Page 1 All manuals and user guides at all-guides.com CD RECEIVER KD-G440 RECEPTOR CON CD KD-G440 RÉCEPTEUR CD KD-G440 For canceling the display demonstration, see page 6. Para cancelar la demostración en pantalla, consulte la página 6. Pour annuler la démonstration des affichages, référez-vous à la page 6.
Page 2 – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2.
Page 3: Table Of Contents
All manuals and user guides at all-guides.com How to reset your unit CONTENTS Control panel ........4 Remote controller — ... 5 RM-RK50 Getting started ........ 6 Basic operations ........... 6 • Your preset adjustments will also be erased. Radio operations ......7 Disc/USB device operations ....
Page 4: Control Panel
All manuals and user guides at all-guides.com Control panel Parts identification Display window 5 (up) / ∞ (down) buttons Number buttons 0 (eject) button RPT (repeat) button (standby/on attenuator) button RND (random) button Control dial AUX (auxiliary) input jack Remote sensor USB (Universal Serial Bus) input jack DO NOT expose the remote sensor to strong light Source display / Track number / Folder number /...
Page 5: Rm-Rk50
All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 Installing the lithium coin battery (CR2025) For USA-California Only: This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material—special (standby/on/attenuator) button handling may apply. •...
Page 6: Getting Started
All manuals and user guides at all-guides.com To drop the volume in a Getting started moment (ATT) To restore the sound, press the Basic operations button again. Turn on the power. To turn off the power Ÿ Basic settings • See also “General settings — PSM” on pages * You cannot select these sources if they are not 12 –...
Page 7: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 8: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Manual presetting Disc / USB device Ex.: Storing the FM station of 92.50MHz into preset operations number 4 of the FM1 band. : For built-in CD player operations. : For external USB device operations. Playing a disc in the unit Preset number flashes for a while.
Page 9 All manuals and user guides at all-guides.com Ÿ To fast-forward or reverse the track To go to the next or previous track USB memory If a USB device has been attached... To go to the next or previous folder (for Playback starts from where it has been stopped MP3/WMA) previously.
Page 10: Changing Display Information
All manuals and user guides at all-guides.com Other main functions Changing the display information Skipping tracks quickly during play While playing an audio CD or CD Text • For MP3/WMA, you can skip tracks within the same folder. A = Disc title/performer * = Track ] = B = (back to the beginning) title *...
Page 11: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Selecting the playback modes You can use only one of the following playback modes You can select a preset sound mode suitable to the at a time. music genre (iEQ: intelligent equalizer). Select your desired playback mode.
Page 12: General Settings - Psm
All manuals and user guides at all-guides.com Indication, [Range] General settings — PSM BASS * , [–06 to +06] You can change PSM (Preferred Setting Mode) items Adjust the bass. listed in the table on pages 13 and 14. MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 13 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) DEMO • DEMO ON : The display demonstration will be activated automatically if no Display operation is done for about 20 seconds, [6]. demonstration •...
Page 14: Other External Component Operations
All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) AMP GAIN • LOW POWER : VOLUME 00 – VOLUME 30 (Select this if the maximum power of the Amplifier gain speaker is less than 50 W to avoid damaging the speaker.) control •...
Page 15: Title Assignment
All manuals and user guides at all-guides.com Title assignment More about this unit You can assign titles to 30 station frequencies (FM and Basic operations AM) and up to 8 characters for each station name. Turning on the power • By pressing SRC or AUX on the unit, you can also turn Select FM/AM.
Page 16 All manuals and user guides at all-guides.com • When a disc is inserted upside down, “PLEASE” and • This unit can display only one-byte characters. No “EJECT appear alternately on the display. Press other characters can be correctly displayed. eject the disc. •...
Page 17 All manuals and user guides at all-guides.com Playing MP3/WMA tracks from a USB device • This unit may not recognized a USB device connected through a USB card reader. • While playing from a USB device, the playback order • This unit may not play back files in a USB device may differ from other players.
Page 18: Maintenance
All manuals and user guides at all-guides.com To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors.
Page 19: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 20 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 21: Specifications
All manuals and user guides at all-guides.com Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Power Output: Type: Compact disc player 20 W RMS × 4 Channels at Signal Detection Non-contact optical pickup System: (semiconductor laser) 4 Ω and ≤ 1% THD+N Number of Channels: 2 channels (stereo) Signal-to-Noise Ratio: Frequency Response: 5 Hz to 20 000 Hz...
Page 22 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! EN, SP, FR © 2007 Victor Company of Japan, Limited 1107DTSMDTJEIN...
Page 23 NEGATIVA. Si su vehículo no posee continu de 12 V à masse NEGATIVE. Si votre véhicule n’offre pas ce voltage inverter is required, which can be purchased at JVC car audio este sistema, será necesario un inversor de tensión, que puede ser type d’alimentation, il vous faut un convertisseur de tension, que vous...
Page 24 JVC car audio dealer or a company supplying kits. instalación, consulte con su concesionario de JVC de equipos de audio d’installation, consulter votre revendeur d’autoradios JVC ou une •...
Page 25 All manuals and user guides at all-guides.com ENGLISH ESPAÑOL FRANÇAIS ELECTRICAL CONNECTIONS CONEXIONES ELECTRICAS RACCORDEMENTS ELECTRIQUES Typical connections / Conexiones tipicas / Raccordements typiques Before connecting: Check the wiring in the vehicle carefully. Antes de la conexión: Verifique atentamente el conexionado del Avant de commencer la connexion: Vérifiez attentivement le Incorrect connection may cause serious damage to this unit.
Page 26 Fil d’alimentation à distance (bleu avec bande blanche) To the remote lead of other equipment or automatic antenna JVC Amplifier Rear speakers if any Amplificador de JVC Altavoces posteriores Al conductor remoto de JVC Amplificateur Enceintes arrière otro equipo o de la antena automática, si hubiere...
Page 27 All manuals and user guides at all-guides.com CD RECEIVER RÉCEPTEUR CD KD-G441/KD-G351 For canceling the display demonstration, see page 5. Pour annuler la démonstration des affichages, référez-vous à la page 5. For installation and connections, refer to the separate manual. Pour l’installation et les raccordements, se référer au manuel séparé.
Page 28 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 29: Detaching The Control Panel
