Belkin F8T001 User Manual

Bluetooth usb adapter
Hide thumbs Also See for F8T001:

Advertisement

Quick Links

Download this manual See also: User Manual
™
B L U E T O O T H
U S B A D A P T E R
U S E R M A N U A L

Advertisement

loading

Related Manuals for Belkin F8T001

Summary of Contents for Belkin F8T001

  • Page 1 ™ B L U E T O O T H U S B A D A P T E R U S E R M A N U A L...
  • Page 2 Introduction ..............2 Product Features .
  • Page 3 Thank you for purchasing the Bluetooth USB Adapter (the USB Adapter) from Belkin featuring Bluetooth wireless technology. The USB Adapter lets you create cable-free connections between your USB desktop PC and devices using Bluetooth wireless technology. The USB Adapter is compatible with all Bluetooth v1.1-certified...
  • Page 4 The USB Adapter is compliant with Bluetooth standard version 1.1 and provides: • Compliancy with Bluetooth specification v1.1 devices • USB bus powering: No external power supply necessary • Support for Microsoft ® Windows ® 98 SE, Me, 2000, and XP •...
  • Page 5 • PC-compatible computer, CPU speed of 200MHz or above • Memory: 64MB or above, 128MB recommended • One available USB port, USB 1.1 standard • Windows 98 SE, Me, 2000, and XP...
  • Page 6 • Bluetooth USB Adapter • 5 Ft. USB Extension Cable • CD-ROM for installation software and documentation • User Manual • Quick Installation Guide...
  • Page 7 Bluetooth Compliance: Version 1.1 Physical Interface: USBUHCI/OHCI 1.1-compliant Operating Frequency: 2.4 to 2.4835GHz Output Power: 0 to 20 dBm, Class 1, 2, 3 Sensitivity: -80 dBm @ 1E-3 BER minimum Data Rate: 723/57.6Kbps Operating Range: 100-meter radius indoors Network Topology: Point-to-Multipoint Packet Support: 1/3/5 Slots Packet...
  • Page 8 The services supported by your USB Adapter are defined as “Profiles”. Available profiles include: • Generic Access • Service Discovery • Serial Port • LAN Access • Dial-Up Networking • Generic Object Exchange • Object Push • File Transfer • Synchronization...
  • Page 9 Your USB Adapter gives you the ability to do the following—without cables: • Transfer files • Access dial-up networks • Connect to local area networks • Perform an ActiveSync ® session • Connect to serial ports • Exchange PIM data •...
  • Page 10 To install the software for the USB Adapter, follow the instructions below: Note: The installation process for Windows XP may look slightly different from Windows 98 SE, Me, and 2000. Note: Do not insert the USB Adapter into the USB port prior to installation. 1.
  • Page 11 3. Choose “I accept the terms in the license agreement” to accept the license agreement. Click on “Next”. 4. Name your device and select the type of computer you are installing your USB Adapter in. Click on “Next”.
  • Page 12 It is recommended that you install the software and driver to the default directory “C:\Program Files\belkin\Bluetooth Software”. Click on “Next”. 6. Confirm that the device software and driver are ready to be installed and click...
  • Page 13 Note: If at any time during the installation process you receive a “Device Signature Notice”, click “Yes” or “OK” to continue the installation process. 7. Confirm the completion of installation; click “Finish” and then restart the system.
  • Page 14 Note: Your USB Adapter is sensitive to static electricity, which can damage its delicate electrical components. To protect your device, always touch the metal chassis of your computer before handling the USB Adapter. This will ground any potential electrostatic discharge. Avoid touching the metal connector when handling the USB Adapter.
  • Page 15 Note: Your USB Adapter is equipped with a powerful antenna, which provides optimal performance of the radio. In some instances, attaching the USB Adapter directly to the rear of a desktop PC is not the optimal place for the antenna to propagate its radio signal. For these instances, we recommend you use the included USB extension cable to extend the USB Adapter to a more optimal place for the radio signals to propagate.
  • Page 16 1. After installing the software and restarting the system, insert the USB Adapter into an available USB port. You should see your system register a new USB device found. 2. Choose “Search for a suitable driver for my device”; then click on “Next”. Note: If you receive a Microsoft Digital Signature Notice, click “Continue”...
  • Page 17 3. Select “Specify a Location” and browse for the location of the device driver “C:\Program Files\Belkin\Bluetooth Software\bin\”; then click “Next”. 4. Confirm that the device driver was found and click on “Next”.
