- Page 1 USB SCSI Adapter with Termpower F5U015-TPW P73276...
-
Page 2: Introduction And System Requirements
If you own a non-iMac machine and wish to add ™ USB ports, please obtain a Belkin USB BusPort for Mac ® (model # F5U005-Mac Your SCSI device must be able to supply termination power to the USB SCSI Adapter. -
Page 3: Package Contents
Package Contents • Belkin Components USB SCSI Adapter withTermpower ® • CD containing both Windows ® and Macintosh ® drivers • Power supply adapter (7.5VDC, 600mA) with DB25 adapter • Registration card • This manual... -
Page 4: Installation And Usage
3. In "System Folder", look for another folder called "Extensions". Once you have located the "Extensions" folder, you will need to select the two files in the Belkin USB to SCSI CD (see #1 above), and drag the two files onto the "Extensions"... - Page 5 Macintosh ® Installation and Usage (continued) Note: If you unplug the USB SCSI Adapter from the computer, or the device(s) from the SCSI chain, the operating system may not recognize this and might think that the device(s) are still connected. In the event that the device(s) and/or the USB-SCSI Adapter is unplugged from the computer, and an application tries to access the device(s), your...
- Page 6 Windows ® 98 Installation and Usage WINDOWS ® 98 INSTALLATION: 1. Connect your SCSI device or device chain to the USB SCSI Adapter. See appendices for adapters and cables you may need. Make sure that the device(s) are powered up. 2.
- Page 7 4. Windows will now prompt you for drivers. Insert the ® Belkin USB SCSI Adapter CD-ROM in your CD-ROM drive. Put a check mark at the box named "Specify a location:". Type D:\PC Driver. (In this example, D is the driver letter for the CD-ROM drive;...
- Page 8 Windows ® 98 Installation and Usage (continued) 5. Windows will automatically find and install the drivers ® from the CD-ROM, and display the next dialog box, confirming it has loaded the correct files: Click on NEXT. 6. Lastly, Windows ® will display this final dialog box.
- Page 9 Appendices Troubleshooting The SCSI device(s) connected to the USB-SCSI Adapter is not detected by my computer. • Make sure the SCSI device(s) are powered up and at least one device provides termination power necessary for the Adapter’s operation. If you are just connecting one device and that device does not have termination power, make sure the power supply adapter provided with the package is connected.
- Page 10 Belkin External SCSI Cross-Reference Table This is only a partial listing of our most common SCSI Cable Assemblies. Contact your Belkin sales representative for assistance in choosing the cable you need.
- Page 11 "Find Now". Delete all the four items that will appear namely: Beluscsi.sys, Belsmsd.pdr, Belsmsd, and Belkin Component…. 3. You can now unplug the Belkin USB to SCSI adapter from the computer. Restart your computer. B. For Mac 1. Double click on your "Hard Drive" icon and look for "System Folder”/Double click on "System Folder".
-
Page 12: Fcc Statement
Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. -
Page 13: Compatibility List
Compatibility List A. Devices that work Stand-alone SCSI Hard Drives " • Seagate ST31220A - 2GB • Seagate ST51080N - 1GB • Microtech P-E-2000 - 2GB SCSI Removable Media Drives " • Coniglio MO 230MB ( FujitsuDrive M2512A ) • Fujitsu 640 Dyna MO - M2513A - F/W: 1300 •... - Page 14 Compatibility List (cont.) SCSI Scanners " • HP 5P C5110A F/W 3638 • Pixelcraft Pro Image 2400 Scanner • UMAX ProLook 2000 Other " • Microtech Digital PhotoAlbum - PC Card Reader • Microtech Digital PhotoAlbum.p - PC Card Reader •...
- Page 15 Compatibility List (cont.) • SyQuest SQ270 - 270MB SCSI CDD\CDR\CD-Changer " • Sony 4X - CDU 76S SCSI CDD F/W 1.0a. • NAKAMICHI 4 tray CD-Changer - MJ 4.8 • NEC Multispin 4x - 7 tray CD-Changer - NRC MBR - 7.4 •...
- Page 16 Compatibility List (cont.) • SCM Microsystems (Intermart) PCD-25 C. Currently incompatible devices Nikon LS-2000 Film Scanner (Super Coolscan 2000) " Microtech Digital PhotoAlbum_P (Old MP01625) " Microtech Digital PhotoAlbum (Old MP01610A) " UMAX Power Look III "...
- Page 17 Fax: +44 (0) 1604678330 Belkin Components B.V. Diamantlaan 8 • 2132 WV Hoofddorp • The Netherlands Tel: +31 (0) 235698765 Fax: +31 (0) 235612694 © 2000 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