All manuals and user guides at all-guides.com How to reset your unit CONTENTS Control panel — ..4 KD-G441/KD-G351 Getting started ......... 5 Basic operations ............ 5 Radio operations ......6 FM RDS operations ......7 • Your preset adjustments will also be erased. Searching for your favorite FM RDS programme ...
Page 30: Control Panel
All manuals and user guides at all-guides.com Control panel — KD-G441/KD-G351 Parts identification Display window 5 (up) / ∞ (down) buttons SSM (Strong-station Sequential Memory) button 0 (eject) button Number buttons (standby/on attenuator) button RPT (repeat) button Control dial RND (random) button Remote sensor AUX (auxiliary) input jack •...
Page 31: Getting Started
All manuals and user guides at all-guides.com To drop the volume in a Getting started moment (ATT) To restore the sound, press the Basic operations button again. Turn on the power. To turn off the power Ÿ Basic settings • See also “General settings — PSM” on pages * You cannot select these sources if they are not 14 –...
Page 32: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 33: Fm Rds Operations
All manuals and user guides at all-guides.com Manual presetting FM RDS operations Ex.: Storing the FM station of 92.50MHz into preset number 4 of the FM1 band. What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals.
Page 34 All manuals and user guides at all-guides.com Using the standby receptions Start searching for your favorite programme. TA Standby Reception TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from any source other than AM. If there is a station broadcasting a programme The volume changes to the preset TA volume level if the of the same PTY code as you have selected, that current level is lower than the preset level (see...
Page 35 All manuals and user guides at all-guides.com To deactivate the PTY Standby Reception, select Automatic station selection— “OFF” for the PTY code (see page 15). The PTY indicator Programme Search goes off. Usually when you press the number buttons, the preset Tracing the same programme—...
Page 36: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Ÿ Disc / USB device operations : For built-in CD player operations. USB memory : For external USB device operations. If a USB device has been attached... Playing a disc in the unit Playback starts from where it has been stopped previously.
Page 37 All manuals and user guides at all-guides.com To fast-forward or reverse the track Other main functions Skipping tracks quickly during play To go to the next or previous track • For MP3/WMA, you can skip tracks within the same folder. Ex.: To select track 32 while playing tracks whose number is a single digit (1 to 9) To go to the next or previous folder (for...
Page 38 All manuals and user guides at all-guides.com Changing the display information Selecting the playback modes You can use only one of the following playback modes at a time. While playing an audio CD or CD Text A = B = Disc title/performer * = Track Select your desired playback mode.
Page 39: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Indication, [Range] BASS * , [–06 to +06] You can select a preset sound mode suitable to the Adjust the bass. music genre (iEQ: intelligent equalizer). MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 40: General Settings - Psm
All manuals and user guides at all-guides.com General settings — PSM You can change PSM (Preferred Setting Mode) items listed in the table below and on pages 15 and 16. Repeat steps 2 and 3 to adjust other PSM items if necessary. Select a PSM item.
Page 41 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) AF-REG * • AF : When the currently received signals become weak, the unit Alternative switches to another station (the programme may differ from the frequency/ one currently received), [9].
Page 42: Other External Component Operations
All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) SUB.W FREQ * • LOW : Frequencies lower than 90 Hz are sent to the subwoofer. Subwoofer cutoff • MID : Frequencies lower than 135 Hz are sent to the subwoofer. frequency •...
Page 43 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 KD-G441 can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 with your unit. Installing the lithium coin battery (CR2025) (standby/on/attenuator) button...
Page 44: More About This Unit
All manuals and user guides at all-guides.com Disc operations More about this unit Caution for DualDisc playback • The Non-DVD side of a “DualDisc” does not comply Basic operations with the “Compact Disc Digital Audio” standard. Turning on the power Therefore, the use of Non-DVD side of a DualDisc on •...
Page 45 All manuals and user guides at all-guides.com • Do not use the following CD-Rs or CD-RWs: • This unit can recognize a total of 512 files, 255 – Discs with stickers, labels, or protective seal stuck folders, and 8 hierarchical levels. to the surface.
Page 46 All manuals and user guides at all-guides.com • This unit can play back MP3/WMA files meeting the Changing the source conditions below: • If you change the source, playback also stops. – Bit rate of MP3: 16 kbps — 320 kbps Next time you select the same source again, playback –...
Page 47: Maintenance
All manuals and user guides at all-guides.com Maintenance How to clean the connectors To keep discs clean Frequent detachment will deteriorate the connectors. A dirty disc may not play correctly. To minimize this possibility, periodically wipe the If a disc does become dirty, wipe it with connectors with a cotton swab or cloth moistened with a soft cloth in a straight line from center alcohol, being careful not to damage the connectors.
Page 48: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 49 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 50: Specifications
All manuals and user guides at all-guides.com Specifications Maximum Power Front/Rear: 50 W per channel Output: Continuous Power Front/Rear: 19 W per channel into 4 Ω, 40 Hz to Output (RMS): 20 000 Hz at no more than 0.8% total harmonic distortion Load Impedance: 4 Ω...
Page 51 All manuals and user guides at all-guides.com Type: Compact disc player Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of Channels: 2 channels (stereo) Frequency Response: 5 Hz to 20 000 Hz Dynamic Range: 96 dB Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit MP3 Decoding Format:...
Page 52 électromagnétique et à la sécurité électrique. European representative of Victor Company of Japan, Limited Représentant européen de la société Victor Company of Japan, Limited: JVC Technology Centre Europe GmbH JVC Technology Centre Europe GmbH Postfach 10 05 52 Postfach 10 05 52...
Page 53 • Assurez-vous de raccorder de nouveau la mise à la masse de cet appareil au châssis de la voiture après l’installation. Notes: • Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC IN-CAR Remarques: ENTERTAINMENT dealer.
Page 54 L’illustration suivante est un exemple d’installation typique. Si vous avez des questions ou avez besoin regarding installation kits, consult your JVC IN-CAR ENTERTAINMENT dealer or a company supplying d’information sur des kits d’installation, consulter votre revendeur d’autoradios JVC ou une compagnie kits.
Page 55 All manuals and user guides at all-guides.com ENGLISH FRANÇAIS ELECTRICAL CONNECTIONS RACCORDEMENTS ELECTRIQUES If your car is equipped with the ISO For some VW/Audi or Opel (Vauxhall) automobiles / Pour certaines automobiles VW/Audi ou connector / Si votre voiture est équippée Opel (Vauxhall) d’un connecteur ISO You may need to modify the wiring of the supplied power cord as illustrated.
