Page 1: Ethernet Adapter
54 Mbps Wireless Ethernet Adapter Model #: HWE05490-01 Firmware version: 1.31 (Utility version: 1.3) User Manual ™ Solutions for the Digital Life... -
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents System Requirements Contacting Technical Support Getting to Know the 54 Mbps Wireless Ethernet Adapter Front Panel Rear Panel Understanding your Wireless Network What is Adhoc Mode? What is Infrastructure Mode? Installing the Actiontec 54 Mbps Wireless Ethernet Adapter Physical installation of the 54 Mbps Wireless Ethernet Adapter Connecting the Adapter to a network Configuring the Actiontec 54 Mbps Wireless Ethernet Adapter... -
Page 3: Introduction
Introduction Congratulations on becoming the owner of the Actiontec 54 Mbps Wireless Ethernet Adapter. Your Wireless Ethernet Adapterprovides bridging capabilities between your Wireless LAN (local area network) and one or more personal computers, gaming consoles, or other Ethernet-ready devices such as printers and storage devices. This User Guide will show you how to set up the Actiontec 54 Mbps Wireless Ethernet Adapter, customize its configuration to get the most out of your network. -
Page 4: System Requirements
System Requirements To use the Wireless Ethernet Adapter, you must have the following: PC with an open Ethernet port Microsoft Windows XP, ME, 2000, NT4.0, 98, 98SE; MAC OS 8 or higher TCP/IP network protocol installed Internet Explorer 4.0 or Netscape 4.0 or higher Contacting Technical Support Actiontec Electronics, Inc., prides itself on making durable, high-quality, high- performance products. -
Page 5: Getting To Know The 54 Mbps Wireless Ethernet Adapter
Getting to Know the 54 Mbps Wireless Ethernet Adapter Front Panel The front panel provides the user with a fast visual feedback of its current status. Figure 1. Front Panel and LEDs Power The Power light will turn green when the 54 Mbps Wireless Ethernet Adapter is powered on. -
Page 6: Rear Panel
Rear Panel The rear panel contains the ports for the unit's data and power connections. Figure 2. Back Panel and Ports Power Connects to the Power Cord. Reset Depress the Reset button to bring the 54Mbsp Wireless Ethernet Adapter to its factory default settings. Hold the button for 15 sec. Antenna The antenna connector allows you to connect to various anten- nae types. -
Page 7: Understanding Your Wireless Network
Understanding your Wireless Network Wireless local area networks (WLAN) perform the exact same functions as wired local area networks (LAN). Each computer in the WLAN uses a data radio device to connect to the network, where all computers in the network share the same frequen- cy and method for identifying wireless devices. -
Page 8: What Is Infrastructure Mode
What is Infrastructure Mode? Infrastructure mode is a networking framework by which devices communicate with each other by first going through an Access Point (AP). Infrastructure mode, lets wireless devices communicate with each other or with a wired network. Two possible types of service can exist while in Infrastructure mode: Basic Service Set (BSS) Basic Service Set is when an Access Point is connected to a wired network and a set of wireless stations. -
Page 9: Installing The Actiontec 54Mbps Wireless Ethernet Adapter
Installing the Actiontec 54 Mbps Wireless Ethernet Adapter This equipment is designed with utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electronic equipment. All guidelines of this manual and of the computer manufacturer must therefore be followed at all times to ensure the safe use of the equipment. -
Page 10: Connecting The Adapter To A Network
Connecting the Adapter to a network Now that your Actiontec 54 Mbps Wireless Ethernet Adapter has been installed, it is ready to be connected to the power outlet and to your wired network. 1. Get the Wireless Ethernet Adapter from your Quick Start Kit. Make sure that the external antenna is connected to the adapter. - Page 11 3. Plug the other end of the Yellow cable into the Ethernet port located on the back of the Computer or Game Console (like a Sony Playstation or Xbox). You will hear a “click” when the Yellow Cable has been properly connected. 4.
