• A pplications and their functions may vary by country, region, or hardware specifications. Samsung is not liable for performance issues caused by applications from any provider other than Samsung. • S amsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software.
Page 3
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics.
Page 4
About this manual Trademarks • S AMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. ® • B luetooth is a registered trademark of Bluetooth SIG, Inc. worldwide. ® ™ ™ ™ • W i-Fi...
Table of Contents Getting started Entering text Connecting to a Wi-Fi network Device layout Setting up accounts Buttons Transferring files Package contents Securing the device Installing the UIM or SIM card and Upgrading the device battery Charging the battery Inserting a memory card Communication Turning the device on and off Phone...
Page 6
About Settings Camera Connections Gallery My device Video Accounts YouTube More 102 Google Settings Application & media stores Troubleshooting Play Store Samsung Apps Play Music Utilities Memo S Planner Dropbox Drive Clock Calculator Voice Recorder Google Voice Search My Files Downloads Travel &...
Getting started Device layout Earpiece Power button Touch screen Home button Menu button Back button Microphone Multipurpose jack Headset jack GPS antenna Rear camera Volume button Back cover Speaker Main antenna...
Getting started • D o not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. • D o not use a screen protector. This causes sensor malfunctions. • D o not allow water to contact the touch screen. The touch screen may malfunction in humid conditions or when exposed to water.
• A ppearances and specifications are subject to change without prior notice. • Y ou can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase. • O ther accessories may not be compatible with your device.
Getting started Installing the UIM or SIM card and battery Insert the UIM or SIM card provided by the mobile telephone service provider, and the included battery. Only microUIM cards and microSIM cards work with the device. Remove the back cover. Be careful not to damage your fingernails when you remove the back cover.
Samsung Service Centre to remove the memory card. • U se caution not to lose or let others use the UIM or SIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.
Use the charger to charge the battery before using it for the first time. A computer can be also used to charge the device by connecting them via the USB cable. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.
Page 14
• I f the device is not charging properly, take the device and the charger to a Samsung Service Centre. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket.
Getting started Reducing the battery consumption Your device provides options that help you save battery power. By customising these options and deactivating features in the background, you can use the device longer between charges: • W hen you are not using the device, switch to sleep mode by pressing the Power button. •...
Page 16
Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.
Getting started Formatting the memory card A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device. On the Home screen, tap Apps → Settings → More → Storage → Format SD card → Format SD card →...
Getting started Holding the device Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. Locking and unlocking the device When not in use, lock the device to prevent unwanted operation. Pressing the Power button turns off the screen and puts the device into lock mode.
Getting started Using dual UIM or SIM cards If you insert two UIM or SIM cards, you can have two phone numbers or service providers for a single device. Activating UIM or SIM cards On the Home screen, tap Apps → Settings → Connections → UIM/SIM card manager. Select a UIM or SIM card, and then tick Activate.
Basics Indicator icons The icons displayed at the top of the screen provide information about the status of the device. The icons listed in the table below are most common. Icon Meaning No signal Signal strength Currently accessing UIM or SIM card Roaming (outside of normal service area) GPRS network connected EDGE network connected...
Basics Icon Meaning Flight mode activated Error occurred or caution required Battery power level Using the touch screen Use only fingers to use the touch screen. • D o not allow the touch screen to come into contact with other electrical devices. Electrostatic discharges can cause the touch screen to malfunction.
Page 22
Basics Tapping and holding Tap and hold an item for more than 2 seconds to access available options. Dragging To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the target position. Double-tapping Double-tap on a webpage or image to zoom in a part.
Page 23
Basics Flicking Flick left or right on the Home screen or the Applications screen to see another panel. Flick up or down to scroll through a webpage or a list, such as contacts. Pinching Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
Basics Control motions Simple motions allow easy control of the device. Before using motions, make sure the motion feature is activated. On the Home screen, tap Apps → Settings → My device → Motion, and then drag the Motion switch to the right. Excessive shaking or impact to the device may result in unintended inputs.