Page 56 Si votre voiture est munie d’une télécommande de volant, vous pouvez commander cet autoradio en controller. To do it, a JVC’s OE remote adapter (not supplied) which matches with your car is required. utilisant la télécommande. Pour le faire, un adaptateur pour télécommande au volant JVC (non fourni) Consult your JVC IN-CAR ENTERTAINMENT dealer for details.
Page 57 All manuals and user guides at all-guides.com CD RECEIVER CD-RECEIVER РЕСИВЕР С ПРОИГРЫВАТЕЛЕМ КОМПАКТ-ДИСКОВ KD-G441/KD-G351 For canceling the display demonstration, see page 5. Zum Abbrechen der Displaydemonstration siehe Seite 5. Информацию об отмене демонстрации функций дисплея см. на стр. 5. For installation and connections, refer to the separate manual.
Page 58 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 59 All manuals and user guides at all-guides.com How to reset your unit CONTENTS Control panel — ..4 KD-G441/KD-G351 Getting started ......... 5 Basic operations ............ 5 Radio operations ......6 FM RDS operations ......7 • Your preset adjustments will also be erased. Searching for your favorite FM RDS programme ...
Page 60: Kd-G441/Kd-G351
All manuals and user guides at all-guides.com Control panel — KD-G441/KD-G351 Parts identification Display window 5 (up) / ∞ (down) buttons SSM (Strong-station Sequential Memory) button 0 (eject) button Number buttons (standby/on attenuator) button RPT (repeat) button Control dial RND (random) button Remote sensor AUX (auxiliary) input jack •...
Page 61: Getting Started
All manuals and user guides at all-guides.com Getting started To drop the volume in a moment (ATT) To restore the sound, press the Basic operations button again. Turn on the power. To turn off the power Ÿ Basic settings • See also “General settings — PSM” on pages * You cannot select these sources if they are not 14 –...
Page 62: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 63: Fm Rds Operations
All manuals and user guides at all-guides.com Manual presetting FM RDS operations Ex.: Storing the FM station of 92.50MHz into preset number 4 of the FM1 band. What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals.
Page 64 All manuals and user guides at all-guides.com Start searching for your favorite Using the standby receptions programme. TA Standby Reception TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from any source other than AM. If there is a station broadcasting a programme The volume changes to the preset TA volume level if the of the same PTY code as you have selected, that current level is lower than the preset level (see...
Page 65 All manuals and user guides at all-guides.com To deactivate the PTY Standby Reception, select Automatic station selection— “OFF” for the PTY code (see page 15). The PTY indicator Programme Search goes off. Usually when you press the number buttons, the preset Tracing the same programme—...
Page 66: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Ÿ Disc / USB device operations : For built-in CD player operations. USB memory : For external USB device operations. If a USB device has been attached... Playing a disc in the unit Playback starts from where it has been stopped previously.
Page 67 All manuals and user guides at all-guides.com To fast-forward or reverse the track Other main functions Skipping tracks quickly during play To go to the next or previous track • For MP3/WMA, you can skip tracks within the same folder. Ex.: To select track 32 while playing tracks whose number is a single digit (1 to 9) To go to the next or previous folder (for...
Page 68 All manuals and user guides at all-guides.com Changing the display information Selecting the playback modes You can use only one of the following playback modes at a time. While playing an audio CD or CD Text A = B = Disc title/performer * = Track Select your desired playback mode.
Page 69: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Indication, [Range] BASS * , [–06 to +06] You can select a preset sound mode suitable to the Adjust the bass. music genre (iEQ: intelligent equalizer). MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 70: General Settings - Psm
All manuals and user guides at all-guides.com General settings — PSM You can change PSM (Preferred Setting Mode) items listed in the table below and on pages 15 and 16. Repeat steps 2 and 3 to adjust other PSM items if necessary. Select a PSM item.
Page 71 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) AF-REG * • AF : When the currently received signals become weak, the unit Alternative switches to another station (the programme may differ from the frequency/ one currently received), [9].
Page 72: Other External Component Operations
All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) SUB.W FREQ * • LOW : Frequencies lower than 90 Hz are sent to the subwoofer. Subwoofer cutoff • MID : Frequencies lower than 135 Hz are sent to the subwoofer. frequency •...
Page 73 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 KD-G441 can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 with your unit. Installing the lithium coin battery (CR2025) (standby/on/attenuator) button...
Page 74: More About This Unit
All manuals and user guides at all-guides.com Disc operations More about this unit Caution for DualDisc playback • The Non-DVD side of a “DualDisc” does not comply Basic operations with the “Compact Disc Digital Audio” standard. Turning on the power Therefore, the use of Non-DVD side of a DualDisc on •...
Page 75 All manuals and user guides at all-guides.com • Do not use the following CD-Rs or CD-RWs: • This unit can recognize a total of 512 files, 255 – Discs with stickers, labels, or protective seal stuck folders, and 8 hierarchical levels. to the surface.
Page 76 All manuals and user guides at all-guides.com • This unit can play back MP3/WMA files meeting the Changing the source conditions below: • If you change the source, playback also stops. – Bit rate of MP3: 16 kbps — 320 kbps Next time you select the same source again, playback –...
Page 77: Maintenance
All manuals and user guides at all-guides.com Maintenance How to clean the connectors To keep discs clean Frequent detachment will deteriorate the connectors. A dirty disc may not play correctly. To minimize this possibility, periodically wipe the If a disc does become dirty, wipe it with connectors with a cotton swab or cloth moistened with a soft cloth in a straight line from center alcohol, being careful not to damage the connectors.
Page 78: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 79 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 80: Specifications
All manuals and user guides at all-guides.com Specifications Maximum Power Front/Rear: 50 W per channel Output: Continuous Power Front/Rear: 19 W per channel into 4 Ω, 40 Hz to Output (RMS): 20 000 Hz at no more than 0.8% total harmonic distortion Load Impedance: 4 Ω...
Page 81 All manuals and user guides at all-guides.com Type: Compact disc player Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of Channels: 2 channels (stereo) Frequency Response: 5 Hz to 20 000 Hz Dynamic Range: 96 dB Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit MP3 Decoding Format:...
