- Page 1 Instruction Manual Self-Contained Flaker Models F-300BAJ F-500BAJ hoshizakiamerica.com Issued: 12/12/2016...
- Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, send an e-mail message, or write to the Hoshizaki Technical Support Department for assistance. Phone: 1-800-233-1940; (770) 487-2331 Fax: 1-800-843-1056;...
-
Page 3: Table Of Contents
Retain this manual for any further reference that may be necessary. CONTENTS Important Safety Information ....................4 I. Specifications ........................7 A. Electrical and Refrigerant Data ..................7 1. F-300BAJ ......................... 7 2. F-500BAJ ......................... 7 B. Dimensions/Connections ....................8 1. F-300BAJ ......................... 8 2. F-500BAJ ......................... 9 II. -
Page 4: Important Safety Information
Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, damage to the appliance, or damage to property. WARNING Indicates a hazardous situation which could result in death or serious injury. - Page 5 WARNING, continued For Corded Models • This appliance is equipped with a NEMA 5-15 three-prong grounding plug reduce the risk of potential shock hazards. Corded models must be plugged into a properly grounded, independent 3-prong wall outlet. If the outlet is a 2-prong outlet, it is your personal responsibility to have a qualified electrician replace it with a properly grounded, independent 3-prong wall outlet.
- Page 6 WARNING, continued • Do not use combustible spray or place volatile or flammable substances near the appliance. They might catch fire. • Keep the area around the appliance clean. Dirt, dust, or insects in the appliance could cause harm to individuals or damage to the appliance. •...
-
Page 7: Specifications
The nameplate is located on the rear panel. For certification marks, see the nameplate. We reserve the right to make changes in specifications and design without prior notice. 1. F-300BAJ Model Number F-300BAJ... -
Page 8: Dimensions/Connections
B. Dimensions/Connections 1. F-300BAJ Front Side Rear NOTICE Allow 6" (15 cm) clearance at rear and sides for proper air circulation and ease of maintenance and/or service should they be required. Allow 24" (61 cm) clearance at top to allow for removal of... -
Page 9: F-500Baj
2. F-500BAJ Front Side Rear NOTICE Allow 6" (15 cm) clearance at rear and sides for proper air circulation and ease of maintenance and/or service should they be required. Allow 24" (61 cm) clearance at top to allow for removal of the auger. -
Page 10: Installation And Operating Instructions
II. Installation and Operating Instructions WARNING • The appliance must be installed in accordance with applicable national, state, and local codes and regulations. • Failure to install, operate, and maintain the appliance in accordance with this manual will adversely affect safety, performance, component life, and warranty coverage and may result in costly water damage. -
Page 11: How To Remove Panels
C. How to Remove Panels See Fig. 1 • Top Panel: Remove the screws. Lift up at the front slightly, push rearward, and lift off. • Front Panel: Remove the screws. Lift up and pull towards you. Sliding Door Storage Bin Top Panel Front Panel Fig. -
Page 12: Electrical Connection
E. Electrical Connection WARNING • Electrical connection must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or damage. • The appliance requires an independent power supply of proper capacity. See the nameplate for electrical specifications. - Page 13 For Hard-Wired Models • The opening for the power supply connection is 7/8" DIA to fit a 1/2" trade size conduit. • The white lead must be connected to the neutral conductor of the power source. NOTICE! Miswiring may result in damage to the icemaker. F-500BAJ WARNING ELECTRICAL CONNECTION...
-
Page 14: Water Supply And Drain Connections
• External filters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki Certified Service Representative or local Hoshizaki distributor for recommendations. • A plumbing permit and services of a licensed plumber may be required in some areas. - Page 15 F-300BAJ Minimum 1/4" Nominal ID Drain Valve Copper Water Tubing or Icemaker Water Supply Inlet Equivalent 1/2" FPT Icemaker Shut-Off Valve Vent Tube Be sure there is sufficient extra water supply line and drain line for the appliance to be pulled out for service.