-
Page 12: Configuring The Actiontec 54Mbps Wireless Ethernet Adapter
Configuring the Actiontec 54Mbps Wireless Ethernet Adapter How to configure the Actiontec 54 Mbps Wireless Ethernet Adapter Configuring the Actiontec 54 Mbps Wireless Ethernet Adapter means adjusting the following settings: radio channels, security, and identification, etc. You only need to configure the Actiontec 54 Mbps Wireless Ethernet Adapter when you want to change these settings. - Page 13 3. When the following screen appears, click Next to continue. 4. When the following screen appears, click Finish to continue. 5. Once the Installation is complete, from the Windows Desktop click on the 54 Mbps Wireless Ethernet Adapter Configuration Icon. The 54 Mbps Wireless Ethernet Adapter Configuration Note: Utility allows the end user to identify the IP address of the 54...
- Page 14 6. The 54 Mbps Wireless Ethernet Adapter Configuration Utility will scan for any Wireless Ethernet Adapters and display their information. 7. If you wish to change the factory default values, click on any of the choices on the screen. Make sure you record the current settings prior to changing Note: the current configuration.
- Page 15 9. To change the Ethernet Settings, click on IP Settings, enter the appropriate values and click Apply. Make sure you record the current settings prior to changing Note: the current configuration. We recommend keeping the factory defaults if you are not sure 10.
-
Page 16: Starting The Web Interface
11. Once completed, and you Apply your changes, the following screen will appear. Enter the Username and Password to apply the changes. The default values are: Username: admin Password: admin The 54 Mbps Wireless Ethernet Adapter can be adjusted Note: manually by accessing it from any browser. - Page 17 3. When the following screen appears, begin configuring your 54 Mbps Wireless Ethernet Adapter. The Status screen provides information on all the current settings for the 54 Mbps Wireless Ethernet Adapter. 4. Click on Basic Setting to modify the Adapter’s wireless settings. Wireless Network Name (SSID): This is the name of the Ethernet Adapter on the wireless network.
- Page 18 Channel: This is the radio channel that the Ethernet Adapter will operate on, if you experience interference you may need to try different channels. (Available channels are separated by frequencies; channels 1-11 operate at 2.4GHz in the U.S.) Actiontec recommends that you use channel 9. WEP Key: WEP is the wireless encryption standard implemented in the Ethernet Adapter.
- Page 19 5. Click on IP Setting to modify the Ethernet Adapter’s TCP/IP settings. Here you can configure the IP address used by the Ethernet Adapter, you can specify whether you are using a Static IP or a DCHP address provided by a server in your network.
- Page 20 6. Click on Security to modify the 54 Mbps Wireless Ethernet Adapter’s Administrator ID and Password, when completed click Apply to continue. Administrator ID: This is the user name you must type to gain access to the Ethernet Adapter and make changes to these pages. The default Username is: admin AP Password New: This is the password you must type to gain access to the Ethernet Adapter and make changes to these pages.
- Page 21 Restore Settings: By clicking this option, you will restore the Ethernet Adapter’s settings from a file on your PC’s hard drive. Restore to Default Settings: By clicking this option, you will restore the Ethernet Adapter to it’s factory shipped settings. Firmware Upgrade: By clicking this option, you will carry out an Upgrade to the latest Firmware revisions for your 54 Mbps Wireless Ethernet Adapter.
- Page 22 To properly configure your Macintosh Computer for configuring the Actiontec 54 Mbps Wireless Ethernet Adapter, refer to the following procedures: 1. From the Desktop, click on the Apple Icon located at the upper left hand corner of the screen. Click on System Preferences to continue. 2.
- Page 23 3. When the Network preferences screen displays, make sure you have selected Built-in-Ethernet from the Show drop menu. Next, from the TCP/IP Tab, select Manually from the configure drop menu. Enter the appropriate IP Address, Subnet Mask, and Router (optional)name. When all the above criteria has been met, click on Apply Now and close the Network preferences window to continue.
- Page 24 3. When the following screen appears, begin configuring your 54 Mbps Wireless Ethernet Adapter. The Status screen provides information on all the current settings for the 54 Mbps Wireless Ethernet Adapter. 4. Click on Basic Setting to modify the Ethernet Adapter’s wireless set- tings.
- Page 25 Channel: This is the radio channel that the Ethernet Adapter will operate on, if you experience interference you may need to try different channels. (Available channels are separated by frequencies; channels 1-11 operate at 2.4GHz in the U.S.) Actiontec recommends using channel 9. WEP Key: WEP is the wireless encryption standard implemented in the Ethernet Adapter.
