Panasonic Lumix DC-S1 Owner's Manual

Table of Contents

Quick Links

Download this manual

Owner's Manual

Digital Camera

DC-S1

DVQP1869ZA

F0319MR0

Table of Contents

Summary of Contents for Panasonic Lumix DC-S1

Page 1 Owner’s Manual Digital Camera DC-S1 DVQP1869ZA F0319MR0...
Page 2 Register online at http://shop.panasonic.com/support (U.S. customers only) Dear Customer, Thank you for choosing Panasonic! You have purchased one of the most sophisticated and reliable products on the market today. Used properly, we’re sure it will bring you and your family years of enjoyment.
Page 3: About Owner's Manual
About Owner’s Manual This document provides an explanation with the assumption that menu settings are in the default settings. Description in this document is based on the interchangeable lens (S-R24105). Symbols Used in the Text Symbols for recording modes, pictures, and videos that can be used In this document, symbols are placed at the start of functional explanations (recording modes, pictures, and videos) showing conditions in which these functions can be used.
Page 4 About Owner’s Manual Notification classification symbols In this document, notifications are classified and described using the following symbols: To confirm prior to using the function Hints for better use of the camera and tips for recording Notifications and supplementary items regarding specifications Related information and page number...
Page 5: Chapters
Chapters 1. Introduction 2. Getting Started 3. Basic Operations 4. Easy Recording 5. Image Recording 6. Focus/Zoom 7. Drive/Shutter 8. Metering/Exposure/ISO Sensitivity 9. White Balance/Image Quality 10. Flash 11. Recording Videos 12. Playing Back and Editing of Images 13. Camera Customization 14.
Page 6: Table Of Contents
Contents About Owner’s Manual ..............3 Chapters ..................5 Contents by Function..............14 1. Introduction Before Use.................17 Standard Accessories..............20 Lenses That Can Be Used............21 Memory Cards That Can Be Used..........22 Names of Parts ................24 Camera....................24 Supplied Lens..................28 Displaying Viewfinder/Monitor ............29 Status LCD Display ................
Page 7 Contents 3. Basic Operations Basic Recording Operations............56 How to Hold the Camera..............56 Adjusting the Angle of the Monitor .............58 Taking Pictures ..................59 Recording Videos................60 Selecting the Recording Mode ............61 Camera Setting Operations ............62 Display Settings................. 66 Setting the Viewfinder ................66 Switching Between the Monitor and Viewfinder .........67 Switching the Display Information ............68 Turning On the Status LCD Backlight ..........70...
Page 8 Contents 6. Focus/Zoom Selecting the Focus Mode ............91 Using AF ..................92 [AF Custom Setting(Photo)] .............. 96 Selecting the AF Mode ..............98 [Face/Eye/Body/Animal Detect.]............99 [Tracking]..................102 [225-Area]..................104 [Zone (Vert./ Horz.)]/ [Zone (Square)]/ [Zone (Oval)]...... 105 [1-Area+]/ [1-Area]................107 [Pinpoint] ..................108 [Custom1] to [Custom3]..............
Page 9 Contents Post-Focus Recording ............. 161 Selecting the Focus Position for the Picture to Save .......164 Focus Stacking ................166 [Silent Mode]................169 [Shutter Type] ................170 Image Stabilizer............... 172 Image Stabilizer Settings ..............174 8. Metering/Exposure/ISO Sensitivity [Metering Mode]............... 178 Program AE Mode ..............179 Aperture-Priority AE Mode............181 Shutter-Priority AE Mode............
Page 10 Contents [Flash Synchro] ................223 Adjusting the Flash Output .............. 224 [Auto Exposure Comp.] ..............225 [Red-Eye Removal] ................. 225 Recording Using a Wireless Flash...........226 11. Recording Videos Recording Videos ..............230 Video Settings................233 [Rec. File Format] ................233 [Rec Quality] ..................234 [Image Area of Video]..............
Page 11 Contents Group Images................269 Deleting Images............... 270 [RAW Processing] ..............272 [Video Divide] ................277 13. Camera Customization Fn Buttons ................279 Register Functions to the Fn Buttons..........280 Use the Fn Buttons ................286 Fn Lever .................. 287 Register a Function to the Fn Lever..........287 Use the Fn Lever ................289 [Dial Operation Switch] ............
Page 12 Contents 15. Wi-Fi/Bluetooth Wi-Fi/Bluetooth Functions............370 Connecting to a Smartphone ...........372 Installing “LUMIX Sync” ..............373 Connecting to a Smartphone (Bluetooth Connection) ..... 374 Connecting to a Smartphone ([Wi-Fi connection])......377 Terminating the Wi-Fi Connection ........... 382 Operating the Camera with a Smartphone ......383 [Remote shooting] ................
Page 13 Contents 16. Connecting to Other Devices Viewing on a TV ..............426 Importing Images to a PC............430 Installing Software................430 Copying Images to a PC ..............433 Storing on a Recorder ............. 436 Tethered Recording..............438 Installing Software................438 Operating the Camera from a PC ............439 Printing ..................
Page 14: Contents By Function
Contents by Function Power Source Display Charging Recording screen Charging error Playback screen Viewfinder Battery indication Status LCD Power supply Control panel [Battery Information] Switching display Power save function Monitor/viewfinder Usage duration, Number of adjustment pictures Monitor/viewfinder luminance Card Display speed Cards that can be used Level gauge [Card Format]...
Page 15 Contents by Function Drive Exposure Drive mode [Exposure Comp.] Burst Program Shift [6K/4K PHOTO] Preview mode [Time Lapse Shot] [Metering Mode] Recording with Stop Motion AE Lock Animation [One Push AE] [Self Timer] [Touch AE] [Post-Focus] [Sensitivity] [Extended ISO] Image Quality [Picture Size] Video Recording [Picture Quality]...
Page 16 Contents by Function Flash Connecting with Other External flash Devices [Firing Mode] Sending images (PC) [Flash Mode] Printing Flash output adjustment Viewing on a TV [Flash Synchro] HDMI output [Wireless Flash Setup] Tethered recording Cable holder Playback [Auto Review] Wi-Fi/Bluetooth Playing back pictures Bluetooth connection Playing back videos...
Page 17: Introduction
– Touch operations may be incorrectly recognized. When using in low temperatures (s10 oC to 0 oC (14 oF to 32 oF)) – Before use, attach a Panasonic lens with a minimum recommended operating temperature of j10 oC (14 oF).
Page 18 1. Introduction Do not place a hand inside the camera mount. This may cause a failure or damage because the sensor is a precision device. If you shake the camera while turning the camera off, a sensor may operate or a rattling sound may be heard. This is caused by the image stabilizer mechanism in the body.
Page 19 1. Introduction No Compensation Regarding Recording Please note that compensation cannot be provided in the event that recording could not be performed due to a problem with the camera or a card. Be Careful with Regard to Copyrights Under copyright law, you may not use the images and audio you have recorded for other than personal enjoyment without the permission of the copyright holder.
Page 20: Standard Accessories
1. Introduction Standard Accessories Check that all the accessories are supplied before using the camera. The accessories and their shape will differ depending on the country or area where the camera was purchased. For details on the accessories, refer to “Owner’s Manual” (supplied). Digital camera body is referred to as camera in this document.
Page 21: Lenses That Can Be Used
214, 238, 316) 0 Refer to catalogs/websites for most current information regarding supported lenses. https://panasonic.jp/support/global/cs/dsc/ (English only) The angle of view while recording with an APS-C lens is equivalent to the angle of view of a focal length of 1.5k when converted to the focal length of a 35 mm film camera.
Page 22: Memory Cards That Can Be Used
Video Speed Class 90 of the UHS- standard. SDXC memory card Operation with the Panasonic cards on the left has (48 GB to 128 GB) been verified. For the latest information, check the following support website. https://panasonic.jp/support/global/cs/dsc/...
Page 23 1. Introduction SD Cards That Can Be Used Stably with This Camera To ensure the following recording functions can be used stably, use a card of the supported SD Speed Class, UHS Speed Class, and Video Speed Class. Speed classes are SD card standards to guarantee the minimum speed necessary for continuous writing.
Page 24: Names Of Parts
1. Introduction Names of Parts Camera Stereo microphone (l 243) Shutter button (l 59) Take care not to block the [WB] (White Balance) button microphone with a finger. Audio (l 194) will be difficult to record. ] (Exposure compensation) Mode dial (l 61) button (l 189) Mode dial lock button (l 61) [ISO] (ISO sensitivity) button...
Page 25 1. Introduction Diopter adjustment dial (l 66) [Q] button (l 71) Operation lock lever (l 65) Cursor buttons (l 63)/ Fn buttons (l 279) [(] (Playback) button (l 260) 3: Fn13, 1: Fn14, 4: Fn15, Monitor lock lever (l 58) 2: Fn16 Monitor (l 448)/ Control dial (l 63)
Page 26 DC Coupler cover (l 447) Eye cup (l 473) When using an AC adaptor, Eye cup lock lever (l 473) ensure that the Panasonic DC Tripod mount (l 478) Coupler (DMW-DCC16: If you attempt to attach a tripod optional) and AC Adaptor with a screw length of 5.5 mm...
Page 27 1. Introduction 16 15 14 Headphone socket (l 258) Shoulder strap eyelet (l 31) Excessive sound pressure from Self-timer lamp (l 153)/ earphones and headphones can AF assist lamp (l 309) cause hearing loss. Fn button (Fn1) (l 279) USB port (l 433, 441) Grip [HDMI] socket (l 426) Preview button (l 188)/...
Page 28: Supplied Lens
1. Introduction Supplied Lens S-R24105 2 3 4 5 6 Zoom lock switch Lens surface When you set the focal length to Focus ring (l 118) 24 mm and set the switch to Zoom ring (l 121) [LOCK], the zoom ring is locked. O.I.S.
Page 29: Displaying Viewfinder/Monitor
1. Introduction Displaying Viewfinder/Monitor At the time of purchase, the viewfinder/monitor displays the following icons. For information about the icons other than those described here, refer to page 448. Viewfinder Monitor FINE FINE ± 9 1011 12 14 15 16 17 Photo Style (l 199) Shutter speed (l 59) Level gauge (l 339)
Page 30: Status Lcd Display
1. Introduction Status LCD Display This displays the recording settings of the camera. ISO sensitivity (l 192)/ White balance (l 194) Exposure compensation value Exposure compensation value (l 189) (l 189)/ Number of recordable pictures Exposure Bracket (l 158) (l 482)/ Metering mode (l 178) Number of pictures that can be taken Shutter speed (l 59)/...
Page 31: Getting Started
Getting Started Attaching a Shoulder Strap Attach a shoulder strap to the camera with the following procedure to prevent it from dropping. Pass the shoulder strap through the shoulder strap  eyelet A.  Pass the end of the shoulder ...
Page 32 2. Getting Started Use the shoulder strap around your shoulder. – Do not wrap the strap around your neck. It may result in injury or accident. Do not leave the shoulder strap where an infant can reach it. – It may result in an accident by mistakenly wrapping around the neck.
Page 33: Charging The Battery
2. Getting Started Charging the Battery You can charge the battery either using the supplied charger, or in the camera body. If you turn on the camera, you can also charge the battery while the camera is powered from an electrical outlet. Instead of using an electrical outlet, you can also connect the camera using a device that supports USB PD (USB Power Delivery).
Page 34 2. Getting Started Connect the charger and the AC adaptor with the USB connection cable (C–C). Hold the plugs and insert them straight. (Inserting these at an angle may cause deformation or malfunction) Connect the AC cable to the  AC adaptor and then insert into the electrical outlet.
Page 35 2. Getting Started [CHARGE] Lamp Charging 0% to 49% 50% to 79% 80% to 99% 100% status [CHARGE] lamp A Blinking B Lit C Off After charging, disconnect the power source connection and remove the battery. If the [50%] lamp is blinking quickly, then charging is not occurring. –...
Page 36: Battery Insertion
2. Getting Started Battery Insertion Always use genuine Panasonic batteries (DMW-BLJ31). If you use other batteries, we cannot guarantee the quality of this product. Turn off the camera. Open the battery door. ≥Move the battery door release lever to the [OPEN] position.
Page 37 2. Getting Started Removing the Battery Turn off the camera. Open the battery door. Check that the card access lamp A is off and then open the battery door. Push the lever B in the direction of the  arrow and then remove the battery. Ensure that no foreign objects are adhering to the inner side (rubber seal) of the battery door.
Page 38: Charging The Battery With The Camera
2. Getting Started Charging the Battery with the Camera Charging time Approx. 140 min Using the camera body and the supplied AC adaptor. The camera is turned off. The indicated charging time is for when the battery has been discharged completely. The charging time may vary depending on how the battery has been used.
Page 39 2. Getting Started Connect the AC cable to the AC  adaptor and then insert into the electrical outlet.  ≥The battery display on the status LCD will blink, and charging starts. You can also charge the battery by connecting a USB device (PC, etc.) and the camera with the USB connection cable (C–C or A–C).
Page 40: Charging While Using The Camera
2. Getting Started Status LCD Display Charging status Charging Charging complete Charging error Display After charging, disconnect the connection to the power source. When an error is displayed, charging is not possible. – The temperature of the battery or surroundings is either too high or too low. Try charging at an ambient temperature between 10 °C and 30 °C (50 oF and 86 oF).
Page 41 2. Getting Started Even when connecting with devices that support USB PD, you may not be able to charge while using the camera. If connecting with devices (PC, etc.) that do not support USB PD and turning the camera on, then this will supply power only. If the camera temperature rises under the any of following conditions, charging may stop.
Page 42: Notifications Regarding Charging/Power Supply
2. Getting Started Notifications Regarding Charging/Power Supply Power Indications Indication on status LCD Indication on monitor        A Receiving power from the USB D The battery level of the battery in the connection cable Battery Grip B Power source E Battery indication...
Page 43 To ensure that safe products are used, we recommend that a genuine Panasonic battery pack is used. Do not leave any metal items (such as clips) near the contact areas of the power plug.
Page 44: [Power Save Mode]
2. Getting Started [Power Save Mode] This is a function to automatically turn the camera to sleep (power save) status or turn off the viewfinder/monitor if no operation is performed for a set time. Reduces battery consumption. Select [Power Save Mode] [Sleep Mode] Sets the amount of time until the camera is put into sleep.
Page 45 2. Getting Started [Power Save Mode] does not work during the following operations: – PC or printer connection – Video recording/video playback – [6K/4K Pre-Burst] recording – [Time Lapse Shot] – [Stop Motion Animation] (when [Auto Shooting] is set) – [Multiple Exposure] recording –...
Page 46: Inserting Cards (Optional)
2. Getting Started Inserting Cards (Optional) You can use an XQD card and SD card with this camera. (l 22) Open the card door.  ≥Slide the card door in the direction  of the arrow while pushing down the card door lock lever.
Page 47 2. Getting Started Card Access Indications The card access lamp lights while the card is being accessed. Removing a Card Open the card door. Check that the card access lamp A is off and then open the card door. Push the card until it clicks and then pull the card out straight.
Page 48: Formatting Cards (Initialization)
2. Getting Started Formatting Cards (Initialization) Format the cards with the camera before use in order to ensure optimal card performance. When a card is formatted, all of the data stored in the card is erased and cannot be restored. Save a backup of necessary data before formatting the card.
Page 49: Attaching A Lens
2. Getting Started Attaching a Lens You can attach the Leica Camera AG L-Mount standard lens to this camera. For information about the lens that can be used, refer to page 21. Change the lens in a location where there is not a lot of dirt and dust. If dirt or dust gets on the lens, refer to page 472.
Page 50 2. Getting Started Align the lens fitting marks B on the lens and camera and then rotate the lens in the direction of the arrow. ≥Attach the lens by rotating it until it clicks. Insert the lens straight in. Inserting this at an angle to attach it may damage the camera lens mount. Removing a Lens Turn off the camera.
Page 51: Attaching A Lens Hood
2. Getting Started Attaching a Lens Hood For recording against strong backlight, a lens hood can reduce the inclusion of unwanted light in images and drop in contrast resulting from the irregular reflection of light that occurs within the lens. It allows you take more beautiful pictures by cutting out excess light.
Page 52 2. Getting Started Removing the Lens Hood While pressing the lens hood button, rotate the lens hood in the direction of the arrow and then remove it.   The lens hood can be attached in the reverse direction when carrying the camera.
Page 53: Setting The Clock (When Turning On For The First Time)
2. Getting Started Setting the Clock (When Turning On for the First Time) When you turn the camera on for the first time, a screen to set the time zone and clock appears. Be sure to set these settings before use to ensure images are recorded with the correct date and time information.
Page 54 2. Getting Started When [Please set the clock] appears, press Set the clock. 21: Select an item (year, month, day, hour, minute, or second). 34: Select a value. To set the display order B and time display format C ≥If you select [Style] and then press , the screen for setting the display order and time display format appears.
Page 55 2. Getting Started If the camera is used without setting the clock, it will be set to 0:00:00, January 1st 2019. Clock settings are maintained for approx. 3 months using the built-in clock battery even without the battery. (Leave the fully-charged battery in the camera for approx. 24 hours to charge the built-in battery.) [Time Zone] and [Clock Set] can be changed from the menu: –...
Page 56: Basic Operations
Basic Operations Basic Recording Operations How to Hold the Camera To minimize camera shake, hold the camera so that it will not move during recording. Hold the camera with both hands, keep your arms still at your side, and stand with your feet shoulder width apart. ≥Hold the camera firmly by wrapping your right hand around the camera grip.
Page 57 3. Basic Operations Vertical Orientation Detection Function This function detects when pictures were recorded with the camera held vertically orientated. With the default settings, pictures are automatically played back vertically oriented. If you set [Rotate Disp.] to [OFF], pictures will be played back without being rotated.
Page 58: Adjusting The Angle Of The Monitor
3. Basic Operations Adjusting the Angle of the Monitor This camera has a 3-axis tiltable monitor. Adjust the angle of the monitor to match the recording conditions. This is useful for high and low angle recording. ≥High angle recording (horizontal ≥Low angle recording (horizontal position) position)
Page 59: Taking Pictures
3. Basic Operations Taking Pictures Adjust the focus. ≥Press the shutter button halfway (press it gently). ≥The aperture value A and shutter speed B are displayed. (When the correct exposure cannot be obtained, the indications blink in red.) ≥Once the subject is in focus, the focus indication C lights.
Page 60: Recording Videos
3. Basic Operations Recorded pictures can be displayed automatically by setting [Auto Review] of the [Custom] ([Monitor / Display]) menu. You can also change the picture display duration to your preferred setting. (l 338) With the default settings, you cannot take a picture until the subject is brought into focus.
Page 61: Selecting The Recording Mode
3. Basic Operations Selecting the Recording Mode While pressing the mode dial lock button (1), rotate the mode dial (2).   Intelligent Auto mode (l 77) Program AE mode (l 179) Aperture-Priority AE mode (l 181) Shutter-Priority AE mode (l 183) Manual Exposure mode (l 185) Creative Video mode (l 244) C1/C2/C3...
Page 62: Camera Setting Operations
3. Basic Operations Camera Setting Operations When changing the camera settings, operate the camera using the following operation parts. To prevent accidental operation, you can disable operation with the operation lock lever. Front dial (l 63) Rear dial (l 63) Control dial (l 63) Cursor buttons (l 63) [MENU/SET] button (l 63)
Page 63 3. Basic Operations Front Dial ( )/Rear Dial ( Rotate: Selects an item or numeric value. Sets the aperture, shutter speed, and other settings when you are recording in the P/A/S/M modes. The operation method can be changed in [Dial Set.].
Page 64 3. Basic Operations Joystick (3421/ The joystick can be operated in 8 directions by tilting it up, down, left, right and diagonally and by pressing the center part. A Tilt: Selects an item or numeric value, or moves a position. B Press: Confirms a setting.
Page 65 3. Basic Operations Touch the screen with clean and dry fingers. If you will use a commercially available monitor protection sheet, observe the precautions for the sheet. (Visibility and operability may be impaired depending on the type of monitor protection sheet.) The touch screen may not operate correctly in the following cases: –...
Page 66: Display Settings
3. Basic Operations Display Settings Setting the Viewfinder Adjusting the Viewfinder Diopter Rotate the diopter adjustment dial while looking through the viewfinder. Adjust the diopter until you can see the characters clearly. Switching the Viewfinder Display Magnification Press [V.MODE]. ≥The display magnification of the viewfinder can be switched between 3 levels.
Page 67: Switching Between The Monitor And Viewfinder
3. Basic Operations Switching Between the Monitor and Viewfinder With the default settings, automatic viewfinder/monitor switching is set. When you look through the viewfinder, the eye sensor works and the camera switches from monitor display to viewfinder display. You can switch to viewfinder display or monitor display with [LVF]. Press [LVF] A.
