Important Safety Instructions When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference.
Page 3
Service methods not covered in the operating instructions should be referred to qualified service personnel. Contact Pyle Technical Support for any issues: support@pyleaudio.com 13. Environment Attention: Do not dispose of batteries improperly pay attention to the environmental aspects of battery disposal and the use of unit in moderate climates.
Location of Controls Main Unit Front View Bottom View 1. Power / Bluetooth mode LED Indicator - Power off mode: LED indicator is off. - Whilst power on and searching Bluetooth device, LED indicator will blink in red and steadily light in green colour. - Whilst power on and paired a Bluetooth device, LED indicator lights steadily in amber (red + green) colour.
Installation Use only Alkaline batteries or rechargeable batteries like those included inside unit. A battery compartment located at bottom of the unit. (1) Unscrew the compartment cap counter-clockwise and open it. (2) For the first time use: Just remove the insulation tab attached in the battery compartment (if battery is included). Screw the compartment cap clockwise and close it tight.
Page 6
USB cable or Power adaptor connection for charging the Speaker unit rechargeable battery You can use the included USB cable or AC-DC power adaptor (the output DC 5V 500mA, NOT Included) to charge the rechargeable battery in the Speaker unit. (1) Connect the USB cable or adaptor's DC output plug to the DC IN jack of the unit.
Bluetooth Operation The unit playback iPad/iPhone/iPod touch and other smart phone music through Bluetooth operation. Before you did the Bluetooth pairing / connection, following information will help: Whilst the main unit is searching for Bluetooth device (e.g. iPhone), the Bluetooth LED indicator will blink in red and steadily light in green color.
color and the unit will search for the neighboring Bluetooth device. (3) Turn on the Bluetooth function of the desired mobile device and pair with the main unit. Out of range situation: (1) During Bluetooth music playback, if the mobile device is moved to another place which is out of the Bluetooth communication range, the communication link disconnected then moves back the mobile device within range.
Specifications POWER REQUIREMENT Power Adaptor (NOT included) Input: AC 100V – 240V ~ 50/60Hz Output: DC 5V 500mA Battery for the Speaker 3 x AA (UM-3) type rechargeable battery (Included) 3 x AA (UM-3) type Alkaline battery (NOT included) If at any time in the future you want to dispose this product, please note that electrical products should not be disposed with household waste.
