Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station. FOR CUSTOMERS IN EUROPE...
Page 3
Sony office or visit Sony Europe’s web site for business customers: http://www.sonybiz.net/environment Disposal of waste batteries (applicable in the European Union and other European countries with separate collection systems) This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste.
For customers in the U.S.A. If you have any questions about this product, you may call: Sony Customer Information Center 1-800-686 SONY (7669). The number below is for the FCC related matters only. Regulatory Information Declaration of Conformity Trade Name: SONY Model No.: HVR-HD1000P...
Page 5
Dieses Produkt wurde geprüft und erfüllt die EMV-Richtlinie, sofern Verbindungskabel mit einer Länge von weniger als 3 Metern verwendet werden. Hinweis Wenn eine Datenübertragung aufgrund statischer oder elektromagnetischer Störeinflüsse abbricht (fehlschlägt), starten Sie die entsprechende Anwendung neu, oder entfernen Sie das USB- Kabel, und schließen Sie es wieder an.
Page 6
Read this first (Continued) Entsorgung von gebrauchten Batterien und Akkus (anzuwenden in den Ländern der Europäischen Union und anderen europäischen Ländern mit einem separaten Sammelsystem für diese Produkte) Das Symbol auf der Batterie/dem Akku oder der Verpackung weist darauf hin, dass diese nicht als normaler Haushaltsabfall zu behandeln sind.
Page 7
Este producto se ha probado y cumple con la normativa que establece la Directiva EMC si se utiliza un cable de conexión de menos de 3 metros de longitud. Aviso Si la electricidad estática o el electromagnetismo interrumpen la transmisión de datos (fallo), reinicie la aplicación o desconecte el cable de comunicación (USB, etc.) y vuelva a conectarlo.
Page 8
Read this first (Continued) Tratamiento de las baterías al final de su vida útil (aplicable en la Unión Europea y en países europeos con sistemas de recogida selectiva de residuos) Este símbolo en la batería o en el embalaje indica que la batería proporcionada con este producto no puede ser tratada como un residuo doméstico normal.
Page 9
Cet appareil a été testé et jugé conforme aux limites établies par la directive EMC visant l’utilisation de câbles de connexion de moins de 3 mètres. Avis Si l’électricité statique ou les champs électrostatiques entraînent une interruption lors du transfert des données (échec), redémarrez l’application ou débranchez, puis rebranchez le câble de connexion (USB, etc.).
Page 10
Read this first (Continued) ménagers. En vous assurant que ces piles et accumulateurs sont mis au rebut de façon appropriée, vous participez activement à la prévention des conséquences négatives que leur mauvais traitement pourrait provoquer sur l’environnement et sur la santé humaine. Le recyclage des matériaux contribue par ailleurs à...
Page 11
Trattamento delle pile esauste (applicabile in tutti i paesi dell’Unione Europea e in altri paesi Europei con sistema di raccolta differenziata) Questo simbolo sul prodotto o sulla confezione indica che la pila non deve essere considerata un normale rifiuto domestico. Assicurandovi che le pile siano smaltite correttamente, contribuirete a prevenire potenziali conseguenze negative per l’ambiente e per la...
Be sure to insert the “Memory Stick Duo” into the Memory Stick Duo Adaptor. Memory Stick Duo Adaptor Using the camcorder • Do not hold the camcorder by the following parts. (“Memory Stick (“Memory Stick Lens hood panel EVF block...
Page 13
• The camcorder is not dustproof, dripproof or waterproof. See “On using your camcorder” (p. 100). • When connecting your camcorder to another device with communication cables, be sure to insert the connector plug in the correct way. Pushing the plug...
Page 14
About the Carl Zeiss lens Your camcorder is equipped with a Carl Zeiss lens, which was developed jointly by Carl Zeiss, in Germany, and Sony Corporation, and produces superior images. It adopts the MTF measurement system for video cameras and offers a quality typical of a Carl Zeiss lens.
