Thank you for your purchasing KOMTRAX terminal (KDTC730).
■ Read this instruction manual and use your KOMTRAX terminal correctly ■
・Operators and service personnel for machines using KOMTRAX should make sure that they read and
fully understand this document.
・Keep this document together with the Operation and Maintenance manual for the machine equipped with
KOMTRAX, and read it repeatedly.
※KOMTRAX is a machine management system that uses wireless communications.
Instruction Manual
Model No．
KOMTRAX Terminal
Model Name
TC730
KDTC730
KDTC730
1/12
Advertisement
Table of Contents
Related Manuals for Komatsu KOMTRAX TC730
Summary of Contents for Komatsu KOMTRAX TC730
- Page 1 1/12 KOMTRAX Terminal Instruction Manual TC730 Model Name KDTC730 Model No． Thank you for your purchasing KOMTRAX terminal (KDTC730). ■ Read this instruction manual and use your KOMTRAX terminal correctly ■ ・Operators and service personnel for machines using KOMTRAX should make sure that they read and fully understand this document.
- Page 2 For the countries where use of KDTC730 is permitted, ask your Komatsu distributor. ● Always contact your Komatsu distributor when exporting or reselling a vehicle equipped with KDTC730. Note that the radio communication function of KDTC730 may be turned off forcibly, when the vehicle is out of the countries or areas where use of KDTC730 is permitted.
-
Page 3: Safety Precautions
The items to be observed without fail are explained as shown below to prevent an injury to the user and other persons and damage to property. If you do not obey these precautions, neither Komatsu nor your Komatsu distributor can take any responsibility for any problem that is caused or for any loss that results. - Page 4 Neglecting this may cause a For anyone wearing a pacemaker, trouble, a fire, or an accident. the radio waves may have an Your Komatsu distributor will adverse effect on the operation of carry out removal and the pacemaker. installation.
- Page 5 Prohibit Take the action given in "LONG-TERM Contact your Komatsu distributor before STORAGE" Operation installing a top guard or other attachment Maintenance Manual for the machine, that covers the antenna.
-
Page 6: Fcc Statements
CAN ICES-3 (B)/NMB-3(B) NOTICE: Changes or modifications made to this equipment not expressly approved by Komatsu Ltd may void the FCC authorization to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 7 7/12 Request for correct use Lithium battery in body of KDTC730 The set operation, time, and other information are backed up by the lithium battery in the body of KDTC730. Accordingly, if the battery goes dead, the saved data are lost. The life of the lithium battery is about 5 years (when used at the normal temperature), although it depends on the using condition.
-
Page 8: Name And Function Of Each Part
8/12 Name and function of each part KDTC730 ① ③ ④ ② ① LED window Indicates the operating condition with the internal LED. ② Interface connector (AMP) Connects the power cable and signal lines on the vehicle side. For details, see the specifications of interface connector. -
Page 9: How To Install
9/12 How to install Fixing KDTC730 206mm Fix 4 mounting parts with M6 bolts. Communication cable GPS cable connector connector Interface connector KDTC730... - Page 10 10/12 Specifications of interface connector Connector on KDTC530 side: 173866-1 (Manufactured by AMP) Pin Number Name Remark Ａ-1 PWR_OUT_5V DC5V output Ａ-2 － Ａ-3 RS232C TXD Ａ-4 Input RS232C RXD Ａ-5 DIS_L_3 Input ON/OFF INPUT3 Ａ-6 DIS_L_6 Input ON/OFF INPUT6 Ａ-7 DIS_L_2 Input...
-
Page 11: Specifications
Drip-proof (When connectors are directed down. Connector is not included.) Vibration resistance 8.9G (5～200 Hz) Impact-resistant Outside dimensions (mm) 206×114×50 Weight 0.85kg Accessories sold GPS antenna(3.5m) separately (Ask your Communication antenna Komatsu distributor.) Cable for communication antenna(1.5m, 3.5m, 4.5m, 6.5m, 11m, 13m) KDTC730... -
Page 12: Troubles And Causes
12/12 Troubles and causes Trouble Possible cause Remedy KDTC730 cannot communicate. Communication antenna is Connect antenna. not connected. Antenna cable is broken. Replace antenna cable. Foreign matter is in Remove foreign matter. communication antenna connector. Radio wave does not reach Install antenna to place where there are no antenna because...