Page 25
Basics Picking up When you pick up the device after it has been idle for some time or when the screen has turned off, it vibrates if you have missed calls or new messages. Turning over Turn over the device to mute ringtone or pause media playback.
Basics Notifications Notification icons appear on the status bar at the top of the screen to report missed calls, new messages, calendar events, device status, and more. Drag down from the status bar to open the notifications panel. Scroll the list to see additional alerts. To close the notifications panel, drag up the bar that is at the bottom of the screen.
Basics Home screen The Home screen is the starting point to access all of the device’s features. It displays indicator icons, widgets, shortcuts to applications, and others. The Home screen can have multiple panels. To view other panels, scroll left or right. Changing the Home screen mode The Home screen has standard and easy modes.
Page 28
Basics Removing an item Tap and hold an item, and drag it to the rubbish bin that appears at the top of the Home screen. When the rubbish bin turns red, release the item. Rearranging panels Adding a new panel →...
Basics Using widgets Widgets are small applications that provide convenient functions and information on your Home screen. To use them, add widgets from the widgets panel to the Home screen. • S ome widgets connect to web services. Using a web-based widget may result in additional charges.
Page 30
Basics Drag the widgets panel down to expand it. Scroll right to the last page, tap , and then select a widget to add to the locked screen. Rearranging panels Moving a panel Drag the widgets panel down, scroll left or right, tap and hold a panel preview, and then drag it to a new location.
Basics Using applications This device can run many different types of applications, ranging from media to Internet applications. Opening an application On the Home screen or the Applications screen, select an application icon to open it. Some applications are grouped into folders. Tap a folder, and then tap an application to open it.
Page 32
Pinch on the screen, tap and hold a panel preview, and then drag it to a new location. Installing applications Use application stores, such as Samsung Apps, to download and install applications. Uninstalling applications → Uninstall, and then select an application to uninstall it.
Basics Entering text Use the Samsung keyboard or the voice input feature to enter text. Text entry is not supported in some languages. To enter text, you must change the input language to one of the supported languages. Changing the keyboard type Tap any text field, open the notifications panel, tap Select input method, and then select the type of keyboard to use.
Page 34
Basics Changing language keyboards Add languages to the keyboard, and then slide the space key left or right to change language keyboards. Handwriting Tap and hold , tap , and then write a word with a finger. Suggested words appear as characters are entered.
Basics Connecting to a Wi-Fi network Connect the device to a Wi-Fi network to use the Internet or share media files with other devices. (p. 86) Turning Wi-Fi on and off Open the notifications panel, and then tap Wi-Fi to turn it on or off. Turn off Wi-Fi to save the battery when not in use.
Basics Setting up accounts Google applications, such as Play Store, require a Google account, and Samsung Apps requires a Samsung account. Create Google and Samsung accounts to have the best experience with the device. Adding accounts Follow the instructions that appear when opening a Google application without signing in to set up a Google account.
Connect the device to the computer using the USB cable. Samsung Kies launches on the computer automatically. If Samsung Kies does not launch, double-click the Samsung Kies icon on the computer. Transfer files between your device and the computer.
Basics Securing the device Prevent others from using or accessing personal data and information stored in the device by using the security features. The device requires an unlock code whenever unlocking it. Setting a pattern On the Applications screen, tap Settings → My device → Lock screen → Screen lock → Pattern.
Turn on the screen by pressing the Power button or the Home button, and enter the unlock code. If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it. Upgrading the device The device can be upgraded to the latest software.
Page 40
Basics Upgrading over the air The device can be directly upgraded to the latest software by the firmware over-the-air (FOTA) service. On the Applications screen, tap Settings → More → About device → Software update → Update.
Communication Phone Use this application to make or answer a call. Tap Phone on the Applications screen. Making calls Making a call Use one of the following methods: • K eypad: Enter the number using the keypad, and then tap •...
Page 42
Communication Finding contacts Enter a name, phone number, or email address to find a contact in the contacts list. As characters are entered, predicted contacts appear. Select one to place a call to it. Making an international call Tap and hold 0 until the + sign appears. Enter the country code, area code, and phone number, and then tap During a call The following actions are available:...
