- Page 1 UNDERCABINET CD PLAYER UNDERCABINET CD PLAYER with AM/FM Alarm Clock Radio and with AM/FM Alarm Clock Radio and Bluetooth® Wireless Technology Bluetooth® Wireless Technology Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: CKR1307...
- Page 2 This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 5: Preparation For Use
PREPARATION FOR USE Power Sources Main Unit: Unwind the AC power cord and extend it to its full length. Insert the AC plug of the cord into any convenient AC 120V~ 60Hz household outlet as the illustrated on right: NOTES: This unit is equipped with a polarized AC plug which has one blade wider than the other. - Page 6 Remote Control: In first time use, remove and discard the insulation film on the battery compartment as the illustrated follows: PAIR PAIR PULL PULL To replace the button cell if it is consume: 1. Push and slide out the battery tray as the illustrated below. 2.
-
Page 7: Main Unit
LOCATION OF CONTROLS Main Unit: STANDB Y Button STANDBY Indicator CD Door Open/Close Button CD Door Fast Search Forward/Skip Forward Button /PAIR (Play-Pause/BT Pair) Button 14 16 Fast Search Backward/Skip Backward 13 17 Stop Button P-MODE/CLK SET (Program-Mode/Clock set) Button DISPLAY Button LCD Display FUNCTION Button... -
Page 8: Installation
INSTALLATION Install the unit to the bottom of cabinet (if need) as follows: 1. Detach the Plastic Assemble 2. Mount the Plastic Assemble Plate on the desired location as Plate from the top of unit by slide follows illustrated: it to rear of unit as the illustrated: 3. -
Page 9: Operation
OPERATION GENERAL OPERATION: 1. Connected the unit to AC power as instructed earlier. The Red Indicator will illuminate. 2. Press the Button on the unit or Remote Control to power on the unit from standby mode. The Red Indicator will not light and the LCD Display will illuminate. - Page 10 Notes: When the external BT Device searched the unit, our model number “CKR1307” will appear on the display of external BT Device. Pairing code “0000” or “1234” may need to enter. Normal operation after paired: 1. Turn on the BT function of the external BT Device.
-
Page 11: Repeat Playback
4. Close the CD door by press the Button; the unit will start playback automatically. 5. During playback: A. Press the PAIR/ Button to pause; press again to resume normal playback. B. Press the Buttons repeatedly to skip tracks. C. Press and hold the Buttons to fast searching the specific section then release the button to resume normal playback. - Page 12 RADIO: FM Band: 1. In standby mode, press the Button to power on the unit. 2. Press the FUNCTION Button repeatedly until “FM XX.X MHz” appear on the display. 3. Turn the TUNING Knob to receive the desired FM station. 4.
- Page 13 ALARM SET: 1. In power off (Standby) mode. Press and hold the ALARM Button on the unit or Remote Control approximate 2 seconds until indicator "TIMER" and alarm display and the digit of hour of it is blinking. time appear on the 2.
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE... -
Page 15: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Symptom Possible Cause Solution Power Plug from AC Power Cord Insert the plug to wall No power had not inserted to AC outlet having wall outlet. AC 120V~, 60 Hz. Radio Station not tuned properly. Retune the radio station. -
Page 16: General Specifications
GENERAL SPECIFICATIONS: Power Source: AC 120V~, 60 Hz, 15W Clock back up: 4.5V, 3 x AAA size batteries; Not included Audio Power: 1.2 W (RMS) x 2 Impendence of Speakers: 8 Ohm; 2W Radio Band Coverage: AM 520 - 1710 kHz FM 87.5 - 108 MHz BT Version: 2.1 + EDR...
