vikingelectronics.com
Information: (715) 386-8861
PRODUCT MANUAL
Line Powered Devices
show activity. The TBB-1B is not
compatible with Pulse/Rotary dialing.
Applications
• Run line powered devices such as handsfree
phones, touch tone hot-line dialers, digital
announcers, etc.
• Increase maximum loop length on analog
PABX/KSU stations
• Use with wireless doorbox devices
• Increase phone line voltage / current for alarm
panels
Specifications
Power:
120VAC/12V DC 500mA, UL listed
adapter provided
Dimensions: 3.0" x 4.4" x 1.4" (76mm x 112mm
x 36mm)
Shipping Weight: 1.5 lbs (0.68 kg)
Environmental: 32° F to 90° F (0° C to 32° C)
with 5% to 95% non-condensing humidity
Loop Current to Device: 26mA (nominal)
Talk Battery Output: 48V DC (nominal)
Connections: (4) screw terminals
TBB-1B
Talk Battery
Booster
January 3, 2017
Advertisement
Related Manuals for Viking TBB-1B
Summary of Contents for Viking TBB-1B
- Page 1 C O M M U N I C A T I O N & S E C U R I T Y S O L U T I O N S Boost Talk Battery and Current to Line Powered Devices The TBB-1B will boost talk battery voltage up to 48VDC, and current up to 26mA on single analog line extensions behind PABX’s and...
- Page 2 The TBB-1B is designed to boost talk battery voltage and loop current of a single analog line. The TBB-1B achieves this by creating its own 48VDC talk battery supply that is set up as a 26mA current source. An analog phone line can be in three different states: the idle state, the ringing state, and the in-use state.
- Page 3 Low idle voltage from a VoIP ATA, cable company or telco provided phone lines can cause some alarm panels to go into an alarm state. Solve this problem by wiring a TBB-1B as shown below. A TBB-1B increases the idle voltage, converting 24 volt lines to 48 volt lines.
- Page 4 TWO YEAR LIMITED WARRANTY Viking warrants its products to be free from defects in the workmanship or materials, under normal use and service, for a period of two years from the date of purchase from any authorized Viking distributor. If at any time during the warranty period, the product is deemed defective or malfunctions, return the product to Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI., 54016.
