- Page 1 TS TAxx Integrated Interactive Terminals Installation Manual...
-
Page 3: Table Of Contents
TS TAxx TABLE OF CONTENTS FCC NOTICE....................4 Canadian Compliance Statement............4 PRELIMINARY OPERATIONS..........5 Mounting Instructions..................5 Electrical Connections ..................6 Cabling Arrangements ..................7 INSTALLATION ............... 8 Attaching the Terminal Support Plate ............8 Hooking Up the Terminal ................9 Connecting the Cables..................10 Jumpers......................13 Auxiliary Connections ...................14 Closing the Terminal ..................15 Applying the Entry/Exit Labels..............16 TECHNICAL SPECIFICATIONS ........ -
Page 4: Fcc Notice
FCC NOTICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Preliminary Operations
PRELIMINARY OPERATIONS Mounting Instructions It is recommended that you attach the cables to wall box. The position selected for mounting the box must satisfy the requirements laid down for the mounting area and allow the necessary space for opening the box (see Figure 1). -
Page 6: Electrical Connections
Electrical Connections The TemaServer is powered at low voltage (12V ) by means of a transformer connected to the 115/230V 50/60Hz network switch. This switch must be positioned prior to the TemaServer. The cables connecting the transformer and the TemaServer must be at least AWG20 and no more than 10m long (see Figure 2). -
Page 7: Cabling Arrangements
Cabling Arrangements It is recommended that you attach the cables to wall box. The box must be placed 120cm from the ground (see Figure 3). It is strongly recommended that you run the LAN cable into a separate tube from the one used for the 12V∼ power cable. If you wish to keep the LAN cable and the 12V∼... -
Page 8: Installation
INSTALLATION Attaching the Terminal Support Plate To attach the terminal support plate, drill two holes in the wall in which to place the plastic anchors that hold up the support plate (see Figure 4). Make sure that the box attached to the wall is aligned with the niche on the lower part of the support plate (use a ∅... -
Page 9: Hooking Up The Terminal
Hooking Up the Terminal To hook up the terminal, follow the steps described below (see Figure 5): 1. Attach the upper part of the terminal to the upper hooks on the support plate. 2. Insert the cables into the terminal through the specified openings. 3. -
Page 10: Connecting The Cables
Connecting the Cables To connect the cables, follow these steps: 1. Before connecting the cables, insert the power supply jumpers. WARNING Do not press the anti-opening tamper during installation and/or maintenance of the unit. 2. Line up the cables with the grooves at the back of the terminal (see Figure 6) and screw in the small plate which serves as a cable clamp (use a ∅... - Page 11 When 12V of electric current is supplied (see Figure 8), the terminal commences operation and the green “RUN” LED lights up (see Figure 7) Battery JTAG Battery fuse (F1) Battery cable P10 wall-tamper tamper (jumper) P12 connector Status LED for production TX (red) jumper - RX (green)
- Page 12 lamp cable for rear - lighting of LCD jumper JP2 pin 1 -2 = MAG-TEK jumper JP3 pin 2 -3 = bidirectiona l serial interface pin 1 -2 = MAG-TEK pin 2 -3 = Proxy TemaServer mother board connection keyboard cable (4 rightmost keys) keyboard cable (4 leftmost keys)
-
Page 13: Jumpers
Jumpers For normal operation, configure the ju mpers on the main board as specified in Table 2. Jumper Function Default state auxiliary tamper Inserted Open auto -update firmware Ethernet full duplex Open Ethernet loopback Inserted Table 1: Configuration of jumpers on main board Configure the jumpers on the display board as specified in Table 2. -
Page 14: Auxiliary Connections
Auxiliary Connections The I/O plug-in board features a connector that includes two opto-coupled inputs and two relay outputs, as illustrated in Figure 10. jumper jumper jumpers jumpers relay 1 relay 2 input 1 input 2 relay output 1 relay output 1 relay output 2 relay output 2 connector to... -
Page 15: Closing The Terminal
Closing the Terminal To close the terminal, follow these steps: 1. Connect both contacts of the battery cable to the battery 2. Make sure that the rubber gasket is correctly positioned. 3. Close the terminal cover by rotating it. 4. Fasten the cover with the two special screws (see Figure 11) located on the side of the terminal (use a TORX anti-tamper TX10 screwdriver). -
Page 16: Applying The Entry/Exit Labels
Applying the Entry/Exit Labels Apply the two entry/exit labels to the magnetic reader according to the pre- configured transit direction. Make sure that you place the labels in the appropriate hollows (TS-Tax3/TS-Tax4: see details in Figure 12 and Figure 13). O U T ß... -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS TemaServer TS TAx3 (CTU-K03 code 1500064FA) Parameter Value DC power supply ±15% 500mA nominal (6W) 600mA max (for fast battery recharge) AC power supply ±15% 50Hz 500mA (nominal) 600mA max (for fast battery recharge) Power supply via TRN01 230V ±15% 50Hz Transformer... -
Page 18: Spare Parts
Inputs Number of inputs: 2 • opto-coupled mode resistance: 2.2 Kohm logic level high: >4 V (max. positive +18 V logic level low: <1 V (max. negative –0.5 V • self powered mode (dry contacts) open contact: > 2Kohm closed contact: < 100 ohm (10mA) Directive EMC 89/336/EEC, 92/31/EEC, Regulations compliance Directive Low Voltage 72/23/EEC, 93/68/EEC :... -
Page 19: Temaserver Ts Tax4 (Ctu-K04 Code 1500087Ca)
TemaServer TS TAx4 (CTU-K04 code 1500087DA) Parameter Value DC power supply ±15% 500mA nominal (6W) 600mA max (for fast battery recharge) AC power supply ±15% 50Hz 500mA (nominal) 600mA max (for fast battery recharge) Power supply via TRN01 230V ±15% 50Hz Transformer 30mA nominal (7VA) 40mA max. -
Page 20: Spare Parts
Inputs Number of inputs: 2 • opto-coupled mode resistance: 2.2 Kohm logic level high: >4 V (max. positive +18 V logic level low: <1 V (max. negative –0.5 V • self powered mode (dry contacts) open contact: > 2Kohm closed contact: < 100 ohm (10mA) Directive EMC 89/336/EEC, 92/31/EEC, Regulations compliance Directive Low Voltage 72/23/EEC, 93/68/EEC:... -
Page 21: Optional Parts
Optional Parts TORX TX10 screwdriver Code 1500108AA Optional Parts Page 21... - Page 23 Internet: http://www.temaline.com...
