Index ........80 You can find support, information and content downloads at www.sonyericsson.com/support. Draft for Sony Ericsson Internal Use Only...
Page 4
Sony Ericsson Mobile Communications AB or its local affiliated company at any time and without notice. Such changes will, however, be incorporated into new editions of this User guide.
Page 5
Bluetooth™ is a trademark or registered trademark of Bluetooth SIG Inc. T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554;...
Page 7
User guide symbols The following instruction symbols appear in this User guide: Use the navigation key to scroll and select % 14 Navigating the menus. Press the navigation key center. Press the navigation key up. Press the navigation key down. Press the navigation key to the left.
Getting to know your phone Navigation key Volume Infrared port buttons Selection key Selection key Back key C key MEdia Net key On/off key Microphone Charger and USB connector...
Page 9
Camera lens Icon display External display The icon display lights up when the phone is in silent mode and shows information about new events and battery charging. The external display shows information such as time, service provider and signal strength. Press a volume button to activate the external display.
Page 10
jÉåì=çîÉêîáÉï Mobile Email Messaging Recent Calls** Write New Inbox Answered Dialed Call Voicemail Missed Outbox Drafts Sent Messages Saved Messages Templates Settings MEdia Net AT&T Mall Entertainment Online Services Games MusicDJ™ Record Sound My Stuff Address Book* Alarms Camera Album Ringtones Pictures Themes...
Page 11
Applications General Calendar Sounds & Alerts Tasks Display Notes Calls Synchronization Connectivity Timer Stopwatch Calculator Password Saver *Options when phone contacts are set to default. Options change when SmartChip contacts are set to default. **Use the navigation key to move across tabs in submenus. For more information % 14 Navigating the menus.
Page 12
Status bar icons Icon Description GSM network signal strength. Battery status. Battery charging, appears with battery status icon. Missed an incoming call. Call and messaging alerts off, alarm on. Text message received. Email message received. Picture message received. Ongoing call. Calendar reminder.
Page 13
Assembling your phone Insert the SmartChip and the battery to use your phone. SmartChip When you register as a subscriber with AT&T, you get a SmartChip. The SmartChip keeps track of your phone number, the services included in your subscription, and your contacts information, among other things.
Page 14
Some functions use more battery power than others so that your phone need more frequent charging.Talk time or standby time may become shorter in time and you may need a new battery. Only use Sony Ericsson-approved batteries. % 68 Battery.
Page 15
You may need a PIN (Personal Identification Number) from your network operator for your SmartChip. When you enter the PIN, each digit appears as *, unless it starts with emergency number digits, for example 112 or 911. This is so you can make emergency calls without entering a PIN. % 21 Emergency calls.
Page 16
Shut down menu Use the shut down menu to turn off the phone, turn silent mode on or activate a profile. For more information about profiles % 53 Profiles. To open the shut down menu Press and select an option from the list. Making calls During an incoming call, the keypad and outer rim of the phone light up % 44 Light effects.
Page 17
Navigating the menus The main menus are shown as icons. Some submenus include tabs. • Press the center of the navigation key to go to the main menus from standby or to select menu items. • Press to scroll through menus and tabs.
Page 18
Select a shortcut you want to edit Edit. Scroll to and select a function Shortcut. Activity menu Use the activity menu to view and handle new events, and access bookmarks and shortcuts. To open the activity menu Press and use to select a tab.
Page 19
Select Move or Copy. } New Select a folder or Folder. Name the folder Paste. To select several files Menu } My Stuff From standby select and select a file } More } Mark. 2 } Mark Several } Mark All.
Page 20
Entering letters To enter letters using multitap text input Scroll to a function where text input is possible, for Menu } Messaging } Write New } example, Message. • Press – until the desired character appears. • Press to shift between capitals and lower-case letters.
Page 21
To add words to the T9 Text Input dictionary } More } Spell While entering letters Word. Edit the word by using multitap input. Use navigate between letters. To delete a character, press . To delete the entire word, press and hold When you have edited the word Insert.
Calling Making and receiving calls Turn on the phone and make sure that you are within range of a network to make and receive calls % 12 To turn the phone on and off. • If your subscription includes a Calling Line Identification service and the caller’s number is identified, the number is displayed.
Page 23
To change the ear speaker volume During a call, press to increase or decrease the volume. To select more options during a call } More and select an option. To turn off the microphone Press and hold . To resume, press and hold again.
Page 24
Emergency calls Your phone supports international emergency numbers, for example, 911 and 112. These numbers can normally be used to make an emergency call in any country, with or without a SmartChip inserted, if a GSM network is within range. In some countries, other emergency numbers may also be promoted.