Page 82 совместимости и электрической безопасности. European representative of Victor Company of Japan, Limited Представительство компании Victor Company of Japan, Limited в Европе: JVC Technology Centre Europe GmbH JVC Technology Centre Europe GmbH Postfach 10 05 52 Postfach 10 05 52 61145 Friedberg...
Page 83 Gleichstrom und (–) Erdung ausgelegt. Verfügt Ihr Fahrzeug nicht постоянного напряжения с минусом на массе. Если Ваш voltage inverter is required, which can be purchased at JVC IN-CAR über diese Anlage, ist ein Spannungsinverter erforderlich, der bei JVC автомобиль не имеет этой системы, требуется инвертор...
Page 84 Fragen oder wenn Sie Informationen hinsichtlich des Einbausatzes Если у Вас есть какие-либо вопросы, касающиеся установки, consult your JVC IN-CAR ENTERTAINMENT dealer or a company brauchen, wenden Sie sich an ihren JVC Autoradiohändler oder ein обратитесь к Вашему дилеру автомобилнего специалиста JVC или supplying kits.
Page 85 All manuals and user guides at all-guides.com ENGLISH DEUTSCH РУССКИЙ ELECTRICAL CONNECTIONS ELEKTRISCHE ANSCHLÜSSE ЭЛЕКТРИЧЕСКИЕ ПОДКЛЮЧЕНИЯ If your car is equipped with the ISO connector / For some VW/Audi or Opel (Vauxhall) automobiles / Bei bestimmten VW-/Audi- or Opel- Wenn Ihr Fahrzeug mit dem ISO-Steckverbinder (Vauxhall-) Fahrzeugen / Для...
Page 86 Wenn Ihr Fahrzeug mit einer Lenkradferndienung ausgestattet ist, Если автомобиль оборудован рулевым пультом you can operate this unit using the controller. To do it, a JVC’s können Sie damit diesen Receiver steuern. Hierfür ist ein für Ihr дистанционного управления, его можно использовать для...
Page 87 Срок службы (годности), кроме срока хранения дополнительных космети ческих материалов, упомянутых в предыдущих двух пунктах, не затрагивает никаких других прав потребителя, в частности, гарантийного свидетельства JVC, которое он может получить в соответствии с законом о правах потребителя или других законов, связанных с ним.
Page 88 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 89 All manuals and user guides at all-guides.com How to reset your unit CONTENTS Control panel — ..4 KD-G447/KD-G357 Getting started ......... 5 Basic operations ............ 5 Radio operations ......6 • Your preset adjustments will also be erased. FM RDS operations ......7 Searching for your favorite FM RDS programme ...
Page 90: Kd-G447/Kd-G357
All manuals and user guides at all-guides.com Control panel — KD-G447/KD-G357 Parts identification Display window 5 (up) / ∞ (down) buttons SSM (Strong-station Sequential Memory) button 0 (eject) button Number buttons (standby/on attenuator) button RPT (repeat) button Control dial RND (random) button Remote sensor AUX (auxiliary) input jack •...
Page 91: Getting Started
All manuals and user guides at all-guides.com Getting started To drop the volume in a moment (ATT) To restore the sound, press the Basic operations button again. Turn on the power. To turn off the power Ÿ Basic settings • See also “General settings — PSM” on pages * You cannot select these sources if they are not 14 –...
Page 92: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 93: Fm Rds Operations
All manuals and user guides at all-guides.com Manual presetting FM RDS operations Ex.: Storing the FM station of 92.50MHz into preset number 4 of the FM1 band. What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals.
Page 94 All manuals and user guides at all-guides.com Start searching for your favorite Using the standby receptions programme. TA Standby Reception TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from any source other than AM. If there is a station broadcasting a programme The volume changes to the preset TA volume level if the of the same PTY code as you have selected, that current level is lower than the preset level (see...
Page 95 All manuals and user guides at all-guides.com To deactivate the PTY Standby Reception, select Automatic station selection— “OFF” for the PTY code (see page 15). The PTY indicator Programme Search goes off. Usually when you press the number buttons, the preset Tracing the same programme—...
Page 96: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Ÿ Disc / USB device operations : For built-in CD player operations. USB memory : For external USB device operations. If a USB device has been attached... Playing a disc in the unit Playback starts from where it has been stopped previously.
Page 97 All manuals and user guides at all-guides.com To fast-forward or reverse the track Other main functions Skipping tracks quickly during play To go to the next or previous track • For MP3/WMA, you can skip tracks within the same folder. Ex.: To select track 32 while playing tracks whose number is a single digit (1 to 9) To go to the next or previous folder (for...
Page 98 All manuals and user guides at all-guides.com Changing the display information Selecting the playback modes You can use only one of the following playback modes at a time. While playing an audio CD or CD Text A = B = Disc title/performer * = Track Select your desired playback mode.
Page 99: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Indication, [Range] BASS * , [–06 to +06] You can select a preset sound mode suitable to the Adjust the bass. music genre (iEQ: intelligent equalizer). MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 100: General Settings - Psm
All manuals and user guides at all-guides.com General settings — PSM You can change PSM (Preferred Setting Mode) items listed in the table below and on pages 15 and 16. Repeat steps 2 and 3 to adjust other PSM items if necessary. Select a PSM item.
Page 101 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) CLOCK ADJ * • AUTO : The built-in clock is automatically adjusted using the CT (clock Clock adjustment time) data in the RDS signal. •...
Page 102: Other External Component Operations
All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) TAG DISPLAY • TAG ON : Shows the Tag information while playing MP3/WMA tracks, [12]. Tag display • TAG OFF : Cancels. AMP GAIN •...
Page 103 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 KD-G447 can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 with your unit. Installing the lithium coin battery (CR2025) (standby/on/attenuator) button...
Page 104: More About This Unit
All manuals and user guides at all-guides.com Disc operations More about this unit Caution for DualDisc playback • The Non-DVD side of a “DualDisc” does not comply Basic operations with the “Compact Disc Digital Audio” standard. Turning on the power Therefore, the use of Non-DVD side of a DualDisc on •...
Page 105 All manuals and user guides at all-guides.com • Do not use the following CD-Rs or CD-RWs: • This unit can recognize a total of 512 files, 255 – Discs with stickers, labels, or protective seal stuck folders, and 8 hierarchical levels. to the surface.
Page 106 All manuals and user guides at all-guides.com • This unit can play back MP3/WMA files meeting the Changing the source conditions below: • If you change the source, playback also stops. – Bit rate of MP3: 16 kbps — 320 kbps Next time you select the same source again, playback –...
Page 107: Maintenance
