CX600 (MS-1682) Disassemble Guide
■ 1、BATTERY PACK
■ 2、BOTTOM DOOR ASSY
■ 3、HDD MODULE
■ 4、ODD MODULE
■ 5、THERMAL-KIT、CPU、DRAM AND WLAN MODULE
■ 6、KEYBOARD
■ 7、SEPARATE UPPER CASE AND LOWER CASE
■ 8、LOWER CASE ASSY
■ 9、UPPER CASE ASSY
■ 10、LCD MODULE ASSY

Advertisement

Table of Contents
loading

Related Manuals for MSI CX600

Summary of Contents for MSI CX600

  • Page 1 CX600 (MS-1682) Disassemble Guide ■ 1、BATTERY PACK ■ 2、BOTTOM DOOR ASSY ■ 3、HDD MODULE ■ 4、ODD MODULE ■ 5、THERMAL-KIT、CPU、DRAM AND WLAN MODULE ■ 6、KEYBOARD ■ 7、SEPARATE UPPER CASE AND LOWER CASE ■ 8、LOWER CASE ASSY ■ 9、UPPER CASE ASSY ■ 10、LCD MODULE ASSY...

  • Page 2: Battery Pack

    CX600（MS-1682）Disassemble Guide 1、BATTERY PACK 1.1：Move the “Unlock’ button base on left picture shows; 1.2：Release the “Release” button and move the battery pack base on left picture. Component Battery Pack S9N-2062200-CE1...
  • Page 3 CX600（MS-1682）Disassemble Guide 2、BOTTOM DOOR ASSY 2.1：Remove the 4 screws (M2.5*5mm), then remove the Bottom door. Attention: the screw driver touque is: 2.0-2.5Kgf-cm Component Bottom door 307-681J211-Y31 Screw E43-1255007-H29...

  • Page 4: Hdd Module

    CX600（MS-1682）Disassemble Guide 3、HDD MODULE 3.1：Remove the 2 screws(M2.5*5mm); Attention: the screw driver torque: 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 3.2：Remove the HDD Module according to the direction as pic shows;...
  • Page 5 CX600（MS-1682）Disassemble Guide 3、HDD MODULE 3.3：Remove the 2 screws(M3*3.5mm) that stabilize the bracket; Attention: the screw driver torque is 2.0-2.5Kgf-cm Component Screw E43-1303501-H29 3.4：Remove the HDD bracket; Component HDD Bracket 307-6810111-A89 HDD Module S71-2425521-W36...

  • Page 6: Odd Module

    CX600（MS-1682）Disassemble Guide 4、ODD MODULE 4.1：Remove the 1 screw(M2.5*5mm); Attention: the screw driver torque: 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 4.2：Remove the ODD Module according to the direction as pic shows;...
  • Page 7 CX600（MS-1682）Disassemble Guide 4、ODD MODULE 4.3： Remove ODD Bezel as below . Component ODD Bezel E2P-681F211-Y31 4.4： Remove 2pcs M2*3mm Screws Then remove ODD Bracket as below; Component Screw E43-1203003-H29 ODD Bracket E2M-6510211-Y28 ODD Module S7D-2270015-H44...
  • Page 8 CX600（MS-1682）Disassemble Guide 、 、 5、THERMAL-KIT DRAM AND WLAN MODULE 5.1:Remove the 6 screws(M2.5*5mm) and FAN cable, after that remove the Fansink Attention：the screw driver torque is 2.0-2.2Kgf-cm Component Screw E43-1255007-H29 Fansink E32-0800220-F05 5.2： Open the CPU Slot with Screw Driver, then remove CPU Module as below.
  • Page 9 CX600（MS-1682）Disassemble Guide 、 、 5、THERMAL-KIT DRAM AND WLAN MODULE 5.4：Then remove the RAM module according the direction as pic shows; Component RAM Module S7C-S357701-T10 5.5：Remove one screw(M2*3mm); then remove the two side wireless card antenna as pic shows: Attention: the screw driver torque is: 1.5-2.0Kgf-cm...
  • Page 10 CX600（MS-1682）Disassemble Guide 6、KEYBOARD 6.1：Before remove K/B, firstly remove the Hinge Cover; Component Hinge Cover 307-682E221-Y31 6.2：Remove the 5 screws(M2*3mm); Attention: the screw driver torque is: 1.5-2.0Kgf-cm Component Screw E43-1203003-H29 6.3 ： Firstly push connector according to the direction as pic shows; then remove the cable;...
  • Page 11 CX600（MS-1682）Disassemble Guide 7、SEPARATE UPPER CASE AND LOWER CASE 7.1：Remove the 2 screws(M2*3mm); Attention: the screw driver torque is: 1.5-2.0Kgf-cm Component Launch board 607-1682B-01S Screw E43-1203003-H29 7.2：First release the connector that stabilize the cable, then remove Launch board according to the...
  • Page 12 CX600（MS-1682）Disassemble Guide 7、SEPARATE UPPER CASE AND LOWER CASE 7.3：Remove the 2 screws(M2*3mm) that stabilize the hinge Cap Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203003-H29 7.4 ： Remove the 4 screws(M2.5*5mm) that stabilize the hinge Attention: the screw driver torque is 3.0-3.5Kgf-cm...
  • Page 13 CX600（MS-1682）Disassemble Guide 7、SEPARATE UPPER CASE AND LOWER CASE 7.5：Remove the LVDS cable as pic shows: 7.6：Remove the Touchpad cable. 7.7：Remove the 2 screws(M2*3mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm Component MODEM S52-2801180-C59 Screw E43-1203003-H29...
  • Page 14 CX600（MS-1682）Disassemble Guide 7、SEPARATE UPPER CASE AND LOWER CASE 7.8：Remove 5 screws(M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 7.9：Remove 8 screws(M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 7.10：Remove the 4 screws (M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm...

