Dyson Airblade Tap Pre-Installation Information

PRE-INSTALLATION INFORMATION
Sink specification guidelines
Using a specially designed test method, Dyson engineers tested
a wide range of sinks to assess their compatibility with the Dyson
Airblade Tap hand dryer. For recommended sinks, please use
our guide at www.dyson.com/docs
Porcelain or brushed metal sinks are ideal.
Sinks with highly polished surfaces should be avoided
e.g. reflective chrome.
Fig.1
13 7 / " minimum
350mm minimum
8
350mm minimum
Fig.3
15 /
1
385mm minimum
Sink dimensions
(All internal measurements unless otherwise stated)
Fig.1 Width of sink minimum: 13 /
7
8
depth of sink minimum (for all taps): 4"
Fig.2 Maximum depth of sink for Long Neck Tap (AB10) only: 7
(External measurement of vessel/pedestal sink)
WWW.RESTROOMDIRECT.COM
" minimum
8
", Front to back of sink minimum: 12" Internal
/ "
7
8
704 • 937• 2673 129 Oakpark Dr., Unit A, Mooresville, NC 28115
Tap mounting
The tap stem (measured from the outside diameter) should
be mounted / " - 1 / " from the outside edge of the sink. (Fig.2)
1 1
2 2
There should be a minimum of 11
a side wall. When multiple taps are installed side-by-side, tap
centers should be a minimum of 23" apart. This allows sufficient
space for mounting the motor bucket, as well as sufficient
shoulder room for users. (Fig.4)
Fig.2
/ " - 1 / "
1 1
2 2
Dia. 1 / "
3
8
385mm minimum
Fig.4
385mm minimum
23" minimum
Fig.3 Minimum distance from center of horizontal arm to top of sink
(AB11 only) 4". Front edge of sink (all types – pedestal, recessed, slab)
to wall minimum 4".
Fig.4 Minimum distance between tap center and a side wall 11
Multiple taps should have a minimum distance between tap centers of 23".
/ " between a tap center and
1
2
11 / " minimum
1
2
/ ".
1
2