All manuals and user guides at all-guides.com Maintenance How to clean the connectors To keep discs clean Frequent detachment will deteriorate the connectors. A dirty disc may not play correctly. To minimize this possibility, periodically wipe the If a disc does become dirty, wipe it with connectors with a cotton swab or cloth moistened with a soft cloth in a straight line from center alcohol, being careful not to damage the connectors.
Page 108: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 109 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 110: Specifications
All manuals and user guides at all-guides.com Specifications Maximum Power Front/Rear: 50 W per channel Output: Continuous Power Front/Rear: 19 W per channel into 4 Ω, 40 Hz to Output (RMS): 20 000 Hz at no more than 0.8% total harmonic distortion Load Impedance: 4 Ω...
Page 111 All manuals and user guides at all-guides.com Type: Compact disc player Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of Channels: 2 channels (stereo) Frequency Response: 5 Hz to 20 000 Hz Dynamic Range: 96 dB Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit MP3 Decoding Format:...
Page 112 All manuals and user guides at all-guides.com Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Затруднения при эксплуатации? Пожалуйста, перезагрузите Ваше устройство Для получения информации о перезагрузке Вашего устройства обратитесь на соответствующую страницу Маєте...
Page 113 постоянного напряжения с минусом на массе. Если Ваш постійного струму; з електричними системами, що мають voltage inverter is required, which can be purchased at JVC IN-CAR автомобиль не имеет этой системы, требуется инвертор заземлення ВІД’ЄМНОГО полюсу. Якщо ваше авто не...
Page 114 Если у Вас есть какие-либо вопросы, касающиеся установки, встановлення. У разі будь яких запитань або потреби у consult your JVC IN-CAR ENTERTAINMENT dealer or a company обратитесь к Вашему дилеру автомобилнего специалиста інформації щодо набору інструментів та спорядження, supplying kits.
Page 115 All manuals and user guides at all-guides.com РУССКИЙ УКРАЇНА ENGLISH ELECTRICAL CONNECTIONS ЭЛЕКТРИЧЕСКИЕ ПОДКЛЮЧЕНИЯ ЕЛЕКТРИЧНІ З’ЄДНАННЯ PRECAUTIONS on power supply and speaker ПРЕДОСТЕРЕЖЕНИЯ по питанию и ЗАСТЕРЕЖЕННЯ щодо приєднання джерела connections: подключению громкоговорителей: живлення та гучномовців: • DO NOT connect the speaker leads of the power cord to the •...
Page 116 All manuals and user guides at all-guides.com Connections without using the ISO connector / Подключение без использования разъема ISO / З’єднання без допомоги з’єднувача ISO Before connecting: Check the wiring in the vehicle carefully. Перед началом подключений: Тщательно проверьте Перед тим, як з’єднати: Уважно...
Page 117 All manuals and user guides at all-guides.com CD RECEIVER KD-G644 For canceling the display demonstration, see page 6. For installation and connections, refer to the separate manual. INSTRUCTIONS GET0503-001A [UI]...
Page 118 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 119 All manuals and user guides at all-guides.com How to use the M MODE button CONTENTS If you press M MODE, the unit goes into functions mode, then the number buttons and 5/∞ buttons will work Control panel ........4 as different function buttons. Remote controller —...
Page 120: Control Panel
All manuals and user guides at all-guides.com Control panel Parts identification Display window 5 (up) / ∞ (down) buttons Number buttons 0 (eject) button RPT (repeat) button (standby/on attenuator) button RND (random) button Control dial AUX (auxiliary) input jack Remote sensor USB (Universal Serial Bus) input jack DO NOT expose the remote sensor to strong light Source display / Track number / Folder number /...
Page 121: Rm-Rk50
All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 Installing the lithium coin battery (CR2025) Aim the remote controller directly at the remote sensor on the unit. Make sure there is no obstacle (standby/on/attenuator) button in between.
Page 122: Getting Started
All manuals and user guides at all-guides.com Getting started Basic settings • See also “General settings — PSM” on pages 12 and Basic operations Turn on the power. Ÿ 1 Canceling the display demonstrations Select “DEMO,” then “DEMO OFF.” * You cannot select these sources if they are not 2 Setting the clock ready or not connected.
Page 123: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 124: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Manual presetting Disc / USB device Ex.: Storing the FM station of 92.50MHz into preset operations number 4 of the FM1 band. : For built-in CD player operations. : For external USB device operations. Playing a disc in the unit Preset number flashes for a while.
Page 125 All manuals and user guides at all-guides.com Ÿ To fast-forward or reverse the track USB memory To go to the next or previous track If a USB device has been attached... To go to the next or previous folder (for Playback starts from where it has been stopped MP3/WMA) previously.
Page 126 All manuals and user guides at all-guides.com Other main functions Changing the display information Skipping tracks quickly during play While playing an audio CD or CD Text • For MP3/WMA, you can skip tracks within the same folder A = Disc title/performer * = Track ] = B = (back to the beginning) title *...
Page 127: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Selecting the playback modes You can use only one of the following playback modes You can select a preset sound mode suitable to the at a time. music genre (iEQ: intelligent equalizer). Select your desired playback mode.
Page 128 All manuals and user guides at all-guides.com General settings — PSM Indication, [Range] BASS * , [–06 to +06] You can change PSM (Preferred Setting Mode) items Adjust the bass. listed in the table on page 13. MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 129 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) DEMO • DEMO ON : The display demonstration will be activated automatically if no Display operation is done for about 20 seconds, [6]. demonstration •...
Page 130 All manuals and user guides at all-guides.com Other external component Title assignment operations You can assign titles to 30 station frequencies (FM and AM) and up to 8 characters for each station name. You can connect an external component to the AUX (auxiliary) input jack on the control panel.
Page 131 All manuals and user guides at all-guides.com To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors.
Page 132 All manuals and user guides at all-guides.com • MP3 and WMA “tracks” (words “file” and “track” are More about this unit used interchangeably) are recorded in “folders.” • When a disc is inserted upside down, “PLEASE” and Basic operations “EJECT appear alternately on the display. Press eject the disc.
Page 133 All manuals and user guides at all-guides.com Playing an MP3/WMA disc • This unit cannot play back the following files: – MP3 files encoded in MP3i and MP3 PRO format. • This unit can play back MP3/WMA files with the –...
Page 134 All manuals and user guides at all-guides.com • The maximum number of characters for: General settings—PSM – Folder names : 25 characters • “AUTO” setting for “DIMMER” may not work correctly – File names : 25 characters on some vehicles, particularly on those having a –...