Page 43
Communication Adding contacts To add a phone number to the contacts list from the keypad, enter the number and tap Add to contacts. Viewing call logs Tap Logs to view the history of incoming and outgoing calls. → View, and then select an option. To filter a call log, tap Fixed dialling number The device can be set to restrict outgoing calls only to numbers with specified prefixes.
Page 44
Communication Rejecting a call When a call comes in, drag outside the large circle. To send a message when rejecting an incoming call, tap Reject call with message. To create → Call settings → Set up call rejection messages. the rejection message, tap Missed calls If a call is missed, appears on the status bar.
Communication Contacts Use this application to manage contacts, including phone numbers, email addresses, and others. Tap Contacts on the Applications screen. Managing contacts Tap Contacts. Creating a contact and enter contact information. • : Add an image. • / : Add or delete a contact field.
Page 46
→ Merge accounts → Merge with Google. Contacts moved to Google Contacts appear with in the contacts list. Moving contacts to Samsung → Merge accounts → Merge with Samsung. Contacts moved to Samsung Contacts appear with in the contacts list.
Page 47
Communication Importing and exporting contacts Tap Contacts. Importing contacts → Import/Export, and then select an import option. Exporting contacts → Import/Export, and then select an export option. Sharing contacts → Share namecard via, select contacts, tap Done, and then select a sharing method. Favourite contacts Tap Favorites.
Page 48
Communication Managing groups , and then take one of the following actions: • C reate: Make a new group. • S earch: Search for contacts. • C hange order: Tap and hold next to the group name, drag it up or down to another position, and then tap Done.
Communication Messages Use this application to send text messages (SMS) or multimedia messages (MMS). Tap Messages on the Applications screen. You may incur additional charges for sending or receiving messages while you are outside your home service area. For details, contact your service provider. Sending messages , add recipients, enter a message, and then tap Use the following methods to add recipients:...
Communication Email Use this application to send or view email messages. Tap Email on the Applications screen. Setting up email accounts Set up an email account when opening Email for the first time. Enter the email address and password. Tap Next for a private email account, such as Google Mail, or tap Manual setup for a company email account.
Communication Reading messages Select an email account to use, and new messages are retrieved. To manually retrieve new messages, tap Tap a message to read. Add this email address to the contacts list. Mark the message as a reminder. Open attachments. Forward the message.
Page 52
Communication Sending messages In any mailbox, tap , enter recipients, a subject, and a message, and then tap → Attach picture to attach images. → Attach file to attach videos. → Add Cc/Bcc to add more recipients. → Save draft to save the message for later delivery. →...
Communication Labels Google Mail does not use actual folders, but uses labels instead. When Google Mail is launched, it displays messages labelled Inbox. Tap to view messages in other labels. → Change labels, and then select To add a label to a message, select the message, tap the label to assign.
Tap ChatON on the Applications screen. This application may not be available depending on the region or service provider. Create a buddies list by entering phone numbers or Samsung account email addresses, or by selecting buddies from the list of suggestions.
Web & network Internet Use this application to browse the Internet. Tap Internet on the Applications screen. Viewing webpages Tap the address field, enter the web address, and then tap Go. to access additional options while viewing a webpage. Opening a new page →...
Web & network History → History to open a webpage from the list of recently-visited webpages. To clear the → Clear history. history, tap Saved pages → Saved pages. To view saved webpages, tap Links Tap and hold a link on the webpage to open it in a new page, save, or copy. →...
• D o not use the Bluetooth feature for illegal purposes (for example, pirating copies of files or illegally tapping communications for commercial purposes). Samsung is not responsible for the repercussion of illegal use of the Bluetooth feature. To activate Bluetooth, on the Applications screen, tap Settings → Connections →...
Page 58
Web & network Pairing with other Bluetooth devices On the Applications screen, tap Settings → Connections → Bluetooth → Scan, and detected devices are listed. Select the device you want to pair with, and then accept the auto- generated passkey on both devices to confirm. Sending and receiving data Many applications support data transfer via Bluetooth.
