Thinkify IDT 1000D TF3 User Manual And Installation Instructions

Rail reader

Advertisement

Quick Links

User manual – Installation Instructions
IDT 1000D TF3 Rail Reader
Thinkify
18450 Technology Drive
Morgan Hill, Ca. 95037
Product name: IDT T1000D
Model Number: TF3

Advertisement

loading

Summary of Contents for Thinkify IDT 1000D TF3

  • Page 1 User manual – Installation Instructions IDT 1000D TF3 Rail Reader Thinkify 18450 Technology Drive Morgan Hill, Ca. 95037 Product name: IDT T1000D Model Number: TF3...
  • Page 2 Legal Notice: Copyright 2009 Thinkify LLC all rights reserved. DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESSED OR IMPLIED CONDITIONS,REPRESENTATIONS AND WARANTEES, INCLUDING ANY IMPLIED WARRANTY, FITNESS FOR A PARTICULAR PURPOSE OR NON- INFRINGMENT ARE HEREBY ISCLAIMED, EXCEPT TO THE EXTENT THAT...
  • Page 3 Professional Installation: The TF3 is a Part 90 LMS device. It is not available to the general public. This product requires Professional Installation. Only professional installers are allowed to set this unit up for its' intended use. The TF3 is only available to these professional installers.
  • Page 4: Installation Instructions

    Installation Instructions: The unit should be removed from the box and mounted on a metal plate for heat dissipation. The power supply should be also mounted on a metal plate for heat dissipation. Coax connectors should be attached and ran to an antenna of 11.5 dBi gain or less.
  • Page 5 Specifications Table Architecture XScale processor, Linux, 64 Mbytes RAM, 64 Mbytes Flash Supported RFID Tag Protocols EPC Gen 2; ISO 18000-6c, North American Rail Reader Protocols Alien Reader Protocol, SNMP, firmware upgradeable LAN Protocols DHCP, TCP/IP, NTP Frequency 902.75 MHz – 927.25 MHz Channels 50 Channel Spacing 500 KHz RF Power Max at output port 2 watts Power Tri-voltage AC/DC power converter;...
  • Page 6 Pinouts RS-232 Port Pinouts RS-232 Connector (Female DB-9F) Pin 1 DCD Connected to Pin 6 Pin 2 TR1 Transmit Data (Output) Pin 3 RC1 Receive Data (Input) Pin 4 DTR Connected to Pin 6 Pin 5 Ground Pin 6 DSR Connected to Pin 4 Pin 7 RTS Connected to Pin 8...
  • Page 7 Diagnostic LEDs The ALR-9890 - RR includes diagnostic LEDs on the face of the reader to provide easy and convenient external indication for various operating conditions: POWER (green) - indicates power is applied to the reader LINK (green) – indicates that the reader is connected to the network ACTIVE (green) –...