Page 135 All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 136 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 137 All manuals and user guides at all-guides.com Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Type: Compact disc player Front/Rear: 50 W per channel Signal Detection Non-contact optical pickup System: (semiconductor laser) Continuous Power Output (RMS): Number of Channels: 2 channels (stereo) Front/Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more...
Page 138 All manuals and user guides at all-guides.com Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit © 2007 Victor Company of Japan, Limited 1107DTSMDTJEIN...
Page 139 Be sure to ground this unit to the car’s chassis again after installation. Notes: • Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer. • It is recommended to connect speakers with a maximum power of more than 50 W (both at the rear and at the front, with an impedance of 4 Ω...
Page 140 Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of this unit unused. Y-connector (not supplied for this unit) Front speakers JVC Amplifier Remote lead (blue with white stripe) To the remote lead of other equipment or automatic antenna Set “L/O MODE”...
Page 141 All manuals and user guides at all-guides.com CD RECEIVER KD-G646/KD-G645 KD-G646/KD-G645 For canceling the display demonstration, see page 6. For installation and connections, refer to the separate manual. INSTRUCTIONS GET0502-001A [U/UH]...
Page 142 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 143 All manuals and user guides at all-guides.com How to use the M MODE button CONTENTS If you press M MODE, the unit goes into functions mode, then the number buttons and 5/∞ buttons will work Control panel — ..4 KD-G646/KD-G645 as different function buttons.
Page 144 All manuals and user guides at all-guides.com Control panel — KD-G646/KD-G645 Parts identification Display window 5 (up) / ∞ (down) buttons Number buttons 0 (eject) button RPT (repeat) button (standby/on attenuator) button RND (random) button Control dial AUX (auxiliary) input jack Remote sensor USB (Universal Serial Bus) input jack DO NOT expose the remote sensor to strong light...
Page 145 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 Installing the lithium coin battery (CR2025) Aim the remote controller directly at the remote sensor on the unit. Make sure there is no obstacle (standby/on/attenuator) button in between.
Page 146 All manuals and user guides at all-guides.com Getting started Basic settings • See also “General settings — PSM” on pages 12 and Basic operations Turn on the power. Ÿ 1 Canceling the display demonstrations Select “DEMO,” then “DEMO OFF.” * You cannot select these sources if they are not 2 Setting the clock ready or not connected.
Page 147 All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 148 All manuals and user guides at all-guides.com Manual presetting Disc / USB device Ex.: Storing the FM station of 92.50MHz into preset operations number 4 of the FM1 band. : For built-in CD player operations. : For external USB device operations. Playing a disc in the unit Preset number flashes for a while.
Page 149 All manuals and user guides at all-guides.com Ÿ To fast-forward or reverse the track USB memory To go to the next or previous track If a USB device has been attached... To go to the next or previous folder (for Playback starts from where it has been stopped MP3/WMA) previously.
Page 150 All manuals and user guides at all-guides.com Other main functions Changing the display information Skipping tracks quickly during play While playing an audio CD or CD Text • For MP3/WMA, you can skip tracks within the same folder A = Disc title/performer * = Track ] = B = (back to the beginning) title *...
Page 151 All manuals and user guides at all-guides.com Sound adjustments Selecting the playback modes You can use only one of the following playback modes You can select a preset sound mode suitable to the at a time. music genre (iEQ: intelligent equalizer). Select your desired playback mode.
Page 152: General Settings - Psm
All manuals and user guides at all-guides.com Indication, [Range] General settings — PSM BASS * , [–06 to +06] You can change PSM (Preferred Setting Mode) items Adjust the bass. listed in the table on page 13. MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 153 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) DEMO • DEMO ON : The display demonstration will be activated automatically if no Display operation is done for about 20 seconds, [6]. demonstration •...
Page 154: Other External Component
All manuals and user guides at all-guides.com Other external component Title assignment operations You can assign titles to 30 station frequencies (FM and AM) and up to 8 characters for each station name. You can connect an external component to the AUX (auxiliary) input jack on the control panel.
Page 155: Maintenance
All manuals and user guides at all-guides.com To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors.
Page 156: More About This Unit
All manuals and user guides at all-guides.com • MP3 and WMA “tracks” (words “file” and “track” are More about this unit used interchangeably) are recorded in “folders.” • When a disc is inserted upside down, “PLEASE” and Basic operations “EJECT appear alternately on the display. Press eject the disc.
Page 157 All manuals and user guides at all-guides.com Playing an MP3/WMA disc • This unit cannot play back the following files: – MP3 files encoded in MP3i and MP3 PRO format. • This unit can play back MP3/WMA files with the –...
Page 158 All manuals and user guides at all-guides.com • The maximum number of characters for: General settings—PSM – Folder names : 25 characters • “AUTO” setting for “DIMMER” may not work correctly – File names : 25 characters on some vehicles, particularly on those having a –...
Page 159: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 160 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 161: Specifications
All manuals and user guides at all-guides.com Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Type: Compact disc player Front/Rear: 50 W per channel Signal Detection Non-contact optical pickup System: (semiconductor laser) Continuous Power Output (RMS): Number of Channels: 2 channels (stereo) Front/Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more...
Page 162 All manuals and user guides at all-guides.com Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit EN, TH © 2007 Victor Company of Japan, Limited 1007DTSMDTJEIN...
Page 163 „™È æ ‘ ° — ¥ ®”‡æ“–·∑πøî « À“°øî « Ï ¢ “¥∫Ë Õ ¬ „ÀÈ ª √÷ ° …“√È “ π¢“¬‡§√◊ Ë Õ ß‡ ’ ¬ ß√∂¬πµÏ • Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer.
Page 164 ¿“æµ— « Õ¬Ë “ ßµË Õ ‰ªπ’ È · ¥ß∂÷ ß °“√µ‘ ¥ µ— È ß ·∫∫∑— Ë « ‰ª À“°§ÿ ≥ ¡’ ª í ≠ À“À√◊ Õ µÈ Õ ß°“√¢È Õ ¡Ÿ ≈ ‡°’ Ë ¬ «°— ∫ ™ÿ ¥ µ‘ ¥ µ— È ß °√ÿ ≥ “ª√÷ ° …“°— ∫ ºŸ È ¢ “¬‡§√◊ Ë Õ ß‡ ’ regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
Page 165 All manuals and user guides at all-guides.com ENGLISH ‰∑¬ ELECTRICAL CONNECTIONS °“√‡™◊ Ë Õ ¡‚¥¬„™È ‰øøÈ “ Typical connections / °“√‡™◊ Ë Õ ¡µË Õ ·∫∫ª°µ Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious °Ë...
Page 166 µ‚π¡— µ ‘ ∂ È “ ¡’ À√◊ Õ Subwoofer Rear speakers ´— ∫ «Ÿ ø ‡øÕ√Ï ≈”‚æßÀ≈— ß JVC Amplifier JVC Amplifier ‡§√◊ Ë Õ ß¢¬“¬‡ ’ ¬ ß ‡§√◊ Ë Õ ß¢¬“¬‡ ’ ¬ ß Front speakers ≈”‚æßÀπÈ “ Remote lead “¬µ–°—...
Page 167: Kd-G646/Kd-G645