Page 68: Switching The Display Information
3. Basic Operations Switching the Display Information The recording information (icons) on the recording screen and playback screen can be hidden. The monitor on the rear of the camera can be set to display only recording information or turned off. Press [DISP.].
Page 69 3. Basic Operations Press [ ] to switch between display/hide of the level gauge. This can also be set by using [Level Gauge]. (l 339) Control panel operation You can touch items on the control panel to directly change their settings. These can also be changed with the following operations: Press one of the cursor buttons to enable selection of items.
Page 70: Turning On The Status Lcd Backlight
3. Basic Operations Turning On the Status LCD Backlight Press [ ≥The backlight will turn on. ≥If the camera is left without any operations for approx. 5 seconds, the backlight turns off. With the default settings, the illumination button will also light. If you press [ ] again or fully press the shutter button, the backlight turns off.
Page 71: Quick Menu
3. Basic Operations Quick Menu This menu enables you to quickly set functions that are frequently used during recording without calling the menu screen. You can also change the Quick menu display method and the items to display. Display the Quick menu. ≥Press [Q].
Page 72 3. Basic Operations Some items cannot be set depending on the recording mode or camera settings. The Quick menu can be customized: [Q.MENU Settings] (l 292)
Page 73: Menu Operation Methods
3. Basic Operations Menu Operation Methods In this camera, the menu is used for setting a wide variety of functions and performing camera customizations. Menu operation is possible in a variety of ways including using the cursors, joystick, dials, and touch. Configuration and operation parts of the menu The menu can be operated by pressing 21 to move between menu screens.
Page 74 3. Basic Operations Select a sub tab. ≥Press 34 to select a sub tab and then press 1. ≥You can also perform the same operation by rotating to select the sub tab and then pressing Select a menu item. ≥Press 34 to select a menu item and then press 1.
Page 75 3. Basic Operations Close the menu. ≥Press the shutter button halfway. ≥You can also close the menu by pressing [ ] several times. For details about menu items, refer to Menu Guide. (l 303) Displaying Descriptions About Menu Items and Settings If you press [DISP.] while a menu item or setting item is selected, a description about the item is displayed on the screen.
Page 76: [Reset]
3. Basic Operations [Reset] Return each of the following settings to the default setting: – Recording settings – Network settings (settings of [Wi-Fi Setup] and [Bluetooth]) – Setup and custom settings (other than [Wi-Fi Setup] and [Bluetooth]) Select [Reset] If you reset the setup and custom settings, the following settings will also be reset: –...
Page 77: Easy Recording
Easy Recording Intelligent Auto Mode The [iA] mode (Intelligent Auto mode) can record images using settings automatically selected by the camera. The camera detects the scene to set the optimal recording settings automatically to match the subject and recording conditions. Set the mode dial to [iA].
Page 78 4. Easy Recording Start recording. ≥Press the shutter button fully. Backlight compensation operates automatically to prevent subjects from appearing dark when there is a backlight. Types of Automatic Scene Detection : Scenes detected during picture taking : Scenes detected during video recording i-Portrait &...
Page 79 4. Easy Recording If none of the scenes are applicable, recording is with [ ] (standard setting). Different scene types may be selected for the same subject depending on the recording conditions. AF Mode Changing the AF mode. Each press of [ ] changes the AF mode.
Page 80: Recording Using Touch Functions
4. Easy Recording Recording Using Touch Functions Touch Shutter This function focuses on a touched position and then releases the shutter. With the default settings, the Touch Tab is not displayed. Set [Touch Tab] to [ON] in [Touch Settings]. (l 333) Touch [ Touch [ ×...
Page 81: Touch Ae
4. Easy Recording Touch AE This function adjusts the brightness according to a touched position. When a subject’s face appears dark, you can make the screen brighter to match the face. With the default settings, the Touch Tab is not displayed. Set [Touch Tab] to [ON] in [Touch Settings].
Page 82: Image Recording
Image Recording [Aspect Ratio] You can select the image aspect ratio. Select [Aspect Ratio] [4:3] Aspect ratio of a 4:3 monitor [3:2] Aspect ratio of a standard film camera [16:9] Aspect ratio of a 16:9 TV [1:1] Square aspect ratio [65:24] Panoramic aspect ratio [2:1]...
Page 83: [Picture Size]
5. Image Recording [Picture Size] Sets the picture’s image size. The image size varies depending on the [Aspect Ratio] or the lens used. When an APS-C lens is used, the image area switches to the one for APS-C, thereby narrowing the angle of view. Select [Picture Size] Picture size [Aspect...
Page 84 5. Image Recording [Picture Size] is not available when the following functions are being used: – [6K/4K PHOTO]/[Post-Focus] – [RAW] ([Picture Quality]) – [High Resolution Mode] – [Multiple Exposure] You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Picture Size] (l 279)
Page 85: [Picture Quality]
5. Image Recording [Picture Quality] Set the compression rate used for storing pictures. Select [Picture Quality] Setting File format Settings details [FINE] JPEG images that give priority to image quality. JPEG images of standard image quality. JPEG This is useful for increasing the number of [STD.] recordable pictures without changing the picture size.
Page 86 5. Image Recording Note on RAW RAW format refers to a data format of images that have not been processed on the camera. Playback and editing of RAW images require the camera or the dedicated software. You can process RAW images on the camera. (l 272) Use software (“SILKYPIX Developer Studio”...
Page 87: [Double Card Slot Function]
5. Image Recording [Double Card Slot Function] This sets the way recording to the card slots 1 and 2 is performed. Select [Double Card Slot Function] Selects the priority of card slots for recording. [Destination Card Slot]: [ [Relay Rec] Relays recording to the card in the other card slot after the first card runs out of free space.
Page 88: [Folder / File Settings]
5. Image Recording [Folder / File Settings] Set the folder and file name where to save the images. Folder name File name 100ABCDE PABC0001.JPG       Color space 1 Folder number (3 digits, 100 to 999) ([P]: sRGB, [ _ ]: AdobeRGB) 2 5-character user-defined segment 4 3-character user-defined segment...
Page 89 5. Image Recording Each folder can store up to 1000 files. File numbers are assigned sequentially from 0001 to 9999 in the order of recording. If you change the storage folder, a number continuing on from the last file number will be assigned. In the following cases, a new folder with an incremented folder number will be created automatically when the next file is saved: –...
Page 90: [File Number Reset]
5. Image Recording [File Number Reset] Resets the file number of the next recording to 0001. Select [File Number Reset] Settings: [Card Slot 1(XQD)]/[Card Slot 2(SD)] When recording is performed after resetting this item, the folder number is updated and the file number starts from 0001. Folder numbers from 100 to 999 can be assigned.
Page 91: Focus/Zoom
Focus/Zoom Selecting the Focus Mode Select the focusing method (focus mode) to match subject movement. Set the focus mode lever. This is suitable for recording still subjects. While the shutter button is pressed halfway, this maintains a single ([AFS]) point of focus. The focus stays locked while the shutter button is pressed halfway.
Page 92: Using Af
6. Focus/Zoom Using AF AF (Auto Focus) refers to automatic focusing. Select the focus mode and the AF mode appropriate for the subject and scene. Set the focus mode to [S] or [C]. ≥Set the focus mode lever. (l 91) Select the AF mode.
Page 93 6. Focus/Zoom Focus In focus Not in focus Focus icon A Lights Blinking AF area B Green AF beep Two beeps — Low illumination AF In dark environments, low illumination AF automatically operates, and the focus icon is indicated as [ Achieving focus may take more time than usual.
Page 94 6. Focus/Zoom [AF ON] button You can also activate AF by pressing [AF ON]. Subjects and recording conditions that make focusing difficult with AF mode – Fast-moving subjects – Extremely bright subjects – Subjects without contrast – Subjects recorded through windows –...
Page 95 6. Focus/Zoom On the recording screen, press and hold [Fn1]. Part of the screen is displayed enlarged while [Fn1] is pressed and held. When the screen is enlarged, pressing the shutter button halfway re-acquires focus in a small central AF area. When the screen is enlarged, turn to adjust the magnification.
Page 96: [Af Custom Setting(Photo)]
6. Focus/Zoom [AF Custom Setting(Photo)] Select features of AF operation when recording using [AFC] that are appropriate for the subject and scene. Each of these features can be further customized. Set the focus mode to [AFC]. (l 91) Set [AF Custom Setting(Photo)].
Page 97 6. Focus/Zoom Adjusting AF Custom Settings Press 21 to select the AF Custom setting type. Press 34 to select items and press 21 to adjust. To reset settings to the default, press [DISP.]. Press Sets the tracking sensitivity for the movement of subjects. When the distance to the subject changes drastically, the camera re-adjusts the focus immediately.
Page 98: Selecting The Af Mode
6. Focus/Zoom Selecting the AF Mode Select the focusing method to match the position and number of subjects. Press [ ≥The AF mode selection screen appears. Select the AF mode. ≥Press 21 to select an item and then press [Face/Eye/Body/ Animal Detect.] [Tracking] [225-Area]...
Page 99: [Face/Eye/Body/Animal Detect.]
6. Focus/Zoom In [Time Lapse Shot], [ ] cannot be used. When the focus mode is set to [AFC], [ ] is not available. When the following functions are being used, the AF mode is fixed to [ – [65:24]/[2:1] ([Aspect Ratio]) –...
Page 100 6. Focus/Zoom Specify the Person, Animal, or Eye to Bring into Focus When the person or animal to be brought into focus is shown using the white AF area, you can change this to a yellow AF area. ≥Touch operation Touch the person, animal or eye indicated with the white AF area.
Page 101 6. Focus/Zoom Move and Change the Size of the Yellow AF Area You can move the yellow AF area to the position of the white AF area and replace the white AF area with the yellow AF area. If moving to a position outside an AF area, then the [ ] AF area will be set.
Page 102: [Tracking]
6. Focus/Zoom [Tracking] When the focus mode is set to [AFC], the AF area follows the movement of the subject, maintaining focusing. Start tracking. ≥Aim the AF area over the subject, and press the shutter button halfway. The camera will track the subject while the shutter button is pressed halfway or pressed fully.
Page 103 6. Focus/Zoom Move the Position of the AF Area Press [ ] to display the AF mode selection screen. Select [ ] and then press 4. Press 3421 to move the position of the AF area. Positions can be moved to the diagonal directions using the joystick. You can also move the AF area by touching.
Page 104: [225-Area]
6. Focus/Zoom [225-Area] The camera selects the most optimal AF area to focus from 225 areas. When multiple AF areas are selected, all selected AF areas will be brought into focus. When the focus mode is set to [AFC], ensuring that the subject stays within the 225 areas during recording will ensure the subject stays in focus.
Page 105: [Zone (Vert./ Horz.)]/ [Zone (Square)]/ [Zone (Oval)]
6. Focus/Zoom [Zone (Vert./ Horz.)]/ [Zone (Square)]/ [Zone (Oval)] [Zone (Vert./ Horz.)] From the 225 AF areas, vertical and horizontal zones can be focused. Horizontal pattern Vertical pattern [Zone (Square)] From the 225 AF areas, a central square zone can be focused. [Zone (Oval)] From the 225 AF areas, a central oval zone can be focused.
Page 106 6. Focus/Zoom Move and Change the Size of the AF Area Press [ ] to display the AF mode selection screen. Select [ ], [ ] or [ ] and then press 4. Press 3421 to move the position of the AF area.
Page 107: [1-Area+]/ [1-Area]
6. Focus/Zoom [1-Area+]/ [1-Area] [1-Area+]  Emphasis within a single AF area can be focused. Even when the subject moves out of the single AF area, this remains focused in a supplementary AF area (A). Effective when recording moving subjects that are difficult to track with [ [1-Area] Specify the position to be brought into...
Page 108: [Pinpoint]
6. Focus/Zoom Operations on the AF area movement screen Button Touch Description of operation operation operation Moves the AF area Touch Positions can be moved to the diagonal 3421 directions using the joystick. Pinch out/ Enlarges/reduces the AF area in small steps. pinch in Enlarges/reduces the AF area.
Page 109 6. Focus/Zoom Move the Position of the AF Area Press [ ] to display the AF mode selection screen. Select [ ] and then press 4. Press 3421 to set the position of [i] and then press Positions can be moved to the diagonal directions using the joystick. The selected position on the screen will be enlarged.
Page 110: [Custom1] To [Custom3]
6. Focus/Zoom When the picture is displayed in windowed mode, you can enlarge the picture by approx. 3k to 6k; when the picture is displayed in full screen, you can enlarge the picture by approx. 3k to 10k. You can also take a picture by touching [ When the following functions are being used, [ ] switches to [Ø]: –...
Page 111 6. Focus/Zoom Select the AF area. Touch operation ≥ Touch the area to make the AF area. To select consecutive points, drag the screen. To cancel selection of the selected AF area, touch it again. Button operation ≥ Press 3421 to select the AF area and then set with (Repeat this) Positions can be moved to the diagonal directions using the joystick.
Page 112: Af Area Movement Operation
6. Focus/Zoom AF Area Movement Operation In default settings, you can use the joystick to directly move and change the size of the AF area when recording. Move the position of the AF area. ≥On the recording screen, tilt the joystick.
Page 113: Moving The Af Area By Touch
6. Focus/Zoom Confirm your selection. ≥Press the shutter button halfway. ≥Return to the recording screen. For [ ], on the recording screen, press to cancel the AF area setting. When [Metering Mode] is [ ], the metering target also moves together with the AF area.
Page 114 6. Focus/Zoom Focus on the Touched Position ([AF]) Touch the subject. Moves the AF area to the touched position. Pinch in/pinch out to change the AF area size. The first touch of [Reset] returns the AF area position to the center. The second press returns the size of the AF area to the default.
Page 115: Moving The Af Area Position With The Touch Pad
6. Focus/Zoom Moving the AF Area Position with the Touch Pad During viewfinder display, you can touch the monitor to change the position and size of the AF area. Set [Touch Pad AF]. [Touch ≥ Settings] [Touch Pad AF] [EXACT]/[OFFSET] Move the position of the AF area.
Page 116: [Focus Switching For Vert / Hor]
6. Focus/Zoom Setting Items ([Touch Pad AF]) Moves the AF area of the viewfinder by [EXACT] touching a desired position on the touch pad. Moves the AF area of the viewfinder [OFFSET] according to the distance you drag the touch pad. [OFF] —...
Page 117: Record Using Mf
6. Focus/Zoom Record Using MF MF (Manual Focus) refers to manual focusing. Use this function when you want to fix the focus or when the distance between the lens and the subject is determined and you do not want to activate AF.
Page 118 6. Focus/Zoom Adjust the focus. ≥Rotate the focus ring. A MF Assist (enlarged screen) This will display the in-focus portion highlighted with color. (Peaking B) A recording distance guideline is displayed. (MF Guide C) D Indicator for ¶ (infinity) (ft) 15 10 4"...
Page 119 6. Focus/Zoom Operations on the MF Assist Screen Button Touch Description of operation operation operation Moves the enlarged display position. Drag Positions can be moved to the diagonal 3421 directions using the joystick. Pinch out/ Enlarges/reduces the screen in small steps. pinch in Enlarges/reduces the screen.
Page 120 6. Focus/Zoom On the recording screen, you can rotate the focus ring to display the MF Assist screen. If you have enlarged the picture by rotating the focus ring, the assist screen will close approx. 10 seconds after the operation. During MF, pressing [AF ON] will activate AF.
Page 121: Recording Images With Zoom
6. Focus/Zoom Recording Images with Zoom Use the optical zoom of the lens to zoom to telephoto or wide-angle. When taking pictures, use [Ex. Tele Conv.] to increase a telescopic effect without image deterioration. When recording videos, use [Image Area of Video] to obtain the same telescopic effect as [Ex.
Page 122: Extended Tele Conversion
6. Focus/Zoom Extended Tele Conversion [Ex. Tele Conv.] enables you to take pictures that are further enlarged beyond what is available with the optical zoom, without any deterioration in image quality. The [Ex. Tele Conv.] maximum magnification ratio differs depending on the [Picture Size] set in the [Photo] ([Image Quality]) menu.
Page 123 6. Focus/Zoom Changing the Zoom Magnification Button operation Set [Ex. Tele Conv.] to [ZOOM]. [Ex. Tele Conv.] [ZOOM] Set the Fn button to [Zoom Control]. (l 279) Press the Fn button. Press the cursor buttons to operate the zoom. 31: T (telephoto) 24: W (wide-angle) Press the Fn button again, or wait a EX1.8x...
Page 124 6. Focus/Zoom Drag the slide bar to operate the zoom.  T: Telephoto W: Wide-angle To end Touch Zoom operations, touch ] again.          You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Ex.
Page 125: Drive/Shutter
Drive/Shutter Selecting the Drive Mode You can switch the drive mode to Single, Burst, etc. to match the recording conditions. Rotating the drive mode dial. Takes one picture each time the shutter button is Single pressed. Takes pictures continuously while the shutter Burst button is pressed and held.
Page 126: Taking Burst Pictures
7. Drive/Shutter Taking Burst Pictures Takes pictures continuously while the shutter button is pressed and held. You can choose a burst setting which enables burst recording in high image quality, [H], [M] or [L], or one which enables high-speed burst recording, [ ] (6K/4K photo), to suit the recording conditions.
Page 127 90 frames or more (Medium speed) (Low speed) When recording under the test conditions specified by Panasonic. The number of burst picture frames that can be taken becomes fewer depending on the recording conditions. The burst rate will become lower during recording but pictures can continue to be...
Page 128 7. Drive/Shutter Number of Pictures That Can Be Taken Continuously When you press the shutter button halfway, the number of pictures that can be taken continuously will appear on the recording screen and the status LCD. Example) When 20 frames: [r20] Once recording starts, the number of pictures that can be taken continuously will decrease.
Page 129 7. Drive/Shutter Exposure when Taking Burst Pictures Focus mode [M]/[L] Fixed to the exposure of [AFS] the first frame The exposure is adjusted The exposure is adjusted [AFC] for each frame for each frame Fixed to the exposure of [MF] the first frame It may take a while to save burst pictures.
Page 130: 6K/4K Photo Recording
7. Drive/Shutter 6K/4K Photo Recording With 6K Photo, you can take high-speed burst pictures at 30 frames/ second and save the desired pictures, each made up of approx. 18 million pixels, extracted from their burst file. With 4K Photo, you can take high-speed burst pictures at 60 frames/ second and save the desired pictures, each made up of approx.
Page 131 7. Drive/Shutter Select [Picture Size / Burst Speed]. [6K/4K ≥ PHOTO] [Picture Size / Burst Speed] Picture size Burst rate [4:3]: 4992k3744 [6K 18M] 30 frames/second ¢1 [3:2]: 5184k3456 [4:3]: 3328k2496 ¢2 [4K H 8M] 60 frames/second [3:2]: 3504k2336 [16:9]: 3840k2160 [4K 8M] ¢2...
Page 132 7. Drive/Shutter When you wish to capture an unpredictable photo opportunity Starts taking burst pictures when the shutter button [6K/4K Burst(S/S)] is pressed. Pressing the button again stops taking “S/S” is an abbreviation burst pictures. for start/stop. The start tone and stop tone are output. Audio recording: Available ¢...
Page 133 7. Drive/Shutter [6K/4K Burst(S/S)] Press the shutter button fully to start recording. Press the shutter button fully again to stop recording. C Start (First) D Stop (Second) E Recording is performed You can add markers by pressing [Q] during recording. (Up to 40 markers per recording) This allows you to skip to the positions where you added markers when selecting pictures from a 6K/4K burst file.
Page 134 7. Drive/Shutter The continuous recordable time varies depending on the [Picture Size / Burst Speed] setting. – [6K 18M]: 10 minutes – [4K H 8M]/[4K 8M]: 15 minutes The file save method differs depending on the type of card. – SDHC memory card, XQD card of 32 GB or less: A new file will be created to continue recording if the file size exceeds 4 GB.
Page 135: Notes On 6K/4K Photos
7. Drive/Shutter Notes on 6K/4K Photos Shutter Sound for Recording An electronic shutter is used for 6K/4K photo recording. You can set a shutter sound or beep tone in [Beep] of the [Setup] ([IN/OUT]) menu. (l 354) High-speed burst pictures can be taken quietly when used in combination with [Silent Mode].
Page 136 7. Drive/Shutter Camera Settings for 6K/4K Photo The settings are automatically switched to the optimal settings for 6K/4K photo recording. The following [Photo] menus are fixed: [Picture Quality] [FINE] [6K] (18 M) [Picture Size] ¢ [4K] (8 M) [Shutter Type] [ELEC.] 6K/4K burst files are taken using the following settings.