  • Page 18 5. A window will appear that confirms the completion of the driver installation; click on “Finish”. 6. “My Bluetooth Places” should appear on your desktop. Your installation process now complete.
  • Page 19 A variety of Bluetooth services and explanations of each service can be found in the “Help” file of the “My Bluetooth Places” program. To customize the configuration settings of Bluetooth software for Windows operating system, follow the instructions described below: 1.
  • Page 20 2. Click on “Configuration”. a) The “General” tab of “Configuration” allows you to customize the device’s user name, type, and security type. b) The “Accessibility” tab allows you to specify which individual devices are allowed to access the user’s computer. c) The “Discovery”...
  • Page 21 d) The “Information Exchange” tab allows you to specify the location of different types of files. e) The “Local Services” tab indicates the services this computer makes available to the other computers. f) The “Client Applications” tab indicates the properties of each application. g) The “Hardware”...
  • Page 22 The “My Bluetooth Places” program provides a quick and easy way to perform different application services through Bluetooth connections. A variety of Bluetooth services and explanations of each service can be found in the “Help” file of the “My Bluetooth Places” program. Dial-Up Networking: Allows your computer (as client) to establish a Bluetooth wireless connection to a Bluetooth device (as server) to access the server’s modem service to the Internet.
  • Page 23 FTP: Allows your computer (as client) to establish a Bluetooth wireless connection to a Bluetooth device (as server) to perform file system actions. Inbox: Allows your computer (as client) to establish a Bluetooth wireless connection to a Bluetooth device (as server) to send files, e.g. business card, e-mail, etc., through server’s personal information manager (PIM) actions.
  • Page 24 1. Click “My Bluetooth Places” on your screen. Three icons—“My Device”, “Entire Bluetooth Neighborhood”, and “Add Bluetooth Connection”—appear inside the window. 2. Click “My Device” to see which of your application services are available to other devices. The icons without “X” indicate the available Bluetooth services.
  • Page 25 3. Click “Entire Bluetooth Neighborhood” from the “My Bluetooth Places” window to search for devices available to you. Once Bluetooth devices are detected, icons with device names will be displayed on your screen. You may initiate a search for devices by selecting “Bluetooth” from the toolbar of the “Entire Bluetooth Neighborhood”...
  • Page 26 This section contains instructions for uninstalling the software required to use your USB Adapter. 1. Insert the CD-ROM included with your USB Adapter. 2. The “InstallShield Wizard” should automatically load. If it does not load, explore the CD and run the “Setup.exe” file. 3.
  • Page 27 4. Click “Remove” to initiate the UninstallShield Wizard and remove the software from your PC. 5. Click “Finish” to complete the uninstall.
  • Page 28 Authentication Security feature that requires users to verify a numeric password before exchanging data. Authorization Security feature that requires user approval before another user is allowed to share data. Bluetooth Neighborhood A collection of Bluetooth devices. Bonded Device Recognized by your device so as not to require authentication or authorization.

  • Page 29: Electromagnetic Compatibility

    DECLARATION OF CONFORMITY WITH FCC RULES FOR We, Belkin Components, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product, to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 30: Canada-Industry Canada (Ic)

    • Consult the dealer or an experienced radio/TV technician for help. Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin Components may void the users authority to operate the equipment.
  • Page 31 • ETS 300 826 General EMC requirements for radio equipment. To determine the type of transmitter, check the identification label on your Belkin product. Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community.
  • Page 32 Belkin Components warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
  • Page 34 Fax: +61 (2) 4325 4277 P74069 © 2002 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The Bluetooth name and the Bluetooth trademarks are owned by Bluetooth SIG, Inc., and are used by Belkin Components under license.