Page 25
To add a picture, light effect or a ringtone to a phone contact Menu } Address Book From standby select and select a contact. 2 } More } Edit Contact. to scroll to the relevant tab. Light Effect } Picture, Ringtone Add.
Page 26
to select a number Call. To call a SmartChip contact Menu } Address • SmartChip contacts is default, Book, scroll to or enter the first letters of a contact. When the contact is highlighted Call. Menu } Address Book } •...
Page 27
To copy SmartChip contacts to phone contacts Menu } Address Book } More } From standby select Options } Advanced } Copy from SmartChip. Select Copy All, Copy a Contact Copy a Mumber. To automatically save contacts to the SmartChip Menu } Address Book } More } From standby select Options } Advanced } Auto Save on...
Page 28
To check memory status Menu } Address Book } More } From standby select Options } Advanced } Memory status. The number of entries you can save in the phone or on the SmartChip depends on the available memory. Synchronizing contacts For more information, % 46 Synchronizing.
Page 29
To check your voicemail number Menu } Messaging } Settings } From standby select Voicemail Number. Forwarding calls Forward calls, for example, to an answering service. To activate a call forward Menu } Settings } Calls } From standby select Forward Calls.
Page 30
Receiving a second call When you receive a second call, you can: • } Answer and put the ongoing call on hold. • } Busy to reject and continue the ongoing call. • } Replace Actve Call to answer and to end the ongoing call.
Page 31
Repeat steps 1-3 to include more participants. To release a participant } More } Release part. and select the participant. To have a private conversation 1 } More } Talk to and select a participant. 2 } More } Join Calls to resume the conference call.
Page 32
Notepad Use the screen as a notepad to enter a phonenumber during a call. When you end the call, the number remains on the screen to call or save. Showing or hiding your number If your subscription supports Calling Line Identification Restriction, you can hide your phone number when making a call.
Messaging Your phone supports various messaging services. Contact your service provider about the services you can use, or for more information see www.sonyericsson.com/ support. If there is no memory available, you must delete messages or email messages before you can receive new ones. Text and picture messaging Text messages can contain pictures, videos, sound effects, animations, and melodies.
Page 34
• Enter Email Addr. to send the message to an email address. • Enter Phone no. to send the message to a contact not in the Address Book. • Addr. Book Look-up to send the message to an address. To copy and paste text in a mesage 1 When writing your message, select More } Copy &...
Page 35
To select additional send options 1 When the message is ready and a recipient is selected, select More: • Add Recipient to add another recipient. • Edit Recipients to edit and add recipients. • Edit Subject to edit the subject. •...
Page 36
To save several messages 1 From standby select Menu } Messaging and select a folder. 2 Scroll to and select a message. 3 Select More } Mark Several. 4 Scroll to and select the messages. 5 Select More } Saved Messages to save messages. To close a text or picture message •...
Page 37
3 } Send to send the message. 4 Select Enter Phone no. to enter the recipient’s number or Addr. Book Look-up to retrieve a number or group from Address Book, or select from the last used recipients list. } Send. Mobile Email Check your Yahoo!™...
Page 38
and receive messages and see contact status when they are online. Contact your network operator for more information. To log in/out to your IM server 1 From standby select Menu } Messaging } IM. 2 Sign into the IM community you want to access. To add a contact to the list 1 From standby select Menu } Messaging } IM } Buddies tab } More.
Imaging Camera Your phone has a digital camera to take pictures to save or send. Use a picture as a screen saver, wallpaper or to add to a contact. To start the camera and take a picture Menu } Press or from standby select Camera=to start the camera.
Page 41
To adjust brightness Use the volume buttons to increase or decrease brightness. If you take a picture of a strong light source such as direct sunlight or a lamp in the background, the screen may black out or the picture may be distorted.
Page 42
To blog a photo } More } Blog Take a photo This. Follow the instructions for first-time use. } OK } Add title and text Publish. You will receive a text message with your Web address and log-in information. Pictures Your phone comes with one or more pictures that you can delete to free memory.
Page 43
To send a picture Menu } Camera From standby select Album. } More } Send Select a picture and select a transfer method. To receive and save a picture From a message containing the file, % 30 Messaging. • • Via another transfer method, make sure the transfer method is activated and follow the instructions that appear.
Entertainment Ringtones, sounds and alerts Your phone comes with melodies that can be used as ringtones. You can exchange melodies by selecting a transfer method. Certain non-supported sound files cannot be used as ringtones. You may not be allowed to exchange copyright-protected material.