Page 137 7. Drive/Shutter The following functions are not available during 6K/4K photo recording: – HDMI output Using HDMI output results in the following: – [6K/4K Pre-Burst] changes to [6K/4K Burst]. – [Pre-Burst Recording] is not available. 6K/4K photo recording does not work while you are using the following functions: –...
Page 138: Selecting Pictures From A 6K/4K Burst File
7. Drive/Shutter Selecting Pictures from a 6K/4K Burst File Select a 6K/4K burst file on the playback screen. (l 260) ≥Select an image with the [ ] or ] icon and then press 3. ≥You can also perform the same operation by touching [ ] or If the images were recorded with [6K/4K Pre-Burst], proceed to Step...
Page 139 7. Drive/Shutter Save the picture. ≥Touch [ ] or [ ≥A confirmation screen appears. The picture is saved in JPEG format. The recording information (Exif information), such as the shutter speed, aperture, and ISO sensitivity, is also saved with the picture that is saved.
Page 140: Correcting Pictures After Recording (Post-Recording Refinement)
7. Drive/Shutter Correcting Pictures After Recording (Post-Recording Refinement) Correcting Distortion in Pictures ([Reduce Rolling Shutter]) When saving pictures, correct any distortion caused by the electronic shutter (rolling shutter effect). On the save confirmation screen in Step on page 139, touch [Reduce Rolling Shutter].
Page 141: Picture Selection Operations
7. Drive/Shutter Picture Selection Operations Picture Selection Slide View Screen Operations A Slide bar B Picture selection slide view C Position of displayed frame Button Touch Description of operation operation operation Selects a frame. Drag/ To change the frames displayed in the picture selection slide view, select the frame at the left/ right end and then touch [ ] or [...
Page 142 7. Drive/Shutter Switches to marker operation. Adds or deletes a marker. Displays the in-focus portion highlighted with color ([Focus Peaking]). Switches in the order of [OFF] > [ON]. Saves the picture. During marker operation, you can skip to set markers or the beginning or end of the 6K/4K burst file.
Page 143 7. Drive/Shutter Performs fast-forward playback or performs frame-by-frame forwarding (while paused). Performs fast-rewind playback or performs frame-by-frame rewinding (while paused). Selects the frame to display (while paused). Touch/drag Pinch out/ Enlarges or reduces the display (while paused). pinch in Selects a frame while maintaining the enlarged display (during enlarged display).
Page 144 7. Drive/Shutter Selecting and Saving Pictures Using a TV Screen 6K burst files are output to a TV connected via HDMI at a resolution of [4K]. Set [HDMI Mode (Playback)] of the [Setup] ([IN/OUT]) menu to either [AUTO] or a setting with a resolution of [4K].
Page 145: Recording With Time Lapse Shot
7. Drive/Shutter Recording with Time Lapse Shot Pictures are taken automatically at a set recording interval. This feature is ideal for keeping track of changes over time in subjects such as animals and plants. The pictures taken will be saved as a set of group images that can also be combined into a video.
Page 146 7. Drive/Shutter Starts recording when the shutter [Now] button is pressed fully. [Start Time] [Start Time Set] Starts recording at the set time. Sets the number of pictures and the recording interval to [Image Count]/ be taken. [Shooting [Shooting Interval] is not displayed when [Shooting Interval] Interval Setting] is set to [OFF].
Page 147 7. Drive/Shutter Operations during Time Lapse Shot Recording Pressing the shutter button halfway during sleep status will turn on the camera. You can perform the following operations by pressing [Q] during Time Lapse Shot recording. [Continue] Returns to the recording. (Only during recording) [Pause] Pauses the recording.
Page 148: Recording With Stop Motion Animation
7. Drive/Shutter Recording with Stop Motion Animation Take pictures while moving the subject little by little. The pictures taken will be saved as a set of group images that can be combined into a stop motion video. Set the drive mode dial to Set [Mode] to [Stop Motion Animation].
Page 149 7. Drive/Shutter Close the menu. ≥Press the shutter button halfway. Start recording. ≥Press the shutter button fully. ≥Take pictures repeatedly while moving the subject little by little. The recording screen displays up to two pictures taken previously. Use them as reference for the amount of movement.
Page 150 7. Drive/Shutter Group images containing pictures taken with [HLG Photo] cannot be converted to videos. Up to 9999 frames can be recorded. If the camera is turned off while recording, a message for resuming the recording is displayed when it is turned on. Selecting [Yes] allows you to continue the recording from the interruption point.
Page 151: Time Lapse Shot/Stop Motion Animation Videos
7. Drive/Shutter Time Lapse Shot/Stop Motion Animation Videos After performing Time Lapse Shot or stop motion recording, you can proceed to create a video. Refer to the sections below about these recording functions. – Time Lapse Shot recording: l – Stop motion recording: l You can also create videos with [Time Lapse Video] (l 364) or [Stop Motion Video] (l 364) in the [Playback] menu.
Page 152 7. Drive/Shutter Videos cannot be created if the recording time exceeds 29 minutes and 59 seconds. In the following cases, videos cannot be created if the file size exceeds 4 GB: – When an SDHC memory card or an XQD card of 32 GB or less is being used and the size for [Rec Quality] is set to [4K] –...
Page 153: Recording Using The Self-Timer
7. Drive/Shutter Recording Using the Self-timer Set the drive mode dial to [ Decide on the composition and then adjust the focus. ≥Press the shutter button halfway. The focus and exposure are fixed when the shutter button is pressed halfway. Start recording.
Page 154 7. Drive/Shutter Setting the Self-timer Time Select [Self Timer] Takes a picture after 10 seconds. Takes 3 pictures at approx. 2 second intervals after 10 seconds. Takes a picture after 2 seconds. This setting is a convenient way to avoid camera blur caused by pressing the shutter button.
Page 155: Bracket Recording
7. Drive/Shutter Bracket Recording When the shutter button is pressed, the camera can record multiple images while automatically changing the setting value for exposure, aperture, focus or white balance (adjustment value or color temperature). Aperture Bracket can be selected in the following modes: –...
Page 156 7. Drive/Shutter Setting Items ([Bracketing Type]) When the shutter button is pressed, the camera Exposure Bracket records while changing the exposure. (l 158) When the shutter button is pressed, the camera Aperture Bracket records while changing the aperture value. (l 158) When the shutter button is pressed, the camera ] Focus Bracket records while changing the focus position.
Page 157 7. Drive/Shutter Only Exposure Bracket is available when [Aspect Ratio] is set to [65:24] or [2:1]. White Balance Bracket and White Balance Bracket (Color Temperature) are not available when using the following functions: – [iA] mode – Taking burst pictures –...
Page 158 7. Drive/Shutter [More Settings] (Exposure Bracket) Sets the image count and exposure compensation step. [Step] [3•1/3] (record 3 images in 1/3 EV steps) to [7•1] (record 7 images in 1 EV steps) [Sequence] Sets the order in which images are recorded. ]: Takes only one image each time the shutter button is pressed.
Page 159 7. Drive/Shutter [More Settings] (Focus Bracket) Sets the focus adjustment step. [Step] The distance that the focus position is moved becomes shorter if the initial focus position is close, and longer if it is far away. Sets the image count. [Image Count] This cannot be set when taking burst pictures.
Page 160 7. Drive/Shutter [More Settings] (White Balance Bracket) Rotate to set the G G G G G G G correction step and then press Rotate to the right: A A A A A A B B B B B B B Horizontal direction ([A] to [B]) Rotate to the left: M M M M M M...
Page 161: Post-Focus Recording
7. Drive/Shutter Post-Focus Recording Taking burst pictures with the same image quality as 6K/4K photos while automatically changing the focus position. You can select the focus position for the picture to save after recording. Also Focus Stacking lets you combine images with multiple focus positions.
Page 162 7. Drive/Shutter Close the menu. ≥Press the shutter button halfway. Decide on the composition and then adjust the focus. ≥Press the shutter button halfway. ≥AF detects the focus position on the ± screen. (Excluding the edges of the  screen) If no areas on the screen can be brought into focus, the focus indication (A) blinks and recording is not possible.
Page 163 7. Drive/Shutter Limitations on Post-Focus Recording Since recording is performed with the same image quality as 6K/4K photos, limitations apply to recording functions and menus. For details, refer to “Camera Settings for 6K/4K Photo” on page 136. In addition to the limitations of 6K/4K photos, focus settings cannot be changed during Post-Focus recording.
Page 164: Selecting The Focus Position For The Picture To Save
7. Drive/Shutter Selecting the Focus Position for the Picture to Save Select a Post-Focus image on the playback screen. (l 260) ≥Select an image with the [ icon and then press 3. ≥You can also perform the same operation by touching the [ icon.
Page 165 7. Drive/Shutter Focus Position Selection Operations Button Touch Description of operation operation operation Selects a focus position. 3421/ Touch Selection is not possible during enlarged display. Enlarges the display. During enlarged display, you can fine-adjust the focus by dragging the slide bar. (You can also perform the same operation by pressing 21.) Reduces the display (during enlarged display).
Page 166: Focus Stacking
7. Drive/Shutter Focus Stacking Save a picture with multiple focus positions merged. A Focus: closer B Focus: more distant On the screen for selecting the focus position in Step page 164, touch [ ≥You can also perform the same operation by pressing [ Select the merging method.
Page 167 7. Drive/Shutter (When [Range Merging] is selected) Touch the points to be brought into focus. Select at least two points. Selected points are indicated with a green frame. The in-focus range between the two selected points is displayed in green. Ranges that cannot be selected are displayed in gray.
Page 168 7. Drive/Shutter Operations when [Range Merging] is Selected Button Touch Description of operation operation operation 3421 / Touch Selects a point. [Set/Cancel] Sets or cancels a point. Selects all points. [All] (Before selecting points) [DISP.] Cancels all selections. [Reset] (After selecting points) Merges the pictures and saves the resulting picture.
Page 169: [Silent Mode]
7. Drive/Shutter [Silent Mode] This disables all operation sounds and light output at once. The audio from the speaker will be muted and the flash and the AF assist lamp will be set to forced off mode. The following settings are fixed: –...
Page 170: [Shutter Type]
7. Drive/Shutter [Shutter Type] Select the shutter type to use for taking pictures. Select [Shutter Type] Switches the shutter type automatically depending on the [AUTO] recording conditions and shutter speed. [MECH.] Records with the mechanical shutter type. [EFC] Records with the electronic front curtain type. [ELEC.] Records with the electronic shutter type.
Page 171 7. Drive/Shutter The electronic front curtain type reduces blur caused by the shutter because the amount of vibration from the shutter is small compared to the mechanical shutter type. The electronic shutter type allows you to record without vibration from the shutter. When [ ] is displayed on the screen, recording will be with the electronic shutter type.
Page 172: Image Stabilizer
Image stabilizers that can be used will differ depending on the attached lens. Available image Example of screen Attached lens stabilizer display Panasonic lenses with image BodyrLens stabilization function (Dual I.S.2) Other manufacturer’s lenses with image stabilization Body or Lens...
Page 173 7. Drive/Shutter Using the Image Stabilizer When using a lens with an O.I.S. switch, set it to [ON]. When using lenses without a function for communicating with this camera, a message asking you to check the focal length setting is displayed after you turn on the camera.
Page 174: Image Stabilizer Settings
7. Drive/Shutter Image Stabilizer Settings Set the image stabilizer movement to match the recording situation. Select [Image Stabilizer] Sets the stabilization movement (blur) to match the [Operation Mode] recording method (normal, panning). (l 175) ([Body]) Uses the in-body image stabilizer. [Body(B.I.S.) / ([Lens]) Uses the in-lens image stabilizer.
Page 175 7. Drive/Shutter When the following functions are being used, [When to Activate] is fixed to [ALWAYS]: – [ ] ([Body(B.I.S.) / Lens(O.I.S.)]) – Video recording/[6K/4K PHOTO]/[Post-Focus] When the following function is being used, [E-Stabilization (Video)] is not available: – [High Speed Video] You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode]...
Page 176 7. Drive/Shutter You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Image Stabilizer] (l 279) [Boost I.S. (Video)] Increase the effectiveness of the image stabilizer during video recording. This effect can help provide a stable composition when you want to perform recording from a fixed perspective.
Page 177 7. Drive/Shutter [Focal Length Set] When using lenses without a function for communicating with this camera, manually set the focal length inscribed on the lens. Up to three focal length settings can be registered. Registered focal length settings can be called. Enter the focal length.
Page 178: Metering/Exposure/Iso Sensitivity
Metering/Exposure/ISO Sensitivity [Metering Mode] Type of optical measurement to measure brightness can be changed. Select [Metering Mode] Method in which the most suitable exposure is (Multi-metering) measured by judging the allocation of brightness on the whole screen. Method used to perform measuring which focuses on (Center-weighted) the center of the screen.
Page 179: Program Ae Mode
8. Metering/Exposure/ISO Sensitivity Program AE Mode In [P] mode (Program AE mode), the camera automatically sets the shutter speed and aperture value for the brightness of the subject. You can also use Program Shift to change combinations of shutter speed and aperture values while keeping the same exposure.
Page 180 8. Metering/Exposure/ISO Sensitivity Program Shift You can change the shutter speed and aperture value combination set automatically by the camera while maintaining the same exposure. With this, you can, for example, make the background more defocused by decreasing the aperture value or capture a moving subject more dynamically by slowing the shutter speed.
Page 181: Aperture-Priority Ae Mode
8. Metering/Exposure/ISO Sensitivity Aperture-Priority AE Mode In [A] mode (Aperture-Priority AE mode), you can set the aperture value before recording. The shutter speed will be automatically set by the camera. Smaller aperture values Larger aperture values It becomes easier to defocus the It becomes easier to bring everything into background.
Page 182 8. Metering/Exposure/ISO Sensitivity Depth of Field Characteristics Aperture value Small Large Focal length of lens Tele Wide ¢1 Distance to subject Near More distant Shallow (narrow) Deep (wide) Example: When you Example: When you Depth of field want to take a image want to take a image (area in sharp focus) with a defocused...
Page 183: Shutter-Priority Ae Mode
8. Metering/Exposure/ISO Sensitivity Shutter-Priority AE Mode In [S] mode (Shutter-Priority AE mode), you can set the shutter speed before recording. The aperture value will be automatically set by the camera. Slower shutter speeds Faster shutter speeds It becomes easier to capture motion It becomes easier to freeze motion Set the mode dial to [S].
Page 184 8. Metering/Exposure/ISO Sensitivity The effects of the set aperture value and shutter speed will not be visible on the recording screen. To check the effects on the recording screen, use [Preview]. (l 188) The brightness of the recording screen and of actual recorded images may differ.
Page 185: Manual Exposure Mode
8. Metering/Exposure/ISO Sensitivity Manual Exposure Mode In [M] mode (Manual Exposure mode), you can take pictures by manually setting the aperture value and shutter speed. In default settings, the ISO sensitivity is set to [AUTO]. As a result, the ISO sensitivity will be adjusted according to the aperture value and shutter speed.
Page 186 8. Metering/Exposure/ISO Sensitivity Available Shutter Speeds (Sec.) [MECH.] [B] (Bulb, max. approx. 30 minutes), 60 to 1/8000 [EFC] [B] (Bulb, max. approx. 30 minutes), 60 to 1/2000 [ELEC.] [B] (Bulb, max. approx. 60 seconds), 60 to 1/8000 The effects of the set aperture value and shutter speed will not be visible on the recording screen.
Page 187 8. Metering/Exposure/ISO Sensitivity [B] (Bulb) If you set the shutter speed to [B] (Bulb), the shutter stays open while the shutter button is pressed fully. (up to approx. 30 minutes) The shutter closes when the shutter button is released. Use this when you want to keep the shutter open for a long time to record images of fireworks, night scenery or a starry sky.
Page 188: Preview Mode
8. Metering/Exposure/ISO Sensitivity Preview Mode You can check the effects of aperture on the recording screen by physically closing the aperture blades of the lens to the aperture value set for actual recording. In addition to the effects of aperture, you can check the effects of shutter speed at the same time.
Page 189: Exposure Compensation
8. Metering/Exposure/ISO Sensitivity Exposure Compensation You can compensate the exposure when the correct exposure determined by the camera is too bright or too dark. You can adjust the exposure in 1/3 EV steps in a range of n5 EV. When recording videos or recording with 6K/4K Photo or Post-Focus, the range changes to n3 EV.
Page 190 8. Metering/Exposure/ISO Sensitivity In [M] mode, you can compensate the exposure by setting the ISO sensitivity to [AUTO]. When [Auto Exposure Comp.] is set to [ON], the flash output will automatically be set to the level appropriate to the exposure compensation. When the exposure compensation value falls below or exceeds n3 EV, the brightness of the recording screen will no longer change.
Page 191: Locking Focus And Exposure (Af/Ae Lock)
8. Metering/Exposure/ISO Sensitivity Locking Focus and Exposure (AF/AE Lock) Lock the focus and exposure in advance to take pictures with the same focus and exposure settings while changing the composition. This is useful when you want to bring an edge of the screen into focus or there is a backlight, for example.
Page 192: Setting The Iso Sensitivity
8. Metering/Exposure/ISO Sensitivity Setting the ISO Sensitivity You can set light sensitivity (ISO sensitivity). With the default settings, you can set ISO100 to 51200 in 1/3 EV increments. The range that can be set will differ depending on the functions used. Press [ISO].
Page 193 8. Metering/Exposure/ISO Sensitivity Setting Items (ISO Sensitivity) The ISO sensitivity is automatically adjusted according to the brightness. Confirm ISO sensitivity by pressing the shutter button [AUTO] halfway. Taking picture: Maximum [ISO6400] ¢1 Video recording: Maximum [ISO6400] ¢2 The ISO sensitivity is fixed at the selected value. You can extend the ISO sensitivity range in between [100] to [51200] a lower limit of L.50 and an upper limit of H.204800...
Page 194: White Balance/Image Quality
White Balance/Image Quality Setting the White Balance (WB) White balance (WB) is a function that corrects the color cast produced by the light illuminating the subject. It corrects the colors so that white objects appear in white to make the overall color closer to what is seen by the eye.
Page 195 9. White Balance/Image Quality Confirm your selection. ≥Press the shutter button halfway. Setting Items (White Balance) [AWB] Auto Auto (Reduces the reddish hue under an incandescent light [AWBc] source) Auto (Leaves the reddish hue under an incandescent light [AWBw] source) Clear sky [Ð] Cloudy sky...
Page 196 9. White Balance/Image Quality [AWB] will work within this range. Blue sky Cloudy sky (Rain) Shade Sunlight White fluorescent light Incandescent light bulb Sunrise and sunset Candlelight KlKelvin Color Temperature Under fluorescent lighting, LED lighting fixture, etc., the appropriate white balance will vary depending on the lighting type.
Page 197: Adjusting The White Balance
9. White Balance/Image Quality White Sets ([ ] to [ Take pictures of a white object under the light source of the recording location to adjust the white balance until it appears white. Press [WB] and then select any value from [ ] to [ Press 3.
Page 198 9. White Balance/Image Quality Select the white balance and then press 4. ≥The adjustment screen is displayed. Adjust the coloring. G G G G G G 2: [A] (AMBER: ORANGE) A A A A A A B B B B B B B 3: [G] (GREEN: GREENISH) 1: [B] (BLUE: BLUISH) M M M M M M...
Page 199: [Photo Style]
9. White Balance/Image Quality [Photo Style] You can select the finishing settings of images to suit your subjects and expression styles. The image quality can be adjusted for each Photo Style. Select [Photo Style] [Standard] The standard setting. A setting that produces a more vivid quality with [Vivid] higher saturation and contrast.
Page 200 9. White Balance/Image Quality A setting that minimizes overexposure by applying a gamma curve correction equivalent to Rec.709 to perform compression (knee [Like709] adjustment) of high-luminance areas. Rec.709 is an abbreviation of “ITU-R Recommendation BT.709”, a standard for high- definition broadcasting. [Standard(HLG)] ¢1 A setting used to record [HLG Photo].
Page 201 9. White Balance/Image Quality Adjusting the Image Quality Press 21 to select the type of Photo Style. Press 34 to select an item and then press 21 to adjust. Adjusted items are indicated with [¢]. ±0 ±0 Press ±0 ±0 When the image quality is adjusted, the ±0 - 5 - 5...
Page 202 9. White Balance/Image Quality [Low]/ [Standard]/ Sets the grain effect level. [Grain [High] Effect] ¢4 [Off] [Sharpness] Adjusts the outlines in the image. Adjusts the noise reduction effect. [Noise Increasing the effect may cause a slight drop in picture Reduction] resolution.
Page 203 9. White Balance/Image Quality Registering Settings in My Photo Style Press 21 to select the type of Photo Style. Adjust the image quality. My Photo Style displays the types of Photo Style at the top of image quality adjustment. Select the base Photo Style. Press [DISP.].
