Inmarsat FleetBroadband JUE-501/JUE-251 Quick Reference Guide
1. Power ON
Turn on JUE-501/JUE-251 by pushing power switch of Main unit.
ON
Initializing
Initialize
Satellite searching
APAC E143.5
14:03 UTC
SAT SEARCH
Registering to network
APAC E143.5
14:03 UTC
REGISTERING
Communication available status
APAC E143.5
14:03 UTC
CS PS READY
[READY] lamp lit. Refer to [3.4.1. LCD/LED section] of Instruction Manual.
[When Satellite Search is failed] Carry out setting again by pressing
(See [Satellite selection/setting] (p3) in this Reference Guide. )
[How to turn OFF the JUE-501/JUE-251] Press the power switch again.
Screen and all LED lamps are cleared, then operation is terminated.
A LED of Main unit starts blinking.
About 90 seconds later, initializing is
started and blinking [Initialize] text is
displayed.
[SAT SEARCH] text is displayed in the
lowest, [Status] line.
Satellite searching is started.
Although there is nothing wrong with
*
JUE-501/JUE-251, selecting satellite makes
some noise on ADE.
Satellite searching is terminated and
then [REGISTERING] text is displayed.
Registering to Inmarsat network is
started.
Registering is terminated and [CS PS
READY] text is displayed.
Various services are available.
* Antenna bars display communication status
0 : Impossible to communicate (no reception)
1 - 2:Possible to communicate but unstable
3 - 6: Possible to stable communicate
button.
CODE: 7ZPSC0431
