Toshiba 32L220U19 Quick Setup Manual

V1
FINAL
FOR PRINT
Toshiba_32L220U19_17-0908_QSG_V1_EN_Final.ai 1 12/22/2017 9:55:10 AM Toshiba_32L220U19_17-0908_QSG_V1_EN_Final.ai 1 12/22/2017 9:55:10 AM
1
INCLUDED ACCESSORIES
Remote control and two AAA batteries
+ +
Stands
C
M
Y
CM
ST4 screws (25 mm length)
MY
(4 pcs.)
CY
CMY
K
FIND YOUR USER GUIDE ONLINE!
Go to www.tv.toshiba.com and search
for 32L220U19.
WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"hazardous voltage" within the product's enclosure, which may be
of sufficient magnitude to induce a risk of electric shock to persons.
The exclamation mark inside an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the product.
START HERE
How do I attach the stand to my TV? (not for wall mounting)
You'll need: Soft surface and a Phillips screwdriver.
Carefully place your TV face-down on a cushioned, clean surface.
Align the screw holes on the TV stands with the holes on the bottom of your TV, then secure each stand to your TV with two of
the provided screws.
Features
Front
Remote sensor
Power On/Standby LED
Back
Before using your new product, please read these instructions to prevent any damage.
ST4 type (25 mm) screws
2
MAKING CONNECTIONS
How do I watch TV (cable, satellite, or antenna) or connect a device such as a DVD or Blu-ray disc player or game console?
HDMI® (BEST)
Best video quality
Note: Connect an ARC-enabled home theater
receiver to the HDMI IN 1 (ARC) jack.
Quick Setup Guide
32" 720p, 60Hz, LED TV
WALL MOUNT
How do I prepare my TV for wall mounting? (not for use with a TV stand)
You'll need: Soft surface and a Phillips screwdriver.
Before you mount your TV, make sure that:
• You remove the stand legs.
• The bracket supports the weight of your TV.
A Carefully place your TV face-down on a cushioned, clean surface.
B See the instructions that came with your wall mount for more information about how to
correctly mount your TV.
OR
A
VESA Mounting Pattern
VESA mount (mm): 100 × 100 – M4 x 12mm type screws (4 pcs)
Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket
B
to the back of your TV, the bracket must be securely attached, using all four holes.
If you do not use all four mounting holes, your TV may fall and cause property damage
or personal injury. See the documentation that came with your wall mount for complete
mounting instructions.
Coaxial
AV (GOOD)
(GOOD)
AUDIO/VIDEO OUT
| 32L220U19