Page 204: [Filter Settings]
9. White Balance/Image Quality [Filter Settings] This mode records with additional image effects (filters). You can adjust the effect for each filter. In addition, you can simultaneously take pictures without effects. Set the [Filter Effect]. [Filter ≥ Settings] [Filter Effect] [SET] Select the filter.
Page 205 9. White Balance/Image Quality Filter Items that can be adjusted [Expressive] Vividness [Retro] Coloring [Old Days] Contrast [High Key] Coloring [Low Key] Coloring [Sepia] Contrast [Monochrome] Coloring [Dynamic Monochrome] Contrast [Rough Monochrome] Grittiness [Silky Monochrome] Defocus level [Impressive Art] Vividness [High Dynamic] Vividness [Cross Process]...
Page 206 9. White Balance/Image Quality Setting a Filter with Touch Operation The default settings are for the touch tab to not be displayed. Set the [Touch Tab] in [Touch Settings] to [ON]. (l 333) Touch [ EXPS EXPS EXPS Touch the item to set. EXPS EXPS EXPS...
Page 207 9. White Balance/Image Quality Setting the Type of Defocus ([Miniature Effect]) Set [Filter Effect] to [Miniature Effect]. Press 3 to display the setting screen. The setting screen can also be displayed by touching [ ] then [ Press 34 or 21 to move the in- focus portion.
Page 208 9. White Balance/Image Quality Setting the Color to Be Left ([One Point Color]) Set [Filter Effect] to [One Point Color]. Press 3 to display the setting screen. The setting screen can also be displayed by touching [ ] then [ Press 3421 to move the frame and select the color you want to leave.
Page 209: [Simultaneous Record W/O Filter]
9. White Balance/Image Quality [Simultaneous Record w/o Filter] You can simultaneously take pictures with no added filter effects. [Filter Settings] Select [Simultaneous Record w/ o Filter] Settings: [ON]/[OFF] [Simultaneous Record w/o Filter] is not available when using the following functions: –...
Page 210: [High Resolution Mode]
9. White Balance/Image Quality [High Resolution Mode] This merges pictures with a high resolution from multiple recorded images. This function is suitable for recording subjects that do not move. Merged pictures will be saved as RAW files with a maximum image size of 96 M.
Page 211 9. White Balance/Image Quality Decide on the composition and then fix the camera in place. If blurring is detected, the High Resolution mode icon A blinks. Start recording. ≥Press the shutter button fully. With the default settings, [Shutter Delay] is activated, so there will be a gap in time from when the shutter button is pressed until the shutter is released.
Page 212 9. White Balance/Image Quality Setting Items ([High Resolution Mode]) [Start] Starts High Resolution mode. [Simul Record Simultaneously takes pictures that are not merged when [ON] is Normal Shot] set. The first picture will be saved with [Picture Size] set to [L]. Sets the delay time from when the shutter button is pressed until [Shutter Delay] the shutter is released.
Page 213 9. White Balance/Image Quality In [High Resolution Mode], the following functions are restricted: – [Shutter Type]: Fixed to [ELEC.] – Minimum aperture value: F16 – Shutter speed: 1 second to 1/8000 of a second – ISO sensitivity: Up to [ISO3200] –...
Page 214: [Hlg Photo]
9. White Balance/Image Quality [HLG Photo] Records an HLG format picture with a wide dynamic range. Bright lights that are easily overexposed, and dark areas that are easily underexposed can be recorded showing fine quality and rich colors just as seen with the human eyes.
Page 215 9. White Balance/Image Quality The monitor and viewfinder on this camera do not support display of HLG format images. With [HLG View Assist] in the [Custom] ([Monitor / Display]) menu, you can display images that have been converted for confirmation on the monitor/ viewfinder of the camera or a device connected via HDMI.
Page 216: Flash
Flash Using an External Flash (Optional) If you attach the Flash (DMW-FL580L/DMW-FL360L/DMW-FL200L: optional) to the hot shoe, you can record using the flash. You can also use a commercially available external flash by connecting a commercially available synchro cable to the flash synchro socket. Furthermore, by attaching a compatible external flash to the camera, you can wirelessly control external flashes placed in positions away from the camera.
Page 217 10. Flash Connecting a Synchro Cable to the Flash Synchro Socket You can use a commercially available external flash by connecting a commercially available synchro cable to the flash synchro socket. The socket has a lock screw to prevent the cable from falling off. Before connecting the synchro cable to the flash synchro socket, remove the flash synchro socket cap.
Page 218 10. Flash Notes on Flash Recording Do not bring any object near the flash. Heat or light may cause the object to deform or discolor. If you record repeatedly, time may be needed to charge the flash. While the flash is charging, images will be recorded without the flash firing. When an external flash is attached, do not carry the camera by holding only the external flash.
Page 219: Setting Flash Functions
Firing mode cannot be set when using a Flash (DMW-FL580L/DMW-FL360L/ DMW-FL200L: optional). It can be set only when using an external flash that does not use a battery (supplied with some models of Panasonic digital cameras). Set the [Firing Mode].
Page 220: [Flash Mode]
10. Flash (When set to [MANUAL]) Select [Manual Flash Adjust.] and then press Press 21 to set the flash output and then press It can be set within the range of [1/1] (full flash output) to [1/64] in 1/3 steps. [Flash Mode] Set the flash mode.
Page 221 10. Flash (Forced Flash The flash fires every time regardless of the recording [‰] conditions. This is suitable for recording when there is backlighting (Forced On/Red- or under lighting such as fluorescent light. Eye) When recording images against a dark background (Slow Sync.) landscape, this feature will slow the shutter speed when the flash fires.
Page 222 10. Flash Available flash settings by recording mode The available flash settings depend on the recording mode. ( : Available, —: Not available) Recording ‰ Œ mode [P]/[A] [S]/[M] — — In [iA] mode, this will be [ Shutter speeds for flash modes [Flash Mode] Shutter speed (sec.) ‰...
Page 223: [Flash Synchro]
10. Flash [Flash Synchro] When a moving subject is recorded at night using a slow shutter and flash, a trail of light may appear in front of the subject. If you set [Flash Synchro] to [2ND], you can take a dynamic picture with a trail of light appearing behind the subject by firing the flash immediately before the shutter closes.
Page 224: Adjusting The Flash Output
10. Flash Adjusting the Flash Output You can adjust the flash output when taking pictures with the flash in TTL output mode. Select [Flash Adjust.]. [Flash ≥ Adjust.] Press 21 to adjust the flash output and then press It can be adjusted within the range of [j3 EV] to [i3 EV] in 1/3 EV steps.
Page 225: [Auto Exposure Comp.]
10. Flash [Auto Exposure Comp.] Automatically adjust the flash output in conjunction with the exposure compensation value. (l 189) Select [Auto Exposure Comp.] Settings: [ON]/[OFF] [Red-Eye Removal] When [Flash Mode] is set to [ ] or [ ], the camera automatically detects red-eye and corrects image data.
Page 226: Recording Using A Wireless Flash
10. Flash Recording Using a Wireless Flash You can use a Flash (DMW-FL580L/DMW-FL360L/DMW-FL200L: optional) to record using a wireless flash. You can separately control the firing of three flash groups and the flash attached to the hot shoe of the camera. Placing a Wireless Flash Place the wireless flash with its wireless sensor facing the camera.
Page 227 10. Flash Attach an external flash to the camera. (l 216) Set the wireless flashes to [RC] mode and then place them. Set the channel and group for the wireless flashes. Enable the wireless flash function of the camera. [Wireless] ≥...
Page 228 10. Flash Setting Items ([Wireless Setup]) To fire a test flash, press [DISP.]. [TTL]: The camera automatically sets the flash output. [AUTO] ¢2 : Sets the flash output on the external flash side. [Firing [MANUAL]: Sets the flash output of the external flash Mode] manually.
Page 229 10. Flash You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Wireless Flash Setup] (l 279) [Wireless FP] The external flash performs FP firing (repeated high-speed firing of the flash) during wireless recording, enabling recording using the Flash even at fast shutter speeds.
Page 230: Recording Videos
Recording Videos Recording Videos This camera can record 4K videos in MP4 format and full high-definition videos that comply with the AVCHD standard. Furthermore, the Creative Video mode, especially created for video recording, enables you to record using settings for exposure, white balance, etc., especially suited to video.
Page 231 11. Recording Videos The available recording time can be displayed during recording standby: [Photos/Videos Remaining] (l 345) You can switch the live view angle of view to the angle of view for video recording: [Photo/Video Preview] (l 344) Exposure Control While Video Recording Videos will be recorded using the aperture, shutter speed, and ISO sensitivity settings below.
Page 232: Playback
11. Recording Videos If an operation such as a zoom or button operation is performed during video recording, that operation sound may be recorded. The functions available during the video recording differ depending on the lens you are using. Also, the lens operation sound may be recorded. If the operation sound of pressing the video rec.
Page 233: Video Settings
Playback on other than this camera requires a playback device that supports HEVC/H.265. This is available in [ ] mode. (l 244) You can play back videos recorded with [MP4 HEVC] on Panasonic TVs that support 4K/HDR (HLG format). You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Motion Pic.
Page 234: [Rec Quality]
11. Recording Videos [Rec Quality] Sets the video recording image quality. This camera can record videos in 4K (3840k2160) or full high-definition (1920k1080) resolution. The image quality settings that can be selected vary depending on the [Rec. File Format] setting. Select [Rec Quality] [Rec.
Page 235: Playback
11. Recording Videos [Rec. File Format]: [MP4] Audio Frame [Rec Quality] Resolution Bit rate YUV/bit compression rate method [4K/LPCM/150M/ 3840k2160 150 Mbps 4:2:0/8 bit LPCM ¢3, 4 60p] [4K/100M/30p] 3840k2160 100 Mbps 4:2:0/8 bit [4K/100M/24p] 3840k2160 100 Mbps 4:2:0/8 bit [FHD/28M/60p] 1920k1080 28 Mbps...
Page 236 11. Recording Videos All videos will be recorded using Long GOP to compress the images. The higher the bit rate value is, the higher the image quality becomes. Since the camera employs the VBR recording format, the bit rate is changed automatically depending on the subject to record.
Page 237 11. Recording Videos Size Interval for Dividing Files [Rec. File Format] [Rec Quality] Size interval for dividing files A new file will be created to continue recording if the file size exceeds 4 GB. [AVCHD] The files recorded can be played back continuously.
Page 238: [Image Area Of Video]
11. Recording Videos [Image Area of Video] Set the image area during video recording. The angle of view differs depending on the image area. Narrowing the image area allows you to achieve a telescopic effect without image deterioration. Select [Image Area of Video] Angle of Telescopic Item...
Page 239: [Continuous Af]
11. Recording Videos Image area (Ex.: FHD video) FULL APS-C PIXEL/PIXEL When the following functions are being used, [Image Area of Video] is fixed to [APS-C]: – [4K/LPCM/150M/60p] ([Rec Quality]) – [60/30p 4K]/[48/23.98p 4K] ([High Speed Video]) When the following functions are being used, [PIXEL/PIXEL] is not available: –...
Page 240: [Af Custom Setting(Video)]
11. Recording Videos If you press the shutter button halfway while recording a video, the camera will re-adjust the focus. Depending on the recording conditions or lens used, the AF operation sound may be recorded during video recording. If the operation sound bothers you, we recommend recording with [Continuous AF] set to [OFF].
Page 241: [Luminance Level]
11. Recording Videos [Luminance Level] You can set the luminance range to suit the purpose of video recording. This can be set when [Rec. File Format] is set to [MP4]. Select [Luminance Level] Settings: [0-255]/[16-255] This is fixed to [16-255] when [Rec. File Format] is set to [AVCHD], and [64-940] when set to [MP4 HEVC].
Page 242 11. Recording Videos Press [Q]. Select a knee setting. ≥Press 21 to select a setting item. Adjusts the compression levels of high-luminance areas [AUTO] automatically. Allows you to adjust the master knee point and master knee slope manually. Press 34 to select an item and then press 21 to adjust.
Page 243: Displaying/Setting The Sound Recording Level
11. Recording Videos Displaying/Setting the Sound Recording Level [Sound Rec Level Disp.] The sound recording level is displayed on the recording screen. Select [Sound Rec Level Disp.] Settings: [ON]/[OFF] When [Sound Rec Level Limiter] is set to [OFF], [Sound Rec Level Disp.] is fixed to [ON].
Page 244: Creative Video Mode
11. Recording Videos Creative Video Mode The [ ] mode (Creative Video mode) is a recording mode used exclusively for video recording. In this mode, you can perform the same exposure operations as in [P]/[A]/[S]/[M] modes. Change the exposure and audio settings with touch operation to prevent operation sounds from being recorded.
Page 245 11. Recording Videos You can register functions to Fn buttons: [Fn Button Set] [Setting in REC mode] [Exposure Mode] (l 279) You can set the upper and lower limits for ISO auto when recording in Creative Video mode. [ISO Sensitivity (video)] (l 319) Operations During Video Recording Change the exposure and audio settings with touch operation to prevent operation sounds from being recorded.
Page 246: [Creativevideo Combined Set.]
11. Recording Videos [CreativeVideo Combined Set.] In default settings, settings such as exposure and white balance changed in [ ] mode are also reflected in picture recording in [P]/[A]/[S]/[M] modes. From the [CreativeVideo Combined Set.] menu, you can separate settings for video recording and for picture recording.
Page 247: [High Speed Video]
11. Recording Videos [High Speed Video] Records slow videos of MP4 format by performing ultra-high-speed recording. Use a card rated at UHS Speed Class 3 or higher when using an SD card for this function. Select [High Speed Video] Frame rate [Rec Quality] Item Slow motion effect...
Page 248: Recording Hlg Videos
11. Recording Videos Recording HLG Videos Record videos with the wide dynamic range of the HLG format. You can record in very bright light where overexposure can occur or in dark areas where underexposure can occur, maintaining the rich yet subtle colors you can see with your naked eye.
Page 249: Recording Videos Using A Connected External Device
11. Recording Videos Recording Videos Using a Connected External Device External Monitor/Recorder ([HDMI Rec Output]) You can record while outputting the camera images to an external monitor or external recorder connected with an HDMI cable. HDMI output control differs between during recording and during playback. Refer to page for settings during playback.
Page 250 11. Recording Videos Use a “High Speed HDMI cable” with the HDMI logo. Cables that do not comply with the HDMI standards will not work. “High Speed HDMI cable” (Type A–Type A plug, up to 1.5 m (4.9 feet) long) Attaching the Cable Holder Use of the supplied cable holder prevents detachment of the cable and damage to the terminals.
Page 251 11. Recording Videos Fit the USB connection cable (C–C or A–C) (F) and HDMI cable (G) to the clamp. Slide the clamp portion (H) to attach it to the cable holder. Connect the USB connection cable (C–C or A–C) to the USB port (I). Connect the HDMI cable to the [HDMI] socket (J).
Page 252 11. Recording Videos Images Output via the [HDMI] Socket (Sorted by Recording Mode) Recording Mode iA/P/A/S/M Output is in accordance with the [Aspect Ratio] setting in the [Photo] ([Image Quality]) menu. Aspect ratio Output is in accordance with With other than [16:9], the [Rec Quality] setting in the pictures are output with [Video] ([Image Format])
Page 253 11. Recording Videos Setting the Information Display During HDMI Output Select whether or not to output the information display of the camera to an external device connected via HDMI. [HDMI Rec Output] Select [Info Display] Settings: [ON]/[OFF] When you use the HDMI output during recording, the image may be displayed with a time lag.
Page 254: External Microphones (Optional)
11. Recording Videos External Microphones (Optional) With a Stereo Shotgun Microphone (DMW-MS2: optional) or Stereo Microphone (VW-VMS10: optional), you can record higher-quality audio compared to the built-in microphone. Set the [Mic Socket] that suits the device to be connected. [Mic Socket] ≥...
Page 255 11. Recording Videos Connect the camera and external microphone. If mounting the external microphone on the camera hot shoe A, remove the hot shoe cover. (l 216) Do not use the stereo microphone cables with the length of 3 m (9.8 feet) or more.
Page 256 11. Recording Videos You can register a function with the Fn button: [Fn Button Set] [Setting in REC mode] [Mic. Directivity Adjust] (l 279) Reduction of Wind Noise This reduces wind noise when an external microphone is connected. Select [Wind Cut] Settings: [HIGH]/[STANDARD]/[LOW]/[OFF] While the external microphone is connected, [ ] is displayed on the screen.
Page 257: Xlr Microphone Adaptor (Optional)
11. Recording Videos XLR Microphone Adaptor (Optional) By attaching an XLR Microphone Adaptor (DMW-XLR1: optional) to the camera, you can use a commercially available XLR microphone to enable the recording of superior-quality stereo audio. A Hot shoe B Commercially available XLR microphone Getting started: Turn off the camera, and remove the hot shoe cover.
Page 258: Headphones
11. Recording Videos When [XLR Mic Adaptor Setting] is set to [ON], the following settings are fixed: – [Sound Rec Level Limiter]: [OFF] – [Wind Noise Canceller]: [OFF] – [Special Mic.]: [STEREO] – [Sound Output]: [REC SOUND] [Sound Rec Level Adj.] cannot be used when [XLR Mic Adaptor Setting] is set to [ON].
Page 259: Playback
11. Recording Videos Switching the Sound Output Method Select [Sound Output] Audio without time lag. [REALTIME] It may differ from the sound recorded in videos. Audio to be recorded in videos. [REC SOUND] Output sound may be delayed from actual sound. When recording with an HDMI connection, this is fixed to [REC SOUND].
Page 260: Playing Back And Editing Of Images
Playing Back and Editing of Images This chapter explains the playing back and editing of images. Refer to “[Playback] Menu” starting on page for details about protection, ratings, and other playback and editing functions. Playing Back Pictures Display the playback screen. ≥Press [(].
Page 261: Playback
12. Playing Back and Editing of Images Stop playback. ≥Press the shutter button halfway. ≥You can also stop playback by pressing [(]. Switching the Card to Display Images are displayed separately by card slot. To switch the card to display, after pressing [ ], press 34 to select [Card Slot 1(XQD)] or [Card Slot 2(SD)], and then press You can transfer pictures to a smartphone connected by Bluetooth by pressing...
Page 262: Playing Back Videos
12. Playing Back and Editing of Images Playing Back Videos Display the playback screen. ≥Press [(]. Select a video. 8m30s 8m30s 8m30s For information about how to select images, refer to page 260. The [ ] video icon is displayed for a video.
Page 263: Playback
12. Playing Back and Editing of Images Operations During Video Playback Button Touch Description of operation operation operation Plays/pauses. Stops. Performs fast-rewind playback. If you press 2 again, the fast-rewind speed increases. Performs frame-by-frame rewinding (while paused). During the playback of AVCHD video, frame- by-frame rewinding will be at an approx.
Page 264: Extracting A Picture
12. Playing Back and Editing of Images Extracting a Picture Extract one frame of a video and save it as a JPEG image. Pause playback at the position you wish to extract a picture. ≥Press 3. To fine-adjust the position, press 21 (frame-by-frame forward or frame-by- frame rewind).
Page 265: Switching The Display Mode
12. Playing Back and Editing of Images Switching the Display Mode You can use features to do things like enlarge recorded images for display and switch to thumbnail display to display multiple images at once (multi- playback). You can also switch to Calendar display to show images of a selected recording date.
Page 266 12. Playing Back and Editing of Images Operations During Enlarged Display Button Touch Description of operation operation operation Enlarges/reduces the screen. Pinch out/ Enlarges/reduces the screen in small steps. pinch in Moves the enlarged display position. Drag Positions can be moved to the diagonal 3421 directions using the joystick.
Page 267: Thumbnail Screen
12. Playing Back and Editing of Images Thumbnail Screen Switch to thumbnail display. 1/999 to the left. ≥Rotate ≥The display is switched in the order of 12-image screen 30-image screen. A Card An orange frame is shown around the selected image. Rotating to the left during 30-image screen display switches to calendar display.
Page 268: Calendar Playback
12. Playing Back and Editing of Images Calendar Playback Switch to Calendar Playback. to the left. ≥Rotate 2019 ≥The display is switched in the order of thumbnail screen (12 images) thumbnail screen (30 images) Calendar Playback. Rotating to the right returns to the previous display. Select the recording date.
Page 269: Group Images
12. Playing Back and Editing of Images Group Images Images recorded with Time Lapse Shot or Stop Motion Shooting are handled as group images in the camera, and can be deleted and edited on a group basis. (For example, if you delete a group image, all images in the group are deleted.) You can also delete and edit each image in a group individually.