Page 45
Composing ringtone melodies ™ Use MusicDJ to compose and edit melodies to use as ringtones. To compose a melody Menu } Entertainment } From standby select MusicDJ™. Select Insert, Copy Paste blocks to compose. Use to move between the blocks. Press } More to delete a block.
Page 46
2 } Play to listen to the recording. Press to go to } Stop the previous or next recording. to stop } More playback. to view options. Themes, light effects, games and applications Your phone comes with predefined themes, light effects games and applications.
Page 47
To select a day or night theme Menu } Settings } Display } From standby select Night Theme Theme. Select a theme Set. Light effects Light effects notify you of an incoming call or a new message by lighting up the keypad and outer rim of the phone.
Connectivity Using MEdia Net Browse the Internet using HTTP (Hyper Text Transfer Protocol). To select an Internet profile Menu } Settings } Connectivity } From standby select Internet Settings } Internet Profiles and select a profile to use. To start browsing Menu } MEdia From standby select Net, select a service...
Page 49
To check certificates in your phone Menu } Settings } General } From standby select Security } Certificates } Trusted Certificate. Synchronizing Synchronize contacts, appointments, tasks, notes and bookmarks using one of the available transfer methods.Visit www.sonyericsson.com/support to download Sony Ericsson PC Suite software for...
Page 50
You can also download the Getting started guide for synchronization. Synchronization with a computer Install Sony Ericsson PC Suite software by downloading it from www.sonyericsson.com/support. The software includes help information. Remote synchronization via Internet Synchronize online via an Internet service.
Page 51
Bluetooth™ wireless technology Bluetooth wireless technology makes wireless connection to other Bluetooth devices, for example a Bluetooth headset possible. You can: • connect to several devices at the same time. • synchronize information with other devices. • exchange items. The recommended maximum distance between two Bluetooth devices is 33 feet or 10 meters, with no solid objects in between.
Page 52
To pair a device with your phone Menu } Settings } Connectivity } From standby select Bluetooth } My Devices } New Device to search for available devices. Select a device from the list. Enter a passcode, if required. To save power Menu } Settings } Connectivity } From standby select Bluetooth } Powersave }...
Page 53
You may use a USB cable to exchange information between your phone and a computer. A USB cable is sold separately. To start a USB connection Install the Sony Ericsson PC Suite software on your computer. Download and install the PC Suite from www.sonyericsson.com/support. Turn on your phone.
Page 54
Transferring files You can transfer pictures, sounds, and themes by using one of the following transfer methods: Bluetooth % 48 Bluetooth™ wireless technology • Infrared % 49 Infrared port • USB cable % 50 USB cable • You can also send files via email % 34 Mobile Email or picture messages % 30 Text and picture messaging.
More features Time and date Time and date are always displayed in standby. To set the time and date Menu } Settings } General } Time & From standby select Date: } Time • To set time and time format, and enter the time } Format and select a format...
Page 56
Profiles Your phone has predefined profiles that are set to suit a certain environment. You can reset all profile settings to the way they were set when you bought your phone. To use profiles Menu } Settings } General } From standby select Profiles: •...
Page 57
To view an appointment Menu } Organizer } Calendar From standby select select a day. Select an appointment View. To view a calendar week Menu } Organizer } Calendar } From standby select More } View Week. To set reminders options Menu } Organizer } Calendar } From standby select More } Advanced }...
Page 58
• Advanced – view options to find and set reminders or select a start day for the week. • Delete – delete appointments. • Help – view help text for more calendar information. To send an appointment Menu } Organizer } Calendar From standby select } More } Send select an appointment...
Page 59
Notes Make notes and save them in a list. You can also view notes in standby. To add a note Menu } Organizer } Notes } New From standby select Note } Add. Enter the note Save. To edit notes Menu } Organizer } Notes From standby select select a note.
Page 60
Enter a new four- to eight-digit PIN OK. Re-enter the new PIN to confirm To edit your PIN Menu } Settings } General } From standby select Security } Locks } SmartChip Protection } Change PIN. Enter your PIN Enter a new four- to eight-digit PIN OK.
Page 61
Security } Locks } Phone Protection } Change Code. It is important that you remember your new code. If you forget it, you have to take your phone to your local Sony Ericsson retailer. Password Saver You can save security codes, such as pincodes and passwords.
Page 62
} Continue } New Code } Enter your passcode Add. Enter a name associated with the code; for example, the name of the credit card company Continue. Enter the code Done. To change the passcode Menu } Organizer } Password From standby select Saver.