  • Page 15: Lower Case Assy

    CX600（MS-1682）Disassemble Guide 8、LOWER CASE ASSY 8.1：Remove the USB board cable as left pic shows: Component USB board FPC K1C-1012039-J36 8.2：Remove the 1screw (M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm Component USB board 607-1682A-01S Screw E43-1255007-H29...
  • Page 16 CX600（MS-1682）Disassemble Guide 8、LOWER CASE ASSY 8.3：Remove the B/T module; Component Bluetooth Module 605-6837D-160 8.4：Remove the 1screw (M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 8.5：Remove the main board from Lower case; Component Main Board 607-16821-01S...
  • Page 17 CX600（MS-1682）Disassemble Guide 8、LOWER CASE ASSY 8.6：Remove the RJ11 from Lower case; Component RJ11 CABLE K10-3002131-V03 8.7 ： Remove the 4 screws (M2*3mm), then remove the Speaker module from lower case; Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203003-H29...

  • Page 18: Upper Case Assy

    CX600（MS-1682）Disassemble Guide 9、UPPER CASE ASSY 9.1：Remove the T/P module, Component Touchpad Module S78-3700360-SD2 Upper Case 307-682C111-TC7 9.2：Release the connector that stabilize the T/P cable, then remove the T/P module FFC according to direction of left pic shows; Component FFC Cable...
  • Page 19 CX600（MS-1682）Disassemble Guide 10、 LCD MODULE ASSY 10.1：Remove the 8 cover rubber Component UP Rubber E2Y-6810111-Y40 DOWN Rubber E2Y-6740611-Y40 10.2 ： Remove the 4screw (M2.5*5mm). When removing the LCD bezel, should begin from the two sides, then the upside to downside;...
  • Page 20 CX600（MS-1682）Disassemble Guide 10、 LCD MODULE ASSY 10.3：Remove the 3 magnet on LCD cover; Component LCD Cover Magnet E2Y-2210512-SF7 LCD Cover Magnet E2Y-6710411-SF7 10.4：Remove INVERTER Component INVERTER S78-3300470-SG3 10.5：Remove the 6 screws (M2.5*5mm); Remove the two LCD hinges on two sides;...
  • Page 21 CX600（MS-1682）Disassemble Guide 10、 LCD MODULE ASSY 10.6：Remove the 2 screws (M2.5*5mm) Attention: the screw driver torque is 2.0-2.5Kgf-cm Component Screw E43-1255007-H29 10.7：Remove the display module from LCD cover; 10.8：Remove the LVDS cable from display module; Component LVDS Cable K19-3028001-H39...
  • Page 22 CX600（MS-1682）Disassemble Guide 10、 LCD MODULE ASSY 10.9：Remove the 8 screws (M2*3mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Display Module S1J-A42G002-S02 LCD BRACKET-L E2M-6810211-A89 LCD BRACKET-R E2M-6810111-A89 Screw E43-1203003-H29 10.10：Remove the CMOS camera module according to the sequence as pic shows;...
  • Page 23 CX600（MS-1682）Disassemble Guide 10、 LCD MODULE ASSY 10.12：Remove the MIC Module as left picture show Component MIC Module S34-2100910-K03 10.13：Remove the WIRELESS L-Antenna board from LCD Cover. Component L-Antenna S79-1800K80-J51 10.14：Remove the WIRELESS R-Antenna board from LCD Cover. Component R-Antenna S79-1800K70-J51...