Page 270: Deleting Images
12. Playing Back and Editing of Images Deleting Images Images cannot be restored once they have been deleted. Carefully confirm the images before deletion. You can only delete the images in the card of the selected card slot. If you delete a group image, all images in the group are deleted. [Delete Single] Press [ ] in playback state.
Page 271 12. Playing Back and Editing of Images To switch the card selected for deleting images, press [ ] and then select the card slot. Depending on the number of images to be deleted, it may take some time to delete them. You can register functions to Fn buttons: [Fn Button Set] [Setting in PLAY mode]...
Page 272: [Raw Processing]
12. Playing Back and Editing of Images [RAW Processing] This processes pictures taken in RAW format on the camera and saves them in JPEG format. You can also save images recorded with [HLG Photo] in the RAW format as HLG format. Select [RAW Processing].
Page 273 12. Playing Back and Editing of Images Change the setting. , or ≥Rotate The image can be enlarged/reduced by pinching out/pinching in the screen. DISP. - 2 - 2 - 1 - 1 +1 +1 +2 +2 Confirm the setting. ≥Press ≥The screen of Step reappears.
Page 274 12. Playing Back and Editing of Images Setting Items ([RAW Processing]) [Begin Processing] Saves the image. Selects and adjusts the white balance. Selecting the item with [ ] enables processing with the same setting as at the time of recording. [White Balance] If you press 4 in the [White Balance] selection screen, the white balance adjustment screen appears.
Page 275 12. Playing Back and Editing of Images [Revert To Original]: Returns the settings to the ones from the time of recording. [File Format]: Selects a file format from [JPG] or [HLG]. (Only images recorded with [HLG Photo]) [Color Space]: Selects a Color Space setting from [sRGB] and [Adobe RGB].
Page 276 12. Playing Back and Editing of Images Displaying a Comparison Screen You can change a setting while checking the effect by displaying images with the applied setting value side by side. Press [DISP.] in the screen of Step The image with the current setting A is displayed at the center.
Page 277: [Video Divide]
12. Playing Back and Editing of Images [Video Divide] Divide a recorded video or 6K/4K burst file into two. Images cannot be returned to their original state once they have been divided. Carefully confirm the images before performing the divide operation. Do not remove the card or battery from the camera during the divide process.
Page 278: Camera Customization
Camera Customization This chapter explains the customization function with which you can configure the camera to your preferred settings. Change how buttons, dials, etc. on the camera are to be operated. Fn buttons Fn lever Dials Register the currently set information of the camera. Custom mode Change menu display items.
Page 279: Fn Buttons
13. Camera Customization Fn Buttons You can register functions to the Fn (Function) buttons. Additionally, you can register other functions to specialized buttons such as [WB], in the same way as with the Fn buttons. Different functions can be set for both during recording and playback. V.MODE AF ON : Fn9...
Page 280: Register Functions To The Fn Buttons
13. Camera Customization Register Functions to the Fn Buttons With default settings, [Fn8] to [Fn12] on the joystick cannot be used. When using functions, set the [Joystick Setting] to [Fn]. (l 337) Select [Fn Button Set]. [Fn Button ≥ Set] [Setting in REC mode]/ [Setting in PLAY mode] Select the button.
Page 281 13. Camera Customization Register the function. ≥Press 34 to select a function and then press ≥Selection is also possible by rotating Select items with [N] by selecting the item again. Depending on the button, some functions cannot be registered. You can also touch [ ] on the control panel (l 68) to display the screen in Step You can also press and hold the Fn button (2 sec.) to display the screen in...
Page 282 13. Camera Customization Setting Items ([Fn Button Set]/[Setting in REC mode]) [1] Tab [Image Quality] [Focus/Shutter] – [Exposure Comp.] (l 189) – [AF Mode/MF] (l 98) ¢ ¢ – [Sensitivity] (l 192) – [AF Custom Setting(Photo)] (l 96) [ISO] ¢ –...
Page 283: Playback
13. Camera Customization [2] Tab [Image Format] [Monitor / Display] – [Motion Pic. Rec Format] (l 233) – [Preview] (l 188) – [Motion Pic. Rec Quality] (l 234) [Fn2] ¢ – [Constant Preview] (l 339) – [Level Gauge] (l 339) [Audio] ¢...
Page 284: Playback
13. Camera Customization For details about some of the functions, refer to the section below. [1 Shot Spot Records with the metering mode set to [ ] (Spot Metering] metering) once only. Records a RAW image and a JPEG image simultaneously [1 Shot RAW+JPG] once only.
Page 285: Playback
13. Camera Customization Setting Items ([Fn Button Set]/[Setting in PLAY mode]) [1] Tab [Playback Mode] [Operation] – [Magnify from AF Point] (l 363) – [Rec / Playback Switch] (l 286) – [HLG View Assist (Monitor)] (l 347) – [LVF/Monitor Switch] (l 67) [LVF] ¢...
Page 286: Use The Fn Buttons
13. Camera Customization For details about some of the functions, refer to the section below. [Rec / Playback Switches to the recording screen. Switch] Displays the screen to select pictures to save from a 6K/4K [6K/4K Photo Play] burst file. Use the Fn Buttons During recording, pressing the Fn buttons enables usage of the functions registered in [Setting in REC mode], and during playback, usage of the...
Page 287: Fn Lever
13. Camera Customization Fn Lever You can register a function with the Fn (function) lever. The registered function can be enabled instantly by toggling the Fn lever. In default settings, [Silent Mode] is registered. Register a Function to the Fn Lever Register the function and setting value that operate for when the Fn lever is switched to [MODE2].
Page 288 13. Camera Customization Select a setting value. ≥Press 34 to select a setting value and then press Setting Items ([Function of Fn Lever]) – [AF Mode] (l 98) – [Focus Ring Lock] (l 330) – [Photo Style] (l 199) – [Touch Screen] (l 64) –...
Page 289: Use The Fn Lever
13. Camera Customization Use the Fn Lever Turning the lever to the [MODE2] position enables the function registered with the Fn lever. Switching the Fn lever. The registered function is MODE2 enabled. Depending on the recording mode and camera settings, some registered functions may not work.
Page 290: [Dial Operation Switch]
13. Camera Customization [Dial Operation Switch] This temporarily changes the functions operated with (front dial) and (rear dial). Register Functions to the Dials Register functions to each of Select [Dial Operation Switch Setup]. [Dial Set.] ≥ [Dial Operation Switch Setup] Register the function.
Page 291: Temporarily Change Dial Operation
13. Camera Customization Temporarily Change Dial Operation Use the Fn button to temporarily change dial operation. Set [Dial Operation Switch] to the Fn button. (l 279) Switch dial operation. ≥Press the Fn button set in Step ≥A guide will display the functions registered to If no operations are performed, then several seconds later, the guide...
Page 292: Quick Menu Customization
13. Camera Customization Quick Menu Customization You can change Quick menu items depending on the recording mode. Additionally, you can change the items to display on the Quick menu and their order to suit your preferences. For information about Quick menu operation methods, refer to page 71. Register to the Quick Menu Change the menus to be displayed in the Quick menu.
Page 293 13. Camera Customization Find the function to register. to select the sub tab ≥Rotate where the function to register is categorized (l 294) and then press ≥You can also select by pressing 2 to select the sub tab, pressing 34 or rotating , and then pressing 1.
Page 294 13. Camera Customization Menu Items That Can Be Registered [1] Tab [Image Quality] [Others (Photo)] – [Exposure Comp.] (l 189) – [Drive Mode] (l 125) – [Sensitivity] (l 192) – [Bracketing] (l 155) – [White Balance] (l 194) – [Silent Mode] (l 169) –...
Page 295 13. Camera Customization [2] Tab [Monitor / Display] [Lens / Others] – [Constant Preview] (l 339) – [Focus Ring Control] (l 348) – [Level Gauge] (l 339) – [Histogram] (l 340) [Card/File] – [Photo Grid Line] (l 341) – [Card Slot Change] (l 261) –...
Page 296: Custom Mode
13. Camera Customization Custom Mode Recording modes and menu settings that match your preferences can be registered in Custom mode. You can use registered settings by switching the mode dial to [C1] to [C3] modes. Register in Custom Mode You can register the currently set information of the camera. At the time of purchase, the default settings of the [P] mode menus are registered with all Custom modes.
Page 297 13. Camera Customization Custom Mode Detailed Settings Set the ease of use of Custom mode. You can create additional Custom mode sets, and how long to retain temporarily changed settings details. Select [Custom Mode Settings] Sets the number of Custom modes that can be registered in [Limit No.
Page 298: Using Custom Mode
13. Camera Customization Using Custom Mode Set the mode dial to one of [C1] to [C3]. ≥If [C3], the last-used Custom mode will be called up. [C3] Custom Mode Selection Set the mode dial to [C3]. Press The Custom mode selection menu appears. Press 34 to select the Custom mode and then press The selected Custom mode icon will be...
Page 299: Calling Settings
13. Camera Customization Calling Settings Call registered Custom mode settings to the selected recording mode and overwrite the current settings with these. Set to the mode dial to use. Select [Load Custom Mode]. [Load ≥ Custom Mode] Select the Custom mode to call.
Page 300: My Menu
13. Camera Customization My Menu Register frequently-used menus in My Menu. A maximum of 23 items can be registered. Registered menus can be called up from [ ] to [ Registration in My Menu Select a menu, and register this in My Menu. Select [Add].
Page 301: Edit My Menu
13. Camera Customization Edit My Menu You can reorder the display order of My Menu, and delete unnecessary menus. Select [ Selects and registers the menus to be displayed in My [Add] Menu. Changes the order of My Menu. [Sorting] Select the menu to change, then set the destination.
Page 302: [Save/Restore Camera Setting]
13. Camera Customization [Save/Restore Camera Setting] Saves the camera’s settings information to the card. Saved settings information can be loaded to the camera, letting you set the same settings on multiple cameras. Select [Save/Restore Camera Setting] Settings: [Card Slot 1(XQD)]/[Card Slot 2(SD)] Saves the camera’s settings information to the card.
Page 303: Menu Guide
Menu Guide This chapter provides a menu list and default settings. Menus explained in detail in other chapters are indicated with page numbers. For information about menu operation methods, refer to page 73. For information about methods of entering characters, refer to page 369. [Photo] Menu (l 304) [Setup] Menu (l 349) [Video] Menu (l 318)
Page 304: [Photo] Menu
14. Menu Guide [Photo] Menu [Flash Synchro] [Image Quality] [Manual Flash Adjust.] [Photo Style] [Auto Exposure Comp.] [Metering Mode] [Red-Eye Removal] [Aspect Ratio] [Wireless] [Picture Quality] [Wireless Channel] [Picture Size] [Wireless FP] [HLG Photo] [Communication Light] [High Resolution Mode] [Wireless Setup] [Long Exposure NR] [Others (Photo)] [ISO Sensitivity (photo)]...
Page 305 14. Menu Guide : Default settings [Image Quality] [Standard]/[Vivid]/[Natural]/[Flat]/[Landscape]/ [Portrait]/[Monochrome]/[L.Monochrome]/ [L.Monochrome D]/[Cinelike D]/[Cinelike V]/ [Like709]/[Standard(HLG)]/[Monochrome(HLG)]/ [Photo Style] [MY PHOTO STYLE 1] to [MY PHOTO STYLE 10] You can select the finishing settings of images to suit your subjects and expression styles. Type of optical measurement to measure [Metering Mode] brightness can be changed.
Page 306 14. Menu Guide [Image Quality] [ON]/[OFF] The camera automatically removes noise generated when recording images with a slow shutter speed. The next picture cannot be taken during noise [Long Exposure — removal. When the following functions are being used, [Long Exposure NR] is not available: –...
Page 307 14. Menu Guide [Image Quality] [AUTO]/[1/8000] to [1/1] Sets the minimum shutter speed when the ISO [Min. Shutter sensitivity is set to [AUTO]. — Speed] The shutter speed may become slower than the set value in recording situations where correct exposure cannot be achieved.
Page 308 14. Menu Guide [Image Quality] [ON]/[OFF] When the screen periphery darkens as a result of the lens characteristics, you can record pictures with the brightness of the screen periphery corrected. Compensation effect may not be achieved — depending on the recording conditions. [Vignetting Comp.] Noise in the periphery of the picture may stand out with higher ISO sensitivity.
Page 309 14. Menu Guide [Focus] [Set 1]/[Set 2]/[Set 3]/[Set 4] [AF Custom Select features of AF operation when recording Setting(Photo)] using [AFC] that are appropriate for the subject and scene. [ON]/[OFF] When recording in low light conditions, pressing the shutter button halfway lights the AF assist lamp, making it easier for the camera to focus.
Page 310 14. Menu Guide [Focus] [ON]/[OFF] [SET] [Focus Peaking Sensitivity] [Display Color] [Display While AFS] During MF operation, in-focus portions (portions on the screen with clear outlines) are highlighted with color. If the [Focus Peaking Sensitivity] is adjusted to the negative direction, portions to be highlighted are reduced, allowing you to achieve a more —...
Page 311 14. Menu Guide [Focus] [FAST]/[NORMAL] Sets the speed when moving a single AF area. [1-Area AF Moving — This operates when AF mode is set to [ ], [ Speed] or [ This menu item can be registered to the Fn button.
Page 312 14. Menu Guide [Flash] [ON]/ [OFF] When [Flash Mode] is set to [ ] or [ ], the [Red-Eye Removal] camera automatically detects red-eye and corrects image data. [ON]/ [OFF] [Wireless] Enables recording using a wireless flash. [1CH]/[2CH]/[3CH]/[4CH] [Wireless Channel] Sets the channel to use when recording with a wireless flash.
Page 313 14. Menu Guide [Others (Photo)] [Bracketing Type] ]/ [OFF] [Bracketing] [More Settings] You can take multiple pictures while automatically adjusting a setting. [ON]/ [OFF] [Silent Mode] Disables all operation sounds and light output at once. [Operation Mode] ]/[OFF] [Body(B.I.S.) / ]/ [ Lens(O.I.S.)] [When to Activate]...
Page 314 14. Menu Guide [Others (Photo)] [8SEC]/[4SEC]/[2SEC]/[1SEC]/ [OFF] To reduce camera shake and shutter-induced blur, the shutter is released after the specified time has [Shutter Delay] — passed since the shutter button was pressed. When the following functions are being used, [Shutter Delay] is not available: –...
Page 315 14. Menu Guide [Others (Photo)] [ON]/ [OFF] Detects flickering such as that under fluorescent lighting, and records using a timing that minimizes this. The reduction effect may not be obtained depending on the recording conditions. When Flicker Decrease is operating, the [Flicker Decrease [FLICKER] icon will be displayed in yellow on —...
Page 316 14. Menu Guide [Others (Photo)] [6K 18M]/[4K 8M]/ [OFF] Taking burst pictures with the same image quality as 6K/4K photos while automatically changing the [Post-Focus] focus position. You can select the focus position for the picture to save after recording. [Start] [Auto Gain] [ON]/[OFF]...
Page 317 14. Menu Guide [Others (Photo)] Recording the picture will automatically stop multiple exposure recording. To finish multiple exposure recording before starting the recording, press [Q] on the recording screen. Recording information for the last-recorded image will be saved as recording information for images recorded with multiple exposures.
Page 318: [Video] Menu
14. Menu Guide [Video] Menu [Image Quality] [Audio] [Exposure Mode] [Sound Rec Level Disp.] [Photo Style] [Sound Rec Level Adj.] [Metering Mode] [Sound Rec Level Limiter] [ISO Sensitivity (video)] [Wind Noise Canceller] [Flicker Decrease (Video)] [Wind Cut] [i.Dynamic Range] [Mic Socket] [Vignetting Comp.] [Special Mic.] [Diffraction...
Page 319 14. Menu Guide : Default settings [Image Quality] [P]/[A]/[S]/[M] [Exposure Mode] Sets the exposure mode to use in [ ] mode. [Standard]/[Vivid]/[Natural]/[Flat]/[Landscape]/ [Portrait]/[Monochrome]/[L.Monochrome]/ [L.Monochrome D]/[Cinelike D]/[Cinelike V]/ [Like709]/[Standard(HLG)]/[Monochrome(HLG)]/ [Like2100(HLG)]/[MY PHOTO STYLE 1] to [MY [Photo Style] PHOTO STYLE 10] You can select the finishing settings of images to suit your subjects and expression styles.
Page 320 14. Menu Guide [Image Quality] [1/50]/[1/60]/[1/100]/[1/120]/ [OFF] [Flicker Decrease The shutter speed can be fixed to reduce the — (Video)] flicker or striping in the video. When [Auto Exposure in P/A/S/M] is [OFF], [Flicker Decrease (Video)] is not available. [AUTO]/[HIGH]/[STANDARD]/[LOW]/ [OFF] Contrast and exposure are compensated when [i.Dynamic Range] the brightness difference between the background...
Page 321 14. Menu Guide [Image Quality] [ON]/[OFF] Selects the setting method for aperture value, [Auto Exposure in shutter speed, and ISO sensitivity for the video — P/A/S/M] being recorded. (l 231) [ON]: Records with values set automatically by the camera. [OFF]: Records with manually set values. [F/SS/ISO/Exposure Comp.] [White Balance]...
Page 322 14. Menu Guide [Focus] [ON]/ [OFF] [SET] [AF Speed]/ [AF Custom [AF Sensitivity] Setting(Video)] You can fine-adjust the focusing method for video recording using [Continuous AF]. [ON]/[OFF] [Continuous AF] You can select how to set the focus in AF when recording videos.
Page 323 14. Menu Guide [Audio] [HIGH]/ [STANDARD]/[OFF] This reduces the wind noise coming into the built- in microphone while maintaining sound quality. [HIGH] effectively reduces the wind noise by reducing the low-pitched sound when a strong wind is detected. [Wind Noise —...
Page 324 14. Menu Guide [Monitor / Display] [Info Display] [ON]/[OFF] Select whether or not to output the information [HDMI Rec Output] display of the camera to an external device connected via HDMI. [Others (Video)] [Operation Mode] ]/[OFF] [Body(B.I.S.) / ]/ [ Lens(O.I.S.)] [When to Activate] [ALWAYS]/ [HALF-...
Page 325: [Custom] Menu
14. Menu Guide [Custom] Menu [Image Quality] [Operation] [Photo Style Settings] [Q.MENU Settings] [ISO Increments] [Touch Settings] [Extended ISO] [Lock Lever Setting] [Exposure Offset Adjust.] [Fn Button Set] [Color Space] [Fn Lever Setting] [Exposure Comp. Reset] [WB/ISO/Expo. Button] [ISO Displayed Setting] [Focus/Shutter] [Exposure Comp.
Page 326 14. Menu Guide [Monitor / Display] [Auto Review] [Constant Preview] [Level Gauge] [Histogram] [Photo Grid Line] [Framing Outline] [Center Marker] [AF Area Display] [Live View Boost] [Monochrome Live View] [Night Mode] [LVF/Monitor Disp. Set] [Expo.Meter] [Focal Length] [Photo/Video Preview] [Photos/Videos Remaining] [Show/Hide Monitor Layout] [Blinking Highlights] [Zebra Pattern]...
Page 327 14. Menu Guide : Default settings [Image Quality] [Show/Hide Photo [Vivid]/[Natural]/[Flat]/[Landscape]/ Style] [Portrait]/[L.Monochrome]/ [L.Monochrome D]/[Cinelike D]/ [Cinelike V]/[Like709]/[MY PHOTO STYLE 1] to [MY PHOTO STYLE Sets Photo Style items to be displayed on the menu. [My Photo Style [Add Effects] Settings] [Load Preset Setting] [Photo Style...
Page 328: Color Space]
14. Menu Guide [Image Quality] [Multi Metering] [j1EV] to [i1EV] ( [±0EV]) [Center Weighted] [j1EV] to [i1EV] ( [±0EV]) [Spot] [j1EV] to [i1EV] ( [±0EV]) [Highlight Weighted] [j1EV] to [i1EV] ( [±0EV]) Adjusts the exposure level that is the standard correct [Exposure Offset exposure for each item of [Metering Mode].
Page 329 14. Menu Guide [Focus/Shutter] [AFS] [FOCUS]/[BALANCE]/[RELEASE] [AFC] [FOCUS]/ [BALANCE]/[RELEASE] This sets whether to give priority to focus or shutter release during AF. [Focus/Shutter [FOCUS]: Disables recording when focus is not achieved. Priority] [BALANCE]: Performs recording while controlling the balance between focusing and shutter release timing. [RELEASE]: Enables recording even when focus is not achieved.
Page 330: Mf Assist]
14. Menu Guide [Focus/Shutter] [Focus Ring] [ON]/[OFF] [AF Mode/MF] [ON]/ [OFF] [Press Joystick] [ON]/ [OFF] [MF Assist Display] [FULL]/ [PIP] This sets the display method of MF Assist (enlarged screen). [Focus Ring]: The screen is enlarged by focusing with the lens.