... 39 Using the Menu Using the menu items ... 42 Menu items ...43 CAMERA SET menu ...45 Settings to adjust your camcorder to the recording conditions MEMORY SET menu ...52 Settings for the “Memory Stick Duo” PICT.APPLI. menu ...55...
Page 16
Warning indicators and messages ... 91 Self-diagnosis display/Warning indicators ... 91 Additional Information Using your camcorder abroad ... 94 Maintenance and precautions ... 95 Usable cassette tapes ... 95 About the “Memory Stick” ... 96 About the “InfoLITHIUM” battery pack ... 98 About i.LINK ...
Using the CD-ROM Manual The supplied CD-ROM includes versions of the Operating Guide for the HVR- HD1000E/HD1000P series in English, French, German, Italian, Spanish, and Simplified Chinese in PDF format. Preparation The following program must be installed on your computer in order to read the Operating Guide contained on the CD- ROM.
To attach the lens cap to the grip belt Remove the grip belt and attach the lens cap by leading the grip belt through the attachment on the lens cap string. Then attach the grip belt to the camcorder again.
Step 2: Attaching the supplied microphone, eyecup and the lens hood Attaching the supplied microphone Attach the wind screen 1 to the microphone 2. Unlock the stopper of the microphone holder 3 and open the cover. Align the convex part of the microphone with the concave part of the holder, then place the microphone into the holder.
Page 20
Step 2: Attaching the supplied microphone and the lens hood (Continued) Attaching the lens hood Align the marks on the lens hood to those on the camcorder, and turn the lens hood in the direction of the arrow. To remove the Lens hood...
(L series) (p. 98) after attaching it to your camcorder. b Notes • You cannot attach any “InfoLITHIUM” battery pack other than the L series to your camcorder. Attach the battery pack to your camcorder. Attach the battery pack by sliding it in the direction of the arrow while pressing it until it clicks.
Page 22
Step 3: Charging the battery pack (Continued) To remove the battery pack Slide the POWER switch to OFF (CHG). Push the [BATT (battery) RELEASE] button and remove the battery pack. [BATT (battery) RELEASE] When storing the battery pack Fully discharge the battery before storing it for an extended period (p.
• Do not short-circuit the DC plug of the AC Adaptor or battery terminal with any metallic objects. This may cause a malfunction. • Even if your camcorder is turned off, AC power (house current) is still supplied to it while LCD panel...
You can set the desired date and time by touching (p. 42). b Notes • If you do not use your camcorder for about 3 z Tips • The date and time are not displayed while • If the buttons on the touch panel do not work...
Step 5: Making setting adjustments before recording The LCD panel Open the LCD panel (1), then rotate it to the best angle to record or play (2). 180 degrees (max.) 180 degrees (max.) To turn off the LCD screen Set the LCD ON/OFF switch to OFF. This helps to make the battery last longer.
Step 6: Inserting a tape or a “Memory Stick Duo” Cassette tape You can use mini DV (p. 95). b Notes • The recordable time varies depending on [ REC MODE] (p. 60). Slide and hold the EJECT lever in the direction of the arrow and open the lid.
Page 27
• When the access lamp is lit or flashing, your camcorder is reading/writing data. Do not shake or knock your camcorder, turn the power off, eject the “Memory Stick Duo,” or remove the battery pack. Otherwise, image data may be damaged.
Recording/Playback Recording START/STOP B Recording movies Movies are recorded on a tape. Remove the lens cap by pressing both knobs on its sides. Slide the POWER switch to TAPE while pressing the green button. Note on the LOCK switch When you slide the LOCK switch to the lock position (the POWER switch side), the POWER switch can no longer be set to MEMORY accidentally.
Page 29
To record high quality still images during tape recording (Dual Rec) See page 30 for details. Recording still images Still images are recorded on the “Memory Stick Duo.” Remove the lens cap by pressing both knobs on its sides. Slide the POWER switch to MEMORY while pressing the green button.