All manuals and user guides at all-guides.com CD RECEIVER KD-G646/KD-G645 ALAT PENERIMA CD KD-G646/KD-G645 For canceling the display demonstration, see page 6. Untuk membatalkan tampilan demonstrasi, lihat halaman 6. For installation and connections, refer to the separate manual. Untuk instalasi dan penyambungan, lihat buku pedoman terpisah. INSTRUCTIONS BUKU PETUNJUK GET0502-004A...
Page 168 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 169: Remote Controller - Rm-Rk50
All manuals and user guides at all-guides.com How to use the M MODE button CONTENTS If you press M MODE, the unit goes into functions mode, then the number buttons and 5/∞ buttons will work Control panel — ..4 KD-G646/KD-G645 as different function buttons.
Page 170 All manuals and user guides at all-guides.com Control panel — KD-G646/KD-G645 Parts identification Display window 5 (up) / ∞ (down) buttons Number buttons 0 (eject) button RPT (repeat) button (standby/on attenuator) button RND (random) button Control dial AUX (auxiliary) input jack Remote sensor USB (Universal Serial Bus) input jack DO NOT expose the remote sensor to strong light...
Page 171 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 Installing the lithium coin battery (CR2025) Aim the remote controller directly at the remote sensor on the unit. Make sure there is no obstacle (standby/on/attenuator) button in between.
Page 172: Getting Started
All manuals and user guides at all-guides.com Getting started Basic settings • See also “General settings — PSM” on pages 12 and Basic operations Turn on the power. Ÿ 1 Canceling the display demonstrations Select “DEMO,” then “DEMO OFF.” * You cannot select these sources if they are not 2 Setting the clock ready or not connected.
Page 173: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 174: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Manual presetting Disc / USB device Ex.: Storing the FM station of 92.50MHz into preset operations number 4 of the FM1 band. : For built-in CD player operations. : For external USB device operations. Playing a disc in the unit Preset number flashes for a while.
Page 175 All manuals and user guides at all-guides.com Ÿ To fast-forward or reverse the track USB memory To go to the next or previous track If a USB device has been attached... To go to the next or previous folder (for Playback starts from where it has been stopped MP3/WMA) previously.
Page 176 All manuals and user guides at all-guides.com Other main functions Changing the display information Skipping tracks quickly during play While playing an audio CD or CD Text • For MP3/WMA, you can skip tracks within the same folder A = Disc title/performer * = Track ] = B = (back to the beginning) title *...
Page 177: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Selecting the playback modes You can use only one of the following playback modes You can select a preset sound mode suitable to the at a time. music genre (iEQ: intelligent equalizer). Select your desired playback mode.
Page 178: General Settings - Psm
All manuals and user guides at all-guides.com Indication, [Range] General settings — PSM BASS * , [–06 to +06] You can change PSM (Preferred Setting Mode) items Adjust the bass. listed in the table on page 13. MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 179 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) DEMO • DEMO ON : The display demonstration will be activated automatically if no Display operation is done for about 20 seconds, [6]. demonstration •...
Page 180: Other External Component Operations
All manuals and user guides at all-guides.com Other external component Title assignment operations You can assign titles to 30 station frequencies (FM and AM) and up to 8 characters for each station name. You can connect an external component to the AUX (auxiliary) input jack on the control panel.
Page 181: Maintenance
All manuals and user guides at all-guides.com To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors.
Page 182: More About This Unit
All manuals and user guides at all-guides.com • MP3 and WMA “tracks” (words “file” and “track” are More about this unit used interchangeably) are recorded in “folders.” • When a disc is inserted upside down, “PLEASE” and Basic operations “EJECT appear alternately on the display. Press eject the disc.
Page 183 All manuals and user guides at all-guides.com Playing an MP3/WMA disc • This unit cannot play back the following files: – MP3 files encoded in MP3i and MP3 PRO format. • This unit can play back MP3/WMA files with the –...
Page 184 All manuals and user guides at all-guides.com • The maximum number of characters for: General settings—PSM – Folder names : 25 characters • “AUTO” setting for “DIMMER” may not work correctly – File names : 25 characters on some vehicles, particularly on those having a –...
Page 185: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 186 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 187: Specifications
All manuals and user guides at all-guides.com Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Type: Compact disc player Front/Rear: 50 W per channel Signal Detection Non-contact optical pickup System: (semiconductor laser) Continuous Power Output (RMS): Number of Channels: 2 channels (stereo) Front/Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more...
Page 188 All manuals and user guides at all-guides.com Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Ada MASALAH dengan cara pengoperasian? Setel kembali unit Anda Lihat halaman mengenai Bagaimana mereset unit anda EN, IN ©...
Page 189 Catatan: • • Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio Ganti sekring dengan voltase yang sudah ditetapkan. Jika sekring sering meledak, konsultasikan pada dealer. penyalur audio mobil JVC anda.
Page 190 The following illustration shows a typical installation. If you have any questions or require information Ilustrasi berikut menunjukkan sebuah tipe pemasangan. Jika anda mempunyai suatu pertanyaan atau regarding installation kits, consult your JVC car audio dealer or a company supplying kits. informasi yang diperlukan mengenai alat-alat pemasangan, konsultasikan pada penyalur audio mobil JVC atau sebuah perusahaan yang mensuplai alat-alat.
Page 191 All manuals and user guides at all-guides.com ENGLISH INDONESIA ELECTRICAL CONNECTIONS SAMBUNGAN-SAMBUNGAN LISTRIK Typical connections / Ciri khas sambungan-sambungan Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious Sebelum penyambungan: Cek perkabelan dalam mobil dengan hati-hati. Penyambungan yang tidak damage to this unit.
Page 192 Biarkan ujung speaker dari unit ini tidak digunakan. Y-connector (not supplied for this unit) Konektor Y (tidak disediakan untuk unit ini) Front speakers Speaker-speaker depan JVC Amplifier Penguat JVC Set “L/O MODE” to “REAR” (See page Set “L/O MODE” to “SUB.W” (See page 13 of the INSTRUCTIONS.) 13 of the INSTRUCTIONS.)
Page 193 All manuals and user guides at all-guides.com CD RECEIVER KD-G646/KD-G645 KD-G646/KD-G645 For canceling the display demonstration, see page 6. For installation and connections, refer to the separate manual. INSTRUCTIONS GET0502-005A [UT]...
Page 194 All manuals and user guides at all-guides.com Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1.
Page 195: Control Panel - Kd-G646/Kd-G645