Media Music Use this application to listen to music. Tap Music on the Applications screen. Playing music Select a music category, and then select a song to play. Tap the album image at the bottom of the screen to open the music player screen. Search for other devices to play Adjust the volume.
Media → Settings → Smart volume. To listen to songs at equal volume levels, tap When Smart volume is activated, the volume may end up louder than the device volume level. Use caution to avoid long-term exposure to loud sounds to prevent damage to your hearing.
Page 61
Media Camera etiquette • D o not take photos or videos of other people without their permission. • D o not take photos or videos where legally prohibited. • D o not take photos or videos in places where you may violate other people’s privacy. Taking photos Taking a photo to take the photo.
Page 62
Media • B each/Snow: Use this setting for well-lit or sunny outdoor scenes. • S unset: Use this setting for richer colours and sharper contrasts. • D awn: Use this setting for very subtle colours. • A utumn color: Use this setting for red-shifted background scenery. •...
Page 63
Media Panoramic photos A panoramic photo is a wide landscape image consisting of multiple shots. → Shooting mode → Panorama. and move the camera in one direction. When the blue frame aligns with the viewfinder, the camera automatically takes another shot in a panoramic sequence. To stop shooting, tap If the viewfinder is out of the direction, the device stops shooting.
Page 64
Media Recording mode Select among various effects that are available. Indicates which storage is in use. Change the recording mode. Switch between still and video mode. Adjust the brightness. Change the camera View photos and settings. videos you have taken. Set delayed-time shots.
Page 65
Media Use one of the following methods: • U se the Volume button to zoom in or out. • S pread two fingers apart on the screen to zoom in, and pinch to zoom out. The zoom in/out effect is available when using the zoom feature while shooting video.
Media • M etering: Select a metering method. This determines how light values are calculated. Center-weighted measures background light in the centre of the scene. Spot measures the light value at a specific location. Matrix averages the entire scene. •...
Page 67
Media Zooming in and out Use one of the following methods to zoom in an image: • D ouble-tap anywhere to zoom in. • S pread two fingers apart on any place to zoom in. Pinch to zoom out, or double-tap to return.
Page 68
Media • R otate left: Rotate anticlockwise. • R otate right: Rotate clockwise. • C rop: Resize the blue frame to crop and save the image in it. • S et as: Set the image as wallpaper or a contact image. •...
Page 69
Media Setting as wallpaper → Set as to set the image as wallpaper or to assign it to a When viewing an image, tap contact. Tagging faces → Settings, and then tick Face tag. A yellow frame appears around the recognised face.
Media Video Use this application to play video files. Tap Video on the Applications screen. Playing videos Select a video to play. Search for other Adjust the volume. devices to play the file. Move forwards or Skip to the next video. backwards by Tap and hold to move dragging the bar.
Media Using Popup Video player Use this feature to use other applications without closing the video player. While watching videos, tap to use the pop-up player. Spread two fingers apart on the screen to enlarge the player or pinch to reduce it. To move the player, drag the player to another location.
Application & media stores Play Store Use this application to purchase and download applications and games that are able to run on the device. Tap Play Store on the Applications screen. This application may not be available depending on the region or service provider. Installing applications Browse applications by category, or tap to search with a keyword.
Application & media stores Samsung Apps Use this application to purchase and download dedicated Samsung applications. For more information, visit apps.samsung.com . Tap Samsung Apps on the Applications screen. This application may not be available depending on the region or service provider.
Utilities Memo Use this application to record important information to save and view at a later date. Tap Memo on the Applications screen. Composing memos , enter a memo, and then tap Save. → Color. To change the background colour, tap →...
Utilities Viewing a memo Tap the memo thumbnail to open it. Scroll left or right to see more memos. and use the following: • D elete: Delete the memo. • C olor: Change the background colour. • L ock: Lock the memo so that others cannot view it. •...