• You can not change the zoom speed of the zoom lever A on the handdle. • The minimum possible distance between camcorder and subject while maintaining sharp focus is about 1 cm (about 13/32 in.) for wide angle and about 80 cm (about 2 5/8 feet) for telephoto.
z Tips • During the standby mode, still images will be stored in the same way as when the POWER switch is set to MEMORY. • When the POWER switch is set to TAPE, still images will be recorded at image size 4.6M in the HDV format, 3.4M (4:3) or 4.6M (16:9) in the DV format.
BACK LIGHT again. Recording in mirror mode Open the LCD panel 90 degrees to the camcorder (1), then rotate it 180 degrees to the lens side (2). z Tips • A mirror-image of the subject appears on the LCD screen, but the picture will be normal when recorded.
Playback Slide the POWER switch to PLAY/EDIT while pressing the green button. Playing movies Touch to rewind to the desired scene, then touch to start playback. Toggles Play or Pause as you touch* 60min 60min P-MENU Rewind/Fast forward Stop** * Playback automatically stops if pause is engaged for more than 3 minutes. is displayed instead of when a “Memory Stick Duo”...
Playback (Continued) Viewing still images Touch The most recently recorded image is displayed. Switches the playback media* is displayed on the tape playback screen. To display pictures on a “Memory Stick Duo” on the Index screen Touch . Touch one of the pictures to back to the single display mode. A Previous/Next 6 pictures B The picture displayed before switching to the index screen To view pictures in other folders, touch...
Using PB zoom You can magnify images from about 1.1 to 5 times (from about 1.5 to 5 times in still images) the original size. Magnification can be adjusted with the power zoom lever. 1 Play back the picture you want to magnify.
Make sure that the POWER switch is set to TAPE. Touch 0:00:00 CANCEL 60min STBY 0:00:00 The last 2 seconds (approx.) of the most recently recorded scene are played back. Then, your camcorder is set to standby.
Refer also to the instruction manuals supplied with the device to be connected. b Notes • Make all menu settings on your camcorder before connecting. The TV may not recognize the video signal properly if the [VCR HDV/DV] or [i.LINK CONV] setting is changed after the TV and your camcorder were connected with an i.LINK cable.
Playing the picture on a TV (Continued) Connecting to a high definition TV Type Camcorder Component video cable (optional) A/V connecting cable (supplied) • An A/V connecting cable is also needed to output audio signals. Connect the white and red plugs of the A/ V connecting cable to the audio input jack of your TV.
• If your TV is not compatible with HDV1080i specification, connect your camcorder and TV with the optional component video cable and supplied A/V connecting cable as illustrated in • The TV needs to be set so that it recognizes that the camcorder is connected. See the instruction manuals supplied with your TV.
Page 40
TV. i.LINK cable (optional) • The TV needs to be set so that it recognizes that the camcorder is connected. See the instruction manuals supplied with your TV. : Signal flow, ( ): Reference pages...
Page 41
• If you connect your camcorder to your TV using more than one type of cable to output images from a jack other than the i.LINK jack, the order...
Using the Menu Using the menu items Slide the POWER switch to the desired position while pressing the green button. TAPE: settings on a tape MEMORY: settings on a “Memory Stick Duo” PLAY/EDIT: settings for viewing/editing Touch the LCD screen to select the menu item. Unavailable items will be grayed out.
Menu items Available menu items (z) vary depending on the position of the switch. CAMERA SET menu SCENE SELECT SPOT METER EXPOSURE WHITE BAL. SHARPNESS SHUTTR SPEED AUTOSLW SHTR AE SHIFT CAMERA COLOR WB SHIFT SPOT FOCUS FOCUS TELE MACRO SUPER NS NS LIGHT COLOR SLOW S...
Page 44
Menu items (Continued) USB SELECT EDIT/PLAY menu VAR.SPD PB REC CTRL END SEARCH STANDARD SET menu VCR HDV/DV REC FORMAT DV SET VOLUME MIC LEVEL AU.LVL DISP LCD/VF SET COMPONENT DOWN CONVERT STATUS CHECK GUIDEFRAME COLOR BAR DATA CODE REMAINING REC LAMP BEEP DISP OUTPUT...
