AR402 Administration
AR402 FINGERPRINT KEY
Manual
Version 1.6
e-DATA GmbH
1

Advertisement

Table of Contents
loading

Summary of Contents for E-data AR402

  • Page 1 AR402 Administration AR402 FINGERPRINT KEY Manual Version 1.6 e-DATA GmbH...
  • Page 2 GmbH. e-DATA GmbH reserves the right to make changes to the user manual and to the devices without special notice. e-DATA GmbH does not accept any liability whatsoever for direct or...

  • Page 3: Table Of Contents

    AR402 Administration Content General Comments Symbols ..................5 Device name ................6 Intended Usage................6 Protection Class................. 6 Safety Measures ................ 6 Before Commissioning............... 6 Operation ................... 8 Installation and Service.............. 8 CE Conformance ............... 8 1.10 FCC Conformance ..............9 Technical Data Mechanical Structure ...............
  • Page 4 Enrollment................17 5.2.1 Enroll user................17 5.2.2 Write Template onto smart Card (AR402-smart card reader type only) ..................18 Define the Number of Digits for the User ID (optional) .... 19 Enable Validation of the User ID (optional)......19 Delete Specific User(s) ............20 Delete Entire Database............

  • Page 5: General Comments

    1 General Comments Symbols The following symbols have been used in this manual: Helpful tips and special characteristics of the AR402. Possible danger, which – if the warning is not observed – can Careful result in damage to property, or slight to moderate bodily injury.

  • Page 6: Device Name

    The device is connected to superordinated data processing systems by a RS485 data line Device name This manual outlines the AR402 and the supported functions. Intended Usage The device may only be used under conditions and for purposes for which it has been designed.
  • Page 7 AR402 Administration...

  • Page 8: Operation

    AR402 Administration Operation Do not subject the device to any mechanical stresses such as impacts, violent shaking or heavy loads. Impacts and shaking can damage the electronics. Installation and Service The device may only be opened by trained specialists. Disconnect the device from the power source before opening.

  • Page 9: Fcc Conformance

    AR402 Administration 1.11 FCC Conformance This device complies with interference resistance criteria according to FCC Rules 47 CFR Part 15 – Subpart C Section 15.209 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 10: Technical Data

    AR402 Administration 2 Technical Data Mechanical Structure • Plastic body + metal wall mount panel • Resin sealed electronics • 12 inch cable molded into body Hardware Features • Fingerprint biometric sensor • MIFARE,DESFire,iCLASS- reader • 12-key Keypad • Beeper •...

  • Page 11: Power Supply

    AR402 Administration Power Supply • DC Voltage, 12...24V Minimum 1A and complying with Limited Power Source according to IEC/EN 60950-1 • Power consumption max 5W • CSA or UL listing is recommended Environment Conditions • Temperature range 14° to 122º F •...

  • Page 12: Installation

    AR402 Administration 3 Installation Installation Requirements For outdoor use, determine an appropriate place for mounting the AR402. Avoid mounting in direct sunlight as this may affect the function of the biometric sensor. Direct sunlight may overheat the AR402. Condition Check the following for mounting the AR402 Device needs proper clearance.

  • Page 13: Operation

    AR402 Administration 4 Operation View of the Control Elements LEDs green / red 1-2-3-4 Keypad Execute Button # Fingerprint Sensor Antenna to read smart cards Wall Mount Panel...

  • Page 14: Basics

    The 'Template on Card' mode allows you to write Templates onto smart cards (currently 16k2 cards only). The AR402 can either be run using the RS485 interface or the Wiegand output: Running the reader using the RS485 interface means that...

  • Page 15: User Operation

    => Green LEDs (Access granted) The AR402-smart card type reads fingers and smart cards alternatively without having to switch between operating modes. If a mistype occurs on the keypad simply press the “#” three times to reset and start over.

  • Page 16: Wiegand Configuration - Administrator Functions

    Wiegand configuration, i.e. connecting the AR402 to the access controller via Wiegand. Administration of the AR402 with Wiegand is done on the reader. The Fingerprint Key user interface is comprised of the keypad, fingerprint reader and smart reader as input devices and the LEDs and beeper as output devices.