Page 76
Utilities To add an event or task more briefly, tap a date to select it and tap it again. Enter a title and specify which calendar to use or sync with. Then tap Edit event details or Edit task details to add more details, such as how often the event repeats, when it has an advance alert, or where it takes place.
Utilities Changing calendar type Select one from among different types of calendars including year, month, week, and others at the right side of the screen. A pinch gesture can be used to change calendar type. For example, pinch to change from the monthly calendar to the yearly calendar, and spread apart to change yearly calendar back to monthly calendar.
Utilities When running Dropbox for the first time, tap Start to activate it. Follow the on-screen instructions to complete the setup. Sign in to your Dropbox account. If you do not have it, create a Dropbox account. Once Dropbox is activated, tap Turn on Camera Upload to upload photos and videos taken with the device’s camera to Dropbox automatically.
Utilities Clock Use this application to set alarms, check the time of many major cities in the world, measure the duration of an event, or set a timer. Tap Clock on the Applications screen. Turn this alarm on or off. Alarm Setting alarms Tap Create alarm, set a time for the alarm to go off, select days for the alarm to repeat, and...
Utilities Deleting alarms Tap and hold the alarm, and then tap Delete. World Clock Creating clocks Tap Add city and enter a city name or select a city from the cities list. To apply summer time, tap and hold a clock, and then tap DST settings. Deleting clocks →...
Utilities Voice Recorder Use this application to record or play voice memos. Tap Voice Recorder on the Applications screen. Recording voice memos to start recording. Speak into the microphone at the bottom of the device. Tap pause recording. Tap to finish recording. Change the recording quality.
Utilities Managing voice memos In the list of voice memos, tap and select one of the following: • S hare via: Select voice memos to send, and then select a sharing method. • D elete: Select voice memos to delete. •...
Utilities Google Now Launch Google search to view Google Now cards that show the current weather, public transit info, your next appointment, and more when you are most likely to need it. Join Google Now when opening Google search for the first time. To change Google Now →...
Utilities Searching for a file → Search, and then enter search criteria. Adding shortcuts to folders → Add shortcut, enter Add a shortcut of frequently-used folders to the root directory. Tap a shortcut name, tap OK, select a folder, and then tap Set here. Downloads Use this application to see what files are downloaded through the applications.
Travel & local Maps Use this application to pinpoint the location of the device, search for places, or get directions. Tap Maps on the Applications screen. This application may not be available depending on the region or service provider. Searching for locations Search for locations by entering an address or a keyword.
Settings About Settings Use this application to configure the device, set application options, and add accounts. Tap Settings on the Applications screen. Connections Wi-Fi Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other network devices.
Page 87
Settings Setting Network notification The device can detect open Wi-Fi networks and display an icon on the status bar to notify when available. On the Settings screen, tap Wi-Fi → → Advanced and tick Network notification to activate this feature. Wi-Fi Direct Wi-Fi Direct connects two devices directly via a Wi-Fi network without requiring an access point.
Page 88
Settings UIM/SIM card manager Activate your UIM or SIM cards and customise the card settings. Mobile data Set the device to use data connections on any mobile network. More networks Customise settings to control networks. Airplane mode This disables all wireless functions on your device. You can use only non-network services. Mobile networks •...
Settings Tethering and portable hotspot • P ortable Wi-Fi hotspot: Use the portable Wi-Fi hotspot to share the device’s mobile network connection with computers or other devices through the Wi-Fi network. • U SB tethering: Use USB tethering to share the device’s mobile network connection with a computer via USB.
Page 90
Settings For a clock: – Dual clock: Set the device to show the dual clock. – Clock size: Change the size of the clock. – Show date: Set the device to show the date with the clock. – Owner information: Enter your information that is shown with the clock. For a personal message: –...
Page 91
Settings Sound Change settings for various sounds on the device. • V olume: Adjust the volume level for call ringtones, music and videos, system sounds, and notifications. • V oice call ringtone (slot 1): Select a ringtone for incoming calls for CDMA networks. •...