Page 331 14. Menu Guide [Focus/Shutter] [Face/Eye/Body/ [ON]/[OFF] Animal Detect.] [Tracking] [ON]/[OFF] [225-Area] [ON]/[OFF] [Zone (Vert./ Horz.)] [ON]/[OFF] [Zone (Square)] [ON]/ [OFF] [Zone (Oval)] [ON]/[OFF] [Show/Hide AF Mode] [1-Area+] [ON]/[OFF] [Pinpoint] [ON]/[OFF] [Custom1] [ON]/ [OFF] [Custom2] [ON]/ [OFF] [Custom3] [ON]/ [OFF] Sets the AF mode items to be displayed on the AF mode selection screen.
Page 332 14. Menu Guide [Focus/Shutter] [Keep Enlarged [ON]/ [OFF] Display] [PIP Display] [FULL]/ [PIP] Changes the enlarged screen settings of AF-Point Scope [AF-Point Scope (l 94). Setting] [Keep Enlarged Display]: Setting this to [ON] maintains the enlarged screen after pressing the Fn button until it is pressed again.
Page 333 14. Menu Guide [Focus/Shutter] [ON]/ [OFF] [Looped Focus When moving the AF area or MF Assist, this enables its Frame] position to loop from one edge to the other edge of the screen. [ON]/ [OFF] [AFC Start Point When using [ ] with the focus mode set to [AFC], you can (225-Area)] specify at which area to start [AFC].
Page 334 14. Menu Guide [Operation] [Cursor] [Joystick] [Touch Screen] [Dial] [DISP. Button] Sets the operations to be disabled with the operation lock [Lock Lever Setting] lever. (Only for recording screen) [Cursor]: Cursor buttons, [MENU/SET] button, and [Joystick]: Joystick [Touch Screen]: Touch screen [Dial]: , and [DISP.
Page 335 14. Menu Guide [Operation] [WHILE PRESSING]/[AFTER PRESSING1]/ [AFTER PRESSING2] This sets the operation to be performed when [WB] (White Balance), [ISO] (ISO sensitivity) or [ ] (Exposure Compensation) is pressed. [WHILE PRESSING]: Allows you to change the setting while pressing and holding the button. Release the button to confirm the settings value, and to [WB/ISO/Expo.
Page 336 14. Menu Guide [Operation] [Assign Dial (F/SS)] [SET1]/[SET2]/[SET3]/[SET4]/ [SET5] Sets the operations to be assigned to the dials in [P]/[A]/[S]/ [M] modes. : Program Shift, F: Aperture value, SS: Shutter speed [SET1] [SET2] [SET3] [SET4] [Dial Set.] [SET5] [Rotation (F/SS)] Changes the rotational directions of the dials for aperture value and shutter speed adjustment.
Page 337 14. Menu Guide [Operation] [Exposure Comp.] ]/ [OFF] Assigns exposure compensation to . (Except in [M] mode) The [Assign Dial (F/SS)] setting takes priority. [Dial Operation Switch Setup] [Dial Set.] (Continued) In the Fn button [Dial Operation Switch], this sets the items to be assigned temporarily to .
Page 338 14. Menu Guide [Operation] [ON]/[OFF] [Video Rec. Button Disables the video rec. button on the Shutter Remote (Remote)] Control (optional). For details, refer to page 446. [Monitor / Display] [Duration Time [HOLD]/[5SEC] to [1SEC]/ [OFF] (photo)] [Duration Time (6K/ [HOLD]/[OFF] 4K PHOTO)] [Duration Time (Post- [HOLD]/[OFF]...
Page 339 14. Menu Guide [Monitor / Display] [ON]/ [OFF] [SET] [Preview While MF Assist] You can always confirm the effects of aperture and shutter speed on the recording screen when in [M] mode. [Constant Preview] Preview also operates in the MF Assist screen when [Preview While MF Assist] is set to [ON].
Page 340 14. Menu Guide [Monitor / Display] [ON]/ [OFF] This displays the histogram. Turning this [ON] displays the histogram transition screen. Press 3421 to set the position. Positions can be moved to the diagonal directions using the joystick. You can also move the position by dragging the histogram on the recording screen.
Page 341 14. Menu Guide [Monitor / Display] ]/ [OFF] Sets the grid line pattern to be displayed on the recording screen. When using [ ], you can press 3421 to set the position. Positions can be moved to the diagonal directions using the [Photo Grid Line] joystick.
Page 342 14. Menu Guide [Monitor / Display] [MODE1]/[MODE2]/ [OFF] [SET] [P/A/S/M]/ [M] Displays the screen brighter to make it easier to check subjects and compositions even in low-light environment. [MODE1]: Setting for low brightness, with priority given to a soft display. [MODE2]: Setting for high brightness, with priority given to image visibility.
Page 343 14. Menu Guide [Monitor / Display] [Monitor] [ON]/ [OFF] [LVF] [ON]/ [OFF] Displays monitor and viewfinder in red. In dark environments, this reduces brightness of the screen that can make the surroundings difficult to see. You can also set the luminance of the red display. Press 3421 to select [ON] on the monitor or viewfinder (LVF).
Page 344 14. Menu Guide [Monitor / Display] [ON]/ [OFF] This displays the exposure meter. [Expo.Meter] Set to [ON] to display the exposure meter when performing Program Shift, setting aperture, and setting shutter speed. If no operations are performed for approx. 4 seconds, the exposure meter disappears.
Page 345 14. Menu Guide [Monitor / Display] This will switch display between the number of recordable pictures and available recording time. ]: Displays the number of recordable pictures. ]: Displays the available recording time for video. Even when this is set to [ ], the number of recordable pictures is displayed for a while after a picture [Photos/Videos...
Page 346 14. Menu Guide [Monitor / Display] [ZEBRA1]/[ZEBRA2]/ [OFF] [SET] [Zebra 1]/[Zebra 2] This indicates areas where overexposure may occur in a zebra pattern. [ZEBRA1] [ZEBRA2] [Zebra Pattern] Select [SET] to set the brightness to be processed as a zebra pattern. You can select a brightness value between [50%] and [105%].
Page 347 14. Menu Guide [Monitor / Display] [Monitor] [MODE1]/ [MODE2]/[OFF] [HDMI] [AUTO]/[MODE1]/[MODE2]/[OFF] At recording or playback of [HLG Photo] and HLG video, this displays images with converted color gamut and brightness on the camera monitor/viewfinder, or outputs these over HDMI. [AUTO]: Converts images before outputting them via HDMI while applying the effect of [MODE2].
Page 348 14. Menu Guide [Monitor / Display] [ON]/ [OFF] Displays a reference point on the recording screen in order to let you check for camera shake. A Reference point [I.S. Status Scope] When the following functions are being used, [I.S. Status Scope] is not available: –...
Page 349: [Setup] Menu
14. Menu Guide [Setup] Menu [Card/File] [Setting] [Card Format] [Save to Custom Mode] [Double Card Slot Function] [Load Custom Mode] [Folder / File Settings] [Custom Mode Settings] [File Number Reset] [Save/Restore Camera Setting] l [Copyright Information] [Reset] [Monitor / Display] [Others] [Power Save Mode] [Clock Set]...
Page 350: Copyright Information]
14. Menu Guide : Default settings [Card/File] [Card Slot 1(XQD)]/[Card Slot 2(SD)] [Card Format] Formats the card (initialization). For details, refer to page 48. [Recording Method] [Double Card Slot This sets the way recording to the card slots 1 and 2 is Function] performed.
Page 351 14. Menu Guide [Monitor / Display] [Sleep Mode] [10MIN.]/ [5MIN.]/[2MIN.]/[1MIN.]/ [OFF] [Sleep Mode(Wi-Fi)] [ON]/[OFF] [Auto LVF/Monitor [5MIN.]/[2MIN.]/[1MIN.]/[OFF] Off] [Power Save Mode] [Power Save LVF [Time to Sleep] Shooting] [Method of Activation] This is a function to automatically turn the camera to sleep (power save) status or turn off the viewfinder/monitor if no operation is performed for a set time.
Page 352: Monitor/Viewfinder L
14. Menu Guide [Monitor / Display] [Brightness]/[Contrast]/[Saturation]/[Red Tint]/[Blue Tint] This adjusts the brightness, coloring, and red or blue tints of the monitor/viewfinder. [Monitor Settings]/ Press 34 to select the setting item, and press 21 to [Viewfinder] adjust. Press to confirm the setting. It will adjust the monitor when the monitor is in use, and the viewfinder when the viewfinder is in use.
Page 353: Wi-Fi/Bluetooth
14. Menu Guide [Monitor / Display] [Backlight] [H]/[L]/[OFF] Sets the lighting method of the status LCD backlight. [H]: Brightens the status LCD backlight. [L]: Darkens the status LCD backlight. [OFF]: Turns off the status LCD backlight. [Display While Power [ON]/[OFF] Off] [Status-LCD] When set to [ON], this displays the following information on...
Page 354 14. Menu Guide [IN/OUT] [Beep Volume] ] (High)/ [ ] (Low)/[ (Off) [AF Beep Volume] ] (High)/ [ ] (Low)/[ (Off) [AF Beep Tone] ] (Pattern 1)/[ ] (Pattern 2)/ ] (Pattern 3) [E-Shutter Vol] ] (High)/ [ ] (Low)/[ [Beep] (Off) [E-Shutter Tone]...
Page 355 14. Menu Guide [IN/OUT] [USB Mode] [y][Select on connection]/ [z][PC(Storage)]/ ][PC(Tether)]/ [{][PictBridge(PTP)] This sets the communication method to be used when the USB connection cable is connected. [y][Select on connection]: Select this setting to select the USB communication system when connecting to another device.
Page 356 14. Menu Guide [IN/OUT] Displays the remaining level and degree of deterioration of the battery. If the usage duration drops significantly even when the battery is fully charged, then the battery is at the end of its service life. Check its status, and replace with a new battery. [Remaining Level]: Displays the battery remaining level as [Battery a percentage (1% units) and as a bar.
Page 357 14. Menu Guide [IN/OUT] [HDMI Mode [AUTO]/[4K/60p]/[4K/30p]/[1080p]/ (Playback)] [1080i]/[720p]/[480p] Sets the output resolution during HDMI connection. [AUTO]: Outputs images at an output resolution suited to the connected TV. If no image appears on the TV with [AUTO], switch to a constant setting other than [AUTO] to set a format supported by your TV.
Page 358 14. Menu Guide [Setting] [Background ]/ [ Color(Playback)] Sets the color of the bands displayed on the top and bottom [TV Connection] or the left and right of images output on a TV or similar (Continued) display. We recommend setting to [ ] to prevent burn-in on the screen of the output destination.
Page 359: Sensor Cleaning] L
14. Menu Guide [Others] Sets the date and time. [Clock Set] For details, refer to page 53. Sets the time zone. Press 21 to select the time zone and then press to confirm. A Current time B Time difference from GMT (Greenwich [Time Zone] Mean Time)
Page 360 14. Menu Guide [Others] [Firmware Update]/[Software info] You can check the firmware versions of the camera and lens. In addition, you can update the firmware, and display information about the camera software. [Firmware Update]: Updates firmware. Download the firmware from the site on page 17. Save the firmware to the root directory of the card (the first folder that appears when you access the card on [Firmware Version]...
Page 361: [Playback] Menu
14. Menu Guide [Playback] Menu [Playback Mode] [Add/Delete Info.] [Rotate Disp.] [Protect] [Picture Sort] [Rating] [Magnify from AF Point] [Edit Image] [HLG View Assist (Monitor)] [Resize] [Process Image] [Rotate] [RAW Processing] [Video Divide] [6K/4K PHOTO Bulk Saving] [Copy] [6K/4K PHOTO Noise [Others] Reduction] [Delete Confirmation]...
Page 362 14. Menu Guide How to Select an Image(s) in the [Playback] menu Follow the steps below when the image selection screen is displayed. When [Single] and [Multi] are not available, select an image in the same way as when [Single] is selected. Images are displayed separately by card slot.
Page 363 14. Menu Guide : Default settings [Playback Mode] [ON]/[OFF] Automatically displays pictures vertically if they were recorded when holding the camera vertically. [Rotate Disp.] When you play back pictures on a PC, use an OS and software that support Exif. The picture may not be displayed as rotated.
Page 364 14. Menu Guide [Process Image] Processes pictures taken in RAW format on the camera and saves them in JPEG format. In addition, RAW images [RAW Processing] recorded using [HLG Photo] can be saved in HLG format. For details, refer to page 272. You can save any 5 second period of pictures from a 6K/4K [6K/4K PHOTO Bulk burst file all at once.
Page 365: Rating] L
14. Menu Guide [Add/Delete Info.] [Single]/[Multi]/[Cancel] You can set protection for images so that they will not be deleted by mistake. However, if you format the card, the protected images will also be deleted. For information about how to select images, refer to page [Protect] 362.
Page 366 14. Menu Guide [Edit Image] [Single]/[Multi] Reduce the picture size of JPEG images and save them as different images to enable them to be easily used for web pages or sent as email attachments. For information about how to select images, refer to page 362.
Page 367 14. Menu Guide [Edit Image] [Copy Direction] [Select Copy]/[Copy All in Folder]/[Copy All in Card] You can copy the images in one of the cards to the other card. Copied images will be saved in a new folder. [Select Copy]: Copies selected images. Select the folder containing the images to copy.
Page 368 14. Menu Guide [Edit Image] You can set up to 100 images at once with [Select Copy]. The [Protect] setting is not copied. Copying may take a while. AVCHD videos cannot be copied. When using the following combinations of cards, videos, [Copy] 6K/4K photos, and images recorded with [Post-Focus] (Continued)
Page 369: Entering Characters
14. Menu Guide Entering Characters Follow the steps below when the character entry screen is displayed. Enter characters. ≥Press 3421 to select characters and then press until the character to enter is displayed. (Repeat this) To repeatedly enter the same character, rotate to the right to move the entry position cursor.
Page 370: Wi-Fi/Bluetooth
Wi-Fi/Bluetooth Wi-Fi/Bluetooth Functions Using the camera Wi-Fi /Bluetooth functionality, you can remotely operate the camera from a smartphone, and transfer images to a smartphone by the camera operation. You can use the “LUMIX Sync” smartphone app for remote recording and image transfers. (l 372) You can transfer images to another device, such as a smartphone or PC, by operating the camera.
Page 371 15. Wi-Fi/Bluetooth Do not remove the card or battery or move to an area without any reception while sending images. The camera cannot be used to connect to a public wireless LAN connection. We strongly recommend that you set an encryption to maintain information security.
Page 372: Connecting To A Smartphone
15. Wi-Fi/Bluetooth Connecting to a Smartphone Connect with a smartphone which has the “Panasonic LUMIX Sync” (below: “LUMIX Sync”) smartphone app installed. Use “LUMIX Sync” for remote recording and image transfers. Connecting to a smartphone Install “LUMIX Sync ” on your smartphone. (l 373) Connect to a network, and install “LUMIX Sync”...
Page 373: Installing "Lumix Sync
15. Wi-Fi/Bluetooth Installing “LUMIX Sync” “LUMIX Sync” is an application for smartphones provided by Panasonic. Supported OS Android™: Android 5 or higher iOS: iOS 11 or higher Connect the smartphone to a network. (Android) Select “Google Play™ Store”. (iOS) Select “App Store”.
Page 374: Connecting To A Smartphone (Bluetooth Connection)
15. Wi-Fi/Bluetooth Connecting to a Smartphone (Bluetooth Connection) Follow a simple connection setup procedure (pairing) to connect to a smartphone that supports Bluetooth Low Energy. When pairing is set up, the camera also automatically connects to the smartphone via Wi-Fi. For the first-time connection, pairing settings are required.
Page 375 15. Wi-Fi/Bluetooth Operating the camera in accordance with the smartphone guide. Set the camera to Bluetooth pairing standby status. [Bluetooth] ≥ [Bluetooth] [SET] [Pairing] ≥The camera enters connection standby status, and the device  name (A) is displayed. On the smartphone, select the camera device name.
Page 376 15. Wi-Fi/Bluetooth (iOS devices) If the Wi-Fi connection attempt fails during Bluetooth connection, follow the message displayed to allow connection to the camera. If you still cannot connect, select the SSID of the camera on the Wi-Fi setup screen of the smartphone to connect. If the SSID is not displayed, turn off and on the camera, then perform the Bluetooth connection settings again.
Page 377: Connecting To A Smartphone ([Wi-Fi Connection])
15. Wi-Fi/Bluetooth Even if you set up pairing with more than one smartphone, you can only connect to one smartphone at a time. When pairing takes some time, canceling the pairing settings on both the smartphone and camera and re-establishing the connection may result in the camera being detected correctly.
Page 378 15. Wi-Fi/Bluetooth Set the camera to Wi-Fi connection standby status. [Wi-Fi] ≥ [Wi-Fi Function] [New Connection] [Remote Shooting & View]  ≥The SSID (A) of the camera is displayed on the screen. You can also perform the same operation by pressing the Fn button assigned with [Wi-Fi].
Page 379 15. Wi-Fi/Bluetooth When a device different than the one you want to connect to is displayed, the camera will automatically connect to that device if you select [Yes]. If there are other Wi-Fi connection devices nearby, we recommend using either manual password input or QR code to connect with password authentication.
Page 380 15. Wi-Fi/Bluetooth (iOS devices) If the Wi-Fi connection fails, follow the message displayed to allow connection to the camera. If you still cannot connect, select the SSID of the camera on the Wi-Fi setup screen of the smartphone to connect. If the SSID is not displayed, turn off and on the camera, then perform the Wi-Fi connection settings again.
Page 381 15. Wi-Fi/Bluetooth Connection Methods Other Than the Default Settings When connecting with [Via Network], or [WPS Connection] in [Direct], follow the steps below: Display the connection method setting screen for the camera. [Wi-Fi] [Wi-Fi Function] [New Connection] [Remote Shooting & View] Press [DISP.].
Page 382: Terminating The Wi-Fi Connection
15. Wi-Fi/Bluetooth Terminating the Wi-Fi Connection To end the Wi-Fi connection between the camera and smartphone, follow the steps below: Set the camera to recording mode. ≥Press the shutter button halfway. End Wi-Fi connection. [Wi-Fi] ≥ [Wi-Fi Function] [Yes] You can also perform the same operation by pressing the Fn button assigned with [Wi-Fi].
Page 383: Operating The Camera With A Smartphone
15. Wi-Fi/Bluetooth Operating the Camera with a Smartphone Required Wireless Connectivity Type Depending on the function used, the required type of wireless connection will differ. Wireless connectivity Support for Bluetooth Low Energy required Indicates that the function can be used with smartphones Bluetooth that support Bluetooth Low Energy.
Page 384: [Remote Shooting]
15. Wi-Fi/Bluetooth [Remote shooting] Wi-Fi You can use the smartphone to record from a remote location while viewing the live view images from the camera. Getting started: Connect the camera to a smartphone. (l 374, 377) On the smartphone, start up “LUMIX Sync”. Select [ ] ([Remote shooting]) in the home screen.
Page 385 15. Wi-Fi/Bluetooth Operation Method During Remote Recording Set either the camera or the smartphone as the priority control device to be used during remote recording. [Wi-Fi] [Wi-Fi Setup] Select [Priority of Remote Device] Operation is possible on both the camera and the smartphone.
Page 386: [Shutter Remote Control]
15. Wi-Fi/Bluetooth [Shutter Remote Control] Bluetooth You can use the smartphone as a remote control for the shutter. Getting started: Connect the camera to a smartphone by Bluetooth. (l 374) On the smartphone, start up “LUMIX Sync”. Select [ ] ([Shutter Remote Control]) in the home screen.
Page 387 15. Wi-Fi/Bluetooth Bulb Recording The shutter can be kept open from the start to end of recording, which is useful for recording of starry skies or night scenery. Getting started: Set the camera to [M] mode. (l 185) Set the camera shutter speed to [B] (Bulb). (l 187) Touch [ ] to start recording (keep touching, without removing your finger).
Page 388: Transferring Recorded Images
15. Wi-Fi/Bluetooth Transferring Recorded Images Wi-Fi Transfer an image stored on the card to the smartphone connected via Wi-Fi. Getting started: Connect the camera to a smartphone. (l 374, 377) On the smartphone, start up “LUMIX Sync”. Select [ ] ([Import images]) in the “LUMIX Sync” home screen.
Page 389 15. Wi-Fi/Bluetooth You will need Android 7.0 or higher to save RAW pictures on an Android device. Depending on the smartphone or the OS, these may not be displayed correctly. When a video is played back, this has a small data size and is transmitted using “LUMIX Sync”, therefore its image quality will differ from that of the actual video recording.