- Page 26 5. Click on IP Setting to modify the Ethernet Adapter’s TCP/IP settings. Here you can configure the IP address used by the Ethernet Adapter, you can specify whether you are using a Static IP or a DCHP address provided by a server in your network.
- Page 27 6. Click on Security to modify the Ethernet Adapter’s Administrator ID and Password. When completed click Apply to continue. Administrator ID: This is the user name you must type to gain access to the Ethernet Adapter and make changes to these pages. The default Username is: admin AP Password New: This is the password you must type to gain access to the Ethernet Adapter and make changes to these pages.
-
Page 28: Configuring The Adapter For Operating With A Game Console
Restore Settings: By clicking this option, you will restore the Ethernet Adapter’s settings from a file on your PC’s hard drive. Restore to Default Settings: By clicking this option, you will restore the Ethernet Adapter’s to its factory shipped settings. Firmware Upgrade: By clicking this option, you will carry out an Upgrade to the latest Firmware revisions for your 54 Mbps Wireless Ethernet Adapter. -
Page 29: Troubleshooting/Frequently Asked Questions
This section will help you solve potential problems with installation and opera- tion of the 54Mbps Wireless Ethernet Adapter. For further information, check the Actiontec Electronic Inc. website at www.actiontec.com. The 54 Mbps Wireless Ethernet Adapter can’t connect to an access point. - Page 30 The Configuration Utility won’t open. Make sure that you have a network adapter installed on the PC so you can use the Configuration Utility. The Configuration Utility will not recognize my password. The password is case-sensitive. Make sure you are using the correct case(s)when entering the password.
- Page 31 Can I use this 54 Mbps (802.11g) Wireless Ethernet Adapter to connect to the 802.11b Access Point? Yes, this Ethernet Adapter can connect to an 802.11b Access Point. Will cordless phones interfere with the wireless Ethernet Adapter? The 802.11g PC Cards use 2.4 GHz frequency. If your cordless phone uses this frequency, problems may occur.
-
Page 32: Glossary
Glossary 802.11b - A wireless networking products standard defined by the IEEE that calls for wireless product to talk to each other regardless of manufacturer. The 802.11b standard specifies a maximum data transfer rate of 11Mbps, operating in the ISM operating frequency of 2.4GHz, security must be WEP encryption as a minimum. - Page 33 Static IP Address - A permanent IP address that is assigned to a node in a network. Subnet Mask - The method used for separating IP networks into multiple subgroups, or subnets. The mask is a binary array that is paired with the IP address to turn part of the host ID address field into a field for subnets.
-
Page 34: Specifications
Specifications Software Specifications Actiontec 54 Mbps Wireless Ethernet Adapter User Manual... - Page 35 Physical Specifications Enclosure. Length: 3 3/4 inch Width: 3 1/4 inch Height: 1 1/4 inch Visual indicators. Power: ON/OFF Ready indicator; Solid Green = Power on Off = Power off WLAN: WLAN indicator light that indicates whether or not it has at least one session up.
-
Page 36: Notices
Notices Regulatory Compliance Notices Class B Equipment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 37 Note: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 38: Limited Warranty
Limited Warranty Hardware: Actiontec Electronics, Inc., warrants to the end user (“Customer”) that this hardware product will be free from defects in workmanship and materials, under normal use and service, for twelve (12) months from the date of purchasefrom Actiontec Electronics or its authorized reseller. Actiontec Electronics’... - Page 39 THIS ACTIONTEC ELECTRONICS PRODUCT MAY INCLUDE OR BE BUNDLED WITH THIRD-PARTY SOFTWARE, THE USE OF WHICH IS GOVERNED BY A SEPARATE END-USER LICENSE AGREEMENT. THIS ACTIONTEC ELECTRONICS WARRANTY DOES NOT APPLY TO SUCH THIRDPARTY SOFTWARE. FOR THE APPLICABLE WARRANTY, PLEASE REFER TO THE END-USER LICENSE AGREEMENT GOVERNING THE USE OF SUCH SOFTWARE.
- Page 40 ACTIONTEC ELECTRONICS NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. ACTIONTEC ELECTRONICS SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT OR MALFUNCTION IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED...
- Page 41 Governing Law: This Limited Warranty shall be governed by the laws of the State of California, U.S.A., excluding its conflicts of laws and principles, and excluding the United Nations Convention on Contracts for the International Sale of Goods. Limited Warranty...
