A B B M E A S U R E M E N T & A N A LY T I C S | U S E R G U I D E S U P P L E M E N T | I M/A Z T 6 P B S R E V. D
Aztec 600
Colorimetric and ion-selective analyzers
Overview
—
Reliable on-line
colorimetric and ion-
The Aztec 600 analyzers from ABB are a range of
selective analyzers
compact, yet reliable, on-line colorimetric and ion-
selective (ISE) analyzers for monitoring the key
parameters in water treatment.
This supplementary user guide contains information
specific to Profibus® DP-enabled Aztec 600 and
Aztec ISE analyzers and must be read in conjunction
with the user guide relevant to each model.
Profibus supplement
Measurement made easy