Page 390: Transferring Recorded Images Automatically
15. Wi-Fi/Bluetooth Transferring Recorded Images Bluetooth Wi-Fi Automatically You can automatically transfer recorded pictures to a smartphone as they are taken. Getting started: Connect the camera to a smartphone by Bluetooth. (l 374) Enable [Auto Transfer] on the camera. [Bluetooth] ≥...
Page 391 15. Wi-Fi/Bluetooth Record with the camera. This automatically sends the recorded pictures to the specified device as they are taken. ] is displayed in the recording screen of the camera while a file is being sent. To Stop the Automatic Transfer of Images [Bluetooth] [Auto Transfer] Select [OFF]...
Page 392: Recording Location Information
15. Wi-Fi/Bluetooth Recording Location Information Bluetooth The smartphone sends its location information to the camera via Bluetooth, and the camera performs recording while writing the acquired location information. Getting started: Enable the GPS function on the smartphone. Connect the camera to a smartphone by Bluetooth. (l 374) Enable [Location Logging] on the camera.
Page 393: Camera Power Operations
15. Wi-Fi/Bluetooth Camera Power Operations Bluetooth Wi-Fi Even when the camera is turned off, the smartphone can be used to start the camera and record images, or check the recorded images. Getting started: Connect to a smartphone using Bluetooth. (l 374) Enable [Remote Wakeup] on the camera.
Page 394: Automatically Setting The Clock
15. Wi-Fi/Bluetooth Automatically Setting the Clock Bluetooth Synchronize the clock and the time zone setting of the camera with those of a smartphone. Getting started: Connect the camera to a smartphone by Bluetooth. (l 374) Enabling [Auto Clock Set] on the camera.
Page 395: Saving Settings Information
15. Wi-Fi/Bluetooth Saving Settings Information Bluetooth Wi-Fi This saves the camera’s settings information to the smartphone. Saved settings information can be loaded to the camera, letting you set the same settings on multiple cameras. Getting started: Connect the camera to a smartphone by Bluetooth. (l 374) Select [ ] ([Camera settings copy]) in the “LUMIX Sync”...
Page 396: Sending Images From The Camera
15. Wi-Fi/Bluetooth Sending Images from the Camera Operate the camera to send recorded images to a device connected by Wi-Fi. Operation flow Select the sending method. Use the camera menu to select the sending method from either [Send Images While Recording] or [Send Images Stored in the Camera].
Page 397 15. Wi-Fi/Bluetooth Detailed information about connection methods for each destination device is described on pages to 411. Refer to the following pages for the steps common to all devices. – Wi-Fi connections: [Via Network] (l 412)/[Direct] (l 416) – Image send settings (l 419) –...
Page 398 15. Wi-Fi/Bluetooth Sending may not be possible depending on your device. It may not be possible to send images recorded with devices other than this camera, or images edited or processed on a PC. Fn Button Assigned with [Wi-Fi] You can perform the following operations by pressing the Fn button assigned with [Wi-Fi] after connecting to Wi-Fi.
Page 399: [Smartphone]
15. Wi-Fi/Bluetooth [Smartphone] Transfer recorded images to a smartphone connected using Wi-Fi. Getting started: Install “LUMIX Sync” on your smartphone. (l 373) Select the method for sending the images on the camera. [Wi-Fi] ≥ [Wi-Fi Function] [New Connection] [Send Images While Recording] or [Send Images Stored in the Camera] Set the destination to...
Page 400 15. Wi-Fi/Bluetooth When [Send Images While Recording] is selected: Take pictures. This automatically sends the recorded pictures to the specified device as they are taken. ] is displayed in the recording screen of the camera while a file is being sent.
Page 401 15. Wi-Fi/Bluetooth Sending Images on the Camera to a Smartphone with Simple Operations You can transfer pictures to a smartphone connected by Bluetooth just by pressing the Fn button during playback. You can also use the menu to connect easily. Use the Fn button registered with [Send Image (Smartphone)] to operate.
Page 402 15. Wi-Fi/Bluetooth Using the menu to transfer easily. [Bluetooth] [Send Image (Smartphone)] Settings: [Single Select]/[Multi Select] If [Single Select], press 21 to select the image and then press execute. If [Multi Select], use the same operation as with the Fn button to execute. [PC] Send recorded images to the PC connected with Wi-Fi.
Page 403 15. Wi-Fi/Bluetooth Create a PC account name (up to 254 characters) and password (up to 32 characters) consisting of alphanumeric characters. A destination folder may not be created if the account name includes non- alphanumeric characters. When the computer name (NetBIOS name for Mac) contains a space (blank character), etc., it may not be recognized.
Page 404 15. Wi-Fi/Bluetooth Enter the computer name of the PC name you want to connect to (for Mac, the NetBIOS name). For information on how to enter characters, refer to page 369. Select a folder for storing images. Folders sorted by sent date will be created in the selected folder, and images will be saved there.
Page 405: [Printer]
15. Wi-Fi/Bluetooth If the screen for a user account and password entry appears, enter the one you set on your PC. When the firewall of the OS, security software, etc. is enabled, connecting to the PC may not be possible. During recording, these have priority, so it will take time until sending is complete.
Page 406 15. Wi-Fi/Bluetooth Connect the camera to a printer by Wi-Fi. ≥Select [Via Network] (l 412) or [Direct] (l 416), and then connect. Select the destination printer. Select and print images. The procedure for selecting images is the same as the one for when the USB connection cable is connected.
Page 407: [Web Service]
15. Wi-Fi/Bluetooth [Web service] You can use “LUMIX CLUB” to upload recorded images to web services such as social networking sites. Getting started: Register with “LUMIX CLUB”. (l 422) Before sending images to a service, register that web service. (l 424) Select the method for sending images on the camera.
Page 408 15. Wi-Fi/Bluetooth Select the web service. Check the send settings and then press To change the send settings of images, press [DISP.]. (l 419) When [Send Images While Recording] is selected: Take pictures. This automatically sends the recorded pictures to the specified service as they are taken.
Page 409 If image sending fails, a report email outlining the failure will be sent to the email address registered in the “LUMIX CLUB”. Panasonic assumes no responsibility for any damages resulting from the leakage, loss, etc. of images uploaded on web services.
Page 410: [Cloud Sync. Service]
15. Wi-Fi/Bluetooth [Cloud Sync. Service] This camera can automatically transfer recorded images to a cloud sync service via “LUMIX CLUB” to send them to a PC or smartphone. To use [Cloud Sync. Service] (As of January 2019) You need to register to the “LUMIX CLUB” (l 422) and set up cloud synchronization to send images to a cloud folder.
Page 411 15. Wi-Fi/Bluetooth Connect to the cloud sync service. ≥Select [Via Network] and then connect. (l 412) Check the send settings and then press To change the send settings of images, press [DISP.]. (l 419) When [Send Images While Recording] is selected: Take pictures.
Page 412: Wi-Fi Connections
15. Wi-Fi/Bluetooth Wi-Fi Connections When [New Connection] has been selected in [Wi-Fi Function] in [Wi-Fi] of the [Setup] ([IN/OUT]) menu, select the connection method from either [Via Network] or [Direct] to connect. On the other hand, when you use [Select a destination from History] or [Select a destination from Favorite], the camera connects to the selected device with the previously-used settings.
Page 413 15. Wi-Fi/Bluetooth Press the WPS button on the wireless access [WPS (Push-Button)] (l 413) point to set up a connection. Enter a PIN code into the wireless access point to [WPS (PIN code)] (l 414) set up a connection. Searches for a wireless access point to use, and [From List] (l 414) connects to this.
Page 414 15. Wi-Fi/Bluetooth [WPS (PIN code)] Enter a PIN code into the wireless access point to set up a connection. On the camera screen, select the wireless access point you are connecting to. Enter the PIN code displayed on the camera screen into the wireless access point.
Page 415 15. Wi-Fi/Bluetooth Connecting by Manual Input Check the SSID, security type, encryption type, and encryption key of the wireless access point you are using. In the screen in Step of “[From List]”, select [Manual Input]. (l 414) Enter the SSID of the wireless access point you are connecting to, and then select [Set].
Page 416: [Direct]
15. Wi-Fi/Bluetooth [Direct] Directly connect the camera and the destination device. Select the method for connecting with the destination device. Press the WPS button on the destination [WPS (Push- device to connect. Button)] On the camera, press [DISP.] to extend [WPS the connection wait time.
Page 417: Connect To Wi-Fi Using Previously Saved Settings
15. Wi-Fi/Bluetooth Connect to Wi-Fi Using Previously Saved Settings Use the Wi-Fi connection history to connect using the same settings as previously. Display the Wi-Fi connection history. [Wi-Fi] ≥ [Wi-Fi Function] [Select a destination from History] or [Select a destination from Favorite] Select the History item to connect to.
Page 418 15. Wi-Fi/Bluetooth Editing Items Registered in Favorite Display items registered to Favorite. [Wi-Fi] [Wi-Fi Function] [Select a destination from Favorite] Select the History item to edit in Favorite and then press 1. [Remove from Favorite] — [Change the Order in Specify the destination location of the desired Favorite] item to change the display order.
Page 419: Send Settings And Selecting Images
15. Wi-Fi/Bluetooth Send Settings and Selecting Images Image Send Settings Set the size, file format, and other items for sending the image to the destination device. After Wi-Fi connection, the send settings confirmation screen will be displayed, so press [DISP.]. Change the send settings.
Page 420: Selecting Images
15. Wi-Fi/Bluetooth Selecting Images When sending by [Send Images Stored in the Camera], select the images using the following procedure. Select [Single Select] or [Multi Select]. Select the image. [Single Select] setting Press 21 to select an image. Press [Multi Select] setting Press 3421 to select an image and then press .
Page 421: [Wi-Fi Setup] Menu
15. Wi-Fi/Bluetooth [Wi-Fi Setup] Menu This configures the settings required for the Wi-Fi function. The settings cannot be changed when connected to Wi-Fi. Displaying the [Wi-Fi Setup] menu. [Wi-Fi] [Wi-Fi Setup] ≥ This sets either the camera or the smartphone as the [Priority of Remote priority control device to be used during remote Device]...
Page 422: Lumix Club
[Network Address] camera. “LUMIX CLUB” Refer to the “LUMIX CLUB” site for details. https://lumixclub.panasonic.net/eng/c/ The service may be suspended due to regular maintenance or unexpected troubles, and the service contents may be changed or added, without prior notice to the users.
Page 423 15. Wi-Fi/Bluetooth Obtain a New Login ID from the Camera From the camera menu, acquire a “LUMIX CLUB” login ID. Follow the menu path. [Wi-Fi] [Wi-Fi Setup] [LUMIX CLUB] [Set/Add Account] [New account] Connect to the network. Proceed to the next page by selecting [Next].
Page 424 Register a Web Service with “LUMIX CLUB” Confirm web services supported by “LUMIX CLUB” in “FAQ/ Contact us” at the website below. https://lumixclub.panasonic.net/eng/c/lumix_faqs/ Getting started: Make sure that you have created an account on the web service you want to use, and have the login information available.
Page 425 15. Wi-Fi/Bluetooth Enter the login ID or password. For information on how to enter characters, refer to page 369. Select [Exit]. Checking the “LUMIX CLUB” Terms of Use Check the details if the terms of use have been updated, for example. [Wi-Fi] [Wi-Fi Setup] [LUMIX CLUB]...
Page 426: Connecting To Other Devices
Connecting to Other Devices Viewing on a TV You can connect the camera to a TV to view recorded pictures and videos on the TV. Getting started: Turn off the camera and TV. Connect the camera and TV with a commercially available HDMI cable.
Page 427 16. Connecting to Other Devices Display the playback screen. ≥Press [(]. ≥The recorded images are displayed on the TV. (The monitor and viewfinder of the camera will turn off.) With the default settings, pictures are output at the optimal resolution for the connected TV.
Page 428 Using VIERA Link (HDMI) VIERA Link (HDMI) (HDAVI Control™) is a function that allows you to use your remote control for the Panasonic TV for easy operations when the camera has been connected to a VIERA Link compatible device using an HDMI cable for automatic linked operations.
Page 429 Cables that do not comply with the HDMI standards will not work. “High Speed HDMI cable” (Type A–Type A plug, up to 1.5 m (4.9 feet) long) VIERA Link is a unique Panasonic function built on an HDMI control function using the standard HDMI CEC (Consumer Electronics Control) specification.
Page 430: Importing Images To A Pc
16. Connecting to Other Devices Importing Images to a PC If you connect the camera to a PC, you can copy the recorded images to the PC. For Windows, install the supplied software “PHOTOfunSTUDIO” to copy your images. (l 430) For Mac, copy the files or folders inside the card by dragging and dropping.
Page 431 You can also perform operations such as writing images to a DVD, correcting images, and editing videos. Check the following site and then download and install the software. https://panasonic.jp/support/global/cs/soft/download/d_pfs1001pe.html (English only) Download expiration: March 2024 Operating environment Windows 10 (32-bit/64-bit) Windows 8.1 (32-bit/64-bit)
Page 432 16. Connecting to Other Devices SILKYPIX Developer Studio SE This software processes and edits RAW images. Edited images can be saved in a format (JPEG, TIFF, etc.) that can be displayed on a PC. Check the following site and then download and install the software. http://www.isl.co.jp/SILKYPIX/english/p/ Operating environment Windows 10...
Page 433: Copying Images To A Pc
16. Connecting to Other Devices Copying Images to a PC Use “PHOTOfunSTUDIO” to copy recorded images to your PC. If you are using a Mac, or in any situation where “PHOTOfunSTUDIO” cannot be installed, refer to page 434. AVCHD videos may not be imported correctly by copying the files or folders. –...
Page 434 16. Connecting to Other Devices Press 34 to select [PC(Storage)] and then press A message about charging may be displayed. Wait for a while until the message disappears. Copy images to the PC using “PHOTOfunSTUDIO”. Do not delete or move the copied files and folders in, for example, Windows Explorer.
Page 435 16. Connecting to Other Devices Operating environment The camera can be connected to a PC running any of the following OSs which can detect mass storage devices. Windows 10 Windows 8.1 Windows Windows 8 Supported OS Windows 7 OS X v10.5 to v10.11, macOS 10.12 to macOS 10.14 Folder Structure Inside Card For Windows, the drive (“LUMIX”) is displayed in [Computer].
Page 436: Storing On A Recorder
16. Connecting to Other Devices Storing on a Recorder By connecting the camera to a Panasonic Blu-ray disc recorder or DVD recorder, you can store the pictures and videos. Getting started: Turn on the camera and recorder. Images to be stored should be saved on an XQD card and inserted in card slot 1.
Page 437 16. Connecting to Other Devices If [USB Mode] is set to [PC(Storage)] in the [Setup] ([IN/OUT]) menu, the camera will be automatically connected to the recorder without the [USB Mode] selection screen being displayed. (l 355) Do not use any other USB connection cables except the supplied USB connection cables (C–C and A–C).
Page 438: Tethered Recording
It allows you to change various settings and to record remotely and then save the images to the PC. Check the following site and then download and install the software. https://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html Operating environment Windows Windows 10, Windows 8.1, Windows 7 Supported OS OS X v10.10 to v10.11, macOS 10.12, macOS...
Page 439: Operating The Camera From A Pc
16. Connecting to Other Devices Operating the Camera from a PC To output via HDMI to an external monitor or TV, connect the camera and external monitor or TV with an HDMI cable. (l 426) Getting started: Turn on the camera and PC. Install “LUMIX Tether”...
Page 440 16. Connecting to Other Devices If [USB Mode] is set to [PC(Tether)] in the [Setup] ([IN/OUT]) menu, the camera will be automatically connected to the PC without the [USB Mode] selection screen being displayed. (l 355) Do not use any other USB connection cables except the supplied USB connection cables (C–C and A–C).
Page 441: Printing
16. Connecting to Other Devices Printing If you connect the camera to a printer that supports PictBridge, you can select pictures on the camera’s monitor and then print them. Getting started: Turn on the camera and printer. Set the print quality and other settings on the printer. Display the playback screen.
Page 442 16. Connecting to Other Devices Press 34 to select [PictBridge(PTP)] and then press A message about charging may be displayed. Wait for a while until the message disappears. Press 21 to select a picture PictBridge and then press ≥To print multiple pictures, press 3, set the picture selection method, and then select pictures.
Page 443 16. Connecting to Other Devices Start printing. ≥Select [Print start] and then press Setting Items (Print Settings) [Print start] Starts printing. Sets printing with date. [Print with Date] If the printer does not support date printing, the date cannot be printed.
Page 444 16. Connecting to Other Devices If [USB Mode] is set to [PictBridge(PTP)] in the [Setup] ([IN/OUT]) menu, the camera will be automatically connected to the printer without the [USB Mode] selection screen being displayed. (l 355) Do not use any other USB connection cables except the supplied USB connection cables (C–C and A–C).
Page 445: Materials
Materials Using Optional Accessories For information on the external flash, refer to page 216. For information on the external microphone, refer to page 254. For information on the XLR Microphone Adaptor, refer to page 257. Some optional accessories may not be available in some countries. Battery Grip (Optional) When mounted on the camera, the Battery Grip (DMW-BGS1: optional) improves ease of operation...
Page 446: Shutter Remote Control (Optional)
You can disable the video rec. button when not recording a video to prevent erroneous operation. Select [Video Rec. Button (Remote)] Settings: [ON]/[OFF] Always use a genuine Panasonic Shutter Remote Control (DMW-RS2: optional). Refer to the operating instructions for the Shutter Remote Control for details.
Page 447: Ac Adaptor (Optional)/Dc Coupler (Optional)
17. Materials AC Adaptor (Optional)/DC Coupler (Optional) With an AC Adaptor (DMW-AC10: optional) and DC Coupler (DMW- DCC16: optional), you can perform recording and playback without worrying about the remaining battery charge. Be sure to purchase both an AC Adaptor and a DC Coupler as a set. They cannot be used independently of one another.
Page 448: Monitor/Viewfinder Displays
17. Materials Monitor/Viewfinder Displays The screen is an monitor display example of when [LVF/Monitor Disp. Set] is set to Recording Screen  FINE  APS-C MINI MINI ×    24m59s 24m59s  HLG Photo (l 214) ‰ Flash mode (l 220) Œ...
Page 449 17. Materials External microphone (l 254) XLR microphone adaptor AF mode (l 98) setting (l 257) HLG View Assist (l 347) MODE2 HDMI Burst (l 126) Exposure meter (l 344) 6K/4K Photo (l 130) Sound recording level (l 243) Post-Focus (l 161) Time Lapse Shot (l 145) Stop Motion Animation AF area (l 112)
Page 450 17. Materials Program Shift (l 180) Touch Tab (l 333) Metering mode (l 178) Fn button (l 286) AE Lock (l 191) Shutter speed (l 59) Aperture value (l 59) F4.0 Touch Zoom (l 123) Aperture Bracket (l 158) F4.0 Touch Shutter (l 80) ×...
Page 451 17. Materials Control Panel 1/60   AUTO  FINE  Single (l 125) Recording mode (l 61) Burst (l 126) 6K/4K Photo (l 130) 1/60 Shutter speed (l 59) Post-Focus (l 161) F4.0 Aperture value (l 59) Time Lapse Shot Battery indication (l 42) (l 145) Power supply (l 40)
Page 452 17. Materials Number of pictures that can Recording file format/ be taken continuously Recording quality 60 p (l 128) (l 233) Available recording time Picture size/Aspect r8m30s (l 483) ratio (l 83) ---- No card HLG Photo (l 214) Fn button settings (l 279) Photo Style (l 199) AWBc...
Page 453: Playback Screen
17. Materials Playback Screen 10:00 DEC.1.2019 100-0001 1/999   8m30s    FINE ± APS-C Playback status Group images (l 269) Recording date and time DEC.1.2019 (l 53) 10:00 Elapsed playback time Card slot (l 46) 8m30s (l 262) Ü...
Page 454 17. Materials Recording information Battery indication (l 42) Power supply (l 40) Battery Grip (l 445)
Page 455 17. Materials Detailed information display Photo Style display FINE 5500 STD. F4.0 F4.0 10:00 DEC.1.2019 10:00 DEC.1.2019 100-0001 100-0001      White balance display 1 Card slot (l 46) 2 Recording date and time (l 53) 3 Folder/file number (l 435) 5500K 4 Recording information (basic) 5 Recording information (advanced)
Page 456: Message Displays
17. Materials Message Displays Meanings of main messages displayed on the camera screen, and response methods. Card [Memory Card Error]/[Format this card?] It is a format that cannot be used with the camera. Either insert another card, or back up any necessary data before formatting. (l 48) [Memory Card Error]/[This memory card cannot be used] Use a card compatible with the camera.
