- Page 1 MX Series ™ Operating Instructions MX 8 • MX 10 • MX 12 • MX Stand • MAX Cut-Off ™ ™ ™ ™ ™...
- Page 2 Locking handle Assembly 11397 ¼ " x 1 ¼ " Faspin Kit (4) 14271 Lifting Handle Support Bracket (2) 14456 MX Series™ Brake Parts Bag 8' 11398 Locking Handle Plug Kit 14273 Moving Hinge Cap 14457 MX Series™ Brake Parts Bag 10'/12'...
- Page 3 S n a p S e r i e s S t a n d ™ ™ Setting up the MX Series Brake Locking bar Installation Locking Handle Faspin Handle Plug Locking Bar Hex Bolt MX Locking Bar Assembly includes:...
- Page 4 IMPORTANT: The Pivot Links on your MX Industrial Brake have been pre-set at the factory for average holding capacity and ease of operation. However, it's important that you readjust your MX Industrial Brake to your stock thickness. Your MX Series™ Brake may also need periodic adjustment due to extreme weather and/or working conditions.
- Page 5 S n a p S e r i e s S t a n d ™ ™ MX Stand Parts List 14394 14316 (large stand) 10795 14319 14285 14318 (large stand) * 14284 10539 14321 11533 14279 14320 Item# Description 10539 ¼...
- Page 6 S n a p S e r i e s S t a n d ™ ™ MX Stand Set-up Hardware Requirements: (2) 7/16" & (2) 9/16" Open end wrench. STEP 1 Attach Stand Counter Balance Brackets to Plank with Carriage Bolts and Nylock Nuts Stand Counter using a 7/16"...
- Page 7 ™ S n a p S e r i e s S t a n d ™ MX Stand Set-up STEP 4 Rotate the Toggle Pin 90 degrees and Rotate arm on Toggle Pin Toggle Pin in slide the Rear Cross Tube onto the to insert Rear Support Tube.
- Page 8 S e r i e s S t a n d ™ ™ ™ Installing a MX Series Brake on MX Stand STEP 5 Align the hole in the Fixed Hinge with the Slot on the Stand Top Bracket. See 5a.
- Page 9 S n a p S e r i e s S t a n d ™ Adjustable MAX Cut-Off Parts 10008 10013 10021 10020 10021 10227 ASSEMBLY 10225 12263 12264 10015 12293 11409 10227 ASSEMBLY 12396 Item# Description Item# Description 10008 Handle 11409...
- Page 10 S n a p S e r i e s S t a n d ™ Setup for Adjustable MAX Cut-Off LIST OF PARTS: Tools Needed for Initial Set Up: (1) Adjustable MAX Cut-Off hammer, punch or nail set, (2) MX Material Stop Kit #14485 9/16"...
-
Page 11: Care And Maintenance
Use only clean shop towels Moving Hinge that are free of dirt, oil and metal chips. • Do not use your MX Series™ Brake around saw tables as the cuttings may get in between clamping surfaces or hinges and cause excessive wear or material scratching. - Page 12 3. One Piece Soffi t Mitre 8. Brick Frieze 4. Reglet Flashing 9. “F” Channel/Inside Corner 5. Hip/Ridge Cap 10. “D” Style Gutter Tapco Integrated Tools www.tapcotools.com • (800) 521-7567 © Boral Building Products Inc. Item # 14489 T5373 4/06...
