Summary of Contents for Braun Exact Power EP 100
- Page 1 Service Documentation Market Release 10/99 Braun exact power EP 100, 80, 60 5601 5601...
- Page 2 Service Documentation BINC Rev: 9/99 Exploded Drawing 5601 BAG Rev: 9/99 5601 - 2...
- Page 3 Service Documentation BINC Rev: 9/99 Spare Parts List 5601 BAG Rev: 9/99 Pos. No. Part Description Part Number Comb attachment 5601621 Cutter set 5601622 Small parts set 5601623 Swivel frame 5601632 Housing front part (silver) 5601633 Motor 5601624 PCB (1 hr) 5601625 Housing back part 5601634...
-
Page 4: Service Documentation
Service Documentation BINC Rev: 9/99 Service Information 5601 BAG Rev: 9/99 Technical Data Principle Rechargeable / cord shaver Nominal voltage 120 VAC Nominal frequency 50 - 60 Hz Housing Plastic material Cutting system Switchable double cutting system (21 resp. 33 mm width) Switch function Central sliding switch with integrated "speed"-shifting and button for lock function... - Page 5 Service Documentation BINC Rev: 9/99 Service Information 5601 BAG Rev: 9/99 Dismantling Comb attachment (1) Set sliding switch in "0" position. Pull off comb attachment by snap action. Cutter set (2) To be snapped out by pressing buttons "A". Swivel frame (4) Insert a small Torx screwdriver into the hole of the springs (3a) and snap them out by pushing towards the inside of the frame.
- Page 6 Service Documentation BINC: 9/99 Service Information 5601 BAG: 9/99 Reassembly The reassembly is done in reversed order. Please pay attention to the following points: Motor (6) Insert the motor (6) into the housing front part (5) in such a way that the indentations for the swivel head snaps on the left side of the cover point towards the memory slider.
-
Page 7: Service Information
Service Documentation BINC: 9/99 Service Information 5601 BAG: 9/99 Hint To facilitate the reassembly of the springs (3a), and nail (head dia. 4 mm) can be clamped in a vice, the device being supported with the pin head (see diagram). Cutter set (2) Press buttons "A"...