Page 457 [This battery cannot be used] Use a genuine Panasonic battery. If this message is displayed even when a genuine Panasonic battery is used, contact the dealer. If the terminal of the battery is dirty, remove the dirt and dust from them.
Page 458 17. Materials [Connection failed. Please retry in a few minutes.]/[Network disconnected. Transfer stopped.] Radio waves from the wireless access point are getting weak. Perform the connection closer to the wireless access point. Depending on the wireless access point, connection may be automatically disconnected after specific time has passed.
Page 459: Troubleshooting
17. Materials Troubleshooting First, try out the following procedures (l to 469). If the problem is not resolved, it may be improved by selecting [Reset] (l 76) on the [Setup] ([Setting]) menu. Power, Battery The camera turns off automatically. [Power Save Mode] is enabled. (l 44) The battery becomes flat too quickly.
Page 460 17. Materials Recording Recording stops before finishing. Cannot record. Cannot use some functions. In high ambient temperatures or if the camera is used for continuous recording, the temperature of the camera will rise. To protect the camera against a rise in temperature, after [ ] is displayed, recording will be stopped, and the following functions will not be available for a time.
Page 461 17. Materials Multiple images are recorded at once. When drive mode is set to [ ] (Burst Shot 1) or [ ] (Burst Shot 2), pressing and holding the shutter button will take burst pictures. (l 125) When bracketing is set, then pressing the shutter button records multiple images while automatically changing the settings.
Page 462 17. Materials Striping or flicker may appear under lighting such as fluorescent lighting and LED lighting fixture. This is characteristic of CMOS sensors which serve as the camera’s pickup sensors. This is not a malfunction. When using the electronic shutter (l 170), lowering the shutter speed may reduce the effect of the horizontal stripes.
Page 463 17. Materials Video Cannot record videos. When using a large capacity card, you may not be able to record for a while after turning on the camera. Video recording stops in the middle. Recording video using the SD card requires an SD card of a supported speed class. Use a compatible SD card.
Page 464 17. Materials Monitor/Viewfinder The monitor/viewfinder turns off when the camera is turned on. If no operations are performed during the set time period, [Auto LVF/Monitor Off] (l 44) is activated, and the Monitor/Viewfinder turns off. When an object or your hand is positioned near the eye sensor, the Monitor display may switch to the Viewfinder display.
Page 465 17. Materials Wi-Fi Function A Wi-Fi connection cannot be established. Radio waves get disconnected. Wireless access point is not displayed. General tips for using a Wi-Fi connection Use within the communication range of the device to be connected. Usage near devices that utilize the 2.4 GHz frequency such as microwave ovens and cordless telephones may result in the radio wave being lost.
Page 466 17. Materials When trying to connect to a PC by Wi-Fi, this does not recognize the user name and password, and connection is not possible. Depending on the version of the OS, there are two types of user account (local account/Microsoft account).
Page 467 17. Materials I have forgotten the password for the Wi-Fi. In the [Setup] ([Setting]) menu, [Reset], reset network settings. (l 76) However, all information set in [Wi-Fi Setup] and [Bluetooth] will also be reset. (With the exception of [LUMIX CLUB]) TV, PC, Printer No image on the TV.
Page 468 17. Materials The card is not recognized by the PC. (SDXC memory card is used.) Check if your PC supports SDXC memory cards. When connecting the camera to the PC, a message recommending that the card be formatted may be displayed. Do not format the card. If the [Access] displayed on the monitor does not disappear, turn off the camera and disconnect the USB connection cable, and then connect again.
Page 469 17. Materials There is a sound from the lens unit. The lens movement and aperture operation emit sound when turning the camera on or off; this is not a malfunction. This is the sound of aperture operation when brightness changes; this is not a malfunction.
Page 470: Cautions For Use
17. Materials Cautions for Use The camera Keep this unit as far away as possible from electromagnetic equipment (such as microwave ovens, TVs, video games etc.). If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be disrupted by electromagnetic wave radiation.
Page 471 17. Materials Do not spray the camera with insecticides or volatile chemicals. If the camera is sprayed with such chemicals, the body of the camera may be damaged and the surface finish may peel off. Do not keep products made of rubber, PVC or similar materials in contact with the camera for a long period of time.
Page 472 17. Materials Cleaning Before cleaning the camera, remove the battery or the DC Coupler, and disconnect the power plug from the electrical outlet. Then wipe the camera with a dry, soft cloth. When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth, and then with a dry cloth.
Page 473 Do not use any objects except a blower brush to clean the image sensor. If you cannot remove the dirt or dust with the blower, consult the dealer or Panasonic. Cleaning the Viewfinder If the viewfinder is dirty, then remove the eye cup and clean.
Page 474 (S-R24105), a lens mount rubber is used in the mount. – The lens mount rubber will leave scuff marks on the digital camera mount, but this does not impact performance. – To replace the lens mount rubber, contact Panasonic.
Page 475 17. Materials Battery The battery is a rechargeable lithium ion battery. It is highly sensitive to temperature and humidity, and the effect on performance increases as the temperature rises or drops. Always remove the battery after use. Place the removed battery in a plastic bag, and store or keep away from metallic objects (clips, etc.) for storage or transport.
Page 476 Please note in advance that Panasonic is not liable in any way for any direct or indirect damage from the alteration or vanishing of information or personal information.
Page 477 Remove the card from the camera. Settings may return to factory default when camera is repaired. Please contact the dealer where you purchased the camera or Panasonic if above operations are not possible due to malfunction. When transferring/disposing of the card, refer to “Points to remember when disposing of/transferring the memory card”...
Page 478 Recorded data may be damaged or lost if the camera breaks down due to inappropriate handling. Panasonic will not be liable for any damage caused due to loss of recorded data. Tripod Make sure the tripod is stable when the camera is attached to it.
Page 479 There is the risk that the camera violates the radio wave regulations if used in countries other than those where it is sold, and Panasonic takes no responsibility for any violations. There is the risk that data sent and received via radio waves may be...
Page 480: Usage Duration, Number Of Pictures
The numbers of recordable pictures listed here are based on the CIPA (Camera & Imaging Products Association) standard. Using the XQD card from Sony. (Using the SD card from Panasonic for the recordable time and actual recordable time for AVCHD) Using the interchangeable lens (S-R24105).
Page 481 17. Materials Recording Videos (When Using the Monitor) [AVCHD] (Recording with the recording quality set to [FHD/17M/60i]) Recordable time Approx. 150 min Actual recordable time Approx. 75 min [MP4] (Recording with the recording quality set to [FHD/28M/60p]) Recordable time Approx. 140 min Actual recordable time Approx.
Page 482: Number Of Recordable Pictures, Recordable Time
17. Materials Number of Recordable Pictures, Recordable Time Listed below are the numbers of pictures and the time lengths of videos that can be recorded on an XQD card and an SD card. The values listed are approximate. Number of Recordable Pictures [Aspect Ratio]: [3:2];...
Page 483 17. Materials Available Recording Time (When Recording Videos) “h” is an abbreviation for hour, “m” for minute and “s” for second. The recordable time is the total time of all the videos which have been recorded. [Rec. File Format]: [AVCHD] SD card capacity [Rec Quality]...
Page 484 17. Materials [Rec. File Format]: [MP4 HEVC] XQD card capacity SD card capacity [Rec Quality] 32 GB 64 GB 120 GB 240 GB 32 GB 64 GB 128 GB [4K/72M/ 30p] 56m00s 1h50m 3h20m 6h40m 57m00s 1h55m 3h55m [4K/72M/ 24p] Depending on the recording conditions and the type of card, the number of recordable pictures and available recording time vary.
Page 485: List Of Default Settings/Saving Customization/Copied Settings
17. Materials List of Default Settings/Saving Customization/Copied Settings : Using [Reset], the function to return to default settings : Using [Save to Custom Mode], the function to save settings details in the Custom mode : Using [Save/Restore Camera Setting], the function to copy settings details Menu Default settings [Photo]:...
Page 486 17. Materials Menu Default settings [Photo]: [Focus] [AF Custom Setting(Photo)] [Set 1] [AF Assist Light] [ON] [ON]/[OFF] [ON] [Focus Peaking] [Focus Peaking — Sensitivity] [1-Area AF Moving Speed] [FAST] [Photo]: [Flash] [Flash Mode] [‰] [Firing Mode] [TTL] [Flash Adjust.] [±0 EV] [Flash Synchro] [1ST] [Manual Flash Adjust.]...
Page 487 17. Materials Menu Default settings [Burst Shot 1 Setting] [Burst Shot 2 Setting] [Shutter Type] [MECH.] [Shutter Delay] [OFF] [Ex. Tele Conv.] [OFF] [Mode] [Time Lapse Shot] [Shooting Interval Setting] [ON] [Start Time] [Now] [Time Lapse/ Animation] [Image Count] [Shooting Interval] 1m00s [Exposure Leveling] [OFF]...
Page 488 17. Materials Menu Default settings [Filter Effect] [OFF] [Filter Settings] [Simultaneous Record w/o [OFF] Filter] [Auto Exposure in P/A/S/M] [ON] [F/SS/ISO/Exposure Comp.] [White Balance] [CreativeVideo Combined Set.] [Photo Style] [Metering Mode] [AF Mode] [Video]: [Image Format] [Rec Quality] [FHD/28M/60p] [High Speed Video] [OFF] [Rec.
Page 489 17. Materials Menu Default settings [Video]: [Monitor / Display] [HDMI Rec Output] [Info Display] [ON] [Video]: [Others (Video)] [Operation Mode] [Body(B.I.S.) / Lens(O.I.S.)] [When to Activate] [HALF-SHUTTER] [Image Stabilizer] [E-Stabilization (Video)] [OFF] [Boost I.S. (Video)] [OFF] [Focal Length Set] 35.0 mm [Image Area of Video] [FULL] [Custom]:...
Page 490 17. Materials Menu Default settings [Focus Ring] [ON] [AF Mode/MF] [OFF] [MF Assist] [Press Joystick] [OFF] [MF Assist Display] [PIP] [MF Guide] [Focus Ring Lock] [OFF] [Face/Eye/Body/Animal [ON] Detect.] [Tracking] [ON] [225-Area] [ON] [Zone (Vert./ Horz.)] [ON] [Zone (Square)] [OFF] [Show/Hide AF Mode] [Zone (Oval)]...
Page 491 17. Materials Menu Default settings [Custom]: [Operation] [Layout Style] [MODE1] [Front Dial Assignment] [Value] [Q.MENU Settings] [Item Customize (Photo)] — [Item Customize (Video)] — [Touch Screen] [ON] [Touch Tab] [OFF] [Touch Settings] [Touch AF] [AF] [Touch Pad AF] [OFF] [Cursor] [Joystick] [Lock Lever Setting] [Touch Screen]...
Page 492 17. Materials Menu Default settings [Joystick Setting] [D.FOCUS Movement] [Illuminated Button] [ON2] [Video Rec. Button (Remote)] [ON] [Custom]: [Monitor / Display] [Duration Time (photo)] [OFF] [Duration Time (6K/4K [HOLD] PHOTO)] [Auto Review] [Duration Time (Post- [HOLD] Focus)] [Playback Operation [OFF] Priority] [ON]/[OFF] [OFF]...
Page 493 17. Materials Menu Default settings [Control Panel] [ON] [Show/Hide Monitor Layout] [Black Screen] [ON] [Blinking Highlights] [OFF] [ZEBRA1]/[ZEBRA2]/ [OFF] [OFF] [Zebra Pattern] [SET] — [Monitor] [MODE2] [HLG View Assist] [HDMI] [AUTO] [ON]/[OFF] [OFF] [Sheer Overlay] [SET] — [I.S. Status Scope] [OFF] [Custom]: [Lens / Others]...
Page 494 17. Materials Menu Default settings [Setup]: [Monitor / Display] [Sleep Mode] [5MIN.] [Sleep Mode(Wi-Fi)] [ON] [Power Save Mode] [Auto LVF/Monitor Off] [5MIN.] [Power Save LVF — Shooting] [Monitor Frame Rate] [60fps] [LVF Frame Rate] [60fps] [Monitor Settings]/[Viewfinder] — [Monitor Backlight]/[LVF Luminance] [AUTO] [Remaining Battery Level] [Backlight]...
Page 495 17. Materials Menu Default settings [HDMI Mode (Playback)] [AUTO] [HLG View Assist (HDMI)] [AUTO] [TV Connection] [VIERA Link (CEC)] [OFF] [Background Color(Playback)] [Setup]: [Setting] [Save to Custom Mode] — [Load Custom Mode] — [Limit No. of Custom Mode] [Edit Title] —...
Page 496 17. Materials Menu Default settings [My Menu]: [Edit My Menu] [Add] — [Sorting] — [Delete] — [Display from My Menu] [OFF] [Playback] menu: [Playback Mode] [Rotate Disp.] [ON] [Picture Sort] [DATE/TIME] [Magnify from AF Point] [OFF] [HLG View Assist (Monitor)] [MODE2] [Playback] menu: [Process Image]...
Page 497: List Of Functions That Can Be Set In Each Recording Mode
17. Materials List of Functions That Can Be Set in Each Recording Mode Menu [Photo]: [Image Quality] [Photo Style] [Metering Mode] [Aspect Ratio] [Picture Quality] [Picture Size] [HLG Photo] [Start] [Simul Record Normal Shot] [High Resolution Mode] [Shutter Delay] [Motion Blur Processing] [Long Exposure NR] [ISO Auto Lower Limit Setting]...
Page 498 17. Materials Menu [ON]/[OFF] [Focus Peaking] [SET] [1-Area AF Moving Speed] [Photo]: [Flash] [Flash Mode] [Firing Mode] [Flash Adjust.] [Flash Synchro] [Manual Flash Adjust.] [Auto Exposure Comp.] [Red-Eye Removal] [Wireless] [Wireless Channel] [Wireless FP] [Communication Light] [Wireless Setup] [Photo]: [Others (Photo)] [Bracketing Type] [Bracketing] [More Settings]...
Page 499 17. Materials Menu [Burst Shot 1 Setting] [Burst Shot 2 Setting] [Shutter Type] [Shutter Delay] [Ex. Tele Conv.] [Time Lapse/Animation] [Self Timer] [Flicker Decrease (Photo)] [Picture Size / Burst Speed] [6K/4K PHOTO] [Rec Method] [Pre-Burst Recording] [Post-Focus] [Start] [Multiple Exposure] [Auto Gain] [Overlay] [Video]:...
Page 500 17. Materials Menu [Vignetting Comp.] [Diffraction Compensation] [Filter Effect] [Filter Settings] [Simultaneous Record w/ o Filter] [Auto Exposure in P/A/S/M] [F/SS/ISO/Exposure Comp.] [White Balance] [CreativeVideo Combined Set.] [Photo Style] [Metering Mode] [AF Mode] [Video]: [Image Format] [Rec Quality] [High Speed Video] [Rec.
Page 501 17. Materials Menu [Video]: [Audio] [Sound Rec Level Disp.] [Sound Rec Level Adj.] [Sound Rec Level Limiter] [Wind Noise Canceller] [Wind Cut] [Mic Socket] [Special Mic.] [XLR Mic Adaptor Setting] [Sound Output] [Video]: [Monitor / Display] [HDMI Rec Output] [Info Display] [Video]: [Others (Video)] [Operation Mode]...
Page 502: Specifications
17. Materials Specifications The specifications are subject to change for performance enhancement. Digital camera body (DC-S1): Information for your safety Power source: 9.0 V Power consumption: 6.3 W (when recording with the monitor) (When using the interchangeable lens (S-R24105)) 4.6 W (when playing back with the monitor) (When using the interchangeable lens (S-R24105)) Type Type...
Page 503 17. Materials Recording format for still images File format for still JPEG (DCF compliant, Exif 2.31 compliant) / RAW / HLG images photo (CTA-2072 compliant) File format for 6K/4K 6K photo: MP4 (H.265/HEVC, AAC (2ch)) photos 4K photo: MP4 (H.264/MPEG-4 AVC, AAC (2ch)) Picture size When the aspect ratio setting is [4:3] (pixels)
Page 504 17. Materials Recording format for video Video format AVCHD Progressive / AVCHD / MP4 / MP4 HEVC Audio format AVCHD Dolby Audio™ (2ch) AAC (2ch), LPCM (2ch, 48 kHz/16 bit) MP4 HEVC AAC (2ch) Image quality for [Rec. File Format]: [AVCHD], [MP4], [MP4 HEVC] videos Refer to page of this document for details.
Page 505 17. Materials Exposure control Light metering 1728-zone metering, multi-metering / center-weighted system, metering / spot metering / highlight-weighted metering Light metering mode Metering range EV 0 to EV 18 Exposure Program AE, Aperture-Priority AE, Shutter-Priority AE, Manual Exposure Exposure 1/3 EV steps, ±5 EV compensation ISO sensitivity 1/3 EV steps, AUTO / 100 to 51200...
Page 506 [RAWrFINE] / [RAWrSTD.]: 70 frames or more [RAW]: 90 frames or more When recording is performed under the test conditions specified by Panasonic Minimum illumination Approx. 6 lx (when the shutter speed is 1/30 of a second) (When using the interchangeable lens (S-R24105))
Page 507 17. Materials Interface SuperSpeed USB3.1 GEN1 Type C Supports USB Power Delivery (9.0 V/3.0 A) HDMI HDMI Type A [REMOTE] ‰ 2.5 mm jack [MIC] ‰ 3.5 mm jack Headphones ‰ 3.5 mm jack Flash Synchro Splash Resistant Dimensions / Mass Dimensions Approx.
Page 508 17. Materials 35 mm full-frame interchangeable lens: S-R24105 “LUMIX S 24-105 mm F4 MACRO O.I.S.” Mount Leica Camera AG L-Mount Focal length f=24 mm to 105 mm Lens construction 16 elements in 13 groups (2 aspherical ED lenses, 2 aspherical lenses, 1 UED lens, 2 ED lenses) Aperture type 9 diaphragm blades/Circular aperture diaphragm Maximum aperture...
Page 509: Index
17. Materials Index Numerics AFS ............Aperture Bracket ........ 1 Shot "6K/4K PHOTO" ..... Aperture-Priority AE mode ....1 Shot RAW+JPG......Approved Regulations ....... 1 Shot Spot Metering......Aspect Ratio ........1-Area (AF) ........Auto Clock Set ........1-area AF moving speed ....Auto Exposure Comp......
Page 510 17. Materials Delete confirmation ......Delete Location Data......Cable holder........Delete Single ........Calendar screen......... Destination Card Slot ......Card ........ 22, 46, 87, Device Name........Card Slot Change ..... 285, Dial operation switch setup ....Center marker ........Dial setting......... 336, Center-weighted metering....
Page 511 17. Materials Face/Eye/Body/Animal Detect..79, Gamma setting (Photo Style)..... File number....88, 435, 453, Group image ........File Number Reset....... Filter Effect ........Half-press shutter ......Filter Settings........HDAVI Control ........ Firing Mode........HDMI cable ....... 249, 426, Firmware update......17, HDMI mode (play)......
Page 512 17. Materials MF ............. MF Assist........... Joystick ..........MF Assist display ......Joystick setting........MF Guide........... Mic Socket......... Minimum shutter speed ..... Knee........... Monitor ........58, Monitor backlight ....... Monitor frame rate ......Lens ........21, 49, Monitor settings ......... Lens focus resume......
Page 513 17. Materials Photo style settings ......Rec/Playback Switch ....284, Photo/video preview ......Recording distance reference .... PHOTOfunSTUDIO ......Recording videos ....... Photos/videos remaining ....Recording with Time Lapse Shot ..PictBridge .......... Red-eye removal ....... Picture Quality ........Reduce Rolling Shutter ...... Picture Size .........
Page 514 17. Materials Shutter Remote Control .... 386, Shutter type........UHS Speed Class ....... Shutter-Priority AE mode ....USB connection cable Silent mode ............34, 38, 40, 433, 436, 439, Simultaneous Record w/o Filter ..USB mode ......... Sleep Mode.......... USB PD (USB Power Delivery) ...
Page 515 17. Materials Wireless ..........Wireless Channel ......Wireless flash ........Wireless FP ........Wireless icon ........Wireless printing ........ Wireless Setup ........WPS .......... 413, XLR Microphone Adaptor ....XQD card ..........Zebra pattern ........Zoom ..........
Page 516 17. Materials...
Page 517: Trademarks And Licences
Panasonic Corporation and Sony Corporation. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories. HDAVI Control™ is a trademark of Panasonic Corporation. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the United States and/or other countries.
Page 518 ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. ® The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance ®...
Page 519 17. Materials This product is licensed under the AVC Patent Portfolio License for the personal use of a consumer or other uses in which it does not receive remuneration to (i) encode video in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded by a consumer engaged in a personal activity and/or was obtained from a video provider licensed to provide AVC Video.