  • Page 17: Enrollment

    AR402 Administration Enrollment The AR402 assigns 2 different fingers (e.g. left index finger, right index finger) to the unique User ID of a person. Each of the 2 fingers must be scanned 3 times by the Fingerprint Key reader. The biometric sensor reads fingers best when placing your finger on the sensor with some pressure.

  • Page 18: Write Template Onto Smart Card (Ar402-Smart Card Reader Type Only)

    Mode", page 21) and the reader must 'know' the encryption of your iCLASS cards. The 'Template on Card' mode does not store fingerprint templates to the AR402 but writes them onto iCLASS cards instead. The reader identifies authorized users by comparing the fingerprint templates stored on the card with the scanned finger of the card holder.

  • Page 19: Define The Number Of Digits For The User Id (Optional)

    AR402 Administration Define the Number of Digits for the User ID (optional) Here the length of the User IDs (Default = 5 digits) can be set to a value between 2 and 9 digits. In the process of enrollment User IDs need to be entered as a personal and unique ID.

  • Page 20: Delete Specific User(S)

    AR402 Administration Delete Specific User(s) This function allows you to remove a single user (User ID with its fingerprints) or several users of your choice from memory. Admin Mode # 99 # Green 1+2 Default Admin Code 1234 or enter your Admin Code...

  • Page 21: Select Iclass Mode (Ar402-Iclass Only)

    AR402 Administration Select iCLASS Mode (AR402-iCLASS only) In its default setting the iCLASS mode is activated on AR402-iCLASS readers. This mode reads fingerprints and iCLASS cards alternatively. This menu allows you to disable the iCLASS module or to enable the 'Template on Card' mode instead (cp.

  • Page 22: Define Facility Code

    AR402 Administration Define Facility Code These settings only apply to the trigger signal of the reader's biometric sensor sent to the access controller. The Facility Code of iCLASS cards is sent to the access controller untouched and independent of these settings.

  • Page 23: Reset - Manually Switch To Wiegand Mode

    AR402 Administration 5.10 Reset - Manually switch to Wiegand mode This function allows you to reset the AR402 to its factory defaults. All settings like the changed Admin Code, the enabled Validation of the User ID will be affected. Users however will remain untouched.

  • Page 24: Rs485 Configuration With Nextor Series Access Controller

    On a RS485 data bus the devices are distinguished by a device ID (address). The NEXTOR Series access controller recognizes serial numbers of AR402 readers on the bus line. These serial numbers are 12-digit hexadecimal codes (e.g. C03859110000) printed on the back of the readers.

  • Page 25: Maintenance

    First Response e-DATA GmbH identify defects and causes error. Have the following ready before placing your call: • Serial number of the AR402 • Customer details • What troubleshooting steps have you already taken to correct the error? •...

  • Page 26: Datasheet

    AR402 Administration 8 Datasheet smart card reading Credentials Template on card Biometric (fingerprint) PIN Code Host Interface RS485 Wiegand Biometric Features: Search Modes 1 to 1 identification 1 to many verification Response/Reads Enrollment <= 1 sec Identification <= 1 sec Verification <= 0.8 sec...

  • Page 27: Appendix

    1 # Reset - Manually switch to Wiegand Mode 2 # Reset - Manually switch to RS485 Mode 12 # Enroll user 16 # Write Template onto iCLASS Card (AR402-iCLASS only) 13 # Delete Specific User(s) 1357 # Delete Entire Database...
  • Page 28 AR402 Administration 31# learn admin finger-2 + 6-digit pin (take a different finger than delete admin finger-1 (delete of both admin fingers or erase data base => "1234" 301# (default) 311# delete admin finger-2 learn direct access pin-1 (length 4...8, following the '#' position, both pins must have...
  • Page 29 Example for calculating the power supply wiring: 1. AWG22 cable (0,34 mm Loop resistance ca 115 ohm / km AR402 current with 12V = 0,2A Cable length 150m Voltage drop: 115 ohm / km * 0.15km * 0,2A = 3.45V The supply voltage should be ≥...
