  • Page 1 Industrial Radio Remote Controller SAGA1-T Series User Manual Gain Electronic Co., Ltd. www.sagaradio.com.tw...

  • Page 2: Warning And Caution

    Warning and Caution The following symbols may be found on the product or throughout the documentation. Symbol Description Refer to Manual Refer the user manual for additional information when product marked with this sign. Dangerous Voltage Indicates presence of hazardous voltage. Unsafe practice could result in severe personal injury.
  • Page 3 FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Limited Warranty

    Limitation of liability and remedy If your SAGA product fails to work as warranted above, Gain's maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product.
  • Page 5 Important Information before You Start Important Read this manual carefully before operating and installation. Due to the complex nature of equipment, it is necessary to read the entire manual before installation. Never allow any unauthorized personnel to dismantle equipment as this may cause the equipment damage.
  • Page 6 Precautions Press EMS button and switch off main power of crane and receiver after operation. The following situations may cause receiver response delay and stop operation immediately when situation occurs. (a) Beyond operating range (b) During severe radio interference Remove transmitter batteries when not in use for long period of time. To extend product life, please follow the standard operating procedure and maintain system regularly.

  • Page 7: Transmitter Overview

    Transmitter Overview SAGA1-T Transmitter Overview General Operation Getting Started Install 2 new AA-size batteries in the battery compartment (make sure batteries correctly installed according to the indication of “Positive” & “Negative”) and close battery cover firmly. Press ”START pushbutton” to power on the system. Note: Red LED indicator will flash when fail, follow procedures above accordingly.
  • Page 8 Transmitter LED Indicator Green (Full Power) Operate as usual. Yellow (Mid Power) Unload the article as soon as possible and stop operation until new batteries are replaced. Red (Low Power) An EMS signal will be sent to receiver automatically to turn off receiver.