-
Page 16: Final Checklist
G. Final Checklist WARNING CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the ice storage bin. 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3) Is there at least 6"... -
Page 17: Startup
H. Startup WARNING • All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. • To reduce the risk of electric shock, do not touch the power switch, control switch, or plug (on corded models) with damp hands. If you have to slide the appliance back for a built-in installation, make sure you do not damage or pinch the water supply line, drain line, or power cord. -
Page 18: Bin Control Check
I. Bin Control Check A mechanical bin control controls the level of ice in the ice storage bin. IMPORTANT • Make sure the icemaker has been installed as outlined in this manual and that the water supply is on. • Make sure S1 dip switch 7 is in the "OFF" position and dip switch 8 is in the "ON" position. - Page 19 Control Board "SERVICE" Button S1 Dip Switch "COMP" LED "GM" LED Fig. 6 Actuator Model Shown: F-500BAJ Fig. 7...
-
Page 20: Alarm Safeties
J. Alarm Safeties Should an alarm occur, follow the instructions in the table below to address the alarm. If an alarm continues to occur, contact an authorized service agent. WARNING • Only qualified service technicians should service the appliance. • To reduce the risk of electric shock, do not touch the icemaker power switch or control switch with damp hands. -
Page 21: Maintenance
The appliance must be maintained in accordance with the instruction manual and labels provided. Consult with your local Hoshizaki Certified Service Representative about maintenance service. To obtain the name and phone number of your local Hoshizaki Certified Service Representative, visit www.hoshizaki.com. -
Page 22: Maintenance Schedule
A. Maintenance Schedule The maintenance schedule below is a guideline. More frequent maintenance may be required depending on water quality, the appliance's environment, and local sanitation regulations. Maintenance Schedule Frequency Area Task Daily Scoop Clean the scoop using a neutral cleaner. Rinse thoroughly after cleaning. Bi-Weekly Air Filter Inspect. -
Page 23: Cleaning And Sanitizing Instructions
• Do not place fingers or any other objects into the ice discharge opening. 1. Cleaning Solution Dilute 4.8 fl. oz. (142 ml) of Hoshizaki "Scale Away" with 0.8 gal. (3 l) of warm water. This is a minimum amount. Make more solution if necessary. IMPORTANT! For safety and maximum effectiveness, use the solution immediately after dilution. - Page 24 9) Allow the icemaker to sit for 10 min. before operation. If you placed a clamp on the reservoir hose in step 7, remove it before operation. 10) In bad or severe water conditions, clean the float switch assembly as described below. See Fig.
- Page 25 3. Sanitizing Solution Dilute 2.5 fl. oz. (74 ml or 5 tbs) of a 5.25% sodium hypochlorite solution (chlorine bleach) with 5 gal. (19 l) of warm water. This is a minimum amount. Make more solution if necessary. IMPORTANT! For safety and maximum effectiveness, use the solution immediately after dilution.
- Page 26 5. Sanitizing Procedure - Final 1) Mix a new batch of the sanitizing solution. 2) Remove spout B and gasket B, then remove spout A and gasket A. 3) Pour the sanitizing solution over the extruding head until the evaporator assembly and the reservoir are full and the solution starts to run through the overflow hose on the reservoir.
-
Page 27: Preparing The Appliance For Periods Of Non-Use
IV. Preparing the Appliance for Periods of Non-Use NOTICE When storing the appliance for an extended time or in sub-freezing temperatures, follow the instructions below to prevent damage. When the appliance is not used for two or three days under normal conditions, it is sufficient to only move the power switch to the "OFF"... -
Page 28: Disposal
V. Disposal This appliance contains refrigerant and must be disposed of in accordance with applicable national, state, and local codes and regulations. Refrigerant must be recovered by properly certified service personnel. - Page 29 618 Hwy. 74 South, Peachtree City, GA 30269 USA (P) 770.487.2331 (F) 770.487.3360 hoshizakiamerica.com 1A4364-010...