CAMERA SET menu Settings to adjust your camcorder to the recording conditions The default settings are marked with B. The indicators in parentheses appear when the items are selected. See page 42 for details on selecting menu items. SCENE SELECT...
Page 46
CAMERA SET menu (Continued) b Notes • If you set [SCENE SELECT], the settings of [SHUTTR SPEED] and [WHITE BAL.] are canceled. SPOT METER (Flexible spot meter) You can adjust and fix the exposure to the subject, so that it is recorded in suitable brightness even when there is strong contrast between the subject and the background, such as subjects in the...
Page 47
• If you have changed the battery pack while [AUTO] was selected, or taken your camcorder outdoors after inside use (or vice versa), select [AUTO] and aim your camcorder at a nearby white object for about 10 seconds for better color balance adjustment.
Page 48
To adjust the focus automatically, touch [AUTO] t b Notes • The minimum possible distance between camcorder and subject while maintaining sharp focus is about 1 cm (about 13/32 in.) for wide angle and about 80 cm (about 2 5/8 feet) for telephoto.
Page 49
• Remove the conversion lens (optional). • Adjust the focus manually ([FOCUS], p. 48) when it is hard to focus automatically. • The shutter speed of your camcorder changes depending on the brightness. The motion of the picture may slow down in this case.
Page 50
CAMERA SET menu (Continued) ZEBRA Diagonal stripes appear in portions of the screen where brightness is at a preset level. This is useful as a guide when adjusting the brightness. When you change the default setting, is displayed. The zebra pattern is not recorded.
Page 51
CONV.LENS When using an optional conversion lens, use this function to record using the optimum compensation for camera shake for each lens. B OFF Select this when the conversion lens (optional) is not used. WIDE CONV. ( Select this to use the wide conversion lens (optional).
MEMORY SET menu Settings for the “Memory Stick Duo” The default settings are marked with B. The indicators in parentheses appear when the items are selected. See page 42 for details on selecting menu items. STILL SET QUALITY B FINE ( Records still images at the fine image quality level.
Page 53
Sony Corporation. The number of pictures you can record varies depending on the recording environment and the recording media. • The unique pixel array of Sony’s ClearVid CMOS sensor and image processing system (new Enhanced Imaging Processor) allows for still image resolution equivalent to the sizes described.
Page 54
Touch [YES] t b Notes • You cannot delete the created folders using your camcorder. You will have to format the “Memory Stick Duo” (p. 53), or delete them using your computer. • The number of recordable pictures on a “Memory Stick Duo”...
PICT.APPLI. menu Special effects on pictures or additional functions on recording/playback The default settings are marked with B. The indicators in parentheses appear when the items are selected. See page 42 for details on selecting menu items. FADER You can record a transition with the following effects adding to the interval between scenes.
Page 56
PICT.APPLI. menu (Continued) z Tips • You can select the first picture for the slide show with [START]. D.EFFECT (Digital effect) You can add digital effects to recording/ playback. 1 Touch the desired effect. 2 Adjust the effect with touch Effect Items to adjust CINEMA...
Page 57
PICT.EFFECT (Picture effect) You can add special effects to a picture during recording or playback. B OFF Does not use [PICT.EFFECT] setting. SKINTONE* Makes skin texture look more smoother and more appealing. NEG.ART The color and brightness are reversed. SEPIA Pictures appear in sepia.
[END]. PictBridge PRINT See page 75. USB SELECT You can connect the camcorder to a personal computer with a USB cable and import pictures to the computer. You can also connect the camcorder to a PictBridge compatible printer (p. 75) using this function.
VCR HDV/DV Select the playback signal. Normally select [AUTO]. When your camcorder is connected to another device using an i.LINK cable, select the signal to input/output from the HDV/DV Interface (i.LINK). The selected signal is recorded or played back.
