DRAFT
Battery Expansion Unit Manual
/
2032SP

Advertisement

Table of Contents
loading

Summary of Contents for Audiovox Thera/2032SP

  • Page 1 DRAFT Battery Expansion Unit Manual 2032SP...

  • Page 2: Package Contents

    DRAFT Introduction Thank you for purchasing the Battery Expansion Unit. This manual contains the important information concerning the safe and correct use of your Battery Expansion Unit. After reading this manual, keep it in a convenient place for future reference. Package contents The following items are included in the Battery Expansion Unit package.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS ● Before using the Battery Expansion Unit (hereinafter the Unit), be sure to thoroughly read the Manual of Thera/2032SP (here- inafter the Pocket PC Manual) to ensure proper use and to prevent damage to Thera/2032SP and/or to data.
  • Page 4 DRAFT Continued use of the Unit under either of these conditions could cause ignition (i.e., fire) of the leaked battery liquid, or rupture. ● Never touch any fluid that might leak from the Built-in battery. Such liquid when in contact with the eyes or skin, could cause injury to the skin or eyes.
  • Page 5 DRAFT ● The Built-in battery gradually discharges of itself. If you leave the Unit unused for a long period of time, the Built- in battery may completely discharge. Completely charge the battery before using the Unit. ● A lithium ion battery is used in the Unit. When a replacement is needed, please request the dealer from whom the Unit was purchased to assist you.
  • Page 6 DRAFT Safe use and operation of the Unit The Unit is exclusively for Thera/2032SP (hereinafter the pocket PC). Please do not use the Unit for other devices. As a result of the test for the Unit under the condition that the Unit...

  • Page 7: Part Names

    DRAFT Part Names Thera/2032SP Connection Port (plug-in terminal) Battery Switch AC Adapter Jack Charging LED Cradle Connection Port (receptacle terminal) Lock Switch...

  • Page 8: Specifications

    DRAFT Specifications You can use the Unit as auxiliary power supply for the Pocket PC by connecting the Unit to the Pocket PC. Please do not connect two or more Units by putting on top of one another when using the Unit. The Unit has a built-in advanced lithium-ion battery.
  • Page 9 DRAFT How to attach the Fixture to the Pocket PC Please clean off the seal area of the Pocket PC. Seal area Put the Attachment Tool into the Fixture as follows. Attachment Tool Fixture Peel off a protection seal of a double-faced tape on the back of the Fixture.
  • Page 10 DRAFT Fit the two protrusions of the Attachment Tool into the two screw holes of the Pocket PC to attach the Fixture to the Pocket PC. Make sure that the double-faced tape is firmly stuck on the Pocket PC and the Fixture is attached to the Pocket PC, and then remove the Attachment Tool as follows.

  • Page 11: How To Connect

    Put the Pocket PC on top of the Unit. Slide the Pocket PC and put the Cradle Connection Port of the Pocket PC into the Thera/2032SP Connection Port (plug- in terminal) of the Unit. • Firmly put the Port into place until you hear it click.
  • Page 12 DRAFT Check the Lock Switch is on the “LOCK” position. Lock Release ● When you remove the Unit, slide the Lock Switch to the “Re- lease” position before pulling out the Pocket PC.
  • Page 13 DRAFT ■ How to connect the Unit to the USB Cradle Put the Unit on top of the USB Cradle (the Pocket PC accessory), and then slide the Unit into the USB Cradle, and put the Cradle Connection Port (receptacle terminal) of the Unit into the USB Cradle.
  • Page 14 DRAFT ■ How to connect the three Units all together You can connect the Pocket PC, the Unit and the USB Cradle all together by putting on top of one another.
  • Page 15 DRAFT How to charge the Unit You can charge the Built-in battery of the Unit independently. If the Unit is attached to the Pocket PC when you charge the Built- in battery, both the Built-in battery and the Built-in battery of the Pocket PC can be charged at the same time.
  • Page 16 DRAFT There are two ways of connecting the AC Adapter to the Unit. When using the Unit for the first time, set the Battery Switch to the “Supply” position, then charge the Built-in battery with the sup- plied AC Adapter. ■...
  • Page 17 DRAFT ■ Connect the Cradle Connection Port (receptacle terminal) of the Unit into the USB Cradle, and then connect the AC Adapter to the USB Cradle.
  • Page 18 DRAFT How to use the Soft Case Attach the Belt Clip to the Soft Case as follows. • Firmly put the Belt Clip into place until you hear it click. Belt Clip Soft Case Put the Pocket PC into the Soft Case as follows.

  • Page 19: Fcc Information

    DRAFT FCC information Product Name: Battery Expansion Unit Model Number(s): CEX0216A FCC Notice “Declaration of Conformity Infor- mation” This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 20 DRAFT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause undesired operation. PM0007826010...