Page 92
Settings • C all alerts: – Answer vibration: Set the device to vibrate when the other party answers a call. – Call-end vibration: Set the device to vibrate when the other party ends a call. – Call connect tone: Activate or deactivate the call connection tone. –...
Page 93
Settings – Slot 2: Caller ID: Display your caller ID to other parties for outgoing calls. Call forwarding: Divert incoming calls to another number. Call barring: Block incoming or outgoing calls. Call waiting: Allow incoming call alerts when a call is in progress. Auto redial: Activate auto redial for calls that were not connected or that were cut off.
Page 94
Settings Blocking mode Select which notifications will be blocked or set to allow notifications for calls from specified contacts in blocking mode. Hands-free mode Set the device to read contents aloud and specify applications to use in hands-free mode. Call/message block Set the device to reject calls or messages from specified phone numbers or reject messages containing specified text.
Page 95
Settings • A nswering/ending calls: – The home key answers calls: Set the device to answer a call when you press the Home button. – Answer calls by tapping: Set the device to answer a call when you tap the call accept button twice.
Page 96
Select a default keyboard type for text input. Samsung keyboard To change the Samsung keyboard settings, tap The available options may vary depending on the region or service provider. • S elect input languages: Select languages for text input.
Page 97
• S ound: Set the device to vibrate when a key is touched • C haracter preview: Set the device to display a large image of each character tapped. • T utorial: Learn how to enter text with the Samsung keyboard. • R eset settings: Reset Samsung keyboard settings.
Accounts Add account Add email or SNS accounts. Cloud Change settings for syncing data or files with your Samsung account or Dropbox cloud storage. Reset Change the settings for managing settings and data. • B ack up my data: Set the device to back up settings and application data to the Google server.
• R emote controls: Set the device to allow control of your lost or stolen device remotely via the Internet. To use this feature, you must sign in to your Samsung account. – Add account: Add or view your Samsung account.
Page 100
Settings • G o to the find My mobile webpage: Access the Find my mobile website ( findmymobile.samsung.com ). You can track and control your lost or stolen device on the Find my mobile website. • S et UIM/SIM card lock: –...
Page 101
Settings Application manager View and manage the applications on your device. Battery View the amount of battery power consumed by your device. Storage View memory information for your device and memory card, or format a memory card. Formatting a memory card permanently deletes all data from it. The actual available capacity of the internal memory is less than the specified capacity because the operating system and default applications occupy part of the memory.
Settings About device Access device information, edit the device name, or update device software. Google Settings Use this application to configure settings for some features provided by Google. Tap Google Settings on the Applications screen.
Page 103
Troubleshooting Before contacting a Samsung Service Centre, please attempt the following solutions. Some situations may not apply to your device. When you turn on your device or while you are using the device, it prompts you to enter one of the following codes: •...
Page 104
• R estart your device to clear any temporary software bugs. • E nsure that your device software is upgraded to the latest version. • I f the touch screen is scratched or damaged, visit a Samsung Service Centre. Your device freezes or has fatal errors If your device freezes or hangs, you may need to close applications or reinsert the battery and turn on the device to regain functionality.
Page 105
The battery icon is empty Your battery is low. Recharge or replace the battery. The battery does not charge properly (For Samsung-approved chargers) • E nsure that the charger is connected properly. • I f the battery terminals are dirty, the battery may not charge properly or the device may turn off.
Page 106
• F ree some memory by transferring files to a computer or deleting files from your device. • R estart the device. If you are still having trouble with the camera application after trying these tips, contact a Samsung Service Centre. Photo quality is poorer than the preview •...
Page 107
• I f you are a Windows XP user, ensure that you have Windows XP Service Pack 3 or higher installed on your computer. • E nsure that you have Samsung Kies or Windows Media Player 10 or higher installed on your computer.
Page 108
Data stored on the device has been lost Always make backup copies of all important data stored on the device. Otherwise, you cannot restore data if it is corrupted or lost. Samsung is not responsible for the loss of data stored on the device.
Page 109
Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. www.samsung.com English (SEA). 06/2014. Rev.1.0...