Page 60
STANDARD SET menu (Continued) able to recognize the video signal from your camcorder. • When [AUTO] is selected, if the signal switches between HDV and DV formats, the picture and sound are interrupted temporarily. • When [i.LINK CONV] is set to...
Page 61
B NORMAL Standard brightness. BRIGHT Brightens the LCD screen. b Notes • When you connect your camcorder to outside power sources, [BRIGHT] is automatically selected for the setting. • When you select [BRIGHT], battery life is slightly reduced during recording.
Page 62
Display pictures in the viewfinder in color. Display pictures in the viewfinder in black and white. b Notes • When you connect your camcorder to outside power sources, [BRIGHT] is automatically selected for the setting. • When you select [BRIGHT], battery life is slightly reduced during recording.
Page 63
– [VIDEO OUT] (p. 62) – HDMI OUT (p. 107) HOURS METER The cumulative operation time of your camcorder will be displayed with the total hours of operation, drum rotation, tape running, or the total number of tape unthreading operations.
Page 64
STANDARD SET menu (Continued) DATA CODE During playback, displays the information (data code) recorded automatically at the time of recording. B OFF Data code is not displayed. DATE/TIME Displays the date and time. CAMERA DATA (below) Displays camera setting data. 60min F1.
ON ( Slightly reduces the time it takes to start recording when you attempt to record right after you switch on the camcorder (set the POWER switch to TAPE from the OFF (CHG) position), or when you attempt to record when the recording stanby mode is canceled.
Customizing Personal Menu You can add desired menu items to any Personal Menu, and customize Personal Menu settings for each POWER switch position. This is convenient if you add frequently used menu items to Personal Menu. Adding a menu item You can add up to 28 menu items for each POWER switch position.
Page 67
Arranging the order of menu items displayed on Personal Menu t [P-MENU SET UP] Touch t [SORT]. If the desired menu item is not displayed, touch Touch the menu item you want to move. Touch to move the menu item to the desired place. Touch To sort more items, repeat steps 2 to 4.
** When connecting your camcorder to a monaural device, connect the yellow plug of the A/V connecting cable to the video jack on the device, and the white (left channel) or red (right channel) plug to the audio jack on the device.
Page 69
• When the player and the recorder are both HDV1080i compatible devices such as HVR-HD1000E/HD1000P and are connected with the i.LINK cable, after pausing or stopping and then resuming the recording, the images will be unstable or rough at that point.
• Note the following when connecting with an i.LINK cable: – The recorded picture becomes rough when a picture is paused on your camcorder while recording to a VCR or DVD/HDD recorder. – Data codes (date/time/camera settings data) may not be displayed or recorded depending on the device or application.
“Memory Stick Duo.” Be sure to insert a cassette or a “Memory Stick Duo” for recording in your camcorder beforehand. You can connect your camcorder to a VCR device using an i.LINK cable. Connect your camcorder to the wall outlet (wall socket) using the supplied AC Adaptor for this operation (p.
Page 72
• When a 4:3 video signal is input, it appears with black bands on the right and left sides on the screen of your camcorder. (Continued) Recording still images Perform steps 1 to 4 in “Recording movies”.
• The date and time the picture is recorded on the tape and stored on the “Memory Stick Duo” are recorded. On your camcorder, the date and time the picture is recorded on the tape are displayed. Camera setting data recorded on the tape cannot be stored on the “Memory Stick Duo.”...
• To cancel Print mark, touch the image again to cancel Print mark in step 3. • Do not mark images on your camcorder if the “Memory Stick Duo” already has some images with the Print mark put on using other devices.
You can print out pictures using a PictBridge compliant printer without connecting the camcorder to a computer. Connect your camcorder to the AC Adaptor to obtain power from the wall outlet (wall socket) (p. 21). Insert the “Memory Stick Duo” containing still images into your camcorder and turn on the printer.