The phone cannot be turned on The battery is discharged % 11 To charge the battery. Charging a non-Sony Ericsson battery % 68 Battery. The wrong menu language is shown % 16 To change the phone language.
Page 64
To reset your phone Menu } Settings } General } From standby select Master Reset. Select Reset Settings to delete your changes to settings or Reset Device to delete your changes to settings, all contacts, messages, personal data, and content you have downloaded, received or edited. Continue.
Page 65
Codes do not match To change a security code you have to confirm the new code by entering it twice. PIN Blocked PIN2 Blocked To unblock % 56 SmartChip lock. PUK blocked Contact your network operator. Phone locked The phone is locked. To unlock the phone % 57 Phone lock.
Global and local Web sites providing support • A global network of Call Centers • An extensive network of Sony Ericsson service partners • A warranty period. Learn more about the warranty conditions in this User guide On www.sonyericsson.com, under the support section in the...
Page 70
• Do not paint your product. • Do not attempt to disassemble or modify your product. Only Sony Ericsson authorized personnel should perform service. • Do not close your product with an object inserted between keypad and display; this may damage your product.
Page 71
Use only Sony Ericsson branded original chargers intended for use with your phone. Other chargers may not be designed to the same safety and performance standards.
Page 72
Please check if local laws and regulations restrict the use of phones while driving or require drivers to use handsfree solutions. We recommend that you use only Sony Ericsson handsfree solutions intended for use with your product. Please note that because of possible interference to electronic...
Page 73
Check with your local service provider. Antenna This phone contains a built-in antenna. Use of antenna devices not marketed by Sony Ericsson specifically for this model could damage your phone, reduce performance, and produce SAR levels above the established limits (see below).
Page 74
FCC RF exposure guidelines when the handset is positioned a minimum of 15 mm from the body without any metal parts in the vicinity of the phone or when used with the original Sony Ericsson accessory intended for this phone and worn on the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
Page 75
1996 (TTY) or 877 207 2056 (voice), or visit the Sony Ericsson Special Needs Center at www.sonyericsson-snc.com. Disposal of old electrical & electronic equipment This symbol indicates that all electrical and electronic equipment included shall not be treated as household waste.
Page 76
Please adjust the audio volume cautiously when using third-party audio accessories to avoid volume levels that may be harmful to your hearing. Sony Ericsson does not test use of third-party audio accessories with this phone. Sony Ericsson recommends using only Sony Ericsson original audio accessories.
Page 77
Sony Ericsson and its third party suppliers and licensors are the sole and exclusive owner of and retain all rights, title and interest in and to the Software. Sony Ericsson, and, to the extent that the Software contains material or code of a third party, such third party, shall be entitled third party beneficiaries of these terms.
Page 78
Product in accordance with the terms and conditions stipulated herein. Sony Ericsson and its service partners reserve the right to charge a handling fee if a returned Product is found not to be under warranty according to the conditions below.
Page 79
Since the cellular system on which the Product is to operate is provided by a carrier independent from Sony Ericsson, Sony Ericsson will not be responsible for the operation, availability, coverage, services or range of that system.
Page 80
Product is sold in such country by an authorised Sony Ericsson distributor. To find out if your Product is sold in the country you are in, please call the local Sony Ericsson Call Center. Please observe that certain services may not be...
Page 81
(1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. Declaration of Conformity We, Sony Ericsson Mobile Communications AB of Nya Vattentornet SE-221 88 Lund, Sweden declare under our sole responsibility that our product...
44 list 21 making 20 missed 21 handsfree 50 phone contact 23 help 14 redial 20 SmartChip contact 24 two calls 28 instant messaging 35 camera 38 internet 46 camera album 40 Draft for Sony Ericsson Internal Use Only...
Page 83
Mobile email 35 sending My numbers 29 appointments 56 business card 23 navigation key 15 contacts 25 networks 20 melodies 43 notes 57 pictures 40 ringtones 43 tasks 56 password saver 59 themes 44 Draft for Sony Ericsson Internal Use Only...
Page 84
33 warranty 74 text and picture messaging 31–?? text input 18 themes 44 alternating 44 time 53 transfer method 52 Bluetooth 49 infrared 50 USB cable 51 transferring files 52 troubleshooting 61 Draft for Sony Ericsson Internal Use Only...
Page 86
Sony Ericsson Mobile Communications AB SE-221 88 Lund, Sweden XX/LZT 000 0000P1A Printed in XXXXXX...
