- Page 1 Intel® Compute Stick STCK1A32WFC STCK1A32FC STCK1A8LFC Technical Product Specification September 2015 Order Number: H91229-001...
-
Page 2: Revision History
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order. Intel, the Intel logo, Intel Compute Stick, and Intel Core are trademarks of Intel Corporation in the U.S. and/or other countries. -
Page 3: Preface
BIOS for Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC. NOTE In this document, the use of “Intel Compute Stick” will refer to the STCK1A32WFC, STCK1A32FC and STCK1A8LFC versions of the Intel Compute Stick. Intended Audience... - Page 4 Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification Other Common Notation Used after a signal name to identify an active-low signal (such as USBP0#) Gigabyte (1,073,741,824 bytes) GB/s Gigabytes per second Gb/s Gigabits per second Kilobyte (1024 bytes)
-
Page 5: Table Of Contents
Contents Revision History Errata .................................... ii Preface Intended Audience..............................iii What This Document Contains ........................iii Typographical Conventions ..........................iii 1 Product Description Overview ................................. 7 1.1.1 Version Summary ........................7 1.1.2 Feature Summary ........................7 1.1.3 Location of Components ....................... 8 1.1.4 Block Diagram .......................... - Page 6 Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification 3 Overview of BIOS Features Introduction ..............................21 BIOS Flash Memory Organization ..................... 21 System Management BIOS (SMBIOS) ....................21 BIOS Updates ............................. 22 3.4.1 Language Support ......................... 22 BIOS Recovery ............................22 Boot Options ..............................
-
Page 7: Product Description
1.1.1 Version Summary There are three different versions of this model of Intel® Compute Stick available which are summarized in Table 1. Unless otherwise noted in this document all features are available on all versions of the Intel Compute Stick. -
Page 8: Location Of Components
Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification 1.1.3 Location of Components Figures 1 and 2 show the location of the components on the Intel Compute Stick. Item Description HDMI Connector Power LED Micro SD Card Reader Slot Figure 1. -
Page 9: Block Diagram
Product Description 1.1.4 Block Diagram Figure 3 is a block diagram of the major functional areas of the Intel Compute Stick. Figure 3. Block Diagram... -
Page 10: Online Support
To find information about… Visit this World Wide Web site: Intel Compute Stick drivers http://downloadcenter.intel.com Processor The Intel Compute Stick has a soldered-down System-on-a-Chip (SoC), which consists of an Intel Atom Processor Z3735F. • Integrated graphics • Integrated memory controller •... -
Page 11: System Memory
Product Description System Memory The Intel Compute Stick has soldered-down memory and supports the following memory features: • DDR3L/L-RS 1.35 V 1333 MHz • Single-channel memory • 2 GB memory on STCK1A32WFC and STCK1A32FC • 1 GB memory on STCK1A8LFC. -
Page 12: Usb
Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification 1.7.1.3 High Definition Multimedia Interface* (HDMI*) The HDMI port supports standard, enhanced, or high definition video, plus multi-channel digital audio on a single cable. The port is compatible with all ATSC and DVB HDTV standards and supports eight full range channels at 24-bit/96 kHz audio of lossless audio formats. -
Page 13: Hardware Management Subsystem
ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the Intel Compute Stick requires an operating system that provides full ACPI support. ACPI features include: •... -
Page 14: Power States And Targeted System Power
The operating system uses information from applications and user settings to put the system as a whole into a low-power state. Table 4 lists the power states supported by the Intel Compute Stick along with the associated system power targets. See the ACPI specification for a complete description of the various system and power states. -
Page 15: Hardware Support
1.11.2.1 Power Input When resuming from an AC power failure, the Intel Compute Stick may return to the power state it was in before power was interrupted (on or off). The Intel Compute Stick’s response can be set using the Last Power State feature in the BIOS Setup program’s Boot menu. - Page 16 Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification...
-
Page 17: Technical Reference
2.1.1 Addressable Memory The Intel Compute Stick utilizes up to 4 GB of addressable system memory. Typically the address space that is allocated for PCI Conventional bus add-in cards, PCI Express configuration space, BIOS (SPI Flash device), and chipset overhead resides above the top of DRAM (total system memory). -
Page 18: Connectors
This section describes the connectors available on the Intel Compute Stick. 2.2.1 USB 2.0 Connector The Intel Compute Stick has a single full size USB 2.0 connector that supports compliant USB devices. Bootable USB devices are supported. Figure 4. USB 2.0 Connector NOTE It is recommended to only use a powered USB Hub with the Compute Stick’s USB port. -
Page 19: Power Adapter Connector
Figure 6. Power Adapter Connector 2.2.4 Power Adapter The Intel Compute Stick uses a 5V 2A AC to DC power adapter. The power adapter is connected to the Intel Compute Stick via a three foot USB Type A to B cable. Item... -
Page 20: Reliability
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz Before attempting to operate the Intel Compute Stick, the overall temperature of the Intel Compute Stick must be above the minimum and below the maximum operating temperatures specified. The operating and non-operating... -
Page 21: Overview Of Bios Features
Overview of BIOS Features Introduction The Intel Compute Stick uses an Intel BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated using a disk-based program. The SPI Flash contains the BIOS Setup program, POST, the PCI auto-configuration utility, and Plug and Play support. The initial production BIOSs are identified as FCBYT10H.86A. -
Page 22: Bios Updates
CD-ROM. • Intel F7 switch during POST allows a user to select where the BIOS .bio file is located and perform the update from that location/device. All utilities verify that the updated BIOS matches the target system to prevent accidentally installing an incompatible BIOS. -
Page 23: Boot Options
At the point where Setup Entry/Boot would be in the normal boot path, the BIOS will display the following prompt and wait for a keystroke: [ESC] Normal Boot [F2] Intel BIOS [F4] BIOS Recovery [F7] Update BIOS [F8] Operating System Recovery... -
Page 24: Bios Error Messages
Intel Compute Stick STCK1A32WFC, STCK1A32FC and STCK1A8LFC Technical Product Specification BIOS Error Messages Table 9 lists the error messages and provides a brief description of each. Table 9. BIOS Error Messages Error Message Explanation CMOS Battery Low The battery may be losing power. Replace the battery soon.