Printing recorded images (PictBridge compliant printer) (Continued) – Disconnect the USB cable from the printer. – Remove the “Memory Stick Duo” from your camcorder. • If the printer stops working, disconnect the USB cable, turn the printer off and on again and restart the operation from the beginning.
Notes on connecting to a computer • When you are using a USB cable or an i.LINK cable to connect your camcorder to a computer, make sure to connect the connector in the correct direction. If you insert the connector forcibly, it may be damaged, and cause a malfunction of your camcorder.
Page 78
Copying still images to a computer (Continued) To USB jack • Do not connect your camcorder to the computer at this point. • The computer may not recognize the camcorder if you connect them with the USB cable before turning on your camcorder.
Page 79
A Folder containing image files recorded by other camcorders without the folder creation function (for playback only). B Folder containing image files recorded by your camcorder when no new folders have been created, only [101MSDCF] is displayed. C Folder containing movie data recorded...
Observe the following points when connecting to ensure the camcorder operates correctly. • Connect the camcorder to a computer via the USB cable. Make sure no other USB devices are connected to the computer. • If your computer has a USB keyboard and a...
Page 81
(p. 21). 1 Prepare editing software (not provided). 2 Turn on your computer. 3 Insert a tape into your camcorder and set the POWER switch to PLAY/EDIT. 4 Set the menu of your camcorder. The menu settings vary depending on the copying image.
Page 82
MPEG2. When copying the movie in the HDV format from the computer to your camcorder Set [VCR HDV/DV] to [HDV] and [i.LINK CONV] to [OFF] (p. 59). b Notes • To copy an HDV format movie edited on a...
• Attach the battery pack to the camcorder correctly (p. 21). If the problem persists, disconnect the AC Adaptor from the wall outlet (wall socket) and contact your Sony dealer. The battery pack may be damaged. The remaining battery time indicator does not indicate the correct time.
The Cassette Memory indicator or title display does not appear while using a cassette with Cassette Memory. • This camcorder does not support Cassette Memory, so the indicator does not appear. The remaining tape indicator is not displayed. • Set [ display the remaining tape indicator (p.
(p. 95). • The tape is stuck to the drum due to moisture condensation. Remove the cassette and leave your camcorder for at least 1 hour, then reinsert the cassette (p. 101). You cannot record on the “Memory Stick Duo.”...
Troubleshooting (Continued) • There is a blank section between recorded sections of the tape. This is not a malfunction. [COLOR SLOW S] does not operate correctly. • [COLOR SLOW S] may not operate correctly in total darkness. Use NightShot or [SUPER NS]. You cannot use [SUPER NS].
• This occurs if the tape or video head is dirty (p. 101). • Use the Sony mini DV cassette. “---” is displayed on the screen. • The tape you are playing was recorded without setting the date and time.
HDMI OUT jack, if copyright protection signals are recorded in the pictures. • DV format pictures input to the camcorder via i.LINK cable (p. 71) cannot be output. • This occurs if you record on a tape in both HDV and DV formats.
HDMI cable. • You cannot dub pictures using the HDMI cable. New sound added to a recorded tape on another camcorder is not heard. • Adjust [ AUDIO MIX] from the [ST1] (original sound) side until the sound is heard appropriately (p. 60).
Page 90
Troubleshooting (Continued) Not available If this function is set [CINEMA EFECT] [SCENE SELECT], of [D.EFFECT] [SPOT METER], [MANUAL] of [EXPOSURE], other than 0 in [AE SHIFT], [PICT.EFFECT], when [ SELECT] is set to [4:3] [SMTH SLW REC] [CANDLE], [FIREWORKS], [MANUAL] of [SHUTTR SPEED] , [SUPER NS], [COLOR SLOW S],...
If indicators appear on the LCD screen or in the viewfinder, check the following. Some symptoms you can fix by yourself. If the problem persists even after you have tried a couple of times, contact your Sony dealer or local authorized Sony service facility. C:(or E:) ss:ss (Self-diagnosis...