All manuals and user guides at all-guides.com How to use the M MODE button CONTENTS If you press M MODE, the unit goes into functions mode, then the number buttons and 5/∞ buttons will work Control panel — ..4 KD-G646/KD-G645 as different function buttons.
Page 196 All manuals and user guides at all-guides.com Control panel — KD-G646/KD-G645 Parts identification Display window 5 (up) / ∞ (down) buttons Number buttons 0 (eject) button RPT (repeat) button (standby/on attenuator) button RND (random) button Control dial AUX (auxiliary) input jack Remote sensor USB (Universal Serial Bus) input jack DO NOT expose the remote sensor to strong light...
Page 197 All manuals and user guides at all-guides.com Remote controller — Main elements and features RM-RK50 Installing the lithium coin battery (CR2025) Aim the remote controller directly at the remote sensor on the unit. Make sure there is no obstacle (standby/on/attenuator) button in between.
Page 198: Getting Started
All manuals and user guides at all-guides.com Getting started Basic settings • See also “General settings — PSM” on pages 12 and Basic operations Turn on the power. Ÿ 1 Canceling the display demonstrations Select “DEMO,” then “DEMO OFF.” * You cannot select these sources if they are not 2 Setting the clock ready or not connected.
Page 199: Radio Operations
All manuals and user guides at all-guides.com When an FM stereo broadcast is hard to Radio operations receive Lights up when monaural mode is activated. Ÿ Lights up when receiving an FM stereo broadcast with sufficient signal strength. Reception improves, but the stereo effect will be lost. To restore the stereo effect, repeat the same procedure.
Page 200: Playing A Disc In The Unit
All manuals and user guides at all-guides.com Manual presetting Disc / USB device Ex.: Storing the FM station of 92.50MHz into preset operations number 4 of the FM1 band. : For built-in CD player operations. : For external USB device operations. Playing a disc in the unit Preset number flashes for a while.
Page 201 All manuals and user guides at all-guides.com Ÿ To fast-forward or reverse the track USB memory To go to the next or previous track If a USB device has been attached... To go to the next or previous folder (for Playback starts from where it has been stopped MP3/WMA) previously.
Page 202 All manuals and user guides at all-guides.com Other main functions Changing the display information Skipping tracks quickly during play While playing an audio CD or CD Text • For MP3/WMA, you can skip tracks within the same folder A = Disc title/performer * = Track ] = B = (back to the beginning) title *...
Page 203: Sound Adjustments
All manuals and user guides at all-guides.com Sound adjustments Selecting the playback modes You can use only one of the following playback modes You can select a preset sound mode suitable to the at a time. music genre (iEQ: intelligent equalizer). Select your desired playback mode.
Page 204: General Settings - Psm
All manuals and user guides at all-guides.com Indication, [Range] General settings — PSM BASS * , [–06 to +06] You can change PSM (Preferred Setting Mode) items Adjust the bass. listed in the table on page 13. MIDDLE * (mid-range), [–06 to +06] Adjust the mid-range frequencies sound level.
Page 205 All manuals and user guides at all-guides.com Indications Item Selectable settings, [reference page] ( : Initial) DEMO • DEMO ON : The display demonstration will be activated automatically if no Display operation is done for about 20 seconds, [6]. demonstration •...
Page 206: Other External Component Operations
All manuals and user guides at all-guides.com Other external component Title assignment operations You can assign titles to 30 station frequencies (FM and AM) and up to 8 characters for each station name. You can connect an external component to the AUX (auxiliary) input jack on the control panel.
Page 207: Maintenance
All manuals and user guides at all-guides.com To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors.
Page 208: More About This Unit
All manuals and user guides at all-guides.com • MP3 and WMA “tracks” (words “file” and “track” are More about this unit used interchangeably) are recorded in “folders.” • When a disc is inserted upside down, “PLEASE” and Basic operations “EJECT appear alternately on the display. Press eject the disc.
Page 209 All manuals and user guides at all-guides.com Playing an MP3/WMA disc • This unit cannot play back the following files: – MP3 files encoded in MP3i and MP3 PRO format. • This unit can play back MP3/WMA files with the –...
Page 210: General Settings-Psm
All manuals and user guides at all-guides.com • The maximum number of characters for: General settings—PSM – Folder names : 25 characters • “AUTO” setting for “DIMMER” may not work correctly – File names : 25 characters on some vehicles, particularly on those having a –...
Page 211: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. •...
Page 212 All manuals and user guides at all-guides.com Symptoms Remedies/Causes • Tracks are not played back in the order you The playback order is determined when the files are have intended. recorded. • The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.
Page 213: Specifications
All manuals and user guides at all-guides.com Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Type: Compact disc player Front/Rear: 50 W per channel Signal Detection Non-contact optical pickup System: (semiconductor laser) Continuous Power Output (RMS): Number of Channels: 2 channels (stereo) Front/Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more...
Page 214 All manuals and user guides at all-guides.com Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit EN, CT © 2007 Victor Company of Japan, Limited 1007DTSMDTJEIN...
Page 215 注意: Notes: • 把保險絲更換為額定負荷值的保險絲。如果保險絲經常燒壞，請向 JVC 汽車音響分銷商詢問。 • Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio • 後置和前置揚聲器的最大輸入功率應大於 50 W，其阻抗為 4 Ω 8 Ω。如果最大功率小於 50 W， dealer. 請調校“AMP GAIN”設定值，以防止揚聲器損壞。（參閱使用說明書的第 13 頁。）...
Page 216 安裝（裝設、固定在儀表板內） INSTALLATION (IN-DASH MOUNTING) The following illustration shows a typical installation. If you have any questions or require information 下面的圖解表示了典型的安裝程序。如果您有問題，或需要有關配套元件的資料，請向 JVC regarding installation kits, consult your JVC car audio dealer or a company supplying kits. 汽車音響分銷商或配套元件供應公司詢問。 • 如果您不能確定如何正確地安裝本機，應請合格的技術人員來安裝。 • If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Page 217 All manuals and user guides at all-guides.com 中文 ENGLISH 電路連接 ELECTRICAL CONNECTIONS Typical connections / 典型的接線方法 Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious 接線前：仔細檢查汽車內的線路。不正確的接線會導致本機嚴重損壞。 damage to this unit. 電源線的引線和車身的連接器引線在顏色上可能有所不同。 The leads of the power cord and those of the connector from the car body may be different in color. 依照下圖所示之次序連接電源線的顏色導線。...
Page 218 Y-connector (not supplied for this unit) Y-型連接導線（不隨本機提供） Front speakers 前置揚聲器 JVC Amplifier JVC 功率放大器 Set “L/O MODE” to “SUB.W” (See Set “L/O MODE” to “REAR” (See page page 13 of the INSTRUCTIONS.) 13 of the INSTRUCTIONS.) Remote lead (blue with white stripe) 將“L/O MODE”設定為...

JVC KD-G440 Instruction Manual

Table of Contents

Detaching the Control Panel

Table of Contents

Table of Contents

Table of Contents

Table of Contents

Remote Controller - Rm-Rk50

Control Panel - Kd-G646/Kd-G645/Remote Controller - Rm-Rk50

Quick Links

Chapters

Troubleshooting

Related Manuals for JVC KD-G440

Summary of Contents for JVC KD-G440

Table of Contents
