ENFORCER IPV-PD88Q Manual

ENFORCER IP Surge Protector

Troubleshooting:

Wavy or ghost video image if connected
to an image processor (e.g., multiplexer
or DVR), but not if connected directly to
the monitor.
Video image background flutters
between dark and light.
Video image is weak or faded.
No video image.
Also Available from SECO-LARM:
Video Surge Protector PoE Surge Protector
VS-1V12BQ
IMPORTANT
: Users and installers of this product are responsible for ensuring this product complies with all national, state, and local
laws and statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held responsible for the use of this
product in violation of any current laws or statutes.
WARNING
: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure could cause a dangerous electric shock,
damage the device, and void the warranty. Do not open the case of this device, as there are no field-serviceable components inside.
WARRANTY
This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for a
:
period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair, or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating
properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at SECO-LARM's
option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or property damages of any
kind to the purchaser or anyone else.
NOTICE
The information and specifications printed in this manual are current at the time of publication. However, the SECO- LARM policy is
:
one of continual development and improvement. For this reason, SECO-LARM reserves the right to change specifications without notice.
SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2014 SECO- LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part, without the
written permission of SECO-LARM.
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
• Move the cable away from possible sources of interference.
• Replace the cable with a new cable.
• Ensure that the protected cable is as short as possible
• Remove a local power source, or adjust the monitor's
brightness and contrast.
• Reduce the cable length.
• Replace with a higher-grade cable. Cat5 cable meets the
specifications in the manual. Cat6 cable allows longer
range.
• Double-check that the cables were connected properly.
• Run a continuity test on all wires in the cable.
HD-SDI Surge Protector
IPV-P188Q VS-1V22AQ
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
SECO-LARM U.S.A., Inc.
• Helps prevent damage to sensitive computer or CCTV equipment
• Intercepts repeated surges and spikes that could damage network
• Installs on Cat5e/6 4-pair UTP cable with RJ45 jacks
• Passive operation – no external power required
• Includes a grounding post
PITSW4
MilPV-PD88Q_1406.docx
IPV-PD88Q
IP Surge Protector
Manual
such as cameras, monitors, digital video recorders, video splitters,
PCs, servers or networking hubs
equipment
