Controlant CO 13.01 Wireless Logger

Type

CO 13.01

Controlant provides this document "as is," without warranty of any kind, expressed or implied, including,

but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Controlant

may make improvements and/or changes in this manual or in the product(s) and/or the program(s)

described in this manual at any time.

This product could include technical inaccuracies or typographical errors. Changes are periodically made to

the information herein; these changes may be incorporated in new editions of the publication.

User's Guide

Description

Wireless temperature logger

Version 1.0

18/02/2015

Table of Contents

Summary of Contents for Controlant CO 13.01

Page 1 Controlant provides this document “as is,” without warranty of any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Controlant may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time.
Page 2: Table Of Contents
Warranty exception for batteries ........................3 Ratings ................................3 Additional reference material ........................3 Questions and Technical Support ........................3 Controlant Industrial Wireless Logger - CO 13.01 ..................... 4 Overview ................................ 4 Enclosure ............................... 4 Battery ................................4 LED behavior and turning the logger off ....................... 6 Specifications and Measurement Characteristics ..................
Page 3: General Information
This guide covers Controlant wireless logger CO 13.01. Warranty exception for batteries Controlant’s CO 13.01 logger ships with battery included. Battery must be replaced by qualified service personnel approved by Controlant. No warranty is on the behavior of Controlant’s equipment in case of wrong battery installation by non-qualified personnel or in case of usage of batteries which Controlant does not approve of.
Page 4: Controlant Industrial Wireless Logger - Co 13.01
Figure 1: Mechanical drawing of the CO 13.01 wireless logger Overview The CO 13.01 wireless logger has a built in ambient temperature sensor. The logger transmits it´s data to a local transceiver. The transceiver then transmits collected data to an on-line central database. The logger logs data into memory when not in the vicinity of a transceiver and automatically transmits all logged data ones it has established a connection with a transceiver.
Page 5 P a g e...
Page 6: Led Behavior And Turning The Logger Off
The LED and battery plug accessible once bottom plate is removed. The bottom plate should only be removed by qualified personnel approved by Controlant. Figure 2: Internal view of the CO 13.01 wireless logger A green led indicates whether or not the logger is operating normally.
Page 7: Specifications And Measurement Characteristics
Specifications and Measurement Characteristics Environment range The wireless logger’s working range is the following 1. Humidity a. 0-99% non-condensing humidity for normal operation. b. Long term exposure to high levels of humidity may cause fault in device. 2. Temperature a. Operating range: -35°C to 80°C b.
Page 8: Mounting And Connectors
The enclosure is designed to withstand splashing water from any direction. The CO 13.01 wireless logger can be mounted to a non-metal surface by using screws, bolts or straps as shown in the figure above. Care must be taken that screws or bolts are chosen correctly for the surface being mounted on.
Page 9: Antenna
Antenna The CO 13.01 logger has 1 antenna connector, shown in the image below. The antenna connector type is RP-SMA. Figure 4: Antenna connector on CO 13.01 wireless logger Wireless Connectivity Controlant wireless devices have up to 400m range in open air. The communication frequency channels are placed around 868MHz for Europe and 915 MHz in North America.
Page 10: Fcc Regulatory Notices
4) Consult the dealer or an experienced radio/TV technician for help. FCC Antenna Gain Restriction: The CO 13.01 has been designed to operate with Q868-X-Ap antenna, that has 3 dBi gain, and Q8019- 900LW antenna, that has 2.5 dBi gain, both antennas are supplied by Controlant or its resellers. Using antennas with larger gain is prohibited.
