Summary of Contents for Terrain Dynamics AIRhub
- Page 1 O p e r a t i n g M a n u a l Kit includeS: 700c Wheel with AIRhub Viiiiva Dual heart rate monitor • replaces your front wheel • Self powered - no battery needed • Bluetooth to your smartphone info@terraindynamics.com.au...
-
Page 2: Table Of Contents
1. Introduction Page 3 2. Warranty Page 4 3. Before using the AIRhub Page 6 4. Using the AIRhub Smartphone Application Page 8 5. Setting up the AIRhub Page 10 6. Setting up Accessories Page 12 7. Using the AIRhub Page 15 8. -
Page 3: Introduction
We created this tool out of a desire to train efficiently and effectively and to leave no room for excuses out on the road. We hope that the AIRhub will take your performance to all new heights. – Michael Freiberg, Inventor “...I knew that by computer... -
Page 4: Warranty
Summary of Australian statutory of time. In this case, Terrain Dynamics consumer guarantees in relation to can choose to offer you a refund, goods replacement or repair. - Page 5 For goods, there is a major failure to comply with a consumer guarantee when: • You would not have purchased the AIRhub™ if you had known about the problem. • The AIRhub™ is significantly different from the description, www.terraindynamics.com.au...
-
Page 6: Before Using The Airhub
Step 1: Download smartphone Application from Apple App Store or Google Play Store - AIRhub by Terrain Dynamics Step 2: Remove AIRhub from box and fit with tyre and tube. To maintain a high quality ride feel, use a good quality tyre and tube. - Page 7 Step 3: Place AIRhub in front forks and tighten skewer. Ensure red arrows are pointing forward. (See image below) www.terraindynamics.com.au Page 7...
-
Page 8: Using The Airhub Smartphone Application
SRM, Garmin etc. The AIRhub uses BLE to transmit data. BLE protocol uses power similar to that of the super low power wireless protocol ANT+ and will not drain your battery like other Bluetooth devices. -
Page 9: Wheel Circumference
SMartphOne applicatiOn diSplay: Status Indicators Icons show connection status to the AIRhub and heart rate monitor. Settings Page Icon Select to go to App Settings page. (see below) Vital information Displays current session information. Mode Selectors Used to choose training mode. -
Page 10: Setting Up The Airhub
5. Setting up the airhuB 5.1. Connection and resistance parameters The AIRhub requires a minimum speed of 15km/h before data is transmitted to the Smartphone App and pairing can occur. No resistance is applied below 15km/h. Maximum speed where resistance can be applied is 50km/h. - Page 11 Step 4: Radio symbol in top left hand corner will turn green when AIRhub is successfully paired. If after these steps the AIRhub will not pair or data is not being transmitted, please see troubleshooting page (Page 25) for further information. www.terraindynamics.com.au...
-
Page 12: Setting Up Accessories
6.1. Pairing the Viiiiva Heart Rate Monitor to AIRhub app. NB#: Any BLE heart rate monitor can be used with the AIRhub App. The Viiiiva heart rate monitor was specially chosen for dual BLE & ANT+ Broadcasts. This will allow data to record to your Garmin or SRM while simultaneously using the App. - Page 13 Bluetooth-enabled power meters can connect directly to the AIRhub App and begin transmitting data. Please use the following steps to pair to the AIRhub. Step 1: Open AIRhub App - ensuring Bluetooth is enabled on your smartphone and power meter.
- Page 14 6. Setting up acceSSOrieS 6.3. Pairing a Non-Bluetooth Power Meter. In order for the AIRhub App to receive data from your power meter, you must program the Viiiiva Heart Rate Strap to act as a bridge between the two. Once programmed, you will no longer need the Viiiiva App open and only use it if you need to reprogram your HR strap.
- Page 15 www.terraindynamics.com.au Page 15...
- Page 16 6. Setting up acceSSOrieS 6.3. Pairing a Non-Bluetooth Power Meter. In order for the AIRhub App to receive data from your power meter, you must program the Viiiiva Heart Rate Strap to act as a bridge between the two. Once programmed, you will no longer need the Viiiiva App open and only use it if you need to reprogram your HR strap.
- Page 17 www.terraindynamics.com.au Page 17...
-
Page 18: Using The Airhub
7. uSing the airhuB Once your AIRhub and accessories are paired and you are ready to begin your training session, select an Operating mode to set your resistance. 7.1. Selecting an Operating mode See 7.2 for detailed information on each operating mode. - Page 19 0 to 100 additional watts. It allows for the chosen, and a minimum speed of 20km/h has been met, the AIRhub will manual application of large amounts of begin to apply resistance. resistance from 15km/h to 45km/h.
- Page 20 14 and 16 for step by step instructions on how to con gure the AIRhub App to hold a power output that you choose. the Viiiiva Bluetooth bridge to your Android or Apple iOS...
- Page 21 7.2.3. Target Heart Rate Mode Using both Bluetooth and ANT+ the The AIRhub will adjust resistance every Viiiiva Heart Rate Monitor communicates second to give you the most accurate with the Smartphone App and the control of your heart rate.
- Page 22 This chose 1 watt per km/h for this speed will let power requirements update over the AIRhub would apply 25 watts of undulating terrain (Manual Wattage resistance. Mode will still apply up to 100w even on steep hills).
- Page 23 www.terraindynamics.com.au Page 23...
- Page 24 7. uSing the airhuB contd. TO START MAKING THE MOST OF YOU TRAINING, INCLUDE SOME OF THESE TEMPO EFFORTS NEXT TIME YOU ARE OUT ON THE BIKE. SESSION 1 SESSION 3 Warm up for 10-15 minutes Warm up for 10 - 15 minutes...
- Page 25 www.terraindynamics.com.au Page 25...
-
Page 26: Thermal Management
8. therMal ManageMent The AIRhub dissipates your energy through heat. The AIRhub has multiple temperature sensors that monitor the internal conditions and modify the resistance accordingly. 8.1. The maximum temperature of 8.3. During high heat loads a small the resistance mechanisms is limited amount of heat may be transferred to to 110 degrees C. -
Page 27: Troubleshooting
If it remains grey or If no AIRhub is recognised by red try following steps. Step 2: Ensure the serial of the AIRhub app, try the following steps: Step 1: Ensure smartphone Bluetooth is in your front wheel matches the turned on. -
Page 28: Faqs
If you aren’t racing, then it should be fit and healthy. Without the AIRhub, snugly secured in your forks. The AIRhub speeds would be unsafe or the intensity is great for a number of situations;... - Page 29 TRIATHLETES TOO? Yep. All 700c forks work. We are yet to find a company that has managed to The AIRhub will work even better for stump us. We highly recommend quality Triathletes. More training in less time. It forks, as with most bicycle equipment.
- Page 30 WILL MY AIRHUB AUTOMATICALLY CONNECT TO MY PHONE? The App will remember the last AIRhub it connected to and always try to find it. If you want to find another AIRhub Page 30 info@terraindynamics.com.au...
-
Page 31: Safe Use
11. Safe uSe 11.1. The AIRhub has been Road and Rig tested up to speeds of 700RPM (88km/h). We do not recommend using the wheel in scenarios where this speed can be exceeded. REMEMBER: If you have previously paired with a different AIRhub you must first ‘Forget’... - Page 32 110517 info@terraindynamics.com.au www.terraindynamics.com.au...