• The write-protect tab on the “Memory Stick Duo” is set to lock (p. 96). (Warning indicator pertaining to camera-shake warning) • The camcorder is unsteady, so camera- shake easily occurs. Hold the camcorder steady with both hands and shoot the image. However, note that the camera-shake warning indicator does not disappear.
Memory Stick folders are full. • You cannot create folders exceeding 999MSDCF. You cannot delete created folders using your camcorder. • You will have to format the “Memory Stick Duo” (p. 53), or delete them using your computer. x Dual Rec Cannot save still picture.
Additional Information Using your camcorder abroad Power supply You can use your camcorder in any country/region using the AC Adaptor supplied with your camcorder within the AC 100 V to 240 V, 50/60 Hz range. Use a commercially available AC plug adaptor [a], if necessary, depending on the design of the wall outlet [b].
Maintenance and precautions Usable cassette tapes Your camcorder is capable of recording in both HDV and DV formats. You can use mini DV format cassettes only. Use a cassette with the Your camcorder is not compatible with the Cassette Memory function.
“Memory Stick PRO Duo” Do not put a label “Memory Stick PRO-HG Duo” along this border. * This camcorder does not support 8-bit parallel data transfer, but supports 4-bit parallel data transfer as is the case with “Memory Stick PRO Duo”.
Page 97
“Design rule for Camera File system” universal standard established by the JEITA (Japan Electronics and Information Technology Industries Association). • On your camcorder, you cannot play back still images recorded on other devices (DCR- TRV900E or DSC-D700/D770) that do not conform to the universal standard. (These models are not sold in some regions.)
Interfaces, refer to the operating instructions of the device to be connected. z Tips • i.LINK is a more familiar term for the IEEE1394 data transport bus proposed by Sony, and is a trademark approved by many corporations. • IEEE1394 is an international standard standardized by the Institute of Electrical and Electronics Engineers.
(during HDV/DV dubbing). About x.v.Color • x.v.Color is a more familiar term for the xvYCC standard proposed by Sony, and is a trademark of Sony. • xvYCC is an international standard for color space in video. This standard can express a wider color range than the currently used broadcast standard.
Page 101
Such a freezing point cannot be recovered if it was created while recording. To prevent such a problem, use the Sony mini DV cassette. • If the following problem occurs, clean the video heads for 10 seconds with the cleaning cassette.
Page 102
(optional), it might be because the video heads are worn out. Please contact your Sony dealer or local authorized Sony service facility to have the video heads replaced. LCD screen • Do not exert excessive pressure on the LCD screen, as it may cause damage.
Page 103
Adaptor or while the battery pack is inserted. The rechargeable battery will be fully discharged in about 3 months if you do not use your camcorder at all without the AC Adaptor connected or the battery pack attached. Use your camcorder after charging the pre-installed rechargeable battery.
0 lx (lux) (during NightShot function) “Exif” is a file format for still images, established by the JEITA (Japan Electronics and Information Technology Industries Association). Files in this format can have additional information such as your camcorder’s setting information at the time of recording.
Page 105
The unique pixel array of Sony’s ClearVid CMOS sensor and image processing system (new Enhanced Imaging Processor) allows for still image resolution equivalent to the sizes described. Input/Output connectors VIDEO OUT jack Pin jack 1 Vp-p, 75 Ω (ohms) S VIDEO OUT jack 4pin mini DIN Luminance signal: 1 Vp-p, 75 Ω...
Page 106
Type Lithium ion Design and specifications are subject to change without notice. On trademarks • HDV and the HDV logo are trademarks of Sony Corporation and Victor Company of Japan, Ltd. • “Memory Stick,” “ Duo,” “ PRO Duo,” “...
Quick Reference Identifying parts and controls The numbers in ( ) are reference pages. A Cold shoe B HDV/DV Interface (i.LINK) (37, 69, LANC jack (blue) The LANC control jack is used for controlling the tape transport of video devices and peripherals connected to it. D i (Headphone) jack E REC START/STOP button (28) F Power zoom lever (30)
Page 108
